Key Features; Package Contents - Surecom EP-824DX-FS User Manual

Key Features

1. Provide 24 ports 100/10M Ethernet Switch to support Auto MDI/MDI-X
2. Provide one fiber slide-in port for expansion the workgroup distance to 2,000 meters
3. Provide back-pressure in half-duplex and flow control in full-duplex
4. Store-and-forward switching scheme capability supports rate adaptation and ensures
data integrity
5. N-way Auto-negotiation on each RJ-45 port. This allows for auto-sensing of speed
(100/10Mbps) and auto-detecting mode (full-duplex or half-duplex) thereby providing
you with automatic and flexible solutions in your network connections
6. Auto-polarity detection for correction of incorrect polarity on the received twisted-pair
7. Data fowarding rate 148,800 pps per port at 100% of wire-speed
8. Data filtering rate eliminates all error packets, runts, etc. at 148,800pps per port at
100% of wire speed
9. Conform to IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX /FX, and IEEE 802.3x
flow control for full-duplex standards
10. Provide non-blocking twenty-four ports full-wire speed access
11. Support one fiber slide-in port for expansion with the 24th port
12. Full/half-duplex mode operation on all ports
13. Auto-negotiation capability
14. Source address learning and aging function
15. Provide 8K MAC address and 2.5Mbits RAM buffer
16. LEDs to indicate Power, link/activity, full-duplex/collision, and
speed status
17. Support 24*24 bit matrix for port base VLAN
1-2

Package Contents

1.One 24-Port 100/10M N-Way Rack-Mount Smart Switch
2.One Power Cord
3.One Cable and Connector for Console
4.Two Mounting Brackets
5.One User's Manual
Note: If any item is damaged or missing, please contact your supplier.
1-3
