Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Programmer Manual
VM5000
Automatic Video Measurement Set
071-1574-01
This document applies to Option SD/HD software
version 2.X and above.
This document applies to Option VGA software
version 1.X and above.
www.tektronix.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Tektronix VM5000

Summary of Contents for Tektronix VM5000

  • Page 1 Programmer Manual VM5000 Automatic Video Measurement Set 071-1574-01 This document applies to Option SD/HD software version 2.X and above. This document applies to Option VGA software version 1.X and above. www.tektronix.com...
  • Page 2 Copyright © Tektronix, Inc. All rights reserved. Licensed software products are owned by Tektronix or its suppliers and are protected by United States copyright laws and international treaty provisions. Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the...
  • Page 3 Warranty 2 Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.

  • Page 5: Table Of Contents

    ......1- - 4 Compatibility of the VM5000 Option HD with the VM5000HD ...
  • Page 6 ........... . . 2- - 101 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 7 ........2- - 156 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 8 ......... . . 3- - 73 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 9 ........3- - 128 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 10 ........3- - 181 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 11 ..........3- - 237 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 12 ........3- - 290 viii VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 13 ..........3- - 343 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 14 ........3- - 397 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 15 ....... . . 3- - 452 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 16 ..........3- - 506 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 17 ....... 3- - 561 xiii VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 18 ..........3- - 616 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 19 ..........3- - 669 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 20 ........3- - 724 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 21 3- - 732 Appendix Appendix A: Programming the VM5000 ..... . A- -1 Index xvii VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 22 Table of Contents List of Tables Table 1- -1: Compatibility of the VM5000 Option HD and SD with the VM5000HD ........

  • Page 23: Remote Commands

    Remote Commands...

  • Page 25: Syntax

    Commands consist of set commands and query commands (usually called commands and queries). Commands modify the VM5000 settings or tell the instrument to perform a specific action. Queries cause the VM5000 to return data and information about its status. Most commands have both a set and a query form, although some commands only have a query form.
  • Page 26 H There are no abbreviated versions of the “<Command>”, “<Argument>” part of the VM5000 commands; you must enter the full name of this part of a command. H The <Command> field is case sensitive, and use of incorrect command case spelling can result in an unexpected response from the instrument.
  • Page 27 H A 50 ms delay must occur between GPIB Set commands to ensure that the GPIB control program does not overflow the internal command buffer of the instrument. See OpComplete for more information on page 2- -115. 1- 3 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 28: Remote Startup And Exit Of The Instrument

    “VM5000 VGA Video” To exit the application using remote commands, use the following command: VARIable:VALue “application”, “exit” You can check whether or not the VM5000 application is running using the following query: VARIable:VALue? “application” If the application is running, this query will return “VM5000”. However, if the application is not currently running, it will return the empty string “”.

  • Page 29: Compatibility Of The Vm5000 Option Hd With The Vm5000Hd

    H Sync command has three items added to the end. Table 1- 1: Compatibility of the VM5000 Option HD and SD with the VM5000HD Description of setting Default trigger channel Operation menu setting “Run Mode”...
  • Page 30 Remote Commands 1- 6 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 31: Option Sd/Hd Remote Commands

    Option SD/HD Remote Commands...

  • Page 33: Command Groups

    Set or query. whether to measure short time distortion upon execute SyncSet Set or query whether to measure Sync upon Execute Trigger Set or query the video trigger to use for measurement VectorscopeGrat Set or query Vectorscope graticule 2- 1 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 34: Table 2- -2: Miscellaneous Commands (Option Sd

    Set or query the number of samples over which to average the Channel Delay measurement ChannelDelayLine Set or query line number that is to be used for the Channel Delay measurement 2- 2 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 35: Table 2- -5: Results Commands (Option Sd

    Query all three delay measurements performed by Channel Delay ChannelDelayCh1Ch2? Query the Ch1Ch2 delay measurement performed by Channel Delay ChannelDelayCh1Ch3? Query the Ch1Ch3 delay measurement performed by Channel Delay ChannelDelayCh2Ch3? Query the Ch2Ch3 delay measurement performed by Channel Delay 2- 3 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 36 Query the value resulting from the Frequency Response relative results for the specified channel and value measurement FrequencyResponseRelPctCh[1..3]? Query all five values resulting from the Frequency Response Percent relative results for the specified channel 2- 4 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 37 Query the value for the Flag value resulting from the Multiburst Percent relative measurement for the specified channel MultiburstRelPctFreqCh[1..3]? Query all six frequency values resulting from the specified Multiburst Percent relative channel measurement 2- 5 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 38 Query the pass/fail status for all six values resulting from the specified Short Time Distortion channel measurement ShortTimeDistortionPassCh[1..3]Val[1..6]? Query the pass/fail status for the value resulting from the specified Short Time Distortion channel and value measurement 2- 6 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 39: Table 2- -6: Run Commands (Option Sd

    Execute or stop the current set measurement(s), or query whether any measurement is currently being executed OPComplete Controls VM5000 GPIB scripts by ensuring that the previous command is ready before either querying its value or calling the next command. StoponError...

  • Page 40: Table 2- -7: Settings Commands (Option Sd

    Specifies Reference file to be loaded for Relative to Reference testing ReferenceFileSave Saves the current measurement results to a Reference file that can be used for Relative to Reference testing ReferenceSet Set or query whether Reference Testing is enabled or disabled 2- 8 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 41: Commands

    Query whether Application Status is: Configure, Measuring, Done, or Reported. Syntax VARIable:VALue? “AppStatus” Group Miscellaneous Returns Query returns the application status as Configure, Measuring, Done, or Reported. Examples VARIable:VALue? “AppStatus” Query may return: “AppStatus CONFIGURE” 2- 9 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 42: Autoscale

    <setting> specifies auto scale setting that is to be used. Valid settings are: OFF, ON, 0, 1. Returns Query returns the current specified setting. Examples VARIable:VALue “AutoScale”, “ON” VARIable:VALue? “AutoScale” Query may return: “AutoScale 0” 2- 10 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 43: Autoscaleinit

    .vmset, it will not begin with the factory default settings. Returns Query returns the current specified setting. Examples VARIable:VALue “AutoScaleInit”, “InitMeas” VARIable:VALue? “AutoScaleInit” Query may return: “AutoScaleInit InitMeas” 2- 11 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 44: Channeldelayall

    Returns all three delay measurements (in nanoseconds) performed by Channel Delay, in this order: Ch1Ch2 Ch1Ch3 Ch2Ch3. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayAll” Query may return: “ChannelDelayAll 1.84 0.04 –1.54” 2- 12 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 45: Channeldelayaverage

    Floating point notation is allowed. Returns Query returns the current number of samples for Channel Delay measurement. Examples VARIable:VALue “ChannelDelayAverage”, “8” VARIable:VALue? “ChannelDelayAverage” Query may return: “ChannelDelayAverage 8” 2- 13 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 46: Channeldelaych1Ch2

    Returns the Ch1Ch2 delay measurement (in nanoseconds) performed by Channel Delay. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChannelDelayCh1Ch2 Query may return: “ChannelDelayCh1Ch2 1.84” 2- 14 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 47 Returns Returns the Ch1Ch3 delay measurement (in nanoseconds) performed by Channel Delay. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayCh1Ch3” Query may return: “ChannelDelayCh1Ch3 0.04” 2- 15 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 48: Channeldelaych2Ch3

    Returns the Ch2Ch3 delay measurement (in nanoseconds) performed by Channel Delay. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChannelDelayCh2Ch3” Query may return: “ChannelDelayCh2Ch3 –1.54” 2- 16 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 49 <linenumber> can only be whole numbers. Values outside the range will be adjusted to be within range. Returns Query returns the current line number for Channel Delay measurement. Examples VARIable:VALue “ChannelDelayLine”, “200” VARIable:VALue? “ChannelDelayLine” Query may return: “ChannelDelayLine 200” 2- 17 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 50: Channeldelaypassall

    Returns all three delay measurements (in nanoseconds) performed by Channel Delay, in this order: Ch1Ch2 Ch1Ch3 Ch2Ch3. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayPassAll” Query may return: “ChannelDelayPassAll..” 2- 18 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 51: Channeldelaypassch1Ch2

    Returns all pass/fail status performed by Channel Delay for the Ch1Ch2 delay Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayPassCh1Ch2” Query may return: “ChannelDelayPassCh1Ch2 1” 2- 19 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 52: Channeldelaypassch1Ch3

    Returns Returns pass/fail status performed by Channel Delay for the Ch1Ch3 delay Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayPassCh1Ch3” Query may return: “ChannelDelayPassCh1Ch3 1” 2- 20 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 53: Channeldelaypassch2Ch3

    Returns Returns pass/fail status performed by Channel Delay for the Ch2Ch3 delay Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayPassCh2Ch3” Query may return: “ChannelDelayPassCh2Ch3 1” 2- 21 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 54: Channeldelayrelall

    Returns all three relative delay measurements (in nanoseconds) performed by Channel Delay, in this order: Ch1Ch2 Ch1Ch3 Ch2Ch3. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayRelAll” Query may return: “ChannelDelayRelAll 1.0 0.8 - -1.1” 2- 22 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 55: Channeldelayrelch1Ch2

    Return the relative delay measurement (in nanoseconds) performed by Channel Delay for the Ch1Ch2 delay Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayRelCh1Ch2” Query may return: “ChannelDelayRelCh1Ch2 1.5” 2- 23 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 56: Channeldelayrelch1Ch3

    Return the relative delay measurement (in nanoseconds) performed by Channel Delay for the Ch1Ch3 delay Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayRelCh1Ch3” Query may return: “ChannelDelayRelCh1Ch3 1.5” 2- 24 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 57: Channeldelayrelch2Ch3

    Return the relative delay measurement (in nanoseconds) performed by Channel Delay for the Ch2Ch3 delay Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ChannelDelayRelCh2Ch3” Query may return: “ChannelDelayRelCh2Ch3 1.5” 2- 25 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 58: Channeldelayset

    Valid values are: OFF, ON, 0, 1. Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether ChannelDelaySet measurement is selected. Examples VARIable:VALue “ChannelDelaySet”, “ON” VARIable:VALue? “ChannelDelaySet” Query may return: “ChannelDelaySet 1” 2- 26 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 59: Channeldelaystatus

    Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Channel Delay measurement. Examples VARIable:VALue? “ChannelDelayStatus” Query may return: “ChannelDelayStatus Pass” 2- 27 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 60: Colorbarsaverage

    Floating point notation is allowed. Returns Query returns the current number of samples for Color Bars measurement. Examples VARIable:VALue “ColorBarsAverage”, “1” VARIable:VALue? “ColorBarsAverage” Query may return: “ColorBarsAverage 8” 2- 28 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 61: Colorbarsline

    Floating point notation is allowed. Returns Query returns the current line number for Color Bars measurement. Examples VARIable:VALue “ColorBarsLine”, “200” VARIable:VALue? “ColorBarsLine” Query may return: “ColorBarsLine 325” 2- 29 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 62: Colorbarsmvch[1

    White Yellow Cyan Green Magenta Red Blue Black. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsmVCh1” Query may return: “ColorBarsmVCh1 699.76 650.52 552.75 501.98 201.89 150.74 52.11 0.49” 2- 30 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 63 1- -White 2- -Yellow 3- -Cyan 4- -Green 5- -Magenta 6- -Red 7- -Blue 8- -Black. Returns “- -- -- -” if no valid measurement is currently available Examples VARIable:VALue? “ColorBarsmVCh2Val6” Query may return: “ColorBarsmVCh2Val6 –78.89” 2- 31 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 64: Colorbarspassch[1

    Color Bars, in this order: White Yellow Cyan Green Magenta Red Blue Black. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1” Query may return: “ColorBarsPassCh1 1 1 1 0 0 1 1 1” 2- 32 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 65 1- -White 2- -Yellow 3- -Cyan 4- -Green 5- -Magenta 6- -Red 7- -Blue 8- -Black. Returns “- -- -- -” if no valid measurement is currently available Examples VARIable:VALue? “ColorBarsPassCh2Val6” Query may return: “ColorBarsPassCh2Val6 1” 2- 33 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 66: Colorbarsrelmvch[1

    Blue Black. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelmVCh1” Query may return: “ColorBarsRelmVCh1 - -2.66 1.58 0.97 1.27 - -0.52 0.66 0.88 0.77” 2- 34 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 67 White Yellow Cyan Green Magenta Red Blue Black. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelmVCh1Val4” Query may return: “ColorBarsRelmVCh1Val4 1.27” 2- 35 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 68: Colorbarsrelpctmvch[1

    Blue Black. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctmVCh1” Query may return: “ColorBarsRelPctmVCh1 - -0.16 0.28 0.17 0.13 - -0.05 0.01 0.08 0.07” 2- 36 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 69 White Yellow Cyan Green Magenta Red Blue Black. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelmVCh1Val4” Query may return: “ColorBarsRelPctmVCh1Val4 0.27” 2- 37 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 70: Colorbarsset

    Valid values are: OFF, ON, 0, 1 Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether ColorBarsSet measurement is selected. Examples VARIable:VALue “ColorBarsSet”, “ON” VARIable:VALue? “ColorBarsSet” Query may return: “ColorBarsSet 1” 2- 38 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 71: Colorbarsstatus

    Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Color Bars measurement. Examples VARIable:VALue? “ColorBarsStatus” Query may return: “ColorBarsStatus Done” 2- 39 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 72: Colorspace

    <colorspace> specifies color space that is to be set. Valid color spaces are: YPbPr, RGB Returns Query returns the current specified color space Examples VARIable:VALue “ColorSpace”, “YPbPr” VARIable:VALue? “ColorSpace” Query may return: “ColorSpace YPbPr” 2- 40 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 73: Defaultsettings

    Valid value is 1. Returns Query returns “OK” unless the command is still being processed, in which case it returns “1”. Examples VARIable:VALue “DefaultSettings”, “1” VARIable:VALue? “DefaultSettings” Query may return: “DefaultSettings OK” 2- 41 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 74: Display

    Noise Spectrum display on top of all other displays. Minimized option mini- mizes the display and reports whether the display is minimized. Returns The display on top of all other displays. Examples VARIable:VALue “Display”, “Picture” VARIable:VALue? “Display” Query may return: “Display None” 2- 42 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 75: Error

    Returns the most recent error reported by the application. Returns “0” if no error has occurred since the Error command was last reset. Examples VARIable:VALue “Error”, “OFF” VARIable:VALue? “Error” Query may return: “Error No measurement Selected” 2- 43 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 76: Execute

    MultiburstSet NoiseSet NonLinearitySet ShortTimeDistSet SyncSet Returns Query returns 1 if any measurement is currently being executed, otherwise it returns 0. Examples VARIable:VALue “Execute”, “1” VARIable:VALue? “Execute” Query may return: “Execute 1” 2- 44 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 77: Format

    VARIable:VALue “Format”, “SD480I60” VARIable:VALue? “Format” Query may return: “Format SD480I60” NOTE. HD formats are available only if option HD is purchased SD formats are available only if option SD is purchased. 2- 45 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 78: Frequencyresponseaverage

    Floating point notation is allowed. Related Commands FrequencyResponseMeasLocation FrequencyResponseFreq FrequencyResponseLine FrequencyResponseTime Returns Returns the current number of samples for the Frequency Response measure- ment. Examples VARIable:VALue “FrequencyResponseAverage”, “50” VARIable:VALue? “FrequencyResponseAverage” Query may return: “FrequencyResponseAverage 50” 2- 46 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 79: Frequencyresponsech[1

    Frequency (MHz), Time (μs), Flag (mV), Amplitude (dB), RMS Distortion (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponseCh1” Query may return: “FrequencyResponseCh1 10 12.57 417.23 1.92 3.5” 2- 47 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 80 Frequency (MHz), Time (μs), Flag (mV), Amplitude (dB), RMS Distortion (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponseCh1Val3” Query may return: “FrequencyResponseCh1Val3 417.23” 2- 48 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 81: Frequencyresponsefilterbw

    Floating point notation is allowed. Related Commands FrequencyResponseAverage FrequencyResponseLine FrequencyResponseMeasLocation FrequencyResponseTime Returns Query returns the current unweighted Frequency Response filter bandwidth, in Examples VARIable:VALue? “FrequencyResponseFilterBW” Query may return: “FrequencyResponseFilterBW 297000000” 2- 49 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 82: Frequencyresponsefreq

    Returns the current frequency at which the measurement is taken. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue “FrequencyResponseFreq”, “3710000” VARIable:VALue “FrequencyResponseFreq”, “3.71E6” VARIable:VALue? “FrequencyResponseFreq” Query may return: “FrequencyResponseMeasLocation Frequency” 2- 50 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 83: Frequencyresponseline

    Related Commands FrequencyResponseAverage FrequencyResponseFreq FrequencyResponseMeasLocation FrequencyResponseTime Returns Returns the time at which the measurement is taken. Examples VARIable:VALue “FrequencyResponseLine”, “229” VARIable:VALue? “FrequencyResponseLine” Query may return: “FrequencyResponseLine 229” 2- 51 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 84: Frequencyresponsemeaslocation [ Freq444 | Freq422 | Time ]

    Returns the location at which the measurement is taken. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue “FrequencyResponseMeasLocation”, “Freq444” VARIable:VALue? “FrequencyResponseMeasLocation” Query may return: “FrequencyResponseMeasLocation Time” 2- 52 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 85: Frequencyresponsepassch[1

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponsePassCh1” Query may return: “FrequencyResponsePassCh1 1 1 1 0 0” 2- 53 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 86 A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponsePassCh1” Query may return: “FrequencyResponsePassCh1 1 1 1 0 0” 2- 54 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 87: Frequencyresponserelch[1

    Frequency (Mhz), Time (μs), Flag (mV), Amplitude (dB), RMS Distortion (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponseRelCh1” Query may return: “FrequencyResponseRelCh1 0.0 0.03 0.68 - -0.05 0.0” 2- 55 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 88 Frequency (Mhz), Time (μs), Flag (mV), Amplitude (dB), RMS Distortion (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponseRelCh1Val3” Query may return: “FrequencyResponseRelCh1Val3 0.68 ” 2- 56 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 89: Frequencyresponserelpctch[1

    Frequency (Mhz), Time (μs), Flag (mV), Amplitude (dB), RMS Distortion (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponseRelPctCh1” Query may return: “FrequencyResponseRelPctCh1 1 1 1 0 0” 2- 57 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 90 Frequency (Mhz), Time (μs), Flag (mV), Amplitude (dB), RMS Distortion (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “FrequencyResponseRelPctCh1Val3” Query may return: “FrequencyResponseRelPctCh1Val3 0.03 ” 2- 58 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 91: Frequencyresponseset

    Valid values are: OFF, ON, 0, 1. Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether the FrequencyResponseSet measure- ment is selected. Examples VARIable:VALue “FrequencyResponseSet”, “ON” VARIable:VALue? “FrequencyResponseSet” Query may return: “FrequencyResponseSet 1” 2- 59 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 92: Frequencyresponsestatus

    Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Frequency Response measurement. Examples VARIable:VALue? “FrequencyResponseStatus” Query may return: “FrequencyResponseStatus Pass” 2- 60 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 93: Frequencyresponsetime

    Related Commands FrequencyResponseAverage FrequencyResponseFreq FrequencyResponseLine FrequencyResponseMeasLocation Returns Returns the frequency response time. Examples VARIable:VALue “FrequencyResponseTime”, “0.0000125” VARIable:VALue “FrequencyResponseTime”, “12.5E- -6” VARIable:VALue? “FrequencyResponseTime” Query may return: “FrequencyResponseTime 12.5E- -6” 2- 61 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 94 Option SD/HD Remote Commands Query the ID/Version of the application. Syntax VARIable:VALue? “ID” Group Miscellaneous Arguments None Returns Returns the application’s ID Examples VARIable:VALue? “ID” Query may return: “ID Tek/VM5000 FW: 2.x” 2- 62 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 95: Limitfileload

    The pathstring must be less than 60 characters in length, otherwise the command may not be completed successfully. Related Commands LimitSet Returns None Examples VARIable:VALue “LimitFileLoad c:\VM5000TV\RefLimFiles\Default- Lim1080iYPbPr.csv” 2- 63 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 96: Limitset

    Valid values are: OFF, ON, 0, 1. Related Commands Execute Returns Query returns 0 or 1 depending on whether the LimitSet is enabled or disabled. Examples VARIable:VALue “LimitSet”, “ON” VARIable:VALue? “LimitSet” Query may return: “LimitSet 1 ” 2- 64 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 97: Logerrors

    Valid values are: OFF, ON, 0, 1. Related Commands Execute Returns Query returns 0 or 1 depending on whether the LogErrors is enabled or disabled. Examples VARIable:VALue “LogErrors”, “ON” VARIable:VALue? “LogErrors” Query may return: “LogErrors 1 ” 2- 65 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 98: Multiburstampdbch[1

    Returns all six amplitude values (in dB) in burst order. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstAmpdBCh2” Query may return: “MultiburstAmpdBCh2 –0.09 –0.18 –0.14 –0.13 –0.08 –0.02” 2- 66 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 99 MultiburstAmpdBCh[1..3] Returns Returns the specified Multiburst value (in dB). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “MultiburstAmpdBCh1Val2” Query may return: “MultiburstAmpdBCh1Val2 - - 0.26” 2- 67 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 100: Multiburstaverage

    Floating point notation is allowed. Returns Query returns the current number of samples for Multiburst measurement. Examples VARIable:VALue “MultiburstAverage”, “1” VARIable:VALue? “MultiburstAverage” Query may return: “MultiburstAverage 8” 2- 68 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 101: Multiburstflagmvch[1

    VARIable:VALue? “MultiburstFlagmVCh[1..3]” Group Results Arguments None Returns Returns the Flag value (in mV). Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstFlagmVCh3” Query may return: “MultiburstFlagmVCh3 428.01” 2- 69 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 102: Multiburstfreqch[1

    Returns all six frequency values (in MHz) in burst order. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstFreqCh1” Query may return: “MultiburstFreqCh1 10.00 12.00 14.00 16.00 18.01 20.00” 2- 70 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 103 None Related Commands MultiburstFreqCh[1..3] Returns Returns the specified Multiburst frequency (in MHz). Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstFreqCh1Val2” Query may return: “MultiburstFreqCh1Val2 12.00” 2- 71 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 104: Multiburstline

    <linenumber> can be an integer. Fractional numbers will return errors. Floating point notation is allowed. Returns Query returns the current line number for Multiburst measurement. Examples VARIable:VALue “MultiburstLine”, “200” VARIable:VALue? “MultiburstLine” Query may return: “MultiburstLine 325” 2- 72 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 105: Multiburstpassampdbch[1

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstPassAmpdBCh2” Query may return: “MultiburstPassAmpdBCh2 1 1 1 1 1 0” 2- 73 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 106 A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “MultiburstPassAmpdBCh1Val2” Query may return: “MultiburstPassAmpdBCh1Val2 1” 2- 74 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 107: Multiburstpassflagmvch[1

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstPassFlagmVCh3” Query may return: “MultiburstPassFlagmVCh3 0” 2- 75 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 108: Multiburstpassfreqch[1

    A returned status of 1 means Pass; a returned status of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstPassFreqCh1” Query may return: “MultiburstPassFreqCh1 1 1 1 1 1 1” 2- 76 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 109 A returned status of 1 means Pass; a returned status of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstPassFreqCh1Val2” Query may return: “MultiburstPassFreqCh1Val2 1” 2- 77 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 110: Multiburstrelampdbch[1

    Returns values for all six amplitude values (in dB) in burst order. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelAmpdBCh2” Query may return: “MultiburstRelAmpdBCh2 0.0 - -0.01 - -0.22 - -0.42 - -0.66 - -1.02” 2- 78 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 111 Returns Returns the values for the specified Multiburst relative value. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “MultiburstRelAmpdBCh1Val2” Query may return: “MultiburstRelAmpdBCh1Val2 - -0.01” 2- 79 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 112: Multiburstrelflagmvch[1

    None Returns Returns the Flag value of the Multiburst relative measurement. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelFlagmVCh3” Query may return: “MultiburstRelFlagmVCh3 - -0.33” 2- 80 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 113: Multiburstrelfreqch[1

    Returns the values for all six frequency relative values in burst order. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelFreqCh1” Query may return: “MultiburstRelFreqCh1 0.01 0.01 0.01 0.02 0.01 0.01” 2- 81 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 114: Multiburstrelpctampdbch[1

    MultiburstRelFreqCh[1..3] Returns Returns the value of the specified relative Multiburst frequency value. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelFreqCh1Val2” Query may return: “MultiburstRelFreqCh1Val2 0.01” 2- 82 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 115 Returns the values, in percent difference, for the specified Multiburst relative value. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “MultiburstRelPctAmpdBCh1Val2” Query may return: “MultiburstRelPctAmpdBCh1Val2 0.0” 2- 83 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 116: Multiburstrelpctflagmvch[1

    Returns the Flag value, in percent difference, of the Multiburst relative measure- ment. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelPctFlagmVCh3” Query may return: “MultiburstRelPctFlagmVCh3 - -0.01” 2- 84 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 117: Multiburstrelpctfreqch[1

    Returns the values, in percent difference, for all six frequency relative values in burst order. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelPctFreqCh1” Query may return: “MultiburstRelPctFreqCh1 0.01 0.01 0.01 0.02 0.01 0.01” 2- 85 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 118 Returns the value, in percent difference, of the specified relative Multiburst frequency value. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “MultiburstRelPctFreqCh1Val2” Query may return: “MultiburstRelPctFreqCh1Val2 0.0” 2- 86 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 119: Multiburstset

    Valid values are: OFF, ON, 0, 1 Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether MultiburstSet measurement is selected. Examples VARIable:VALue “MultiburstSet”, “ON” VARIable:VALue? “MultiburstSet” Query may return: “MultiburstSet 1” 2- 87 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 120: Multiburststatus

    ExecuteReport Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Multiburst measurement. Examples VARIable:VALue? “MultiburstStatus” Query may return: “MultiburstStatus Pass” 2- 88 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 121: Noiseampdbch[1

    VARIable:VALue? “NoiseAmpdBCh[1..3]” Group Results Arguments None Returns Returns amplitude value (in dB). Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “NoiseAmpdBCh2” Query may return: “NoiseAmpdBCh2 66.43” 2- 89 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 122: Noiseampmvch[1

    VARIable:VALue? “NoiseAmpmVCh[1..3]” Group Results Arguments None Returns Returns amplitude value (in mV). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NoiseAmpmVCh2” Query may return: “NoiseAmpmVCh2 0.33” 2- 90 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 123: Noiseaverage

    Floating point notation is allowed. Returns Query returns the current number of samples for Noise measurement. Examples VARIable:VALue “NoiseAverage”, “1” VARIable:VALue? “NoiseAverage” Query may return: “NoiseAverage 8” 2- 91 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 124: Noisebw

    Floating point notation is allowed. Related Commands NoiseFilter Returns Query returns the current unweighted noise filter bandwidth, in Hz. Examples VARIable:VALue “NoiseBW”, “30000000” VARIable:VALue “NoiseBW”, “3.2E7” VARIable:VALue? “NoiseBW” Query may return: “NoiseBW 50000000” 2- 92 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 125: Noisecursorpos

    Returns Query returns the frequency of the cursor position in the Noise measurement. Examples VARIable:VALue “NoiseCursorPos”, “3710000” VARIable:VALue “NoiseCursorPos”, “3.71E6” VARIable:VALue? “NoiseCursorPos” Query may return: “NoiseCursorPos 3.71E6” 2- 93 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 126: Noisefilter

    Valid noise filters are: Off, Unified, Unweighted. Related Commands NoiseAverage Noise BW NoiseCursorPos? NoiseLine Returns Query returns the current specified noise filter. Examples VARIable:VALue “NoiseFilter”, “Unified” VARIable:VALue? “NoiseFilter” Query may return: “NoiseFilter Off” 2- 94 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 127: Noiseline

    Floating point notation is allowed. Returns Query returns the current line number for Noise measurement. Examples VARIable:VALue “NoiseLine”, “200” VARIable:VALue? “NoiseLine” Query may return: “NoiseLine 325” 2- 95 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 128: Noisepassdbch[1

    VARIable:VALue? “NoisePassdBCh[1..3]” Group Results Arguments None Returns Returns amplitude value (in dB). Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “NoisePassdBCh2” Query may return: “NoisePassdBCh2 1” 2- 96 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 129: Noisepassmvch[1

    A returned status of 1 means Pass; a returned status of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NoisePassmVCh2” Query may return: “NoisePassmVCh2 0” 2- 97 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 130: Noiserelampdbch[1

    Returns Returns the amplitude value (in dB) on the specified channel. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NoiseRelAmpdBCh2” Query may return: “NoiseRelAmpdBCh2 0.08” 2- 98 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 131: Noiserelampmvch[1

    Returns the amplitude value (in mV) on the specified channel. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NoiseRelAmpmVCh2” Query may return: “NoiseRelAmpmVCh2 - -0.15” 2- 99 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 132: Noiseset

    Valid values are: OFF, ON, 0, 1. Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether NoiseSet measurement is selected Examples VARIable:VALue “NoiseSet”, “ON” VARIable:VALue? “NoiseSet” Query may return: “NoiseSet 1” 2- 100 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 133: Noisestatus

    NoiseMeasurements Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Noise measurement. Examples VARIable:VALue? “NoiseStatus” Query may return: “NoiseStatus Pass” 2- 101 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 134: Nonlinearityaverage

    Floating point notation is allowed. Returns Query returns the current number of samples for Non-Linearity measurement. Examples VARIable:VALue “NonLinearityAverage”, “1” VARIable:VALue? “NonLinearityAverage” Query may return: “NonLinearityAverage 8” 2- 102 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 135: Nonlinearityline

    Floating point notation is allowed. Returns Query returns the current line number for Non-Linearity measurement. Examples VARIable:VALue “NonLinearityLine”, “200” VARIable:VALue? “NonLinearityLine” Query may return: “NonLinearityLine 325” 2- 103 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 136: Nonlinearitypass[1

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available Examples VARIable:VALue? “NonLinearityPassCh3” Query may return: “NonLinearityPctCh3 1 0 1 1 1 1” 2- 104 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 137 A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “NonLinearityPassCh3Max” Query may return: “NonLinearityPassCh3Max 1” 2- 105 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 138: Nonlinearitypassch[1..3]Val[1..5

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NonLinearityPassCh3Val4” Query may return: “NonLinearityPassCh3Val4 0” 2- 106 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 139: Nonlinearitypctch[1

    Returns all six non-linearity values (as a percentage) in this order: Maximum Step1 Step2 Step3 Step4 Step5. Returns “- -- -- -” if no valid measurement is currently available Examples VARIable:VALue? “NonLinearityPctCh3” Query may return: “NonLinearityPctCh3 0.82 0.00 0.82 0.69 0.21 0.28” 2- 107 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 140 NonLinearityPctCh[1..3]Val[1..5] Returns Returns maximum non-linearity value (as a percentage) for specified channel. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “NonLinearityPctCh3Max” Query may return: “NonLinearityPctCh3Max 0.82” 2- 108 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 141: Nonlinearitypctch[1..3]Val[1..5

    Returns non-linearity value (as a percentage) for specified channel and step. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NonLinearityPctCh3Val4” Query may return: “NonLinearityPctCh3Val4 0.21” 2- 109 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 142: Nonlinearityrelpctch[1

    Returns all five relative non-linearity step values (as a percentage) in this order: Step1 Step2 Step3 Step4 Step5. Returns “- -- -- -” if no valid measurement is currently available Examples VARIable:VALue? “NonLinearityRelPctCh3” Query may return: “NonLinearityRelPctCh3 0.59 0.0 1.24 0.4 0.4” 2- 110 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 143 Returns maximum non-linearity relative value (as a percentage) for the specified channel. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “NonLinearityRelPctCh3Max” Query may return: “NonLinearityRelPctCh3Max 0.82” 2- 111 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 144: Nonlinearityrelpctch[1..3]Val[1..5

    Returns non-linearity relative value (as a percentage) for the specified channel and step. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “NonLinearityRelPctCh3Val4” Query may return: “NonLinearityRelPctCh3Val4 0.21” 2- 112 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 145: Nonlinearityset

    Valid values are: OFF, ON, 0, 1. Returns Query returns 0 or 1 depending on whether NonLinearitySet measurement is selected. Examples VARIable:VALue “NonLinearitySet”, “ON” VARIable:VALue? “NonLinearitySet” Query may return: “NonLinearitySet 1” 2- 113 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 146: Nonlinearitystatus

    Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Non Linearity measurement. Examples VARIable:VALue? “NonLinearityStatus” Query may return: “NonLinearityStatus Pass” 2- 114 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 147: Opcomplete

    Option SD/HD Remote Commands OPComplete <setting> Controls VM5000 GPIB scripts by ensuring that the previous command is ready before either querying its value or calling the next command. OPComplete is set to “1” whenever a VM5000 GPIB command has been received and processed and a new command is ready to be processed (except for the resetting of OPComplete itself, which sets OPComplete to “0”).
  • Page 148 VARIable:VALue “Command2”, “Argument2” // call next command While ((VARIable:VALue? “OPComplete”) == “0”) ( Wait; // wait till this command is ready before calling next command // and so on for subsequent commands 2- 116 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 149: Pixaspectratio

    4x3 sets the aspect ratio to standard definition. 16x9 sets the aspect ratio to high definition ratio. Related Commands Returns Returns the display aspect ratio. Examples VARIable:VALue “PixAspectRatio”, “Auto” VARIable:VALue? “PixAspectRatio” Query may return: “PixAspectRatio 16x9” 2- 117 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 150: Pixline

    Floating point notation is allowed. Related Commands VectorscopeLine Returns Returns the line number for the picture display. Examples VARIable:VALue “PixLine”, “165” VARIable:VALue? “PixLine” Query may return: “PixLine 1070” 2- 118 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 151: Popupwarnings

    Valid values are: OFF, ON, 0, 1. Related Commands VectorscopeLine Returns Returns setting for whether or not warnings are displayed. Examples VARIable:VALue “PopupWarnings”, “OFF” VARIable:VALue? “PopupWarnings” Query may return: “PopupWarnings 1” 2- 119 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 152: Recallsettings

    Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “RecallSettings”, “c:\VM5000TV\Tek1.vmset” VARIable:VALue “RecallSettings”, “Tek2.vmset” VARIable:VALue? “RecallSettings” Query may return: “RecallSettings OK” 2- 120 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 153: Referencefileload

    Related Commands ReferenceSet Returns Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “ReferenceFileLoad c:\VM5000TV\RefLimFiles\Defaul- tRef1080i60- -YPbPr.csv” 2- 121 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 154: Referencefilesave

    The pathstring must be less than 60 characters in length, otherwise the command may not be completed successfully. Related Commands ReferenceSet Returns Returns OK after the file is written. Examples VARIable:VALue “ReferenceFileSave c:\VM5000TV\RefLimFiles\DU- TRef1080i60- -YPbPr.csv” 2- 122 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 155: Referenceset

    Valid values are: OFF, ON, 0, 1. Returns Query returns 0 or 1 depending on whether NonLinearitySet measurement is selected. Examples VARIable:VALue “ReferenceSet”, “ON” VARIable:VALue? “ReferenceSet” Query may return: “ReferenceSet 1” 2- 123 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 156: Reportcsvtype [Vm5000|Legacy]

    Group Setup Arguments [VM5000|Legacy] specifies the type of data which is written to the report. VM5000 includes additional data (data for all new measurement functions) compared to the Legacy format which is identical to the format used by the VM5000HD (and does not include any data for new measurement functions).

  • Page 157: Reportgenerate

    Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “ReportGenerate”, “J:\netpath\colorbars.csv” VARIable:VALue “ReportGenerate”, “noise02” VARIable:VALue? “ReportGenerate” Query may return: “ReportGenerate OK” 2- 125 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 158: Reportmeasurements

    Related Commands ChannelDelaySet ColorBarsSet FrequencyResponseSet MultiburstSet NoiseSet NonLinearitySet ReportGenerate ShortTimeDistSet SyncSet Returns Query returns the current specified report measurement mode. Examples VARIable:VALue “ReportMeasurements”, “All” VARIable:VALue? “ReportMeasurements” Query may return: “ReportMeasurements Selected” 2- 126 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 159: Reportstring

    VARiable:VALue? ”ReportString” ”ReportString This is a long string which has 45 characters” VARiable:VALue ”ReportString”, ”This string will be truncated, it is 45 chars” VARiable:VALue? ”ReportString” ”ReportString This string will be tr” 2- 127 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 160 ”ReportString This is a long string which has 45 characters” VARiable:VALue ”ReportString”, ”short” VARiable:VALue? ”ReportString” ”ReportString short” VARiable:VALue ”ReportString”, ”This string won’t be truncated, it is 46 chars” VARiable:VALue? ”ReportString” ”ReportString This string won’t be truncated, it is 46 chars” 2- 128 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 161: Runmode

    <runmode> specifies the run mode that is to be used. Valid run modes are: Once, Continuously. Returns Query returns the currently specified run mode. Examples VARIable:VALue “RunMode”, “Once” VARIable:VALue? “RunMode” Query may return: “RunMode Continuously” 2- 129 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 162: Savesettings

    Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “SaveSettings”, “c:\VM5000TV\Tek1.vmset” VARIable:VALue “SaveSettings”, “Tek2.vmset” VARIable:VALue? “SaveSettings” Query may return: “SaveSettings OK” 2- 130 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 163: Setupandorrun

    <setuprunmode> specifies how to perform setup when performing a measurement. Valid modes are: SetupAndRun, SetupOnly, RunOnly. Returns Query returns the current specified setuprunmode. Examples VARIable:VALue “SetupAndOrRun”, “SetupAndRun” VARIable:VALue? “SetupAndOrRun” Query may return: “SetupAndOrRun”, “SetupAndRun” 2- 131 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 164: Shorttimedistortionaverage

    Floating point notation is allowed. Related Commands ShortTimeDistortionLine Returns Returns the current number of samples for the Short Time Distortion measure- ment. Examples VARIable:VALue “ShortTimeDistortionAverage”, “50” VARIable:VALue? “ShortTimeDistortionAverage” Query may return: “ShortTimeDistortionAverage”, “10” 2- 132 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 165: Shorttimedistortionch[1

    Rise (ns), Fall (ns), Overshoot (%), Undershoot (%), Settling Rise (ns), Settling Fall (ns) Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ShortTimeDistortionCh2” Query may return: “ShortTimeDistortionCh2 30.74 25.37 1.33 3.52 0.0 0.0” 2- 133 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 166 1- -Rise (ns), 2- -Fall (ns), 3- -Overshoot (%), 4- -Undershoot (%), 5- -Settling Rise (ns), 6- -Settling Fall (ns) Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ShortTimeDistortionCh2Val2” Query may return: “ShortTimeDistortionCh2Val3 25.37” 2- 134 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 167: Shorttimedistortionk2T

    ShortTimeDistortionCh[1..3] ShortTimeDistortionResults? Arguments None Returns Returns the K2T value in percent. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ShortTimeDistortionK2T” Query may return: “ShortTimeDistortionK2T 2.56” 2- 135 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 168: Shorttimedistortionline

    Floating point notation is allowed. Related Commands ShortTimeDistortionAverage Returns Returns the time at which the measurement is taken. Examples VARIable:VALue “ShortTimeDistortionLine”, “165” VARIable:VALue? “ShortTimeDistortionLine” Query may return: “ShortTimeDistortionLine 165” 2- 136 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 169: Shorttimedistortionpassch[1

    Returns the pass/fail test status for all six values of the Short Time Distortion measurement. A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. 2- 137 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 170 A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ShortTimeDistortionPassCh2Val2” Query may return: “ShortTimeDistortionPassCh2Val3 1” 2- 138 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 171: Shorttimedistortionpassk2T

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ShortTimeDistortionPassK2T” Query may return: “ShortTimeDistortionPassK2T 1” 2- 139 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 172: Shorttimedistortionrelch[1

    Rise (ns), Fall (ns), Overshoot (%), Undershoot (%), Settling Rise (ns), Settling Fall (ns) Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ShortTimeDistortionRelCh2” Query may return: “ShortTimeDistortionRelCh2 0.52 0.13 0.17 0.17 0.0 0.0” 2- 140 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 173 1- -Rise (ns), 2- -Fall (ns), 3- -Overshoot (%), 4- -Undershoot (%), 5- -Settling Rise (ns), 6- -Settling Fall (ns) Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “ShortTimeDistortionRelCh2Val2” Query may return: “ShortTimeDistortionCh2Val2 0.13” 2- 141 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 174: Shorttimedistortionrelk2T

    Related Commands ShortTimeDistortionRelCh[1..3] ShortTimeDistortionRelCh[1..3]Val[1..6] Returns Returns the K2T relative value in percent. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ShortTimeDistortionRelK2T” Query may return: “ShortTimeDistortionRelK2T 0.42” 2- 142 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 175: Shorttimedistset

    Execute. Valid values are: OFF, ON, 0, 1. Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether ShortTimeDistortionSet measure- ment is selected. Examples VARIable:VALue “ShortTimeDistortionSet”, “ON” VARIable:VALue? “ShortTimeDistortionSet” Query may return: “ShortTimeDistortionSet 1” 2- 143 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 176: Shorttimedistortionstatus

    Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Short Time Distortion measurement. Examples VARIable:VALue? “ShortTimeDistortionStatus” Query may return: “ShortTimeDistortionStatus Pass” 2- 144 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 177: Stoponerror

    <setting> specifies whether or not to stop testing if limits are exceeded. Valid values are: OFF, ON, 0, 1. Related Commands Returns Returns setting for whether or not the VM5000 will stop testing on an error. Examples VARIable:VALue “StopOnError”, “OFF” VARIable:VALue? “StopOnError”...

  • Page 178: Syncaverage

    Floating point notation is allowed. Returns Query returns the current number of samples for Sync measurement. Examples VARIable:VALue “SyncAverage”, “1” VARIable:VALue? “SyncAverage” Query may return: “SyncAverage 8” 2- 146 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 179: Synclevelsmv

    Returns all synchronization levels (in mV) in this order: For Tri-Level: FrontPorchLevel NegativeSyncLevel PositiveSyncLevel. For Bi-Level: FrontPorchLevel SyncLevel. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncLevelsmV” Query may return: “SyncLevelsmV 0.89 –298.31 299.11” 2- 147 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 180: Synclevelsmv[1

    Returns all synchronization levels (in mV) in this order: For Tri-Level: FrontPorchLevel NegativeSyncLevel PositiveSyncLevel. For Bi-Level: FrontPorchLevel SyncLevel. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncLevelsmV1” Query may return: “SyncLevelsmV1 299.11” 2- 148 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 181: Synclevelsmvval[1

    For Tri-Level: 1. FrontPorchLevel, 2. NegativeSyncLevel, 3. PositiveSyncLevel. For Bi-Level: 1. FrontPorchLevel, 2. SyncLevel. Returns “- -- -- -” if no valid measurement currently available Examples VARIable:VALue? “SyncLevelsmVVal3” Query may return: “SyncLevelsmVVal3 299.11” 2- 149 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 182: Syncline

    Floating point notation is allowed. Returns Query returns the current line number for Sync measurement. Examples VARIable:VALue “SyncLine”, “200” VARIable:VALue? “SyncLine” Query may return: “SyncLine 325” 2- 150 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 183: Syncpasslevelsmv

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncPassLevelsmV” Query may return: “SyncPassLevelsmV 1 1 - -- -- -” 2- 151 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 184: Syncpasslevelsmvval[1

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available Examples VARIable:VALue? “SyncPassLevelsmVVal3” Query may return: “SyncPassLevelsmVVal3 1” 2- 152 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 185: Syncpasstimes

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available Examples VARIable:VALue? “SyncPassTimes” Query may return: “SyncPassTimes 1 1 1 1 1 1 1 1 1 1” 2- 153 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 186: Syncpasstimesval[1

    A returned value of 1 means Pass; a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncTimesVal2” Query may return: “SyncTimesVal2 0” 2- 154 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 187: Syncrellevelsmv

    For Tri-Level: Front Porch Level, Negative Sync Level, Positive Sync Level. For Bi-Level: Front Porch Level, Sync Level. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncRelLevelsmV” Query may return: “SyncPassLevelsmV 0.36 1.06 - -1.57” 2- 155 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 188: Syncrellevelsmvval[1

    3. Positive Sync Level. For Bi. Level: 1. Front Porch Level, 2. Sync Level. Returns “- -- -- -” if no valid measurement currently available Examples VARIable:VALue? “SyncRelLevelsmVVal3” Query may return: “SyncRelLevelsmVVal3 - -1.57” 2- 156 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 189: Syncreltimes

    8. End of Addressable Video (μs). Returns “- -- -- -” if no valid measurement currently available Examples VARIable:VALue? “SyncRelTimes” Query may return: “SyncRelTimes 40.34 1.47 0.21 - -0.76 1.01 1.19 39.95 0.0 0.04 - -0.04” 2- 157 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 190: Syncreltimesval[1

    6. Total Line Time (μs), 7. Start of Addressable Video (μs), 8. End of Addressable Video (μs). Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncRelTimesVal2” Query may return: “SyncRelTimesVal2 1.47” 2- 158 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 191: Syncset

    OFF, ON, 0, 1. Related Commands Execute ReportMeasurements Returns Query returns 0 or 1 depending on whether SyncSet measurement is selected. Examples VARIable:VALue “SyncSet”, “ON” VARIable:VALue? “SyncSet” Query may return: “SyncSet 1” 2- 159 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 192: Syncstatus

    Status Returns Query returns [ - -- -- - | Done | Stopped | Pass | Fail ] status of the Sync measurement. Examples VARIable:VALue? “SyncStatus” Query may return: “SyncStatus Pass” 2- 160 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 193: Synctimes

    For Bi-Level: 1. FrontPorch, 2. NegativeSyncFall, 3. NegativeSyncWidth 4. SyncRise, 5 BackPorch. Returns “- -- -- -” if no valid measurement currently available Examples VARIable:VALue? “SyncTimes” Query may return: “SyncTimes 3822.39 59.03 592.01 52.61 590.40 55.24 1995.19” 2- 161 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 194: Synctimesval[1

    For Bi-Level: 1. FrontPorch, 2. NegativeSyncFall, 3. NegativeSyncWidth, 4. SyncRise, 5. BackPorch. Returns “- -- -- -” if no valid measurement currently available. Examples VARIable:VALue? “SyncTimesVal2” Query may return: “SyncTimesVal2 59.03” 2- 162 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 195: Trigger

    <trigger> specifies trigger that is to be used. Valid triggers are: Ch1, Ch4. Returns Query returns the current specified trigger. Examples VARIable:VALue “Trigger”, “Ch4” VARIable:VALue? “Trigger” Query may return: “Trigger Ch4” 2- 163 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 196: Vectorscopegrat [Auto|709- Hd|601- Sd]

    709- -HD selects the graticule for HD signals. 601- -Sd selects the graticule for SD signals. Related Commands VectorscopeLine VectorscopeScale Returns Returns the graticule type used for Vectorscope display. Examples VARIable:VALue “VectorscopeGrat”, “709- -HD” VARIable:VALue? “VectorscopeLine” Query may return: “VectorscopeLine Auto” 2- 164 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 197: Vectorscopeline

    Floating point notation is allowed. Related Commands PixLine VectorscopeGrat VectorscopeScale Returns Returns the line number used for the Vectorscope display. Examples VARIable:VALue “VectorscopeLine”, “165” VARIable:VALue? “VectorscopeLine” Query may return: “VectorscopeLine 1070” 2- 165 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 198: Vectorscopescale [Auto|75Pct|100Pct]

    75% scale. 100Pct selects the 100% scale. Related Commands VectorscopeGrat VectorscopeLine Returns Returns the display scale used for the Vectorscope display. Examples VARIable:VALue “VectorscopeGrat”, “709- -HD” VARIable:VALue? “VectorscopeLine” Query may return: “VectorscopeLine Auto” 2- 166 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 199: Warning

    VARIable:VALue “Warning”, “<string>” Group Setup Arguments <string> is the warning message reported when a warning is generated. Related Commands WarningLogSet WarningReportingMeasure WarningReportingResults WarningReportingSignal Returns None Examples VARIable:VALue “Warning”, “An error has been generated” 2- 167 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 200: Warningreportingmeasure

    OFF is the same as 0, and ON is the same as 1. Related Commands WarningReportResults WarningReportSignal Returns Query returns the current specified setting. Examples VARIable:VALue “WarningReportingMeasure”, “ON” VARIable:VALue? “WarningReportingMeasure” Query may return: “WarningReportingMeasure 0” 2- 168 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 201: Warningreportingresults

    OFF is the same as 0, and ON is the same as 1. Related Commands WarningReportingMeasure WarningReportingSignal Returns Query returns the current specified setting. Examples VARIable:VALue “WarningReportingResults”, “ON” VARIable:VALue? “WarningReportingResults” Query may return: “WarningReportingResults 0” 2- 169 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 202: Warningreportingsignal

    OFF is the same as 0, and ON is the same as 1. Related Commands WarningReportingMeasure WarningReportingResults Returns Query returns the current specified setting. Examples VARIable:VALue “WarningReportingSignal”, “ON” VARIable:VALue? “WarningReportingSignal” Query may return: “WarningReportingSignal 0” 2- 170 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 203 Option VGA Remote Commands...

  • Page 205: Command Groups

    Set or query the ending line number used to perform the Color Bars measurement on multiple lines. ColorBarsMultiLineSet Set or query whether to perform the Color Bars measurement on multiple lines upon Execute. 3- 1 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 206 LumaLevelsAverage Set or query the total number of samples over which to average the Luma Levels measurement. LumaLevelsLine Set or query the line number used to perform the Luma Levels measurement. 3- 2 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 207: Table 3- 2: Configuration Commands (Option Vga)

    Set or query whether to perform the Video Transient measurement upon Execute. Table 3- 2: Configuration Commands (Option VGA) Header Description :VARIable:VALue AutoScale Set or query whether to use auto scale during measurement. 3- 3 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 208: Syncpolaritydetectset

    UseMIUSet Set or query, if the hardware accessory ”RGBHV MIU” is connected, the VM5000 runs tests in an automatic mode that does not require user intervention. If the RGBHV MIU is not connected, the user must make manual connection changes when prompted by the VM5000.

  • Page 209: Table 3- 4: Operations Commands (Option Vga)

    Specifies the Reference file to be loaded for Relative to Reference testing. LimitFileLoad Specifies the Limit file to be loaded for Limit Testing. ReferenceSet Set or query whether Reference Testing is enabled or disabled. 3- 5 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 210: Table 3- 6: Reporting Commands (Option Vga)

    Query the pass/fail status of the Ch- - Ch Mismatch Ch1Ch2 measurement. ChChMismatchPassCh1Ch3? Query the pass/fail status of the Ch- - Ch Mismatch Ch1Ch3 measurement. ChChMismatchPassCh2Ch3? Query the pass/fail status of the Ch- - Ch Mismatch Ch2Ch3 measurement. 3- 6 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 211 Query the pass/fail status for all the color bars values resulting from the Color Bars measurement on all the channels. HSyncPassPolarity? Query the pass/fail status for the Polarity value resulting from the H Sync measurement. 3- 7 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 212 Query the pass/fail status for the Time period resulting from the H Sync Jitter measurement. HSyncJitterPassPixelClock? Query the pass/fail status for the (%) Pixel Clock value resulting from the H Sync Jitter measurement. 3- 8 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 213 Noise Inj Ratio measurement on the specified channel. NoisePassIrCh[1..3]? Query the pass/fail status of the Inj Ratio (in %) value resulting from the Noise Inj Ratio measurement on the specified channel. 3- 9 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 214 Logic Level “0” at ± 8 mA with the MIU connected or 301 Ω termination resistance without the MIU connected) resulting from the V Sync measurement. VSyncPassAll? Query the pass/fail status for all the values resulting from the V Sync measurement. 3- 10 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 215 Query pass/fail status for the Undershoot Settling Time resulting from the TimeCh[1..3]? Video Transient measurement on the specified channel. VideoTransientPassAll? Query the pass/fail status for all the values resulting from the Video Transient measurement on all the channels. 3- 11 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 216: Table 3- 8: Results Summary Query Commands (Option Vga)

    Query the measured Ch1Ch2 Skew resulting from the Ch- - Ch Skew measurement. ChChSkewCh1Ch3? Query the measured Ch1Ch3 Skew resulting from the Ch- - Ch Skew measurement. ChChSkewCh2Ch3? Query the measured Ch2Ch3 Skew resulting from the Ch- - Ch Skew measurement. 3- 12 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 217 Query the measured Overshoot Settling Time resulting from the H Sync measurement. HSyncUndershootSettlingTime? Query the measured Undershoot Settling Time resulting from the H Sync measurement. HSyncMonotonicRise? Query the measured Monotonic Rise value resulting from the H Sync measurement. 3- 13 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 218 Query the measured values of all the H Timing measurements on all the channels. LinearityResolutionCh[1..3]? Query the measured Resolution resulting from the Linearity measurement on the specified channel. LinearityMaxINLCh[1..3]? Query the measured Max INL resulting from the Linearity measurement on the specified channel. 3- 14 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 219 Query the measured Overshoot Settling Time resulting from the V Sync measurement. VSyncUndershootSettlingTime? Query the measured Undershoot Settling Time resulting from the V Sync measurement. VSyncMonotonicRise? Query the measured Monotonic Rise value resulting from the V Sync measurement. 3- 15 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 220 Query the measured Video Fall Time percentage resulting from the PercentageCh[1..3]? Video Transient measurement on the specified channel. VideoTransientOvershootCh[1..3]? Query the measured Overshoot resulting from the Video Transient measurement on the specified channel. 3- 16 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 221: Table 3- 10: Relative Results Query Commands (Option Vga)

    Query the Ch- - Ch Skew measurement for all of its relative results. ColorBarsRelCh[1..3]? Query the relative values of all eight color bars resulting from the Color Bars measurement on the specified channel. 3- 17 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 222 Query the Frequency relative value resulting from the H Sync measurement. HSyncRelRiseTime? Query the Rise Time relative value resulting from the H Sync measurement. HSyncRelFallTime? Query the Fall Time relative value resulting from the H Sync measurement. 3- 18 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 223 HTimingRelSyncPulseWidth? Query the Sync Pulse Width relative value resulting from the H Timing measurement. HTimingRelPixelClock? Query the Pixel Clock relative value resulting from the H Timing measurement. 3- 19 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 224 Query the Overshoot relative value resulting from the V Sync measurement. VSyncRelUndershoot? Query the Undershoot relative value resulting from the V Sync measurement. VSyncRelOvershootSettlingTime? Query the Overshoot Settling Time relative value resulting from the V Sync measurement. 3- 20 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 225 Query the Video Rise Time Percentage relative value resulting from PercentageCh[1..3]? Video Transient measurement on the specified channel. VideoTransientRelVideoFallTime Query the Video Fall Time Percentage relative value resulting from PercentageCh[1..3]? Video Transient measurement on the specified channel. 3- 21 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 226: Table 3- 11: Reference Values Query Commands (Option Vga)

    Query the Ch1Ch3 (%) Pixel Clock reference value specified in the Reference file. ChChSkewRefPixelClockCh2Ch3? Query the Ch2Ch3 (%) Pixel Clock reference value specified in the Reference file. ChChSkewRefAll? Query all the Ch- - Ch Skew reference values specified in the Reference file. 3- 22 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 227 Reference file. HSyncRefLogicLevel0Value1? Query the H Sync Logic Level “0” at Value1 (Value1 represents the Logic Level “0” at 2.21 kΩ termination resistance) reference value specified in the Reference file. 3- 23 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 228 Query the Luma Levels Amplitude Maximum reference value specified in the Reference file on the specified channel. LumaLevelsRefAmpMinCh[1..3]? Query the Luma Levels Amplitude Minimum reference value specified in the Reference file on the specified channel. 3- 24 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 229 Query the V Sync Rise Time reference value specified in the Reference file. VSyncRefSyncPeriod? Query the V Sync Sync Period reference value specified in the Reference file. VSyncRefUndershoot? Query the V Sync Undershoot reference value specified in the Reference file. 3- 25 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 230: Table 3- 12: Maximum Limits Query Commands (Option Vga)

    Reference file on the specified channel. Table 3- 12: Maximum Limits Query Commands (Option VGA) Header Description :VARIable:VALue ChChMismatchMaxCh1Ch2? Query the Ch1Ch2 voltage amplitude Mismatch maximum limit value specified in the Limits file. 3- 26 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 231 Query the Color Bars Red color bar maximum limit value specified in the Limits file on the specified channel. ColorBarsMaxCh[1..3]Val7? Query the Color Bars Blue color bar maximum limit value specified in the Limits file on the specified channel. 3- 27 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 232 Query all the H Sync Jitter maximum limit values specified in the Limits file. HTimingMaxBackPorchCh[1..3]? Query the H Timing Back Porch maximum limit value specified in the Limits file on the specified channel. 3- 28 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 233 Query the V Sync Sync Period maximum limit value specified in the Limits file. VSyncMaxFrequency? Query the V Sync Frequency maximum limit value specified in the Limits file. VSyncMaxRiseTime? Query the V Sync Rise Time maximum limit value specified in the Limits file. 3- 29 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 234 Query the V Timing Sync Pulse Width maximum limit value specified in the Limits file on the specified channel. VTimingMaxAll? Query all the V Timing maximum limit values specified in the Limits file on all the channels. 3- 30 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 235: Videotransientmaxovershootch[1

    Query all the Ch- - Ch Mismatch minimum limit values specified in the Limits file. ChChSkewMinCh1Ch2? Query the Ch- - Ch Skew Ch1Ch2 channel skew minimum limit value specified in the Limits file. 3- 31 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 236 Query the H Sync Overshoot minimum limit value specified in the Limits file. HSyncMinUndershoot? Query the H Sync Undershoot minimum limit value specified in the Limits file. HSyncMinOvershootSettlingTime? Query the H Sync Overshoot Settling Time minimum limit value specified in the Limits file. 3- 32 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 237 Limits file. HTimingMinPixelClock? Query the H Timing Pixel Clock minimum limit value specified in the Limits file. HTimingMinAll? Query all the H Timing minimum limit values specified in the Limits file. 3- 33 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 238 Limits file. VSyncMinMonotonicRise? Query the V Sync Monotonic Rise minimum limit value specified in the Limits file. VSyncMinMonotonicFall? Query the V Sync Monotonic Fall minimum limit value specified in the Limits file. 3- 34 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 239: Videotransientminovershootch[1

    Query the Video Transient Overshoot minimum limit value specified in the Limits file on the specified channel. VideoTransientMinUndershootCh[1..3]? Query the Video Transient Undershoot minimum limit value specified in the Limits file on the specified channel. 3- 35 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 240 TimeCh[1..3]? specified in the Limits file on the specified channel. VideoTransientMinUndershootSettling Query the Video Transient Undershoot Settling Time minimum limit value TimeCh[1..3]? specified in the Limits file on the specified channel. 3- 36 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 241: Commands

    Query whether the Application Status is: Configure, Measuring, Done, Reported. Syntax VARIable:VALue? “AppStatus” Group Global Input Arguments None Returns Query returns the application status as Configure, Measuring, Done, Reported. Examples VARIable:VALue? “AppStatus” Query may return: “AppStatus Configure” 3- 37 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 242: Autoscale

    <setting> specifies auto scale setting that is to be used. Valid settings are: OFF (0), ON (1). Return value Query returns the currently specified setting. Examples VARIable:VALue ”AutoScale”, ”ON” VARIable:VALue? ”AutoScale” Query may return: ”AutoScale 0” 3- 38 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 243: Autoscaleinit

    “Default” loads the factory default settings. Returns Query returns the currently specified setting. Examples VARIable:VALue “AutoScaleInit”, “LastMeas” VARIable:VALue? “AutoScaleInit” Query may return: “AutoScaleInit LastMeas” 3- 39 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 244: Chchmismatchall

    Ch1Ch3 (%), and Ch2Ch3 (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchAll” Query may return: “ChChMismatchAll - -1.44 73.97 73.97 - -104.72 42.19 30.23” 3- 40 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 245: Chchmismatchaverage

    Return value Query returns the currently assigned number of samples for the Ch- -Ch Mismatch measurement. Examples VARIable:VALue “ChChMismatchAverage”, “1” VARIable:VALue? “ChChMismatchAverage” Query may return: “ChChMismatchAverage 8” 3- 41 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 246: Chchmismatchch1Ch2

    Ch- -Ch Mismatch measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchCh1Ch2” Query may return: “ChChMismatchCh1Ch2 - -1.44” 3- 42 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 247: Chchmismatchch1Ch3

    Ch- -Ch Mismatch measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchCh1Ch3” Query may return: “ChChMismatchCh1Ch3 73.97” 3- 43 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 248: Chchmismatchch2Ch3

    Ch- -Ch Mismatch measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchCh2Ch3” Query may return: “ChChMismatchCh2Ch3 73.97” 3- 44 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 249: Chchmismatchline

    Related Commands ChChMismatchAverage Return value Query returns the currently assigned line number used to perform the Ch- -Ch Mismatch measurement. Examples VARIable:VALue “ChChMismatchLine”, “200” VARIable:VALue? “ChChMismatchLine” Query may return: “ChChMismatchLine 325” 3- 45 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 250: Chchmismatchmaxall

    Ch1Ch3 (%), and Ch2Ch3 (%). Returns “- -- -- -” if no value in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxAll” Query may return: “ChChMismatchMaxAll - -1.44 73.97 73.97 - -104.72 42.19 30.23” 3- 46 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 251: Chchmismatchmaxch1Ch2

    The returned value is in millivolts (mV). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxCh1Ch2” Query may return: “ChChMismatchMaxCh1Ch2 - -1.44” 3- 47 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 252: Chchmismatchmaxch1Ch3

    The returned value is in millivolts (mV). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxCh1Ch3” Query may return: “ChChMismatchMaxCh1Ch3 73.97” 3- 48 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 253: Chchmismatchmaxch2Ch3

    The returned value is in millivolts (mV). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxCh2Ch3” Query may return: “ChChMismatchMaxCh2Ch3 73.97” 3- 49 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 254: Chchmismatchmaxpeaktopeakch1Ch2

    The returned value is in percent (%). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxPeakToPeakCh1Ch2” Query may return: “ChChMismatchMaxPeakToPeakCh1Ch2 - -104.72” 3- 50 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 255: Chchmismatchmaxpeaktopeakch1Ch3

    The returned value is in percent (%). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxPeakToPeakCh1Ch3” Query may return: “ChChMismatchMaxPeakToPeakCh1Ch3 42.19” 3- 51 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 256: Chchmismatchmaxpeaktopeakch2Ch3

    The returned value is in percent (%). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMaxPeakToPeakCh2Ch3” Query may return: “ChChMismatchMaxPeakToPeakCh2Ch3 30.23” 3- 52 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 257: Chchmismatchminall

    Ch1Ch3 (%), and Ch2Ch3 (%). Returns “- -- -- -” if no value in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinAll” Query may return: “ChChMismatchMinAll - -1.44 73.97 73.97 - -104.72 42.19 30.23” 3- 53 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 258: Chchmismatchminch1Ch2

    The returned value is in millivolts (mV). Returns “- -- -- -” if no minimum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinCh1Ch2” Query may return: “ChChMismatchMinCh1Ch2 - -1.44” 3- 54 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 259: Chchmismatchminch1Ch3

    The returned value is in millivolts (mV). Returns “- -- -- -” if no maximum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinCh1Ch3” Query may return: “ChChMismatchMinCh1Ch3 73.97” 3- 55 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 260: Chchmismatchminch2Ch3

    The returned value is in millivolts (mV). Returns “- -- -- -” if no minimum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinCh2Ch3” Query may return: “ChChMismatchMinCh2Ch3 73.97” 3- 56 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 261: Chchmismatchminpeaktopeakch1Ch2

    The returned value is in percent (%). Returns “- -- -- -” if no minimum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinPeakToPeakCh1Ch2” Query may return: “ChChMismatchMinPeakToPeakCh1Ch2 - -104.72” 3- 57 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 262: Chchmismatchminpeaktopeakch1Ch3

    The returned value is in percent (%). Returns “- -- -- -” if no minimum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinPeakToPeakCh1Ch3” Query may return: “ChChMismatchMinPeakToPeakCh1Ch3 42.19” 3- 58 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 263: Chchmismatchminpeaktopeakch2Ch3

    The returned value is in percent (%). Returns “- -- -- -” if no minimum channel mismatch in the limits file is specified. Examples VARIable:VALue? “ChChMismatchMinPeakToPeakCh2Ch3” Query may return: “ChChMismatchMinPeakToPeakCh2Ch3 30.23” 3- 59 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 264 Return value Query returns the currently assigned ending line number used to perform the Ch- -Ch Mismatch measurement on multiple lines. Examples VARIable:VALue “ChChMismatchMultiLineEnd”, “200” VARIable:VALue? “ChChMismatchMultiLineEnd” Query may return: “ChChMismatchMultiLineEnd 325” 3- 60 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 265 Query returns “0” if the Ch- -Ch Mismatch measurement on multiple lines is not selected. Query returns “1” if the Ch- -Ch Mismatch measurement on multiple lines is selected. Examples VARIable:VALue “ChChMismatchMultiLineSet”,“ON” VARIable:VALue? “ChChMismatchMultiLineSet” Query may return: “ChChMismatchMultiLineSet 1” 3- 61 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 266 Return value Query returns the currently assigned starting line number used to perform the Ch- -Ch Mismatch measurement on multiple lines. Examples VARIable:VALue “ChChMismatchMultiLineStart”, “200” VARIable:VALue? “ChChMismatchMultiLineStart” Query may return: “ChChMismatchMultiLineStart 325” 3- 62 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 267: Chchmismatchpassall

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPassAll” Query may return: “ChChMismatchPassAll 1 1 1 0 0 1 ” 3- 63 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 268: Chchmismatchpassch1Ch2

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchPassCh1Ch2” Query may return: “ChChMismatchPassCh1Ch2 1” 3- 64 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 269: Chchmismatchpassch1Ch3

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchPassCh1Ch3” Query may return: “ChChMismatchPassCh1Ch3 1” 3- 65 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 270: Chchmismatchpassch2Ch3

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPassCh2Ch3” Query may return: “ChChMismatchPassCh2Ch3 1” 3- 66 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 271: Chchmismatchpasspeaktopeakch1Ch2

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPassPeakToPeakCh1Ch2” Query may return: “ChChMismatchPassPeakToPeakCh1Ch2 1” 3- 67 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 272: Chchmismatchpasspeaktopeakch1Ch3

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPassPeakToPeakCh1Ch3” Query may return: “ChChMismatchPassPeakToPeakCh1Ch3 1” 3- 68 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 273: Chchmismatchpasspeaktopeakch2Ch3

    A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPassPeakToPeakCh2Ch3” Query may return: “ChChMismatchPassPeakToPeakCh2Ch3 1” 3- 69 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 274: Chchmismatchpeaktopeakch1Ch2

    Ch- -Ch Mismatch measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”ChChMismatchPeakToPeakCh1Ch2” Query may return: ”ChChMismatchPeakToPeakCh1Ch2 - -104.72” 3- 70 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 275: Chchmismatchpeaktopeakch1Ch3

    Ch- -Ch Mismatch measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPeakToPeakCh1Ch3” Query may return: “ChChMismatchPeakToPeakCh1Ch3 42.19” 3- 71 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 276: Chchmismatchpeaktopeakch2Ch3

    Ch- -Ch Mismatch measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchPeakToPeakCh2Ch3” Query may return: “ChChMismatchPeakToPeakCh2Ch3 30.23” 3- 72 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 277: Chchmismatchrefall

    Ch1Ch3 (%), and Ch2Ch3 (%) Peak- -Peak. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRefAll” Query may return: “ChChMismatchRefAll - -1.44 73.97 73.97 - -104.72 42.19 30.23” 3- 73 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 278 Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchRefCh1Ch2” Query may return: “ChChMismatchRefCh1Ch2 - -1.44” 3- 74 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 279 Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchRefCh1Ch3” Query may return: “ChChMismatchRefCh1Ch3 73.97” 3- 75 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 280 Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchRefCh2Ch3” Query may return: “ChChMismatchRefCh2Ch3 73.97” 3- 76 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 281 Reference file. The returned value is in percent (%). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchRefPeakToPeakCh1Ch2” Query may return: “ChChMismatchRefPeakToPeakCh1Ch2 - -104.72” 3- 77 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 282 Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchRefPeakToPeakCh1Ch3” Query may return: “ChChMismatchRefPeakToPeakCh1Ch3 42.19” 3- 78 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 283 Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ChChMismatchRefPeakToPeakCh2Ch3” Query may return: “ChChMismatchRefPeakToPeakCh2Ch3 30.23” 3- 79 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 284 Ch1Ch2 (%) Peak- -Peak, Ch1Ch3 (%) Peak- -Peak, and Ch2Ch3 (%) Peak- -Peak. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelAll” Query may return: “ChChMismatchRelAll - -1.44 73.97 73.97 - -104.72 42.19 30.23” 3- 80 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 285 Ch- -Ch Mismatch measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelCh1Ch2” Query may return: “ChChMismatchRelCh1Ch2 - -1.44” 3- 81 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 286 Ch- -Ch Mismatch measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelCh1Ch3” Query may return: “ChChMismatchRelCh1Ch3 73.97 3- 82 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 287 Ch- -Ch Mismatch measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelCh2Ch3” Query may return: “ChChMismatchRelCh2Ch3 73.97” 3- 83 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 288 Ch- -Ch Mismatch measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelPeakToPeakCh1Ch2” Query may return: “ChChMismatchRelPeakToPeakCh1Ch2 - -104.72” 3- 84 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 289 Ch- -Ch Mismatch measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelPeakToPeakCh1Ch3” Query may return: “ChChMismatchRelPeakToPeakCh1Ch3 42.19” 3- 85 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 290 Ch- -Ch Mismatch measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChMismatchRelPeakToPeakCh2Ch3” Query may return: “ChChMismatchRelPeakToPeakCh2Ch3 30.23” 3- 86 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 291 Query returns “0” if the Ch- -Ch Mismatch measurement is not selected. Query returns “1” if the Ch- -Ch Mismatch measurement is selected. Examples VARIable:VALue “ChChMismatchSet”, “ON” VARIable:VALue? “ChChMismatchSet” Query may return: “ChChMismatchSet 1” 3- 87 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 292 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “ChChMismatchStatus” Query may return: “ChChMismatchStatus Pass” 3- 88 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 293 Ch1Ch2 (%) Pixel Clock, Ch1Ch3 (%) Pixel Clock, and Ch2Ch3 (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewAll” Query may return: “ChChSkewAll 1.18 0.43 0.21 7.67 2.81 1.38” 3- 89 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 294 Return value Query returns the current assigned total number of samples for the Ch- -Ch Skew measurement. Examples VARIable:VALue “ChChSkewAverage”, “1” VARIable:VALue? “ChChSkewAverage” Query may return: “ChChSkewAverage 8” 3- 90 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 295 Query returns the measured Ch1Ch2 Skew value resulting from the Ch- -Ch Skew measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewCh1Ch2” Query may return: “ChChSkewCh1Ch2 1.18” 3- 91 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 296 Query returns the measured Ch1Ch3 Skew value resulting from the Ch- -Ch Skew measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewCh1Ch3” Query may return: “ChChSkewCh1Ch3 0.43” 3- 92 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 297 Query returns the measured Ch2Ch3 Skew value resulting from the Ch- -Ch Skew measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewCh2Ch3” Query may return: “ChChSkewCh2Ch3 0.21” 3- 93 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 298 Values outside the range will be adjusted to be within the range. Return value Query returns the currently assigned line number used to perform the Ch- -Ch Skew measurement. Examples VARIable:VALue “ChChSkewLine”, “200” VARIable:VALue? “ChChSkewLine” Query may return: “ChChSkewLine 325” 3- 94 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 299 Ch- -Ch Skew measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPixelClockCh1Ch2” Query may return: “ChChSkewPixelClockCh1Ch2 7.67” 3- 95 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 300 Ch- -Ch Skew measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPixelClockCh1Ch3” Query may return: “ChChSkewPixelClockCh1Ch3 2.81” 3- 96 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 301 Ch- -Ch Skew measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPixelClockCh2Ch3” Query may return: “ChChSkewPixelClockCh2Ch3 1.38” 3- 97 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 302 Ch1Ch2 (%) Pixel Clock, Ch1Ch3 (%) Pixel Clock, and Ch2Ch3 (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxAll” Query may return: “ChChSkewMaxAll 1.18 0.43 0.21 7.67 2.81 1.38” 3- 98 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 303 Query returns the Ch- -Ch Skew Ch1Ch2 maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxCh1Ch2” Query may return: “ChChSkewMaxCh1Ch2 1.18” 3- 99 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 304 Query returns the Ch- -Ch Skew Ch1Ch3 maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxCh1Ch3” Query may return: “ChChSkewMaxCh1Ch3 0.43” 3- 100 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 305 Query returns the Ch- -Ch Skew Ch2Ch3 maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxCh2Ch3” Query may return: “ChChSkewMaxCh2Ch3 0.21” 3- 101 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 306 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxPixelClockCh1Ch2” Query may return: “ChChSkewMaxPixelClockCh1Ch2 7.67” 3- 102 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 307 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxPixelClockCh1Ch3” Query may return: “ChChSkewMaxPixelClockCh1Ch3 2.81” 3- 103 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 308 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMaxPixelClockCh2Ch3” Query may return: “ChChSkewMaxPixelClockCh2Ch3 1.38” 3- 104 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 309 Ch1Ch2 (%) Pixel Clock, Ch1Ch3 (%) Pixel Clock, and Ch2Ch3 (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinAll” Query may return: “ChChSkewMinAll 1.18 0.43 0.21 7.67 2.81 1.38” 3- 105 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 310 Query returns the Ch- -Ch Skew Ch1Ch2 minimum limit value specified in the Limits file. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinCh1Ch2” Query may return: “ChChSkewMinCh1Ch2 1.18” 3- 106 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 311 Query returns the Ch- -Ch Skew Ch1Ch3 minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinCh1Ch3” Query may return: “ChChSkewMinCh1Ch3 0.43” 3- 107 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 312 Query returns the Ch- -Ch Skew Ch2Ch3 minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinCh2Ch3” Query may return: “ChChSkewMinCh2Ch3 0.21” 3- 108 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 313 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinPixelClockCh1Ch2” Query may return: “ChChSkewMinPixelClockCh1Ch2 7.67” 3- 109 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 314 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinPixelClockCh1Ch3” Query may return: “ChChSkewMinPixelClockCh1Ch3 2.81” 3- 110 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 315 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewMinPixelClockCh2Ch3” Query may return: “ChChSkewMinPixelClockCh2Ch3 1.38” 3- 111 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 316 Return value Query returns the currently assigned ending line number used to perform the Ch- -Ch Skew measurement on multiple lines. Examples VARIable:VALue “ChChSkewMultiLineEnd”, “200” VARIable:VALue? “ChChSkewMultiLineEnd” Query may return: “ChChSkewMultiLineEnd 325” 3- 112 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 317 Query returns “0” if the Ch- -Ch Skew measurement on multiple lines is not selected. Query returns “1” if the Ch- -Ch Skew measurement on multiple lines is selected. Examples VARIable:VALue “ChChSkewMultiLineSet”, “ON” VARIable:VALue? “ChChSkewMultiLineSet” Query may return: “ChChSkewMultiLineSet 1” 3- 113 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 318 Return value Query returns the currently assigned starting line number used to perform the Ch- -Ch Skew measurement on multiple lines. Examples VARIable:VALue “ChChSkewMultiLineStart”, “200” VARIable:VALue? “ChChSkewMultiLineStart” Query may return: “ChChSkewMultiLineStart 325” 3- 114 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 319 Ch1Ch2 (%) Pixel Clock, Ch1Ch3 (%) Pixel Clock, and Ch2Ch3 (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassAll” Query may return: “ChChSkewPassAll 1 1 0 1 1 0” 3- 115 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 320 A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassCh1Ch2” Query may return: “ChChSkewPassCh1Ch2 1” 3- 116 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 321 A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassCh1Ch3” Query may return: “ChChSkewPassCh1Ch3 1” 3- 117 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 322 A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassCh2Ch3” Query may return: “ChChSkewPassCh2Ch3 1” 3- 118 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 323 A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassPixelClockCh1Ch2” Query may return: “ChChSkewPassPixelClockCh1Ch2 1” 3- 119 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 324 A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassPixelClockCh1Ch3” Query may return: “ChChSkewPassPixelClockCh1Ch3 1” 3- 120 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 325 A returned value of 1 means pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewPassPixelClockCh2Ch3” Query may return: “ChChSkewPassPixelClockCh2Ch3 1” 3- 121 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 326 Ch1Ch2 (%) Pixel Clock, Ch1Ch3 (%) Pixel Clock, and Ch2Ch3 (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefAll” Query may return: “ChChSkewRefAll 1.18 0.43 0.21 7.67 2.81 1.38” 3- 122 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 327 Query returns the Ch- -Ch Skew Ch1Ch2 reference value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefCh1Ch2” Query may return: “ChChSkewRefCh1Ch2 1.18” 3- 123 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 328 Query returns the Ch- -Ch Skew Ch1Ch3 reference value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefCh1Ch3” Query may return: “ChChSkewRefCh1Ch3 0.43” 3- 124 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 329 Query returns the Ch- -Ch Skew Ch2Ch3 reference value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefCh2Ch3” Query may return: “ChChSkewRefCh2Ch3 0.21” 3- 125 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 330 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefPixelClockCh1Ch2” Query may return: “ChChSkewRefPixelClockCh1Ch2 7.67” 3- 126 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 331 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefPixelClockCh1Ch3” Query may return: “ChChSkewRefPixelClockCh1Ch3 2.81” 3- 127 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 332 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRefPixelClockCh2Ch3” Query may return: “ChChSkewRefPixelClockCh2Ch3 1.38” 3- 128 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 333 Ch1Ch2 (%) Pixel Clock, Ch1Ch3 (%) Pixel Clock, and Ch2Ch3 (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelAll” Query may return: “ChChSkewRelAll 1.18 0.43 0.21 7.67 2.81 1.38” 3- 129 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 334 Query returns the Ch1Ch2 Skew relative value resulting from the Ch- -Ch Skew measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelCh1Ch2” Query may return: “ChChSkewRelCh1Ch2 1.18” 3- 130 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 335 Query returns the Ch1Ch3 Skew relative value resulting from the Ch- -Ch Skew measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelCh1Ch3” Query may return: “ChChSkewRelCh1Ch3 0.43” 3- 131 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 336 Query returns the Ch2Ch3 Skew relative value resulting from the Ch- -Ch Skew measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelCh2Ch3” Query may return: “ChChSkewRelCh2Ch3 0.21” 3- 132 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 337 Ch- -Ch Skew measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelPixelClockCh1Ch2” Query may return: “ChChSkewRelPixelClockCh1Ch2 7.67” 3- 133 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 338 Ch- -Ch Skew measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelPixelClockCh1Ch3” Query may return: “ChChSkewRelPixelClockCh1Ch3 2.81” 3- 134 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 339 Ch- -Ch Skew measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ChChSkewRelPixelClockCh2Ch3” Query may return: “ChChSkewRelPixelClockCh2Ch3 1.38” 3- 135 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 340 Query returns “0” if the Ch- -Ch Skew measurement is not selected. Query returns “1” if the Ch- -Ch Skew measurement is selected. Examples VARIable:VALue “ChChSkewSet”, “ON” VARIable:VALue? “ChChSkewSet” Query may return: “ChChSkewSet 1” 3- 136 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 341 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “ChChSkewStatus” Query may return: “ChChSkewStatus Pass” 3- 137 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 342 Return value Query returns the currently assigned total number of samples over which to average results from the Color Bars measurement. Examples VARIable:VALue “ColorBarsAverage”, “1” VARIable:VALue? “ColorBarsAverage” Query may return: “ColorBarsAverage 8” 3- 138 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 343 Black(Ch3). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1” Query may return: “ColorBarsCh1 700 700 700 700 0 0 0 0” 3- 139 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 344 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val1” Query may return: “ColorBarsCh1Val1 700” 3- 140 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 345 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val2” Query may return: “ColorBarsCh1Val2 700” 3- 141 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 346 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val3” Query may return: “ColorBarsCh1Val3 700” 3- 142 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 347 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val4” Query may return: “ColorBarsCh1Val4 700” 3- 143 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 348 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val5” Query may return: “ColorBarsCh1Val5 0” 3- 144 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 349 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val6” Query may return: “ColorBarsCh1Val6 0” 3- 145 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 350 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val7” Query may return: “ColorBarsCh1Val7 0” 3- 146 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 351 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsCh1Val8” Query may return: “ColorBarsCh1Val8 0” 3- 147 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 352 Return value Query returns the currently assigned line number used to perform the Color Bars measurement. Examples VARIable:VALue “ColorBarsLine”, “200” VARIable:VALue? “ColorBarsLine” Query may return: “ColorBarsLine 325” 3- 148 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 353 The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1” Query may return: “ColorBarsMaxCh1 700 700 700 700 0 0 0 0” 3- 149 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 354 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val1” Query may return: “ColorBarsMaxCh1Val1 700” 3- 150 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 355 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val2” Query may return: “ColorBarsMaxCh1Val2 700” 3- 151 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 356 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val3” Query may return: “ColorBarsMaxCh1Val3 700” 3- 152 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 357 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val4” Query may return: “ColorBarsMaxCh1Val4 700” 3- 153 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 358 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val5” Query may return: “ColorBarsMaxCh1Val5 0” 3- 154 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 359 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val6” Query may return: “ColorBarsMaxCh1Val6 0” 3- 155 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 360 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val7” Query may return: “ColorBarsMaxCh1Val7 0” 3- 156 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 361 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsMaxCh1Val8” Query may return: “ColorBarsMaxCh1Val8 0” 3- 157 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 362 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1” Query may return: “ColorBarsMinCh1 700 700 700 700 0 0 0 0” 3- 158 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 363 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val1” Query may return: “ColorBarsMinCh1Val1 700” 3- 159 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 364 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val2” Query may return: “ColorBarsMinCh1Val2 700” 3- 160 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 365 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val3” Query may return: “ColorBarsMinCh1Val3 700” 3- 161 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 366 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val4” Query may return: “ColorBarsMinCh1Val4 700” 3- 162 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 367 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val5” Query may return: “ColorBarsMinCh1Val5 0” 3- 163 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 368 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val6” Query may return: “ColorBarsMinCh1Val6 0” 3- 164 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 369 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val7” Query may return: “ColorBarsMinCh1Val7 0” 3- 165 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 370 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsMinCh1Val8” Query may return: “ColorBarsMinCh1Val8 0” 3- 166 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 371 Return value Query returns the currently assigned ending line number used to perform the Color Bars measurement on multiple lines. Examples VARIable:VALue “ColorBarsMultiLineEnd”, “200” VARIable:VALue? “ColorBarsMultiLineEnd” Query may return: “ColorBarsMultiLineEnd 325” 3- 167 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 372 Query returns “0” if the Color Bars measurement on multiple lines is not selected. Query returns “1” if the Color Bars measurement on multiple lines is selected. Examples VARIable:VALue “ColorBarsMultiLineSet”, “ON” VARIable:VALue? “ColorBarsMultiLineSet” Query may return: “ColorBarsMultiLineSet 1” 3- 168 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 373 Return value Query returns the currently assigned starting line number used to perform the Color Bars measurement on multiple lines. Examples VARIable:VALue “ColorBarsMultiLineStart”, “200” VARIable:VALue? “ColorBarsMultiLineStart” Query may return: “ColorBarsMultiLineStart 325” 3- 169 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 374 Examples VARIable:VALue? “ColorBarsPassAll” Query may return: “ColorBarsPassAll 1 0 0 0 1 0 1 1 1 0 0 0 1 0 1 1 1 0 0 0 1 0 1 1” 3- 170 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 375 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1” Query may return: “ColorBarsPassCh1 1 1 1 0 0 1 1 1” 3- 171 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 376 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val1” Query may return: “ColorBarsPassCh1Val1 1” 3- 172 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 377 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val2” Query may return: “ColorBarsPassCh1Val2 1” 3- 173 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 378 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val3” Query may return: “ColorBarsPassCh1Val3 1” 3- 174 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 379 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val4” Query may return: “ColorBarsPassCh1Val4 1” 3- 175 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 380 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val5” Query may return: “ColorBarsPassCh1Val5 1” 3- 176 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 381 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val6” Query may return: “ColorBarsPassCh1Val6 1” 3- 177 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 382 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val7” Query may return: “ColorBarsPassCh1Val7 1” 3- 178 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 383 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsPassCh1Val8” Query may return: “ColorBarsPassCh1Val8 1” 3- 179 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 384 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “ColorBarsRefCh1” Query may return: “ColorBarsRefCh1 700 700 700 700 0 0 0 0” 3- 180 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 385 Reference file on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val1” Query may return: “ColorBarsRefCh1Val1 700” 3- 181 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 386 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val2” Query may return: “ColorBarsRefCh1Val2 700” 3- 182 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 387 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val3” Query may return: “ColorBarsRefCh1Val3 700” 3- 183 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 388 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val4” Query may return: “ColorBarsRefCh1Val4 700” 3- 184 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 389 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val5” Query may return: “ColorBarsRefCh1Val5 0” 3- 185 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 390 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val6” Query may return: “ColorBarsRefCh1Val6 0” 3- 186 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 391 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val7” Query may return: “ColorBarsRefCh1Val7 0” 3- 187 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 392 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRefCh1Val8” Query may return: “ColorBarsRefCh1Val8 0” 3- 188 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 393 The returned values are in millivolts (mV) Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1” Query may return: “ColorBarsRelCh1 700 700 700 700 0 0 0 0” 3- 189 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 394 White color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val1” Query may return: “ColorBarsRelCh1Val1 700” 3- 190 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 395 Yellow color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val2” Query may return: “ColorBarsRelCh1Val2 700” 3- 191 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 396 Cyan color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val3” Query may return: “ColorBarsRelCh1Val3 700” 3- 192 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 397 Green color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val4” Query may return: “ColorBarsRelCh1Val4 700” 3- 193 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 398 Magenta color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val5” Query may return: “ColorBarsRelCh1Val5 0” 3- 194 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 399 Red color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val6” Query may return: “ColorBarsRelCh1Val6 0” 3- 195 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 400 The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val7” Query may return: “ColorBarsRelCh1Val7 0” 3- 196 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 401 Black color bar on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelCh1Val8” Query may return: “ColorBarsRelCh1Val8 0” 3- 197 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 402 The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1” Query may return: “ColorBarsRelPctCh1 97.65 97.65 97.65 97.65 0 0 0 0” 3- 198 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 403 White color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val1” Query may return: “ColorBarsRelPctCh1Val1 97.65” 3- 199 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 404 Yellow color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val2” Query may return: “ColorBarsRelPctCh1Val2 97.65” 3- 200 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 405 Cyan color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val3” Query may return: “ColorBarsRelPctCh1Val3 97.65” 3- 201 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 406 Green color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val4” Query may return: “ColorBarsRelPctCh1Val4 97.65” 3- 202 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 407 Magenta color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val5” Query may return: “ColorBarsRelPctCh1Val5 97.65” 3- 203 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 408 Red color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val6” Query may return: “ColorBarsRelPctCh1Val6 97.65” 3- 204 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 409 Blue color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val7” Query may return: “ColorBarsRelPctCh1Val7 97.65” 3- 205 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 410 Black color bar on the specified channel. The returned value is in percent (%). Returns “- -- -- -- -- -- -” if no valid measurement is currently available. Examples VARIable:VALue? “ColorBarsRelPctCh1Val8” Query may return: “ColorBarsRelPctCh1Val8 97.65” 3- 206 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 411 Query returns “0” if the Color Bars measurement is not selected. Query returns “1” if the Color Bars measurement is selected. Examples VARIable:VALue “ColorBarsSet”, “ON” VARIable:VALue? “ColorBarsSet” Query may return: “ColorBarsSet 1” 3- 207 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 412 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “ColorBarsStatus” Query may return: “ColorBarsStatus Pass” 3- 208 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 413 Valid value is 1. Returns Query returns “OK” unless the command is still being processed, in which case it returns “1”. Examples VARIable:VALue “DefaultSettings”, “1” VARIable:VALue? “DefaultSettings” Query may return: “DefaultSettings OK” 3- 209 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 414 None selects the normal display. Picture places the Picture display on top of all other displays. Returns The display on top of all other displays. Examples VARIable:VALue “Display”, “Picture” VARIable:VALue? “Display” Query may return: “Display None” 3- 210 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 415 Return value Query returns “0” or “1” depending on whether the embed screen capture function is enabled or disabled. Examples VARIable:VALue “EmbedScreenCaptureSet”, “ON” VARIable:VALue? “EmbedScreenCaptureSet” Query may return:“ EmbedScreenCaptureSet 1 ” 3- 211 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 416 OFF is the same as 0, and ON is the same as 1. Return value Query returns 1 if any measurement is currently being executed, otherwise it returns 0. Examples VARIable:VALue “Execute”, “1” VARIable:VALue? “Execute” Query may return: “Execute 1” 3- 212 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 417 Option VGA Remote Commands Format <format> Set or Query the video format to use for measurement. Syntax VARIable:VALue “Format”, “<format>” VARIable:VALue? “Format” Group Configuration Arguments <format>to set the specified format 3- 213 VM5000 Automatic Video Measurement Set Programmer Manual...

  • Page 418: Table 3- 14: Video Format, Refresh Rate, And Timing Standard

    1024x768_85 1024x768_85 1024x768_100 1024x768_100 1024x768_100 1024x768_120 1024x768_120 1024x768_120 1280x1024 1280x1024_60 1280x1024_60 1280x1024_70 1280x1024_75 1280x1024_75 1280x1024_85 1280x1024_85 1280x1024_100 1280x1024_120 1600x1024 1600x1024_60 1600x1024_70 1600x1024_75 1600x1024_76 1600x1024_85 1600x1024_100 1920x1080 1920x1080_50 1920x1080_60 1920x1080_75 1920x1080_85 1920x1080_100 3- 214 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 419 Add a format name and save the new format. For example: 1280x768_60. Return value Query returns the current selected format. Examples VARIable:VALue “Format”, “640x480_60” VARIable:VALue? “Format” Query may return: “640x480_60” 3- 215 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 420 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncAll” Query may return: “HSyncAll Pos 1.015 10.97 91.158 5 5 4.106 4.511 0 0 Yes Yes 3191.7 3000 2820.3 464.8” 3- 216 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 421 Return value Query returns the currently assigned total number of samples the H Sync measurement. Examples VARIable:VALue “HSyncAverage”, “1” VARIable:VALue? “HSyncAverage” Query may return: “HSyncAverage 8” 3- 217 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 422 Query returns the measured fall time value resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncFallTime” Query may return: “HSyncFallTime 7.1” 3- 218 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 423 Query returns the measured frequency value resulting from the H Sync measurement. The returned value is in kilohertz (kHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncFrequency” Query may return: “HSyncFrequency 53.6” 3- 219 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 424 The order is: H Sync Jitter (ns) and H Sync Jitter (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterAll” Query may return: “HSyncJitterAll 2.33 55.49” 3- 220 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 425 Return value Query returns the current value of the number of lines used to perform the H Sync Jitter measurement. Examples VARIable:VALue “HSyncJitterLine”, “200” VARIable:VALue? “HSyncJitterLine” Query may return: “HSyncJitterLine 325” 3- 221 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 426 The order is: H Sync Jitter (ns) and H Sync Jitter (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterMaxAll” Query may return: “HSyncJitterMaxAll 2.33 55.49” 3- 222 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 427 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterMaxPixelClock” Query may return: “HSyncJitterMaxPixelClock 55.49” 3- 223 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 428 Query returns the H Sync Jitter Time period maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterMaxTime” Query may return: “HSyncJitterMaxTime 2.33” 3- 224 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 429 The order is: H Sync Jitter (ns) and H Sync Jitter (%) Pixel Clock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterMinAll” Query may return: “HSyncJitterMinAll 2.33 55.49” 3- 225 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 430 Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterMinPixelClock” Query may return: “HSyncJitterMinPixelClock 55.49” 3- 226 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 431 Query returns the H Sync Jitter Time period minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterMinTime” Query may return: “HSyncJitterMinTime 2.33” 3- 227 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 432 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterPassAll” Query may return: “HSyncJitterPassAll 1 1” 3- 228 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 433 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterPassPixelClock” Query may return: “HSyncJitterPassPixelClock 1” 3- 229 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 434 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterPassTime” Query may return: “HSyncJitterPassTime 1” 3- 230 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 435 Query returns the measured (%) Pixel Clock resulting from the H Sync Jitter measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterPixelClock” Query may return: “HSyncJitterPixelClock 55.49” 3- 231 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 436 The order is: H Sync Jitter (ns) and H Sync Jitter (%) PixelClock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterRefAll” Query may return: “HSyncJitterRefAll 2.33 55.49” 3- 232 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 437 Query returns the H Sync Jitter (%) Pixel Clock reference value specified in the Reference file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterRefPixelClock” Query may return: “HSyncJitterRefPixelClock 55.49” 3- 233 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 438 Query returns the H Sync Jitter Time period reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterRefTime” Query may return: “HSyncJitterRefTime 2.33” 3- 234 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 439 The order is: H Sync Jitter (ns) and H Sync Jitter (%) PixelClock. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterRelAll” Query may return: “HSyncJitterRelAll 2.33 55.49” 3- 235 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 440 Query returns the (%) Pixel Clock relative value resulting from the H Sync Jitter measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterRelPixelClock” Query may return: “HSyncJitterRelPixelClock 55.49” 3- 236 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 441 Query returns the relative Time period resulting from the H Sync Jitter measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterRelTime” Query may return: “HSyncJitterRelTime 2.33” 3- 237 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 442 Query returns “0” if the H Sync Jitter measurement on multiple lines is not selected. Query returns “1” if the H Sync Jitter measurement on multiple lines is selected. Examples VARIable:VALue “HSyncJitterMultiLineSet”,“ON” VARIable:VALue? “HSyncJitterMultiLineSet” Query may return: “HSyncJitterMultiLineSet 1” 3- 238 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 443 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “HSyncJitterStatus” Query may return: “HSyncJitterStatus Pass” 3- 239 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 444 Query returns the measured Time period resulting from the H Sync Jitter measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncJitterTime” Query may return: “HSyncJitterTime 2.33” 3- 240 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 445 Return value Query returns the currently assigned line number used to perform the H Sync measurement. Examples VARIable:VALue “HSyncLine”, “200” VARIable:VALue? “HSyncLine” Query may return: “HSyncLine 325” 3- 241 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 446 Level 0 at 2.21 kΩ termination resistance) resulting from the H Sync measure- ment. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncLogicLevel0Value1” Query may return: “HSyncLogicLevel0Value1 1” 3- 242 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 447 MIU connected) resulting from the H Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncLogicLevel0Value2” Query may return: “HSyncLogicLevel0Value2 1” 3- 243 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 448 Level 1 at 2.21 kΩ termination resistance) resulting from the H Sync measure- ment. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncLogicLevel1Value1” Query may return: “HSyncLogicLevel1Value1 1” 3- 244 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 449 MIU connected) resulting from the H Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncLogicLevel1Value2” Query may return: “HSyncLogicLevel1Value2 1” 3- 245 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 450 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxAll” Query may return: “HSyncMaxAll Pos 1.853 12.949 93.37 5.37 5.37 30.0 30.0 304.8 304.8 Yes Yes 5500 500 5500 500” 3- 246 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 451 Query returns the H Sync Fall Time maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxFallTime” Query may return: “HSyncMaxFallTime 7.1” 3- 247 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 452 Query returns the H Sync Frequency maximum limit value specified in the Limits file. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxFrequency” Query may return: “HSyncMaxFrequency 53674” 3- 248 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 453 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxLogicLevel0Value1” Query may return: “HSyncMaxLogicLevel0Value1 1” 3- 249 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 454 MIU connected) maximum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxLogicLevel0Value2” Query may return: “HSyncMaxLogicLevel0Value2 1” 3- 250 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 455 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxLogicLevel1Value1” Query may return: “HSyncMaxLogicLevel1Value1 1” 3- 251 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 456 MIU connected) maximum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxLogicLevel1Value2” Query may return: “HSyncMaxLogicLevel1Value2 1” 3- 252 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 457 Limits file. The returned value is 1 which is represented by “Yes”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxMonotonicFall” Query may return: “HSyncMaxMonotonicFall Yes” 3- 253 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 458 Query returns the H Sync Monotonic Rise maximum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxMonotonicRise” Query may return: “HSyncMaxMonotonicRise Yes” 3- 254 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 459 Query returns the H Sync Overshoot maximum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxOvershoot” Query may return: “HSyncMaxOvershoot 15” 3- 255 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 460 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxOvershootSettlingTime” Query may return: “HSyncMaxOvershootSettlingTime 7.1” 3- 256 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 461 Query returns the H Sync Polarity maximum limit value specified in the Limits file. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxPolarity” Query may return: “HSyncMaxPolarity Pos” 3- 257 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 462 Query returns the H Sync Pulse Width maximum limit value specified in the Limits file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxPulseWidth” Query may return: “HSyncMaxPulseWidth 1.13” 3- 258 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 463 Query returns the H Sync Rise Time maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxRiseTime” Query may return: “HSyncMaxRiseTime 7.1” 3- 259 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 464 Query returns the H Sync Sync Period maximum limit value specified in the Limits file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxSyncPeriod” Query may return: “HSyncMaxSyncPeriod 18.63” 3- 260 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 465 Query returns the H Sync Undershoot maximum limit value specified in the Limits file. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxUndershoot” Query may return: “HSyncMaxUndershoot 15” 3- 261 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 466 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMaxUndershootSettlingTime” Query may return: “HSyncMaxUndershootSettlingTime 7.1” 3- 262 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 467 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinAll” Query may return: “HSyncMinAll Neg 0.0 8.9 89.37 0.35 0.35 0.0 0.0 0.0 0.0 Yes Yes 2400 0 2400 0” 3- 263 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 468 Query returns the H Sync Fall Time minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinFallTime” Query may return: “HSyncMinFallTime 7.1” 3- 264 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 469 Query returns the H Sync Frequency minimum limit value specified in the Limits file. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinFrequency” Query may return: “HSyncMinFrequency 53674” 3- 265 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 470 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinLogicLevel0Value1” Query may return: “HSyncMinLogicLevel0Value1 1” 3- 266 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 471 MIU connected) minimum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinLogicLevel0Value2” Query may return: “HSyncMinLogicLevel0Value2 1” 3- 267 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 472 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinLogicLevel1Value1” Query may return: “HSyncMinLogicLevel1Value1 1” 3- 268 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 473 MIU connected) minimum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinLogicLevel1Value2” Query may return: “HSyncMinLogicLevel1Value2 1” 3- 269 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 474 Query returns the H Sync Monotonic Fall minimum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinMonotonicFall” Query may return: “HSyncMinMonotonicFall Yes” 3- 270 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 475 Query returns the H Sync Monotonic Rise minimum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinMonotonicRise” Query may return: “HSyncMinMonotonicRise Yes” 3- 271 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 476 Query returns the H Sync Overshoot minimum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinOvershoot” Query may return: “HSyncMinOvershoot 15” 3- 272 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 477 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinOvershootSettlingTime” Query may return: “HSyncMinOvershootSettlingTime 7.1” 3- 273 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 478 Query returns the H Sync Polarity minimum limit value specified in the Limits file. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinPolarity” Query may return: “HSyncMinPolarity Pos” 3- 274 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 479 Query returns the H Sync Pulse Width minimum limit value specified in the Limits file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinPulseWidth” Query may return: “HSyncMinPulseWidth 1.13” 3- 275 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 480 Query returns the H Sync Rise Time minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinRiseTime” Query may return: “HSyncMinRiseTime 7.1” 3- 276 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 481 Query returns the H Sync Sync Period minimum limit value specified in the Limits file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinSyncPeriod” Query may return: “HSyncMinSyncPeriod 18.63” 3- 277 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 482 Query returns the H Sync Undershoot minimum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinUndershoot” Query may return: “HSyncMinUndershoot 15” 3- 278 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 483 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMinUndershootSettlingTime” Query may return: “HSyncMinUndershootSettlingTime 7.1” 3- 279 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 484 Query returns the measured Monotonic Fall value resulting from the H Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMonotonicFall” Query may return: “HSyncMonotonicFall 1” 3- 280 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 485 Query returns the measured Monotonic Rise value resulting from the H Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncMonotonicRise” Query may return: “HSyncMonotonicRise Yes” 3- 281 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 486 Return value Query returns the currently assigned ending line number used to perform the H Sync measurement on multiple lines. Examples VARIable:VALue “HSyncMultiLineEnd”, “200” VARIable:VALue? “HSyncMultiLineEnd” Query may return: “HSyncMultiLineEnd 325” 3- 282 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 487 Query returns “0” if the H Sync measurement on multiple lines is not selected. Query returns “1” if the H Sync measurement on multiple lines is selected. Examples VARIable:VALue “HSyncMultiLineSet”, “ON” VARIable:VALue? “HSyncMultiLineSet” Query may return: “HSyncMultiLineSet 1” 3- 283 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 488 Return value Query returns the currently assigned starting line number used to perform the H Sync measurement on multiple lines. Examples VARIable:VALue “HSyncMultiLineStart”, “200” VARIable:VALue? “HSyncMultiLineStart” Query may return: “HSyncMultiLineStart 325” 3- 284 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 489 Query returns the measured Overshoot value resulting from the H Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncOvershoot” Query may return: “HSyncOvershoot 15” 3- 285 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 490 Query returns the measured Overshoot Settling Time value resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncOvershootSettlingTime” Query may return: “HSyncOvershootSettlingTime 7.1” 3- 286 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 491 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassAll” Query may return: “HSyncPassAll 1 1 1 0 0 0 1 0 0 1 1 1 0 1” 3- 287 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 492 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassFallTime” Query may return: “HSyncPassFallTime 1” 3- 288 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 493 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassFrequency” Query may return: “HSyncPassFrequency 1” 3- 289 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 494 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassLogicLevel0Value1” Query may return: “HSyncPassLogicLevel0Value1 1” 3- 290 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 495 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassLogicLevel0Value2” Query may return: “HSyncPassLogicLevel0Value2 1” 3- 291 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 496 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassLogicLevel1Value1” Query may return: “HSyncPassLogicLevel1Value1 Pos” 3- 292 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 497 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassLogicLevel1Value2” Query may return: “HSyncPassLogicLevel1Value2 1” 3- 293 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 498 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassMonotonicFall” Query may return: “HSyncPassMonotonicFall 1” 3- 294 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 499 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassMonotonicRise” Query may return: “HSyncPassMonotonicRise 1” 3- 295 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 500 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassOvershoot” Query may return: “HSyncPassOvershoot 1” 3- 296 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 501 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassOvershootSettlingTime” Query may return: “HSyncPassOvershootSettlingTime 1” 3- 297 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 502 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassPolarity” Query may return: “HSyncPassPolarity 1” 3- 298 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 503 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassPulseWidth” Query may return: “HSyncPassPulseWidth 1” 3- 299 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 504 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassRiseTime” Query may return: “HSyncPassRiseTime 1” 3- 300 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 505 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassSyncPeriod” Query may return: “HSyncPassSyncPeriod 1” 3- 301 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 506 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassUndershoot” Query may return: “HSyncPassUndershoot 1” 3- 302 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 507 A returned value of 1 means Pass, a returned value of 0 means Fail Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPassUndershootSettlingTime” Query may return: “HSyncPassUndershootSettlingTime 1” 3- 303 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 508 Query returns the measured Polarity value resulting from the H Sync measurement. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPolarity” Query may return: “HSyncPolarity Pos” 3- 304 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 509 Query returns the measured Pulse Width value resulting from the H Sync measurement. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncPulseWidth” Query may return: “HSyncPulseWidth 1.13” 3- 305 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 510 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefAll” Query may return: “HSyncRefAll Pos 0.85 10.9 91.37 2.5 2.5 0 0 0 0 Yes Yes 3950 0 3950 0” 3- 306 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 511 Query returns the H Sync Fall Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefFallTime” Query may return: “HSyncRefFallTime 7.1” 3- 307 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 512 Query returns the H Sync Frequency reference value specified in the Reference file. The returned value is in kilohertz (kHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefFrequency” Query the may return: “HSyncRefFrequency 53.6” 3- 308 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 513 Logic Level 0 at 2.21 kΩ termination resistance) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefLogicLevel0Value1” Query may return: “HSyncRefLogicLevel0Value1 1” 3- 309 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 514 MIU connected) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefLogicLevel0Value2” Query may return: “HSyncRefLogicLevel0Value2 1” 3- 310 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 515 Logic Level 1 at 2.21 kΩ termination resistance) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefLogicLevel1Value1” Query may return: “HSyncRefLogicLevel1Value1 1” 3- 311 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 516 MIU connected) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefLogicLevel1Value2” Query may return: “HSyncRefLogicLevel1Value2 1” 3- 312 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 517 Query returns the H Sync Monotonic Fall reference value specified in the Reference file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefMonotonicFall” Query may return: “HSyncRefMonotonicFall Yes” 3- 313 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 518 Query returns the H Sync Monotonic Rise reference value specified in the Reference file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefMonotonicRise” Query may return: “HSyncRefMonotonicRise Yes” 3- 314 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 519 Query returns the H Sync Overshoot reference value specified in the Reference file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefOvershoot” Query may return: “HSyncRefOvershoot 15” 3- 315 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 520 Query returns the H Sync Overshoot Settling Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefOvershootSettlingTime” Query may return: “HSyncRefOvershootSettlingTime 7.1” 3- 316 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 521 Query returns the H Sync Polarity reference value specified in the Reference file. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefPolarity” Query may return: “HSyncRefPolarity Pos” 3- 317 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 522 Query returns the H Sync Pulse Width reference value specified in the Reference file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefPulseWidth” Query may return: “HSyncRefPulseWidth 1.13” 3- 318 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 523 Query returns the H Sync Sync Period reference value specified in the Reference file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefSyncPeriod” Query may return: “HSyncRefSyncPeriod 18.63” 3- 319 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 524 Query returns the H Sync Rise Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefRiseTime” Query may return: “HSyncRefRiseTime 7.1” 3- 320 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 525 Query returns the H Sync Undershoot reference value specified in the Reference file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefUndershoot” Query may return: “HSyncRefUndershoot 15” 3- 321 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 526 Query returns the H Sync Undershoot Settling Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRefUndershootSettlingTime” Query may return: “HSyncRefUndershootSettlingTime 7.1” 3- 322 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 527 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”HSyncRelAll” Query may return: ”HSyncRelAll Pos 0.162 0.026 - -0.217 5 5 4.1 4.5 0 0 Yes Yes - -758.29 400 1129.65 464.8” 3- 323 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 528 Query returns the Fall Time relative value resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelFallTime” Query may return: “HSyncRelFallTime 7.1” 3- 324 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 529 Query returns the Frequency relative value resulting from the H Sync measurement. The returned value is in kilohertz (kHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelFrequency” Query may return: “HSyncRelFrequency 53.6” 3- 325 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 530 2.21 kΩ termination resistance) relative value resulting from the H Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelLogicLevel0Value1” Query may return: “HSyncRelLogicLevel0Value1 1” 3- 326 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 531 MIU connected) relative value resulting from the H Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelLogicLevel0Value2” Query may return: “HSyncRelLogicLevel0Value2 1” 3- 327 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 532 2.21 kΩ termination resistance) relative value resulting from the H Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelLogicLevel1Value1” Query may return: “HSyncRelLogicLevel1Value1 1” 3- 328 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 533 MIU connected) relative value resulting from the H Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelLogicLevel1Value2” Query may return: “HSyncRelLogicLevel1Value2 1” 3- 329 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 534 Query returns the Monotonic Fall relative value resulting from the H Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelMonotonicFall” Query may return: “HSyncRelMonotonicFall Yes” 3- 330 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 535 Query returns the Monotonic Rise relative value resulting from the H Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelMonotonicRise” Query may return: “HSyncRelMonotonicRise Yes” 3- 331 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 536 Query returns the Overshoot relative value resulting from the H Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelOvershoot” Query may return: “HSyncRelOvershoot 15” 3- 332 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 537 Query returns the Overshoot Settling Time relative value resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelOvershootSettlingTime” Query may return: “HSyncRelOvershootSettlingTime 7.1” 3- 333 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 538 Query returns the Polarity relative value resulting from the H Sync measurement. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelPolarity” Query may return: “HSyncRelPolarity Pos” 3- 334 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 539 Query returns the Pulse Width relative value resulting from the H Sync measurement. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelPulseWidth” Query may return: “HSyncRelPulseWidth 1.13” 3- 335 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 540 Query returns the Rise Time relative value resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelRiseTime” Query may return: “HSyncRelRiseTime 7.1” 3- 336 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 541 Query returns the Sync Period relative value resulting from the H Sync measurement. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelSyncPeriod” Query may return: “HSyncRelSyncPeriod 18.63” 3- 337 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 542 Query returns the Undershoot relative value resulting from the H Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelUndershoot” Query may return: “HSyncRelUndershoot 15” 3- 338 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 543 Query returns the Undershoot Settling Time relative value resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRelUndershootSettlingTime” Query may return: “HSyncRelUndershootSettlingTime 7.1” 3- 339 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 544 Query returns the measured Rise Time resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncRiseTime” Query may return: “HSyncRiseTime 7.1” 3- 340 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 545 Query returns “0” if the H Sync measurement is not selected. Query returns “1” if the H Sync measurement is selected. Examples VARIable:VALue “HSyncSet”, “ON” VARIable:VALue? “HSyncSet” Query may return: “HSyncSet 1” 3- 341 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 546 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “HSyncStatus” Query may return: “HSyncStatus Pass” 3- 342 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 547 Query returns the measured Sync Period resulting from the H Sync measurement. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncSyncPeriod” Query may return: “HSyncSyncPeriod 18.63” 3- 343 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 548 Query returns the measured Undershoot resulting from the H Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncUndershoot” Query may return: “HSyncUndershoot 15” 3- 344 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 549 Query returns the measured Undershoot Settling Time resulting from the H Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HSyncUndershootSettlingTime” Query may return: “HSyncUndershootSettlingTime 7.1” 3- 345 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 550 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingAll” Query may return: “HTimingAll 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 1.13 56.25” 3- 346 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 551 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingAddressableVideoCh1” Query may return: “HTimingAddressableVideoCh1 14.22” 3- 347 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 552 Return value Query returns the currently assigned total number of samples the H Timing measurement. Examples VARIable:VALue “HTimingAverage”, “1” VARIable:VALue? “HTimingAverage” Query may return: “HTimingAverage 8” 3- 348 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 553 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingBackPorchCh1” Query may return: “HTimingBackPorchCh1 2.70” 3- 349 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 554 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingFrontPorchCh1” Query may return: “HTimingFrontPorchCh1 0.56” 3- 350 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 555 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingLeftBorderCh1” Query may return: “HTimingLeftBorderCh1 0” 3- 351 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 556 Return value Query returns the currently assigned line number used to perform the H Timing measurement. Examples VARIable:VALue “HTimingLine”, “200” VARIable:VALue? “HTimingLine” Query may return: “HTimingLine 325” 3- 352 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 557 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxAll” Query may return: “HTimingMaxAll 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 1.13 56.25” 3- 353 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 558 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxAddressableVideoCh1” Query may return: “HTimingMaxAddressableVideoCh1 14.22” 3- 354 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 559 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxBackPorchCh1” Query may return: “HTimingMaxBackPorchCh1 2.70” 3- 355 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 560 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxFrontPorchCh1” Query may return: “HTimingMaxFrontPorchCh1 0.56” 3- 356 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 561 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxLeftBorderCh1” Query may return: “HTimingMaxLeftBorderCh1 0” 3- 357 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 562 Query returns the H Timing Pixel Clock maximum limit value specified in the Limits file. The returned value is in megahertz (MHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxPixelClock” Query may return: “HTimingMaxPixelClock 56.25” 3- 358 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 563 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxRightBorderCh1” Query may return: “HTimingMaxRightBorderCh1 0” 3- 359 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 564 Query returns the H Timing Sync Pulse Width maximum limit value specified in the Limits file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMaxSyncPulseWidth” Query may return: “HTimingMaxSyncPulseWidth 1.13” 3- 360 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 565 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinAll” Query may return: “HTimingMinAll 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 1.13 56.25” 3- 361 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 566 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinAddressableVideoCh1” Query may return: “HTimingMinAddressableVideoCh1 14.22” 3- 362 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 567 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinBackPorchCh1” Query may return: “HTimingMinBackPorchCh1 2.70” 3- 363 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 568 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinFrontPorchCh1” Query may return: “HTimingMinFrontPorchCh1 0.56” 3- 364 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 569 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinLeftBorderCh1” Query may return: “HTimingMinLeftBorderCh1 0” 3- 365 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 570 Query returns the H Timing Pixel Clock minimum limit value specified in the Limits file. The returned value is in megahertz (MHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinPixelClock” Query may return: “HTimingMinPixelClock 56.25” 3- 366 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 571 Limits file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinRightBorderCh1” Query may return: “HTimingMinRightBorderCh1 0” 3- 367 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 572 Query returns the H Timing Sync Pulse Width minimum limit value specified in the Limits file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingMinSyncPulseWidth” Query may return: “HTimingMinSyncPulseWidth 1.13” 3- 368 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 573 Return value Query returns the currently assigned ending line number used to perform the H Timing measurement on multiple lines. Examples VARIable:VALue “HTimingMultiLineEnd”, “200” VARIable:VALue? “HTimingMultiLineEnd” Query may return: “HTimingMultiLineEnd 325” 3- 369 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 574 Query returns “0” if the H Timing measurement on multiple lines is not selected. Query returns “1” if the H Timing measurement on multiple lines is selected. Examples VARIable:VALue “HTimingMultiLineSet”, “ON” VARIable:VALue? “HTimingMultiLineSet” Query may return: “HTimingMultiLineSet 1” 3- 370 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 575 Return value Query returns the currently assigned starting line number used to perform the H Timing measurement on multiple lines. Examples VARIable:VALue “HTimingMultiLineStart”, “200” VARIable:VALue? “HTimingMultiLineStart” Query may return: “HTimingMultiLineStart 325” 3- 371 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 576 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassAll” Query may return: “HTimingPassAll 1 0 0 0 1 1 1 0 1 0 1 1 1 1 1 1 1” 3- 372 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 577 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassAddressableVideoCh1” Query may return: “HTimingPassAddressableVideoCh1 1” 3- 373 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 578 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassBackPorchCh1” Query may return: “HTimingPassBackPorchCh1 1” 3- 374 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 579 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassFrontPorchCh1” Query may return: “HTimingPassFrontPorchCh1 1” 3- 375 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 580 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassLeftBorderCh1” Query may return: “HTimingPassLeftBorderCh1 1” 3- 376 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 581 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassPixelClock” Query may return: “HTimingPassPixelClock 1” 3- 377 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 582 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassRightBorderCh1” Query may return: “HTimingPassRightBorderCh1 1” 3- 378 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 583 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPassSyncPulseWidth” Query may return: “HTimingPassSyncPulseWidth 1” 3- 379 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 584 Query returns the measured Pixel Clock resulting from the H Timing measurement. The returned value is in megahertz (MHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingPixelClock” Query may return: “HTimingPixelClock 56.25” 3- 380 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 585 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefAll” Query may return: “HTimingRefAll 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 1.13 56.25” 3- 381 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 586 Reference file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefAddressableVideoCh1” Query may return: “HTimingRefAddressableVideoCh1 14.22” 3- 382 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 587 Reference file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefBackPorchCh1” Query may return: “HTimingRefBackPorchCh1 2.70” 3- 383 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 588 Reference file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefFrontPorchCh1” Query may return: “HTimingRefFrontPorchCh1 0.56” 3- 384 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 589 Reference file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefLeftBorderCh1” Query may return: “HTimingRefLeftBorderCh1 0” 3- 385 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 590 Query returns the H Timing Pixel Clock reference value specified in the Reference file. The returned value is in megahertz (MHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefPixelClock” Query may return: “HTimingRefPixelClock 56.25” 3- 386 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 591 Reference file on the specified channel. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefRightBorderCh1” Query may return: “HTimingRefRightBorderCh1 0” 3- 387 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 592 Query returns the H Timing Sync Pulse Width reference value specified in the Reference file. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRefSyncPulseWidth” Query may return: “HTimingRefSyncPulseWidth 1.13” 3- 388 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 593 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelAll” Query may return: “HTimingRelAll 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 2.702 0 14.222 0 0.569 1.13 56.25” 3- 389 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 594 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelAddressableVideoCh1” Query may return: “HTimingRelAddressableVideoCh1 14.22” 3- 390 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 595 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelBackPorchCh1” Query may return: “HTimingRelBackPorchCh1 2.70” 3- 391 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 596 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelFrontPorchCh1” Query may return: “HTimingRelFrontPorchCh1 0.56” 3- 392 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 597 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelLeftBorderCh1” Query may return: “HTimingRelLeftBorderCh1 0” 3- 393 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 598 Query returns the Pixel Clock relative value resulting from the H Timing measurement. The returned value is in megahertz (MHz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelPixelClock” Query may return: “HTimingRelPixelClock 56.25” 3- 394 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 599 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelRightBorderCh1” Query may return: “HTimingRelRightBorderCh1 0” 3- 395 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 600 Query returns the Sync Pulse Width relative value resulting from the H Timing measurement. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRelSyncPulseWidth” Query may return: “HTimingRelSyncPulseWidth 1.13” 3- 396 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 601 The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingRightBorderCh1” Query may return: “HTimingRightBorderCh1 0” 3- 397 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 602 Query returns “0” if the H Timing measurement is not selected. Query returns “1” if the H Timing measurement is selected. Examples VARIable:VALue “HTimingSet”, “ON” VARIable:VALue? “HTimingSet” Query may return: “HTimingSet 1” 3- 398 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 603 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid values are currently available. Examples VARIable:VALue? “HTimingStatus” Query may return: “HTimingStatus Pass” 3- 399 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 604 Query returns the measured Sync Pulse Width resulting from the H Timing measurement. The returned value is in microseconds (μs). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “HTimingSyncPulseWidth” Query may return: “HTimingSyncPulseWidth 1.13” 3- 400 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 605 Option VGA Remote Commands Query the ID/Version of the application. Syntax VARIable:VALue? “ID” Group Global Arguments None Returns Returns the application’s ID. Examples VARIable:VALue? “ID” Query may return: “ID Tek/VM5000PC Version 0.96” 3- 401 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 606 Return value Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “LimitFileLoad”, “C:\VM5000PC\RefLimFiles\DMT\DefaultLimit1024X768@75- -RGB.csv” 3- 402 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 607 Valid values are: OFF, ON, 0, 1. Return value Query returns 0 or 1 depending on whether the LimitSet is enabled or disabled. Examples VARIable:VALue “LimitSet”, “ON” VARIable:VALue? “LimitSet” Query may return:“LimitSet 1 ” 3- 403 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 608 Values must be in the range: 1..64. Return value Query returns the currently assigned total number of samples the Linearity Measurement. Examples VARIable:VALue “LinearityAverage”, “1” VARIable:VALue? “LinearityAverage” Query may return: “LinearityAverage 8” 3- 404 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 609 Query returns the step number at which the Max DNL is measured resulting from the Linearity measurement on the specified channel. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxDNLAtStepNumberCh1” Query may return: “LinearityMaxDNLAtStepNumberCh1 23” 3- 405 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 610 Query returns the measured Max DNL resulting from the Linearity measurement on the specified channel. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxDNLCh1” Query may return: “LinearityMaxDNLCh1 0.0” 3- 406 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 611 Query returns the step number at which the Max INL is measured resulting from the Linearity measurement on the specified channel. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxINLAtStepNumberCh1” Query may return: “LinearityMaxINLAtStepNumberCh1 13” 3- 407 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 612 The returned value is in LSB ( Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxINLCh1” Query may return: “LinearityMaxINLCh1 0.0” 3- 408 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 613 Return value Query returns the currently assigned line number used to perform the Linearity measurement. Examples VARIable:VALue “LinearityLine”, “200” VARIable:VALue? “LinearityLine” Query may return: “LinearityLine 325” 3- 409 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 614 Query returns the Linearity Max DNL maximum limit value specified in the Limits file on the specified channel. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxMaxDNLCh1” Query may return: “LinearityMaxMaxDNLCh1 0.0” 3- 410 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 615 Limits file on the specified channel. The returned value is in LSB (Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxMaxINLCh1” Query may return: “LinearityMaxMaxINLCh1 0.0” 3- 411 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 616 Limits file on the specified channel. The value can be either 1 or 0. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxMonotonicCh1” Query may return: “LinearityMaxMonotonicCh1 1” 3- 412 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 617 The value represents the number of bits of resolution of the input signal. The returned value is in Bits. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMaxResolutionCh1” Query may return: “LinearityMaxResolutionCh1 7” 3- 413 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 618 Limits file on the specified channel. The returned value is in LSB (Least Significant Bit) Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMinMaxDNLCh1” Query may return: “LinearityMinMaxDNLCh1 0.0” 3- 414 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 619 Limits file on the specified channel. The returned value is in LSB (Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMinMaxINLCh1” Query may return: “LinearityMinMaxINLCh1 0.0” 3- 415 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 620 Limits file on the specified channel. The value can be either 1 or 0. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMinMonotonicCh1” Query may return: “LinearityMinMonotonicCh1 1” 3- 416 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 621 The value represents the number of bits of resolution of the input signal. The returned value is in Bits. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMinResolutionCh1” Query may return: “LinearityMinResolutionCh1 7” 3- 417 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 622 Linearity measurement on the specified channel. The value can be either 1 or 0. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMonotonicAtStepNumberCh1” Query may return: “LinearityMonotonicAtStepNumberCh1 1” 3- 418 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 623 The value can be either 1 or 0. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityMonotonicCh1” Query may return: “LinearityMonotonicCh1 1” 3- 419 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 624 Return value Query returns the currently assigned ending line number used to perform the Linearity measurement on multiple lines. Examples VARIable:VALue “LinearityMultiLineEnd”, “200” VARIable:VALue? “LinearityMultiLineEnd” Query may return: “LinearityMultiLineEnd 325” 3- 420 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 625 Return value Query returns “0” if the Linearity measurement is not selected. Query returns “1” if the Linearity measurement is selected. Examples VARIable:VALue “LinearityMultiLineSet”, “ON” VARIable:VALue? “LinearityMultiLineSet” Query may return: “LinearityMultiLineSet 1” 3- 421 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 626 Return value Query returns the currently assigned starting line number used to perform the Linearity measurement on multiple lines. Examples VARIable:VALue “LinearityMultiLineStart”, “200” VARIable:VALue? “LinearityMultiLineStart” Query may return: “LinearityMultiLineStart 325” 3- 422 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 627 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityPassAll” Query may return: “LinearityPassAll 1 0 1 1 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1” 3- 423 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 628 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityPassMaxDNLCh1” Query may return: “LinearityPassMaxDNLCh1 1” 3- 424 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 629 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityPassMaxINLCh1” Query may return: “LinearityPassMaxINLCh1 1” 3- 425 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 630 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityPassMonotonicCh1” Query may return: “LinearityPassMonotonicCh1 1” 3- 426 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 631 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityPassResolutionCh1” Query may return: “LinearityPassResolutionCh1 1” 3- 427 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 632 The returned value is in LSB (Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRefMaxDNLCh1” Query may return: “LinearityRefMaxDNLCh1 0.0” 3- 428 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 633 The returned value is in LSB (Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRefMaxINLCh1” Query may return: “LinearityRefMaxINLCh1 0.0” 3- 429 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 634 The value can be either 1 or 0. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRefMonotonicCh1” Query may return: “LinearityRefMonotonicCh1 1” 3- 430 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 635 The value represents the number of bits of resolution of the input signal. The returned value is in Bits. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRefResolutionCh1” Query may return: “LinearityRefResolutionCh1 7” 3- 431 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 636 The returned value is in LSB (Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRelMaxDNLCh1” Query may return: “LinearityRelMaxDNLCh1 0.0” 3- 432 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 637 The returned value is in LSB (Least Significant Bit). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRelMaxINLCh1” Query may return: “LinearityRelMaxINLCh1 0.0” 3- 433 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 638 The returned value can be either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRelMonotonicCh1” Query may return: “LinearityRelMonotonicCh1 Yes” 3- 434 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 639 The returned value is in bits. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityRelResolutionCh1” Query may return: “LinearityRelResolutionCh1 7” 3- 435 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 640 Query returns the measured Resolution resulting from the Linearity measurement on the specified channel. The returned value is in Bits. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LinearityResolutionCh1” Query may return: “LinearityResolutionCh1 7” 3- 436 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 641 Return value Query returns “0” if the Linearity measurement is not selected. Query returns “1” if the Linearity measurement is selected. Examples VARIable:VALue “LinearitySet”, “ON” VARIable:VALue? “LinearitySet” Query may return: “LinearitySet 1” 3- 437 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 642 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “LinearityStatus” Query may return: “LinearityStatus Pass” 3- 438 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 643 Valid values are: OFF, ON, 0, 1. Return value Query returns 0 or 1 depending on whether the LogErrors is enabled or disabled. Examples VARIable:VALue “LogErrors”, “ON” VARIable:VALue? “LogErrors” Query may return: “LogErrors 1 ” 3- 439 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 644 Return value Query returns the currently assigned total number of samples resulting from the Linearity measurement. Examples VARIable:VALue “LumaLevelsAverage”, “1” VARIable:VALue? “LumaLevelsAverage” Query may return: “LumaLevelsAverage 8” 3- 440 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 645 The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsAll” Query may return: “LumaLevelsAll 699.32 119.33 699.32 119.33 699.32 119.33” 3- 441 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 646 Luma Levels measurement on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsAmpMaxCh1” Query may return: “LumaLevelsAmpMaxCh1 699.32” 3- 442 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 647 Luma Levels measurement on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsAmpMinCh1” Query may return: “LumaLevelsAmpMinCh1 119.33” 3- 443 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 648 Return value Query returns the currently assigned line number used to perform the Luma Levels measurement. Examples VARIable:VALue “LumaLevelsLine”, “200” VARIable:VALue? “LumaLevelsLine” Query may return: “LumaLevelsLine 325” 3- 444 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 649 The order is: Max (Ch1), Min (Ch1), Max (Ch2), Min (Ch2), Max (Ch3), and Min (Ch3). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsMaxAll” Query may return: “LumaLevelsMaxAll 699.32 119.33 699.32 119.33 699.32 119.33” 3- 445 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 650 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsMaxAmpMaxCh1” Query may return: “LumaLevelsMaxAmpMaxCh1 699.32” 3- 446 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 651 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsMaxAmpMinCh1” Query may return: “LumaLevelsMaxAmpMinCh1 119.33” 3- 447 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 652 The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsMinAll” Query may return: “LumaLevelsMinAll 699.32 119.33 699.32 119.33 699.32 119.33” 3- 448 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 653 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsMinAmpMaxCh1” Query may return: “LumaLevelsMinAmpMaxCh1 699.32” 3- 449 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 654 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsMinAmpMinCh1” Query may return: “LumaLevelsMinAmpMinCh1 119.33” 3- 450 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 655 Return value Query returns the currently assigned ending line number used to perform the Luma Levels measurement on multiple lines. Examples VARIable:VALue “LumaLevelsMultiLineEnd”, “200” VARIable:VALue? “LumaLevelsMultiLineEnd” Query may return: “LumaLevelsMultiLineEnd 325” 3- 451 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 656 Query returns “0” if the Luma Levels measurement is not selected. Query returns “1” if the Luma Levels measurement is selected. Examples VARIable:VALue “LumaLevelsMultiLineSet”, “ON” VARIable:VALue? “LumaLevelsMultiLineSet” Query may return: “LumaLevelsMultiLineSet 1” 3- 452 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 657 Return value Query returns the currently assigned starting line number used to perform the Luma Levels measurement on multiple lines. Examples VARIable:VALue “LumaLevelsMultiLineStart”, “200” VARIable:VALue? “LumaLevelsMultiLineStart” Query may return: “LumaLevelsMultiLineStart 325” 3- 453 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 658 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsPassAll” Query may return: “LumaLevelsPassAll 1 1 1 0 1 1” 3- 454 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 659 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsPassAmpMaxCh1” Query may return: “LumaLevelsPassAmpMaxCh1 0” 3- 455 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 660 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsPassAmpMinCh1” Query may return: “LumaLevelsPassAmpMinCh1 1” 3- 456 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 661 The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsRefAll” Query may return: “LumaLevelsRefAll 699.32 119.33 699.32 119.33 699.32 119.33” 3- 457 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 662 Reference on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsRefAmpMaxCh1” Query may return: “LumaLevelsRefAmpMaxCh1 699.32” 3- 458 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 663 Reference on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsRefAmpMinCh1” Query may return: “LumaLevelsRefAmpMinCh1 119.33” 3- 459 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 664 The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”LumaLevelsRelAll” Query may return: ”LumaLevelsRelAll 699.32 119.33 699.32 119.33 699.32 119.33” 3- 460 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 665 Luma Levels measurement on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”LumaLevelsRelAmpMaxCh1” Query may return: ”LumaLevelsRelAmpMaxCh1 699.32” 3- 461 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 666 Luma Levels measurement on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”LumaLevelsRelAmpMinCh1” Query may return: ”LumaLevelsRelAmpMinCh1 119.33” 3- 462 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 667 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsRelPctAll” Query may return: “LumaLevelsRelPctAll 99.32 19.33 99.32 19.33 99.32 19.33” 3- 463 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 668 Luma Levels measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsRelPctAmpMaxCh1” Query may return: “LumaLevelsRelPctAmpMaxCh1 99.32” 3- 464 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 669 Luma Levels measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “LumaLevelsRelPctAmpMinCh1” Query may return: “LumaLevelsRelPctAmpMinCh1 19.33” 3- 465 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 670 Query returns “0” if the Luma Levels measurement is not selected. Query returns “1” if the Luma Levels measurement is selected. Examples VARIable:VALue “LumaLevelsSet”, “ON” VARIable:VALue? “LumaLevelsSet” Query may return: “LumaLevelsSet 1” 3- 466 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 671 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “LumaLevelsStatus” Query may return: “LumaLevelsStatus Pass” 3- 467 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 672 <setting> specifies whether to enable the 500 MHz filter for performing the Noise measurement. Valid values are: 0, 1, ON, OFF. Return value Query returns the current specified setting. Examples VARIable:VALue “Noise500MHzFilterSet”, “OFF” VARIable:VALue? “Noise500MHzFilterSet” Query may return: “Noise500MHzFilterSet 1” 3- 468 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 673 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseAll” Query may return: “NoiseAll - -65 17.5 2.5 - -65 17.5 2.5 - -65 17.5 2.5” 3- 469 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 674 Return value Query returns the currently assigned total number of samples for the Noise Inj Ratio measurement. Examples VARIable:VALue “NoiseAverage”, “1” VARIable:VALue? “NoiseAverage” Query may return: “NoiseAverage 8” 3- 470 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 675 Noise Inj Ratio measurement on the specified channel. The returned value is in decibels (dB). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoisedBCh1” Query may return: “NoisedBCh1 17.5” 3- 471 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 676 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseIrCh1” Query may return: “NoiseIrCh1 2.5” 3- 472 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 677 Return value Query returns the currently assigned line number for the Noise Inj Ratio measurement. Examples VARIable:VALue “NoiseLine”, “200” VARIable:VALue? “NoiseLine” Query may return: “NoiseLine 325” 3- 473 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 678 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMaxAll” Query may return: “NoiseMaxAll - -65 17.5 2.5 - -65 17.5 2.5 - -65 17.5 2.5” 3- 474 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 679 Limits file on the specified channel. The returned value is in decibels (dB). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMaxdBCh1” Query may return: “NoiseMaxdBCh1 17.5” 3- 475 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 680 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMaxIrCh1” Query may return: “NoiseMaxIrCh1 2.5” 3- 476 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 681 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMaxmVCh1” Query may return: “NoiseMaxmVCh1 - -65” 3- 477 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 682 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMinAll” Query may return: “NoiseMinAll - -65 17.5 2.5 - -65 17.5 2.5 - -65 17.5 2.5” 3- 478 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 683 Limits file on the specified channel. The returned value is in decibels (dB). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMindBCh1” Query may return: “NoiseMindBCh1 17.5” 3- 479 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 684 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMinIrCh1” Query may return: “NoiseMinIrCh1 2.5” 3- 480 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 685 Limits file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseMinmVCh1” Query may return: “NoiseMinmVCh1 - -65” 3- 481 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 686 Noise Inj Ratio measurement on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoisemVCh1” Query may return: “NoisemVCh1 - -65” 3- 482 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 687 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoisePassAll” Query may return: “NoisePassAll 1 1 1 0 0 1 0 1 0” 3- 483 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 688 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoisePassdBCh1” Query may return: “NoisePassdBCh1 1” 3- 484 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 689 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoisePassIrCh1” Query may return: “NoisePassIrCh1 1” 3- 485 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 690 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoisePassmVCh1” Query may return: “NoisePassmVCh1 1” 3- 486 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 691 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRefAll” Query may return: “NoiseRefAll - -65 17.5 2.5 - -65 17.5 2.5 - -65 17.5 2.5” 3- 487 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 692 Reference file on the specified channel. The returned value is in decibels (dB). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRefdBCh1” Query may return: “NoiseRefdBCh1 17.5” 3- 488 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 693 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRefIrCh1” Query may return: “NoiseRefIrCh1 2.5” 3- 489 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 694 Reference file on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRefmVCh1” Query may return: “NoiseRefmVCh1 - -65” 3- 490 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 695 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRelAll” Query may return: “NoiseRelAll - -65 17.5 2.5 - -65 17.5 2.5 - -65 17.5 2.5” 3- 491 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 696 Query returns the Noise Inj Ratio (in dB) relative value resulting from the Noise Inj Ratio measurement on the specified channel. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseReldBCh1” Query may return: “NoiseReldBCh1 17.5” 3- 492 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 697 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRelIrCh1” Query may return: “NoiseRelIrCh1 2.5” 3- 493 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 698 Inj Ratio measurement on the specified channel. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseRelmVCh1” Query may return: “NoiseRelmVCh1 - -65” 3- 494 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 699 Query returns “0” if the Noise Inj Ratio measurement is not selected. Query returns “1” if the Noise Inj Ratio measurement is selected. Examples VARIable:VALue “NoiseSet”, “ON” VARIable:VALue? “NoiseSet” Query may return: “NoiseSet 1” 3- 495 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 700 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “NoiseStatus” Query may return: “NoiseStatus Pass” 3- 496 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 701 Valid values are: OFF, 0. Returns Query returns “1” if a command has been completed since OPComplete was last reset, otherwise it returns “0”. Examples VARIable:VALue “OPComplete”,“OFF” VARIable:VALue? “OPComplete” Query may return: “OPComplete 1” 3- 497 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 702 <setting> specifies whether or not to display pop- -up warnings. Valid values are: OFF, ON, 0, 1. Return value Returns setting for whether or not warnings are displayed. Examples VARIable:VALue “PopupWarnings”, “OFF” VARIable:VALue? “PopupWarnings” Query may return:“PopupWarnings 1” 3- 498 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 703 Returns Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “RecallSettings”, “C:\VM5000PC\Tek1.vmset” VARIable:VALue? “RecallSettings” Query may return: “RecallSettings OK” 3- 499 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 704 Can either be the full path and filename with extension, or just the filename with extension. Return value Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “ReferenceFileLoad” “C:\VM5000PC\RefLimFiles\DMT\DefaultReference1024X768@75- -RGB.csv” 3- 500 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 705 <filestring> path/filename with extension where file is to be stored. Can either be the full path and filename with extension, or just the filename with extension. Return value Returns OK after the file is written. Examples VARIable:VALue “ReferenceFileSave” “C:\VM5000PC\RefLimFiles\DMT\New_DefaultRefer- ence1024X768@75- -RGB.csv” 3- 501 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 706 Valid values are: OFF, ON, 0, 1. Return value Query returns 0 or 1 depending on whether Reference Testing is selected. Examples VARIable:VALue “ReferenceSet”, “ON” VARIable:VALue? “ReferenceSet” Query may return: “ReferenceSet 1” 3- 502 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 707 Group Reporting Arguments Valid values for <setting> are: “PDF”, “RTF”, “CSV” Returns The file type used by the ReportGenerate command. Examples VARIable:VALue “ReportFormatType”, “PDF” VARIable:VALue? “ReportFormatType” Query may return: “ReportFormatType PDF” 3- 503 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 708 Returns Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “ReportGenerate”, “C:\colorbars.csv” VARIable:VALue? “ReportGenerate” Query may return: “ReportGenerate OK” 3- 504 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 709 ChChSkewSet ColorBarsSet HSyncSet HSyncJitterSet HTimingSet LinearitySet LumaLevelsSet NoiseSet VSyncSet VTimingSet VideoTransientSet Returns Query returns the current specified report measurement mode. Examples VARIable:VALue “ReportMeasurements”, “All” VARIable:VALue? “ReportMeasurements” Query may return: “ReportMeasurements Selected” 3- 505 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 710 All other printable characters are permitted. Returns Query returns the currently specified report string. Examples VARIable:VALue “ReportString”, “Tested by Me” VARIable:VALue? “ReportString” Query may return: “ReportString Tested by Me” 3- 506 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 711 When you select Multi Lines, “Once” and “Continuously” are not available. Return value Query returns the currently specified run mode. Examples VARIable:VALue “RunMode”, “Once” VARIable:VALue? “RunMode” Query may return: “RunMode Continuously” 3- 507 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 712 Returns Query returns “OK” unless the command is still being processed, in which case it returns the current pathstring argument. Examples VARIable:VALue “SaveSettings”, “C:\VM5000PC\Tek1.vmset” VARIable:VALue? “SaveSettings” Query may return: “SaveSettings OK” 3- 508 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 713 <linemode> specifies if the measurements are done on a single line or multiple lines. Valid line modes are: “SingleLine”, “MultiLine” Return value Query returns the currently selected line mode. Examples VARIable:VALue “SelectLine”, “MultiLine” VARIable:VALue? “SelectLine” Query may return: “SelectLine MultiLine” 3- 509 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 714 When you select Multi Lines, SetupOnly and RunOnly are not available. Return value Query returns the current specified setup mode. Examples VARIable:VALue “SetupAndOrRun”, “SetupOnly” VARIable:VALue? “SetupAndOrRun” Query may return: “SetupAndOrRun SetupOnly” 3- 510 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 715 <setting> specifies whether or not to stop testing if limits are exceeded. Valid values are: OFF, ON, 0, 1. Return value Returns setting for whether or not the VM5000 will stop testing on an error. Examples VARIable:VALue “StopOnError”, “OFF” VARIable:VALue? “StopOnError”...
  • Page 716 In the absence of the MIU and with Auto Detect selected, the VM5000 will prompt you to connect the H and V Sync signals to automatically determine the polarities. If you use the MIU, the VM5000 will automatically determine the H and V Sync polarities.
  • Page 717 <TimingStandard> specifies the timing standard used for performing the measurement. The valid/supported timing standards are: DMT, CVT, CVTR and GTF. Return value Query returns the currently configured timing standard. Examples VARIable:VALue ”TimingStandardType”,”CVTR” VARIable:VALue? ”TimingStandardType” Query may return: ”TimingStandardType DMT” 3- 513 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 718 > Set or query, if the hardware accessory ”RGBHV MIU” is connected, the VM5000 runs tests in an automatic mode that does not require user intervention. If the RGBHV MIU is not connected, the user must make manual connection changes when prompted by the VM5000.
  • Page 719 VARIable:VALue “UserFormatDelete”,“<user- -format- -name>” Group Configuration Arguments < user- -format- -name > is a string corresponding to the name of a user- -defined format. Return value None Examples VARIable:VALue “UserFormatDelete”, “myTekUserCustomFormat” 3- 515 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 720 The following command will display the details, if a user- -format named as “myCustomFormat” has been selected. VARIable:VALue? “UserFormatDisplay” Query may return: VARIable:VALue “UserFormatDisplay myCustomFormat 2000 700 300 0 200 1500 70 60 0 4 86 Pos Neg” 3- 516 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 721 Query returns a list of the names of the currently available user- -defined format. The individual names are separated/delimited by a space (“ ”) character. E.g. “user1 user2 user3” Examples VARIable:VALue? “UserFormatListAll” Query may return: “UserFormatListAll myCustomFormat1 myCustomFormat2 myCustomFormat3” 3- 517 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 722 <H- -Sync Polarity> The valid values can be: “Pos” for positive H- -Sync polarity and “Neg”for negative H- -Sync polarity. <V- -Sync Polarity> The valid values can be: “Pos” for positive V- -Sync polarity and “Neg”for negative V- -Sync polarity. 3- 518 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 723 Return value None Examples The following command will create a new user- -defined format named as “myCustomFormat”. VARIable:VALue “UserFormatSave”,“myCustomFormat 2000 700 300 0 200 1500 70 60 0 4 86 Pos Neg” 3- 519 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 724 < user- -format- -name > must be a string corresponding to the name of a user- -defined format already present on the instrument. Return value Query returns the currently selected user- -defined format. Examples VARIable:VALue “UserFormatSet”, “myTekUserCustomFormat” VARIable:VALue? “UserFormatSet” Query may return: “UserFormatSet myTekUserCustomFormat” 3- 520 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 725 Return value Query returns the currently assigned total number of samples for the Video Transient measurement. Examples VARIable:VALue “VideoTransientAverage”, “1” VARIable:VALue? “VideoTransientAverage” Query may return: “VideoTransientAverage 8” 3- 521 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 726 Return value Query returns the currently assigned line number resulting from the Video Transient measurement. Examples VARIable:VALue “VideoTransientLine”, “200” VARIable:VALue? “VideoTransientLine” Query may return: “VideoTransientLine 325” 3- 522 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 727 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxOvershootCh1” Query may return: “VideoTransientMaxOvershootCh1 1.06” 3- 523 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 728 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxOvershootSettlingTimeCh1” Query may return: “VideoTransientMaxOvershootSettlingTimeCh1 2.66” 3- 524 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 729 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxUndershootCh1” Query may return: “VideoTransientMaxUndershootCh1 1.06” 3- 525 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 730 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxUndershootSettlingTimeCh1” Query may return: “VideoTransientMaxUndershootSettlingTimeCh1 2.66” 3- 526 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 731 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxVideoFallTimeCh1” Query may return: “VideoTransientMaxVideoFallTimeCh1 1.77” 3- 527 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 732 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxVideoFallTimePercentageCh1” Query may return: “VideoTransientMaxVideoFallTimePercentageCh1 1.77” 3- 528 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 733 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxVideoRiseTimeCh1” Query may return: “VideoTransientMaxVideoRiseTimeCh1 1.77” 3- 529 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 734 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMaxVideoRiseTimePercentageCh1” Query may return: “VideoTransientMaxVideoRiseTimePercentageCh1 1.77” 3- 530 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 735 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinOvershootCh1” Query may return: “VideoTransientMinOvershootCh1 1.06” 3- 531 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 736 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinOvershootSettlingTimeCh1” Query may return: “VideoTransientMinOvershootSettlingTimeCh1 2.66” 3- 532 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 737 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinUndershootCh1” Query may return: “VideoTransientMinUndershootCh1 1.06” 3- 533 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 738 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinUndershootSettlingTimeCh1” Query may return: “VideoTransientMinUndershootSettlingTimeCh1 2.66” 3- 534 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 739 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinVideoFallTimeCh1” Query may return: “VideoTransientMinVideoFallTimeCh1 1.77” 3- 535 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 740 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinVideoFallTimePercentageCh1” Query the may return: “VideoTransientMinVideoFallTimePercentageCh1 1.77” 3- 536 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 741 Limits file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinVideoRiseTimeCh1” Query may return: “VideoTransientMinVideoRiseTimeCh1 1.77” 3- 537 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 742 Limits file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientMinVideoRiseTimePercentageCh1” Query may return: “VideoTransientMinVideoRiseTimePercentageCh1 1.77” 3- 538 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 743 Return value Query returns the currently assigned ending line number used to perform the Video Transient measurement on multiple lines. Examples VARIable:VALue “VideoTransientMultiLineEnd”, “200” VARIable:VALue? “VideoTransientMultiLineEnd” Query may return: “VideoTransientMultiLineEnd 325” 3- 539 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 744 Query returns “0” if the Video Transient measurement is not selected. Query returns “1” if the Video Transient measurement is selected. Examples VARIable:VALue “VideoTransientMultiLineSet”, “ON” VARIable:VALue? “VideoTransientMultiLineSet” Query may return: “VideoTransientMultiLineSet 1” 3- 540 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 745 Return value Query returns the currently assigned starting line number used to perform the Video Transient measurement on multiple lines. Examples VARIable:VALue “VideoTransientMultiLineStart”, “200” VARIable:VALue? “VideoTransientMultiLineStart” Query may return: “VideoTransientMultiLineStart 325” 3- 541 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 746 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientOvershootCh1” Query may return: “VideoTransientOvershootCh1 1.06” 3- 542 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 747 Video Transient measurement on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientOvershootSettlingTimeCh1” Query may return: “VideoTransientOvershootSettlingTimeCh1 2.66” 3- 543 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 748 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassAll” Query may return: “VideoTransientPassAll 1 1 1 0 0 1 0 1 0 1 0 1 1 1 1 0 1 0” 3- 544 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 749 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassOvershootCh1” Query may return: “VideoTransientPassOvershootCh1 1” 3- 545 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 750 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassOvershootSettlingTimeCh1” Query may return: “VideoTransientPassOvershootSettlingTimeCh1 1” 3- 546 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 751 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassUndershootCh1” Query may return: “VideoTransientPassUndershootCh1 1” 3- 547 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 752 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassUndershootSettlingTimeCh1” Query may return: “VideoTransientPassUndershootSettlingTimeCh1 1” 3- 548 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 753 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassVideoFallTimeCh1” Query may return: “VideoTransientPassVideoFallTimeCh1 1” 3- 549 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 754 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassVideoFallTimePercentageCh1” Query may return: “VideoTransientPassVideoFallTimePercentageCh1 1” 3- 550 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 755 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassVideoRiseTimeCh1” Query may return: “VideoTransientPassVideoRiseTimeCh1 1” 3- 551 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 756 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientPassVideoRiseTimePercentageCh1” Query may return: “VideoTransientPassVideoRiseTimePercentageCh1 1” 3- 552 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 757 Reference file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefOvershootCh1” Query may return: “VideoTransientRefOvershootCh1 1.06” 3- 553 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 758 Reference file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefOvershootSettlingTimeCh1” Query may return: “VideoTransientRefOvershootSettlingTimeCh1 2.66” 3- 554 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 759 Reference file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefUndershootCh1” Query may return: “VideoTransientRefUndershootCh1 1.06” 3- 555 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 760 Reference file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefUndershootSettlingTimeCh1” Query may return: “VideoTransientRefUndershootSettlingTimeCh1 2.66” 3- 556 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 761 Reference file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefVideoFallTimeCh1” Query may return: “VideoTransientRefVideoFallTimeCh1 1.77” 3- 557 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 762 Reference file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefVideoFallTimePercentageCh1” Query may return: “VideoTransientRefVideoFallTimePercentageCh1 1.77” 3- 558 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 763 Reference file on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefVideoRiseTimeCh1” Query may return: “VideoTransientRefVideoRiseTimeCh1 1.77” 3- 559 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 764 Reference file on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRefVideoRiseTimePercentageCh1” Query may return: “VideoTransientRefVideoRiseTimePercentageCh1 1.77” 3- 560 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 765 Video Transient measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelOvershootCh1” Query may return: “VideoTransientRelOvershootCh1 1.06” 3- 561 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 766 Video Transient measurement on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelOvershootSettlingTimeCh1” Query may return: “VideoTransientRelOvershootSettlingTimeCh1 2.66” 3- 562 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 767 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelUndershootCh1” Query may return: “VideoTransientRelUndershootCh1 1.06” 3- 563 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 768 Video Transient measurement on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelUndershootSettlingTimeCh1” Query may return: “VideoTransientRelUndershootSettlingTimeCh1 2.66” 3- 564 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 769 Video Transient measurement on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelVideoFallTimeCh1” Query may return: “VideoTransientRelVideoFallTimeCh1 1.77” 3- 565 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 770 Video Transient measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelVideoFallTimePercentageCh1” Query may return: “VideoTransientRelVideoFallTimePercentageCh1 1.77” 3- 566 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 771 Video Transient measurement on the specified channel. The returned value is in nanoseconds (ns). Returns ”- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”VideoTransientRelVideoRiseTimeCh1” Query may return: ”VideoTransientRelVideoRiseTimeCh1 1.77” 3- 567 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 772 Video Transient measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientRelVideoRiseTimePercentageCh1” Query may return: “VideoTransientRelVideoRiseTimePercentageCh1 1.77” 3- 568 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 773 Query returns “0” if the Video Transient measurement is not selected. Query returns “1” if the Video Transient measurement is selected. Examples VARIable:VALue “VideoTransientSet”, “ON” VARIable:VALue? “VideoTransientSet” Query may return: “VideoTransientSet 1” 3- 569 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 774 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “VideoTransientStatus” Query may return: “VideoTransientStatus Pass” 3- 570 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 775 The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientUndershootCh1” Query may return: “VideoTransientUndershootCh1 1.06” 3- 571 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 776 Video Transient measurement on the specified channel. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientUndershootSettlingTimeCh1” Query may return: “VideoTransientUndershootSettlingTimeCh1 2.66” 3- 572 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 777 The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientVideoFallTimeCh1” Query may return: “VideoTransientVideoFallTimeCh1 1.77” 3- 573 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 778 Video Transient measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientVideoFallTimePercentageCh1” Query may return: “VideoTransientVideoFallTimePercentageCh1 1.77” 3- 574 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 779 The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientVideoRiseTimeCh1” Query may return: “VideoTransientVideoRiseTimeCh1 1.77” 3- 575 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 780 Video Transient measurement on the specified channel. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VideoTransientVideoRiseTimePercentageCh1” Query may return: “VideoTransientVideoRiseTimePercentageCh1 1.77” 3- 576 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 781 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncAll” Query may return: “VSyncAll Pos 1 11.76 85.03 5 5 4.45 5.22 3.8 0.0 Yes Yes 3188.5 400 2820.695 464.411” 3- 577 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 782 Return value Query returns the currently assigned total number of samples for the V Sync measurement. Examples VARIable:VALue “VSyncAverage”, “1” VARIable:VALue? “VSyncAverage” Query may return: “VSyncAverage 8” 3- 578 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 783 Query returns the measured Fall Time resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncFallTime” Query may return: “VSyncFallTime 1” 3- 579 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 784 Query returns the measured Frequency resulting from the V Sync measurement. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncFrequency” Query may return: “VSyncFrequency 85” 3- 580 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 785 Return value Query returns the currently assigned line number used to perform the V Sync measurement. Examples VARIable:VALue? “VSyncLine” Query may return: “VSyncLine 325” 3- 581 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 786 Logic Level 1 at 2.21 kΩ termination resistance) resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncLogicLevel0Value1” Query may return: “VSyncLogicLevel0Value1 1” 3- 582 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 787 MIU connected) resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncLogicLevel0Value2” Query may return: “VSyncLogicLevel0Value2 1” 3- 583 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 788 Logic Level 1 at 2.21 kΩ termination resistance) resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncLogicLevel1Value1” Query may return: “VSyncLogicLevel1Value1 1” 3- 584 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 789 MIU connected) resulting from the V Sync measurement. The unit of the value is millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncLogicLevel1Value2” Query may return: “VSyncLogicLevel1Value2 1” 3- 585 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 790 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxAll” Query may return: “VSyncMaxAll Pos 1.033 13.765 86.0 5.37 5.37 30.0 30.0 304.8 304.8 Yes Yes 5500.0 500 5500.0 500” 3- 586 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 791 Query returns the V Sync Fall Time maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxFallTime” Query may return: “VSyncMaxFallTime 7.1” 3- 587 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 792 Query returns the V Sync Frequency maximum limit value specified in the Limits file. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxFrequency” Query may return: “VSyncMaxFrequency 85” 3- 588 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 793 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxLogicLevel0Value1” Query may return: “VSyncMaxLogicLevel0Value1 1” 3- 589 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 794 MIU connected) maximum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxLogicLevel0Value2” Query may return: “VSyncMaxLogicLevel0Value2 1” 3- 590 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 795 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxLogicLevel1Value1” Query may return: “VSyncMaxLogicLevel1Value1 1” 3- 591 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 796 MIU connected) maximum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxLogicLevel1Value2” Query may return: “VSyncMaxLogicLevel1Value2 1” 3- 592 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 797 Query returns the V Sync Monotonic Fall maximum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxMonotonicFall” Query may return: “VSyncMaxMonotonicFall Yes” 3- 593 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 798 Query returns the V Sync Monotonic Rise maximum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxMonotonicRise” Query may return: “VSyncMaxMonotonicRise Yes” 3- 594 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 799 Query returns the V Sync Overshoot maximum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxOvershoot” Query may return: “VSyncMaxOvershoot 15” 3- 595 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 800 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxOvershootSettlingTime” Query may return: “VSyncMaxOvershootSettlingTime 7.1” 3- 596 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 801 Query returns the V Sync Polarity maximum limit value specified in the Limits file. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxPolarity” Query may return: “VSyncMaxPolarity Pos” 3- 597 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 802 Query returns the V Sync Pulse Width maximum limit value specified in the Limits file. The returned value is in millisecondss (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxPulseWidth” Query may return: “VSyncMaxPulseWidth 0.05” 3- 598 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 803 Query returns the V Sync Rise Time maximum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxRiseTime” Query may return: “VSyncMaxRiseTime 7.1” 3- 599 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 804 Query returns the V Sync Sync Period maximum limit value specified in the Limits file. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxSyncPeriod” Query may return: “VSyncMaxSyncPeriod 11.75” 3- 600 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 805 Query returns the V Sync Undershoot maximum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxUndershoot” Query may return: “VSyncMaxUndershoot 15” 3- 601 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 806 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMaxUndershootSettlingTime” Query may return: “VSyncMaxUndershootSettlingTime 7.1” 3- 602 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 807 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinAll” Query may return: “VSyncMinAll Neg 0.0 9.765 84.0 0.35 0.35 0.0 0.0 0.0 0.0 Yes Yes 2400.0 0.0 2400.0 0.0” 3- 603 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 808 Query returns the V Sync Fall Time minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinFallTime” Query may return: “VSyncMinFallTime 7.1” 3- 604 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 809 Query returns the V Sync Frequency minimum limit value specified in the Limits file. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinFrequency” Query may return: “VSyncMinFrequency 85” 3- 605 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 810 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinLogicLevel0Value1” Query may return: “VSyncMinLogicLevel0Value1 1” 3- 606 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 811 MIU connected) minimum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinLogicLevel0Value2” Query may return: “VSyncMinLogicLevel0Value2 1” 3- 607 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 812 Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinLogicLevel1Value1” Query may return: “VSyncMinLogicLevel1Value1 1” 3- 608 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 813 MIU connected) minimum limit value specified in the Limits file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinLogicLevel1Value2” Query may return: “VSyncMinLogicLevel1Value2 1” 3- 609 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 814 Query returns the V Sync Monotonic Fall minimum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinMonotonicFall” Query may return: “VSyncMinMonotonicFall Yes” 3- 610 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 815 Query returns the V Sync Monotonic Rise minimum limit value specified in the Limits file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinMonotonicRise” Query may return: “VSyncMinMonotonicRise Yes” 3- 611 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 816 Query returns the V Sync Overshoot minimum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinOvershoot” Query may return: “VSyncMinOvershoot 15” 3- 612 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 817 Query returns the V Sync Overshoot minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinOvershootSettlingTime” Query may return: “VSyncMinOvershootSettlingTime 7.1” 3- 613 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 818 Query returns the V Sync Polarity minimum limit value specified in the Limits file. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinPolarity” Query may return: “VSyncMinPolarity Pos” 3- 614 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 819 Query returns the V Sync Pulse Width minimum limit value specified in the Limits file. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinPulseWidth” Query may return: “VSyncMinPulseWidth 0.05” 3- 615 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 820 Query returns the V Sync Rise Time minimum limit value specified in the Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinRiseTime” Query may return: “VSyncMinRiseTime 7.1” 3- 616 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 821 Query returns the V Sync Period minimum limit value specified in the Limits file. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinSyncPeriod” Query may return: “VSyncMinSyncPeriod 11.75” 3- 617 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 822 Query returns the V Sync Undershoot minimum limit value specified in the Limits file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinUndershoot” Query may return: “VSyncMinUndershoot 15” 3- 618 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 823 Limits file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMinUndershootSettlingTime” Query may return: “VSyncMinUndershootSettlingTime 7.1” 3- 619 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 824 Query returns the measured Monotonic Fall value resulting from the V Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMonotonicFall” Query may return: “VSyncMonotonicFall Yes” 3- 620 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 825 Query returns the measured Monotonic Rise value resulting from the V Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncMonotonicRise” Query may return: “VSyncMonotonicRise Yes” 3- 621 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 826 Query returns the measured Overshoot resulting from the V Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncOvershoot” Query may return: “VSyncOvershoot 1” 3- 622 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 827 Query returns the measured Overshoot Settling Time resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncOvershootSettlingTime” Query may return: “VSyncOvershootSettlingTime 1” 3- 623 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 828 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassAll” Query may return: “VSyncPassAll 1 1 1 0 0 0 1 0 0 1 1 1 0 1” 3- 624 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 829 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassFallTime” Query may return: “VSyncPassFallTime 1” 3- 625 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 830 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassFrequency” Query may return: “VSyncPassFrequency 1” 3- 626 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 831 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassLogicLevel0Value1” Query may return: “VSyncPassLogicLevel0Value1 1” 3- 627 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 832 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassLogicLevel0Value2” Query may return: “VSyncPassLogicLevel0Value2 1” 3- 628 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 833 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassLogicLevel1Value1” Query may return: “VSyncPassLogicLevel1Value1 1” 3- 629 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 834 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassLogicLevel0Value2” Query may return: “VSyncPassLogicLevel0Value2 1” 3- 630 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 835 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassMonotonicFall” Query may return: “VSyncPassMonotonicFall 1” 3- 631 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 836 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassMonotonicRise” Query may return: “VSyncPassMonotonicRise 1” 3- 632 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 837 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassOvershoot” Query may return: “VSyncPassOvershoot 1” 3- 633 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 838 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassOvershootSettlingTime” Query may return: “VSyncPassOvershootSettlingTime 1” 3- 634 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 839 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassPolarity” Query may return: “VSyncPassPolarity 1” 3- 635 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 840 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassPulseWidth” Query may return: “VSyncPassPulseWidth 1” 3- 636 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 841 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassRiseTime” Query may return: “VSyncPassRiseTime 1” 3- 637 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 842 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassSyncPeriod” Query may return: “VSyncPassSyncPeriod 1” 3- 638 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 843 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassUndershoot” Query may return: “VSyncPassUndershoot 1” 3- 639 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 844 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPassUndershootSettlingTime” Query may return: “VSyncPassUndershootSettlingTime 1” 3- 640 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 845 Query returns the measured Polarity resulting from the V Sync measurement. The returned value is either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPolarity” Query may return: “VSyncPolarity Pos” 3- 641 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 846 Query returns the measured Pulse Width resulting from the V Sync measurement. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncPulseWidth” Query may return: “VSyncPulseWidth 1” 3- 642 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 847 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefAll” Query may return: “VSyncRefAll Pos 0.033 11.765 85.0 2.51 2.51 0 0 0 0 Yes Yes 3950.0 0.0 3950.0 0.0” 3- 643 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 848 Query returns the V Sync Fall Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefFallTime” Query may return: “VSyncRefFallTime 7.1” 3- 644 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 849 Query returns the V Sync Frequency reference value specified in the Reference file. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefFrequency” Query may return: “VSyncRefFrequency 85” 3- 645 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 850 Logic Level 0 at 2.21 kΩ termination resistance) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefLogicLevel0Value1” Query may return: “VSyncRefLogicLevel0Value1 1” 3- 646 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 851 MIU connected) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefLogicLevel0Value2” Query may return: “VSyncRefLogicLevel0Value2 1” 3- 647 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 852 Logic Level 1 at 2.21 kΩ termination resistance) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefLogicLevel1Value1” Query may return: “VSyncRefLogicLevel1Value1 1” 3- 648 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 853 MIU connected) reference value specified in the Reference file. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefLogicLevel1Value2” Query may return: “VSyncRefLogicLevel1Value2 1” 3- 649 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 854 Query returns the V Sync Monotonic Fall reference value specified in the Reference file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefMonotonicFall” Query may return: “VSyncRefMonotonicFall Yes” 3- 650 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 855 Query returns the V Sync Monotonic Rise reference value specified in the Reference file. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefMonotonicRise” Query may return: “VSyncRefMonotonicRise Yes” 3- 651 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 856 Query returns the V Sync Overshoot reference value specified in the Reference file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefOvershoot” Query may return: “VSyncRefOvershoot 15” 3- 652 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 857 Query returns the V Sync Overshoot Settling Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefOvershootSettlingTime” Query may return: “VSyncRefOvershootSettlingTime 7.1” 3- 653 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 858 Query returns the V Sync Polarity reference value specified in the Reference file. The returned value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefPolarity” Query may return: “VSyncRefPolarity Pos” 3- 654 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 859 Query returns the V Sync Pulse Width reference value specified in the Reference file. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefPulseWidth” Query may return: “VSyncRefPulseWidth 0.05” 3- 655 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 860 Query returns the V Sync Rise Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefRiseTime” Query may return: “VSyncRefRiseTime 7.1” 3- 656 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 861 Query returns the V Sync Sync Period reference value specified in the Reference file. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefSyncPeriod” Query may return: “VSyncRefSyncPeriod 11.75” 3- 657 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 862 Query returns V Sync Undershoot reference value specified in the Reference file. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefUndershoot” Query may return: “VSyncRefUndershoot 15” 3- 658 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 863 Query returns the V Sync Undershoot Settling Time reference value specified in the Reference file. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRefUndershootSettlingTime” Query may return: “VSyncRefUndershootSettlingTime 7.1” 3- 659 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 864 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelAll” Query may return: “VSyncRelAll Pos 1 - -0.005 0,034 5 5 4.458 5.226 3.8 0.0 Yes Yes - -761.48 - -400 - -1129.3 464.4” 3- 660 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 865 Query returns the Fall Time relative value resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelFallTime” Query may return: “VSyncRelFallTime 7.1” 3- 661 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 866 Query returns the Frequency relative value resulting from the V Sync measurement. The returned value is in Hertz (Hz). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelFrequency” Query may return: “VSyncRelFrequency 85” 3- 662 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 867 2.21 kΩ termination resistance) relative value resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelLogicLevel0Value1” Query may return: “VSyncRelLogicLevel0Value1 1” 3- 663 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 868 MIU connected) relative value resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelLogicLevel0Value2” Query may return: “VSyncRelLogicLevel0Value2 1” 3- 664 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 869 2.21 kΩ termination resistance) relative value resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelLogicLevel1Value1” Query may return: “VSyncRelLogicLevel1Value1 1” 3- 665 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 870 MIU connected) relative value resulting from the V Sync measurement. The returned value is in millivolts (mV). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelLogicLevel1Value2” Query may return: “VSyncRelLogicLevel1Value2 1” 3- 666 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 871 Query returns the Monotonic Fall relative value resulting from the V Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelMonotonicFall” Query may return: “VSyncRelMonotonicFall Yes” 3- 667 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 872 Query returns the Monotonic Rise relative value resulting from the V Sync measurement. The returned value is either “Yes” or “No”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelMonotonicRise” Query may return: “VSyncRelMonotonicRise Yes” 3- 668 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 873 Query returns the Overshoot relative value resulting from the V Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelOvershoot” Query may return: “VSyncRelOvershoot 15” 3- 669 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 874 Query returns the Overshoot Settling Time relative value resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelOvershootSettlingTime” Query may return: “VSyncRelOvershootSettlingTime 7.1” 3- 670 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 875 Query returns the Polarity relative value resulting from the V Sync measurement. The value can be either “Pos” or “Neg”. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelPolarity” Query may return: “VSyncRelPolarity Pos” 3- 671 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 876 Query returns the Pulse Width relative value resulting from the V Sync measurement. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelPulseWidth” Query may return: “VSyncRelPulseWidth 0.05” 3- 672 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 877 Query returns the Rise Time relative value resulting from the V Sync measure- ment. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelRiseTime” Query may return: “VSyncRelRiseTime 7.1” 3- 673 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 878 Query returns the Sync Period relative value resulting from the V Sync measure- ment. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelSyncPeriod” Query may return: “VSyncRelSyncPeriod 11.75” 3- 674 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 879 Query returns the Undershoot relative value resulting from the V Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelUndershoot” Query may return: “VSyncRelUndershoot 15” 3- 675 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 880 Query returns the Undershoot Settling Time relative value resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRelUndershootSettlingTime” Query may return: “VSyncRelUndershootSettlingTime 7.1” 3- 676 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 881 Query returns the measured Rise Time resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncRiseTime” Query may return: “VSyncRiseTime 1” 3- 677 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 882 Query returns “0” if the V Sync measurement is not selected. Query returns “1” if the V Sync measurement is selected. Examples VARIable:VALue “VSyncSet”, “ON” VARIable:VALue? “VSyncSet” Query may return: “VSyncSet 1” 3- 678 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 883 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “VSyncStatus” Query may return: “VSyncStatus Pass” 3- 679 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 884 Query returns the measured Sync Period resulting from the V Sync measurement. The returned value is in milliseconds (ms). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncSyncPeriod” Query may return: “VSyncSyncPeriod 1” 3- 680 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 885 Query returns the measured Undershoot resulting from the V Sync measurement. The returned value is in percent (%). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncUndershoot” Query may return: “VSyncUndershoot 1” 3- 681 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 886 Query returns the measured Undershoot Settling Time resulting from the V Sync measurement. The returned value is in nanoseconds (ns). Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VSyncUndershootSettlingTime” Query may return: “VSyncUndershootSettlingTime 1” 3- 682 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 887 V Timing measurement on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingAddressableLinesCh1” Query may return: “VTimingAddressableLinesCh1 600” 3- 683 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 888 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingAll” Query may return: “VTimingAll 47 0.0 1023.0 0.0 2.0 47 0.0 1023.0 0.0 2.0 47 0.0 1023.0 0.0 2.0 47 0.0 1023.0 0.0 2.0 3.0” 3- 684 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 889 Return value Query returns the currently assigned total number of samples for the V Timing measurement Examples VARIable:VALue “VTimingAverage”, “1” VARIable:VALue? “VTimingAverage” Query may return: “VTimingAverage 8” 3- 685 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 890 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingBackPorchCh1” Query may return: “VTimingBackPorchCh1 27” 3- 686 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 891 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingBottomBorderCh1” Query may return: “VTimingBottomBorderCh1 0” 3- 687 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 892 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingFrontPorchCh1” Query may return: “VTimingFrontPorchCh1 1” 3- 688 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 893 Return value Query returns the currently assigned line number resulting from the V Timing measurement. Examples VARIable:VALue? “VTimingLine” Query may return: “VTimingLine 325” 3- 689 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 894 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMaxAddressableLinesCh1” Query may return: “VTimingMaxAddressableLinesCh1 600” 3- 690 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 895 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMaxAll” Query may return: “VTimingMaxAll 48.0 1.0 1025.0 1.0 2.0 48.0 1.0 1025.0 1.0 2.0 48.0 1.0 1025.0 1.0 2.0 4.0” 3- 691 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 896 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMaxBackPorchCh1” Query may return: ”VTimingMaxBackPorchCh1 27” 3- 692 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 897 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMaxBottomBorderCh1” Query may return: “VTimingMaxBottomBorderCh1 0” 3- 693 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 898 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMaxFrontPorchCh1” Query may return: “VTimingMaxFrontPorchCh1 1” 3- 694 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 899 Query returns the V Timing Sync Pulse Width maximum limit value specified in the Limits file. The returned value is a line number. Returns ”- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”VTimingMaxSyncPulseWidth” Query may return: ”VTimingMaxSyncPulseWidth 3” 3- 695 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 900 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMaxTopBorderCh1” Query may return: “VTimingMaxTopBorderCh1 0” 3- 696 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 901 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMinAddressableLinesCh1” Query may return: “VTimingMinAddressableLinesCh1 600” 3- 697 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 902 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMinAll” Query may return: “VTimingMinAll 46.0 0.0 1023.0 0.0 0.0 46.0 0.0 1023.0 0.0 0.0 46.0 0.0 1023.0 0.0 0.0 2.0” 3- 698 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 903 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMinBackPorchCh1” Query may return: “VTimingMinBackPorchCh1 27” 3- 699 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 904 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMinBottomBorderCh1” Query may return: “VTimingMinBottomBorderCh1 0” 3- 700 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 905 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMinFrontPorchCh1” Query may return: “VTimingMinFrontPorchCh1 1” 3- 701 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 906 Query returns the V Timing Sync Pulse Width minimum limit value specified in the Limits file. The returned value is a line number. Returns ”- -- -- -” if no valid value is currently available. Examples VARIable:VALue? ”VTimingMinSyncPulseWidth” Query may return: ”VTimingMinSyncPulseWidth 3” 3- 702 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 907 Limits file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingMinTopBorderCh1” Query may return: “VTimingMinTopBorderCh1 0” 3- 703 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 908 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassAddressableLinesCh1” Query may return: “VTimingPassAddressableLinesCh1 1” 3- 704 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 909 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassAll” Query may return: “VTimingPassAll 1 0 0 0 1 1 1 0 1 0 1 1 1 1 1 1 1” 3- 705 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 910 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassBackPorchCh1” Query may return: “VTimingPassBackPorchCh1 1” 3- 706 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 911 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassBottomBorderCh1” Query may return: “VTimingPassBottomBorderCh1 1” 3- 707 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 912 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassFrontPorchCh1” Query may return: “VTimingPassFrontPorchCh1 1” 3- 708 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 913 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassSyncPulseWidth” Query may return: “VTimingPassSyncPulseWidth 1” 3- 709 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 914 A returned value of 1 means Pass, a returned value of 0 means Fail. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingPassTopBorderCh1” Query may return: “VTimingPassTopBorderCh1 1” 3- 710 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 915 Reference file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefAddressableLinesCh1” Query may return: “VTimingRefAddressableLinesCh1 600” 3- 711 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 916 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefAll” Query may return: “VTimingRefAll 47.0 0.0 1024.0 0.0 1.0 47.0 0.0 1024.0 0.0 1.0 47.0 0.0 1024.0 0.0 1.0 3.0” 3- 712 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 917 Reference file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefBackPorchCh1” Query may return: “VTimingRefBackPorchCh1 27” 3- 713 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 918 Reference file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefBottomBorderCh1” Query may return: “VTimingRefBottomBorderCh1 0” 3- 714 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 919 Reference file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefFrontPorchCh1” Query may return: “VTimingRefFrontPorchCh1 1” 3- 715 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 920 Query returns the V Timing Sync Pulse Width reference value specified in the Reference file. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefSyncPulseWidth” Query may return: “VTimingRefSyncPulseWidth 3” 3- 716 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 921 Reference file on the specified channel. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRefTopBorderCh1” Query may return: “VTimingRefTopBorderCh1 0” 3- 717 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 922 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelAddressableLinesCh1” Query may return: “VTimingRelAddressableLinesCh1 600” 3- 718 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 923 Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelAll” Query may return: “VTimingRelAll 1 0.0 - -1.0 0.0 1.0 1 0.0 - -1.0 0.0 1.0 1 0.0 - -1.0 0.0 1.0 0.0” 3- 719 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 924 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelBackPorchCh1” Query may return: “VTimingRelBackPorchCh1 27” 3- 720 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 925 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelBottomBorderCh1” Query may return: “VTimingRelBottomBorderCh1 0” 3- 721 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 926 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelFrontPorchCh1” Query may return: “VTimingRelFrontPorchCh1 1” 3- 722 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 927 Query returns the Sync Pulse Width relative value resulting from the V Timing measurement. The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelSyncPulseWidth” Query may return: “VTimingRelSyncPulseWidth 3” 3- 723 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 928 The returned value is a line number. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingRelTopBorderCh1” Query may return: “VTimingRelTopBorderCh1 0” 3- 724 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 929 Query returns “0” if the V Timing measurement is not selected. Query returns “1” if the V Timing measurement is selected. Examples VARIable:VALue “VTimingSet”, “ON” VARIable:VALue? “VTimingSet” Query may return: “VTimingSet 1” 3- 725 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 930 Query returns Done when the measurement is completed without limit testing. Query returns Stopped when the measurement is halted before completion. Returns “- -- -- -” if no valid value are currently available. Examples VARIable:VALue? “VTimingStatus” Query may return: “VTimingStatus Pass” 3- 726 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 931 Query returns the measured Sync Pulse Width resulting from the V Timing measurement. The returned value is in Line. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingSyncPulseWidth” Query may return: “VTimingSyncPulseWidth 3” 3- 727 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 932 The returned value is in Line. Returns “- -- -- -” if no valid value is currently available. Examples VARIable:VALue? “VTimingTopBorderCh1” Query may return: “VTimingTopBorderCh1 0” 3- 728 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 933 OFF is the same as 0, and ON is the same as 1. Related Commands WarningReportResults WarningReportSignal Return value Query returns the current specified setting. Examples VARIable:VALue “WarningReportingMeasure”, “ON” VARIable:VALue? “WarningReportingMeasure” Query may return: “WarningReportingMeasure 0” 3- 729 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 934 OFF is the same as 0, and ON is the same as 1. Related Commands WarningReportingMeasure WarningReportingSignal Return value Query returns the current specified setting. Examples VARIable:VALue “WarningReportingResults”, “ON” VARIable:VALue? “WarningReportingResults” Query may return: “WarningReportingResults 0” 3- 730 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 935 OFF is the same as 0, and ON is the same as 1. Related Commands WarningReportingMeasure WarningReportingResults Return value Query returns the current specified setting. Examples VARIable:VALue “WarningReportingSignal”, “ON” VARIable:VALue? “WarningReportingSignal” Query may return: “WarningReportingSignal 0” 3- 731 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 936 OFF is the same as 0, and ON is the same as 1. Return value Query returns the current specified setting. Examples VARIable:VALue “WarningReportingResults”, “ON” VARIable:VALue? “WarningReportingResults” Query may return: “WarningReportingResults 0” 3- 732 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 937 Appendix...
  • Page 939 Option VGA does not have this file. Sending GPIB Commands The time required for a command to transfer from the platform to the VM5000 Java application can vary. In previous versions of this product, we recommended a 50 ms delay between each command to allow time for the instrument to fully process commands.
  • Page 940 } while ( !strstr(receiveBuf, variable) ); Option VGA Example code is as follows: // Send a query to the VM5000 platform and get the response, the ID and version No. strcpy(outString, ”VARI:VAL? \”ID\”\n”); printf(”Query response to VARI:VAL? \”ID\” is %s\n”, queryVM5000(outString, readBuf));...
  • Page 941 The code above takes advantage of the fact that the VM5000 always adds the command back into each GPIB value as it processes it. You can see the actual file to get the complete list of the code in the VM5000 product software CD.
  • Page 942 Appendix A:Programming the VM5000 A- 4 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 943 Index...
  • Page 945 ChChSkewMinPixelClockCh1Ch2?, 3- - 109 ChChMismatchMinPeakToPeakCh1Ch2?, 3- - 57 ChChSkewMinPixelClockCh1Ch3?, 3- - 110 ChChMismatchMinPeakToPeakCh1Ch3?, 3- - 58 ChChSkewMinPixelClockCh2Ch3?, 3- - 111 ChChMismatchMinPeakToPeakCh2Ch3?, 3- - 59 ChChSkewMultiLineEnd, 3- - 112 ChChMismatchMultiLineEnd, 3- - 60 Index- 1 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 946 ColorBarsRelPctmVCh[1..3]Val[1..8]?, 2- - 37 ColorBarsMinCh[1..3]Val3?, 3- - 161 ColorBarsSet, 2- - 38, 3- - 207 ColorBarsMinCh[1..3]Val4?, 3- - 162 ColorBarsStatus, 2- - 39 ColorBarsMinCh[1..3]Val5?, 3- - 163 ColorBarsStatus?, 3- - 208 Index- 2 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 947 ColorSpace, 2- - 40 Commands, 2- - 9, 3- - 37 See also Remote commands HSyncAll?, 3- - 216 Compatibility, VM5000 option HD and SD to HSyncAverage, 3- - 217 VM5000HD, 1- - 5 HSyncFallTime?, 3- - 218 HSyncFrequency?, 3- - 219...
  • Page 948 HSyncRefMonotonicRise?, 3- - 314 HTimingMinRightBorderCh[1..3]?, 3- - 367 HSyncRefOvershoot?, 3- - 315 HTimingMinSyncPulseWidth?, 3- - 368 HSyncRefOvershootSettlingTime?, 3- - 316 HTimingMultiLineEnd, 3- - 369 HSyncRefPolarity?, 3- - 317 HTimingMultiLineSet, 3- - 370 Index- 4 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 949 LinearityMaxMonotonicCh[1..3]?, 3- - 412 LumaLevelsRelPctAmpMaxCh[1..3]?, 3- - 464, 3- - 465 LinearityMaxResolutionCh[1..3]?, 3- - 413 LumaLevelsSet, 3- - 466 LinearityMinDNLCh[1..3]?, 3- - 414 LumaLevelsStatus?, 3- - 467 LinearityMinINLCh[1..3]?, 3- - 415 Index- 5 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 950 Remote commands, 1- - 1, 2- - 1, 3- - 1 NoisePassdBCh[1..3]?, 2- - 96, 3- - 484 command descriptions, 2- - 9, 3- - 37 NoisePassIrCh[1..3]?, 3- - 485 startup and exit, 1- - 4 NoisePassmVCh[1..3]?, 3- - 486 Index- 6 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 951 SyncSet, 2- - 159 3- - 536 SyncStatus, 2- - 160 VideoTransientMinVideoRiseTimeCh[1..3]?, 3- - 537 SyncTimes?, 2- - 161 VideoTransientMinVideoRiseTimePercentageCh[1..3]?, SyncTimesVal[1..10]?, 2- - 154, 2- - 162 3- - 538 Syntax, 1- - 1 Index- 7 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 952 3- - 572 VSyncOvershootSettlingTime?, 3- - 623 VideoTransientVideoFallTimeCh[1..3]?, 3- - 573 VSyncPassAll?, 3- - 624 VideoTransientVideoFallTimePercentageCh[1..3]?, VSyncPassFallTime?, 3- - 625 3- - 574 VSyncPassFrequency?, 3- - 626 VideoTransientVideoRiseTimeCh[1..3]?, 3- - 575 Index- 8 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 953 VSyncRelSyncPeriod?, 3- - 674 VTimingSet, 3- - 725 VSyncRelUndershoot?, 3- - 675 VTimingStatus?, 3- - 726 VSyncRelUndershootSettlingTime?, 3- - 676 VTimingSyncPulseWidth?, 3- - 727 VSyncRiseTime?, 3- - 677 VTimingTopBorderCh[1..3]?, 3- - 728 Index- 9 VM5000 Automatic Video Measurement Set Programmer Manual...
  • Page 954 Index Warning, 2- - 167 WarningReportingMeasure, 2- - 168, 3- - 729 WarningReportingResults, 2- - 169, 3- - 730, 3- - 732 WarningReportingSignal, 2- - 170, 3- - 731 Index- 10 VM5000 Automatic Video Measurement Set Programmer Manual...

Table of Contents
