KLA-Tencor P-16+ / P-6 User's Guide
STEP 1 Click to display
View
the View menu.
STEP 2 Click Image to
Rotate
reveal the Rotate Image
menu.
0142530-000 AB
3/13/09
Option 4 – Rotate Image Menu. Use the
rotation provided by each menu item is identical to that provided by the representative
arrow key (cited next to each option) as described in Table 7.3, and the related Image
Rotation button described in Table 7.1.

Figure 7.5

Image Rotation Using the Rotate Image Menu

Table 7.4 Rotate Image Menu Options (From View Menu)
Menu Item
Use the in the Right-Click menu.
Mouse Tool
1. Right-click to display the
2. Click
to display its menu. (See Figure 7.6.)
Mouse Tools
3. Choose
Rotate Image
4. Choose the required rotation from the menu. This menu is the same as the
Rotate Image menu from in the View drop-down menu in the Menu Bar. (See
Figure 7.5 and Table 7.4.)
Each click moves one increment only. The entire menu process must be
completed for each single movement.
KLA-Tencor Confidential
Analyzing 3D Scan Data - 3D Analysis Screen Features
Rotate Image
Description of Action
Rotates the image to the left on its horizontal plane.
This action only move the image one increment each
time. The menu must be opened again for each move.
Rotates the image to the right on its horizontal plane.
This action only move the image one increment each
time. The menu must be opened again for each move.
Rotates the image in a backward roll. This action only
move the image one increment each time. The menu
must be opened again for each move.
Rotates the image in a forward roll. This action only
move the image one increment each time. The menu
must be opened again for each move.
menu. (See Figure 7.6.)
Right-Click
from the Mouse Tools menu. (See Figure 7.6.)
menu rotation options. The
STEP 3 Click the desired
rotation. The rotation takes
place immediately, moving
same distance that each
Manual Image Rotation
button moves the image.
7-5
