Page 1: Operating Instructions
Cooking Appliances Installation and operating instructions Professional Series Stretch Oven TO851X 9111 TO851 Use and Care.indd 1 28/4/08 12:07:30 PM... -
Page 2: Table Of Contents
Contents Dear customer The first time you use the oven Control panel functions Instructions for use - Conventional Cooking The control panel The first time you use the oven Setting the clock Cooking functions Cooking Using the oven light Child lock Using the time display Setting cooking time Replacing the oven light... -
Page 3: Dear Customer
Dear customer We thank you and congratulate you on your choice. This new carefully designed product, manufactured with the highest quality materials, has been carefully tested to satisfy all your cooking demands. We would therefore request you to read and follow these easy instructions which will allow you to obtain excellent results right from the start. -
Page 4: Control Panel Functions
Control panel functions Oven light (stays on while oven is in use). Bottom heating element.Thermostat setting from 50°C to MAX. Top and bottom heating elements. Thermostat setting from 50°C to MAX. Top and bottom heating elements with fan. Thermostat setting from 50°C to MAX. Circular heating element with fan. -
Page 5: Fan Cooking
Fan cooking For this type of cooking a fan positioned at the back allows the circulation of hot air inside the oven, creating uniform heat. In this way cooking is more rapid than conventional cooking. It is a suitable method for cooking dishes on more than one shelf, especially different types (fish, meat etc.) Defrosting By selecting one of the fan cooking functions and setting the thermostat to zero, the fan allows cold air to cir-... -
Page 6: The Control Panel
Using the Rotisserie - Run meat through with spit and grip securely with forks. - Balance the meat properly (to avoid unnecessary strain on motor) - Insert spit into hole on left support on rotisserie rack and rest on right side and remove black screw handle - Guide rotisserie rack into bottom oven side rails above pan;... -
Page 7: The First Time You Use The Oven
The first time you use the oven Three zeroes flash on the display the first time you connect the oven to the mains electricity supply, and every time power returns after a power failure. This warns you that you must set the time on the clock before you can select any cooking function. -
Page 8: Cooking
Cooking You can start cooking in just a few simple moves. Switch on the oven. Change the default temperature if you wish, or just wait 4 seconds to accept the default temperature. Choose cooking function. After 4 seconds the electronic controller automatically switches on the oven. The degrees centigrade symbol flashes to show that the oven is warming up. -
Page 9: Using The Time Display
Countdown Timer oven off (if it is on) or use the countdown timer. If you press any other key, a key symbol appears on the time display or temperature display to inform you that the child lock is active. Important - You must deactivate the child lock before you can use the oven again. Deactivating the child lock Press and hold the ‘On/Off’... -
Page 10: Setting Cooking Time
Setting cooking time Use the cooking time function to set the duration of cooking starting from the present time. You must select a cooking function before you can set cooking time (see the “Cooking” section). Oven active: a cooking functions has been selected. - Page 11 1. Setting end of cooking time Use the end of cooking time function to set the time at which you want cooking to finish. You must select a cooking function before you can set end of cooking time (see the “Cooking” section). Oven active: a cooking functions has been selected.
- Page 12 2. Setting cooking start and end times You can combine the cooking time and end of cooking time functions to set the start and end times for cooking. In this way you can program your electronic oven to cook while you are out or to defrost foods ready for you to cook when you get back.
- Page 13 Before you set end of cooking time, note the present time. When you set end of cooking time, the timer display presents time plus cooking time by default. Use the + key to set a tme E.g. 10 mins later. The timer registers this new time after a few seconds.
-
Page 14: Replacing The Oven Light
Replacing the oven light IMPORTANT: The oven light must have these precise features: a) it must be able to resist high temperatures (up to 300°C) b) power supply: see V/Hz indicated on data plate. c) power 25W. d) E 14 connection. Before proceeding, disconnect the appliance from the main electricity supply. -
Page 15: Electrical Connections
Electrical connections Before connecting the oven to the mains power supply, make sure that: - The supply voltage corresponds to the specifications on the data plate on the front of the oven. - The mains supply has an efficient earth (ground) connection complying with all applicable laws and regulations. -
Page 16: Installation Instructions
Installation instructions Flush fitting: The oven can be installed under a work top or in a cooking column. Figure shows the installation dimensions. Make sure that surrounding materials are heat resistant. Align the oven centrally with respect to the side walls of the units surrounding it and fix it in place with the screws and Allen screws provided. - Page 17 Outdoor Cooking Centres Wine Cellars Built-In Coffee Machines Vacuum Cleaners Rangehoods To find your nearest Kleenmaid Showroom telephone 13 13 08 or visit www.kleenmaid.com Warranty and Service Warranty Registration Please complete warranty details below. Please retain together with your proof of purchase document.
