Introduction

Welcome to the TDSUSB2 Universal Serial Bus Measurements Package

TDSUSB2 Universal Serial Bus Measurements Package is a Sun Java-based application that runs on the
supported instruments connected to a PC. You can use the application software with the compliance
test fixture to take the following measurements:
Signal Quality
Inrush
Droop
Drop (supported by the test fixture only)
Receiver Sensitivity
Impedance Measurement using Time Domain Reflectometry (TDR), supported by the application
only with the test fixture
Chirp measurements
Packet Parameter
Resume
Reset from Suspend
Reset from High Speed
Suspend
The application runs on the oscilloscope and displays on the lower part of the screen. The oscilloscope
application runs on the upper part of the screen.
