A. Technical Specifications
Standards: IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX/FX Fast Ethernet
ANSI/IEEE Std 802.3 N-way auto-negotiation
IEEE 802.3 MAC layer frame size: 64-1536 Bytes
IEEE 802.3x flow control for Full-Duplex
Protocol: CSMA/CD
Topology: St ar
Transmission
Metho d: Sto re-and -Forward
Tra nsfer Ra te:
Ethernet: 10M (half-duplex); 20M (ful l-duplex)
Fast Et hernet: 100M (half-duplex); 200M (full-duplex)
Media:
10BASE-T: UTP Cat. 3,4,5 (Max. cable length 100 m);
100 BASE-TX: UTP Cat . 5 (Max. cable length 1 00 m);
100BASE-FX: Multi-mode Fiber cable (Max. cable length 2,000m)
No. of Ports: 24 100/10Mbps RJ-45 ports
24 RJ-4 5 ports suppo rt Auto
Media Interface
Excha nge: MDI/MDIX
General
A-1

Physical and Environmental

RAM Buffer: Total 2.5Mbits per device
Filtering Address
Table: 8K
Packet Filtering/ 148800/14800pps
Forwarding Rate: Wire speed per port (for 100Mbps&10Mbps)
Net Weight: 4.2Kg
Power: Internal Univ ersal Po wer,
Input:90~264V(47~63Hz); Output:3.3V/7A
Consumption: 10 watts maximum
Temperature:
Operating: 0 ° ~ 45 °C
Storage: 0 ° ~ 60 °C
Humidity:
Operating: 10% ~ 90%
Storage: 5% ~ 95%
Conformance: FCC Class A, CE M ark Class A
A-2
