Physical and Environmental Specifications

Controller DAC960PG/PJ
Form Factor:
Full-length card Length
Width
Component
Height (max.)
Board Width
(with BBU)
Temperature Operating
Storage
Humidity Operating
Storage
Altitude Operating
Storage
Manual No. 775012
DAC960PG and DAC960PJ Specifications
12.283 inches
4.2 inches
0.105 inches – solder side
0.590 inches – component side
Not to exceed the width of one PCI slot
0°C to +55°C (+32°F to +131°F)
-20°C to +70°C (-4°F to +158°F)
10% to 90% relative humidity (non-condensing)
10% to 90% relative humidity (non-condensing)
Up to 3,048m (10,000 ft )
Up to 15,240m (50,000 ft)
B-3
