Operating Instructions

Radar sensor for continuous level
measurement of water and wastewater
VEGAPULS WL 61
Foundation Fieldbus
Document ID: 38063

Advertisement

Table of Contents
loading

Related Manuals for Vega VEGAPULS WL 61

Summary of Contents for Vega VEGAPULS WL 61

  • Page 1: Operating Instructions

    Operating Instructions Radar sensor for continuous level measurement of water and wastewater VEGAPULS WL 61 Foundation Fieldbus Document ID: 38063...

  • Page 2: Table Of Contents

    How to proceed if a repair is necessary ................32 Dismount Dismounting steps......................34 Disposal ......................... 34 Supplement Technical data ........................ 35 Radio astronomy stations ....................39 Supplementary information Foundation Fieldbus ............40 Dimensions ........................48 VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 3 Contents Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions manual. Editing status: 2016-01-29 VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 4: About This Document

    This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 5: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS WL 61 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Ce Conformity

    • When installed within 4 to 40 km of a radio astronomy station, the instrument must not be mounted higher than 15 m above the ground. You can find a list of the respective radio astronomy stations in chap- ter "Supplement". VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 7: Radio License For Usa/Canada

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 8: Product Description

    Alternatively, you can access the data via your smartphone: • Download the smartphone app "VEGA Tools" from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or •...

  • Page 9: Principle Of Operation

    Principle of operation Application area The radar sensor VEGAPULS WL 61 is the ideal sensor for all appli- cations in the water and waste water industry. It is particularly suitable for level measurement in water treatment, in pump stations as well as storm water overflow tanks, for flow measurement in open flumes and for gauge measurement.
  • Page 10 Protected against solar radiation • Avoiding mechanical shock and vibration • Storage and transport Storage and transport temperature see chapter "Supplement - temperature Technical data - Ambient conditions" • Relative humidity 20 … 85 % VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 11: Mounting

    Mounting bracket For a rigid mounting, a mounting bracket with opening for thread G1½, e.g. from the VEGA product range, is recommended. The mounting of the sensor in the bracket is carried out via a G1½ counter VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 12 The instrument is normally mounted vertically with a bracket on the mounting ceiling. This ensures swivelling of the sensor up to 180° for optimum orienta- tion. Fig. 4: Ceiling mounting via the mounting strap with length 300 mm VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 13 Fig. 6: Wall mounting via the mounting strap with length 170 mm Fig. 7: Wall mounting with inclined wall via the mounting strap with length 300 mm Flange mounting For mounting the instrument on a socket or a manhole cover, an unassembled combi collar flange for DN 80 (ASME 3" or JIS 80) is optionally available also as retrofitting part. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 14: Mounting Preparations, Mounting Strap

    The emitted radar impulses of the radar sensor are electromagnetic waves. The polarisation is the direction of the electrical wave compo- nent. By turning the instrument in the connection flange or mounting strap, the polarisation can be used to reduce the effects of false echoes. The position of the polarisation is marked by marking bars on the instrument. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 15 Fig. 10: Mounting of the radar sensor on round vessel tops In vessels with conical bottom it can be advantageous to mount the sensor in the center of the vessel, as measurement is then possible down to the lowest point of the vessel bottom. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 16 Approximate values of the socket heights are shown in the following illustration. The socket end should be smooth and burr-free, if possi- ble also rounded. After mounting, you have to carry out a false signal memory during the parameter adjustment. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 17 Make sure when planning your measuring point that the radar sensor has a "clear view" to the measured product. In case of existing vessel installations, a false echo storage should be carried out during setup. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 18 Overflow orifice (side view) Headwater Tailwater Overfall orifice (view from tailwater) In general, the following points must be observed: • Install the sensor on the headwater side • Installation in the centre of the flume and vertical to the liquid surface • Distance to the overfall orifice VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 19 Venturi flume In general, the following points must be observed: • Installation of the sensor at the inlet side • Installation in the centre of the flume and vertical to the liquid surface • Distance to the Venturi flume • Min. distance of the sensor to max. storage level VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 20: Connecting To Power Supply

    Wiring plan - version IP 66/IP 68, 2 bar Wire assignment, con- nection cable Fig. 18: Wire assignment in permanently connected connection cable brown (+) and blue (-) to power supply or to the processing system Shielding VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 21: Switch-On Phase

    As soon as a plausible measured value is found, the corresponding current is outputted to the signal cable. The value corresponds to the actual level as well as the settings already carried out, e.g. factory setting. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 22: Setup

    To perform the adjustment, enter the distance with full and empty vessel, see the following example: VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 23 The actual product level during this adjustment is not important, because the min./max. adjustment is always carried out without changing the product level. These settings can be made ahead of time without the instrument having to be installed. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 24: Diagnosis, Asset Management And Service

    Changes in the measure- ment conditions during operation or buildup on the sensor can thus be recognized. The echo curve of the setup is stored via: • PC with PACTware/DTM • Control system with EDD • Display and adjustment module VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 25: Asset Management Function

    Plan in maintenance for the instrument because a failure is expected in the near future (e.g. due to buildup). This status message is inactive by default. It can be activated by the user via PACTware/DTM or EDD. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 26 7 Diagnosis, asset management and service The following table shows the codes and text messages in the status Failure (failure) message "Failure" and gives information on the reason and rectifica- tion. Keep in mind that some specification are only valid for four-wire instruments and the electronics with VEGAPULS WL 61 cannot be exchanged by the user. Code Cause Rectification...
  • Page 27 The following table shows the error codes and text messages in the Function check status message "Function check" and provides information on causes as well as corrective measures. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 28 Error in the non- – Send instru- active linearization ment for repair table M502 – Hardware error – Exchanging the Bit 15 EEPROM electronics Error in the diag- – Send instru- nosis memory ment for repair VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 29: Rectify Faults

    PACTware and the suitable DTM. In many cases, the reasons can be determined in this way and faults rectified. Treatment of measure- The below tables show typical examples of application-related meas- ment errors with liquids urement errors with liquids. The measurement errors are differentiated according to the following: • Constant level • Filling • Emptying VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 30 – Amplitude or position of a false – Determine the reason for the signal has changed (e.g. con- changed false signals, carry out densation, buildup); false signal false signal suppression, e.g. suppression no longer matches with condensation actual conditions VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 31 – Remove contamination on the sensor goes into overfill protec- time antenna tion mode. The max. level (0 m – Use a sensor with a more suit- distance) as well as the status able antenna message "Overfill protection" are outputted. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 32: How To Proceed If A Repair Is Necessary

    24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock.
  • Page 33 7 Diagnosis, asset management and service • Please contact the agency serving you to get the address for the return shipment. You can find the agency on our home page www.vega.com. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 34: Dismount

    Pass the instrument directly on to a spe- cialised recycling company and do not use the municipal collecting points. These may be used only for privately used products according to the WEEE directive. VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 35: Supplement

    Ʋ Flange screws, adapter flange DN 100 7 Nm (5.163 lbf ft) Input variable Measured variable The measured quantity is the distance between the end of the sensor antenna and the product surface. The reference plane for the measurement is the lower side of the flange. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 36 Process reference conditions according to DIN EN 61298-1 Ʋ Temperature +18 … +30 °C (+64 … +86 °F) Ʋ Relative humidity 45 … 75 % Ʋ Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig) VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 37 Emitted HF power Ʋ Average spectral transmission power -34 dBm/MHz EIRP density Ʋ Max. spectral transmission power +6 dBm/50 MHz EIRP density Ʋ Max. power density at a distance of < 1 µW/cm² Time span after a sudden distance change of max. 0.5 m until the output signal reaches for the first time 90% of the final value (IEC 61298-2). Outside the specified beam angle, the energy of the radar signal is reduced by 50 % (-3 dB) EIRP: Equivalent Isotropic Radiated Power VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 38 Additional output parameter - Electronics temperature Output of the temperature values Ʋ Analogue Via the additional current output Ʋ Digital Depending on the electronics version via the HART, Profibus PA, Foundation Fieldbus or Modbus signal Range -40 … +85 °C (-40 … +185 °F) VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 39: Radio Astronomy Stations

    Instruments with approvals can have different technical specifications depending on the version. For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded under www.vega.com, "VEGA Tools" and "Instrument search" as well as in the download area.

  • Page 40: Supplementary Information Foundation Fieldbus

    > 3000 Ohms between 7.8 KHz - 39 KHz Unbalanced Capacitance < 250 pF to ground from either input terminal Output Amplitude 0.8 V P-P Electrical Connection 2 Wire Polarity Insensitive Max. Current Load 10 mA Device minimum operating voltage VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 41 Fig. 37: Schematic presentation Transducer Block (TB) Function block Analog Input (AI) The function block "Analog Input (AI)" takes the original measured value selected by a Channel Number and makes it available to additional function blocks on its output. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 42 The function block "PID Control " is a key component for various tasks in the process automation and is used universally. PID blocks can be cascaded if this is necessary or requested due to differ- ent time constants with the primary and secondary process measurement. Fig. 40: Schematic presentation function block PID Control VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 43 When these default values are reached, digital output signals will be outputted. The integration func- tion is carried out upwardly starting with zero and downwards with a default value. Two flow values are also available so that the net flow volume can be calculated and integrated. This can be used for calculation of volume and mass changes in the vessel or for optimisation of flow controls. VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 44 The function block "Arithmetic" allows the simple integration of usual metrological calculation func- tions. The user can select the requested measurement algortihm according to the name without known the formula. The following algorithms are available: • Flow compensation, linear • Flow compensation, square root VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 45 Selected unit code for "SECONDARY_VALUE_1" UNIT SECONDARY_VALUE_2 This is the distance value ("sensor_value") with the status of the transducer block. The unit is defined in "SECONDARY_VAL- UE_2_UNIT" FILL_HEIGHT_VALUE Filling height. The unit is defined in "FILL_HEIGHT_VALUE_ UNIT" FILL_HEIGHT_VALUE_UNIT Filling height unit CONST_VALUE Constant value SECONDARY_VALUE_1_ Secondary value 1 type TYPE VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 46 0 % and 100 % curve in near and far range FALSE_SIGNAL_CMD_CON- Gradient of the manual sectors, safety at the end of false echo FIGURATION2 memory and depending on the import range gating out the false signals VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 47 Min.-/max.- values of electronics temperature, date USER_MIN_MAX_PHYSI- Min.-/max.- distance values, date CAL_VALUE RESET_PEAK_PHYSICAL_ VALUE RESET_LINEARIZATION_ CURVE DEVICE_STATUS_ASCII Device status ECHO_CURVE_PLICSCOM_ Parameters as curve selection and resolution REQUEST ECHO_CURVE_PLICSCOM_ Parameters as start and end LIMITS APPROVAL_WHG Sensor acc. to WHG VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 48: Dimensions

    System noise treatment ECHO_MEM_SAVE_CURVE_ TYPE ECHO_MEM_STATE Busy, curve type, error code Dimensions The following dimensional drawings represent only an extract of all possible versions. Detailed dimensional drawings can be downloaded at www.vega.com/downloads under "Drawings". VEGAPULS WL 61 • Foundation Fieldbus...

  • Page 49: Vegapuls Wl 61 • Foundation Fieldbus

    9 Supplement VEGAPULS WL 61, basic version G1 1/2 ø 8 mm (0.32") ø 72 mm (2.84") ø 75 mm (2.95") ø 115 mm (4.53") Fig. 46: VEGAPULS WL 61, basic version VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 50 (0.10") 170 mm (6.69") 75 mm (2.95") 107 mm (4.21") 9 mm (0.35") 115 mm (4.53") 12 mm (0.47") Fig. 47: VEGAPULS WL 61, version with mounting strap in 170 or 300 mm length VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 51 9 Supplement VEGAPULS WL 61, version with compression flange ø 21 mm (0.83") ø 156 mm (6.14") ø 200 mm (7.87") Fig. 48: VEGAPULS WL 61, compression flange DN 80/3"/JIS80 VEGAPULS WL 61 • Foundation Fieldbus...
  • Page 52 9 Supplement VEGAPULS WL 61, version with adapter flange ø 98 mm (3.86") Fig. 49: VEGAPULS WL 61, adapter flange DN 100/4"/JIS 100 as well as DN 150/6"/JIS 150 Adapter flange Seal VEGAPULS WL 61 • Foundation Fieldbus...
