- Page 1 SharePod User's Manual Version: 0.1 Brand Name: Awind INC Model Name: WHE-100...
-
Page 2: Table Of Contents
Table of Contents ..................3 VERVIEW ................ 4 ACKAGE ONTENTS ................4 HYSICAL ETAILS ..............5 IGHT ............5 RESENT HARE OD PAIRING ................5 AIRING ................6 ANUAL PAIRING ........... 7 RESENT HARE IRRORING ..............7 HARE IRRORING ............. 8 DVANCED OLLABORATION ................. -
Page 3: Overview
HDMI source to wePresent receiver wirelessly and enables the collaboration feature easily for the meeting room and classroom. By connecting the HDMI cable to SharePod, it will mirror the audio/video from supported HDMI device to big screen immediately, no any software installation or complicated configuration required. -
Page 4: Package Contents
Package Contents wePresent SharePod device Power Adapter (DC +5V, 1.2A) Setup Guide Warranty Card CE DoC Physical Details... -
Page 5: What You Might Need
SharePod pairing 5.1 Auto Pairing Plug in the micro USB cable from SharePod to wePresent receiver, and it will start the pairing automatically. Please wait until you can see the “Pairing successful” message on wePresent receiver screen, and then remove the USB cable to finish the pairing. -
Page 6: Manual Pairing
5.2 Manual pairing 1) Plug in the micro USB cable from SharePod to laptop and launch the configuration tool from the CD-ROM disk, then you can configure the pairing information manually as below. Receiver IP Address: the IP address of target wePresent receiver ... -
Page 7: Wepresent Sharepod Mirroring
SharePod Mirroring 6.1 SharePod Mirroring 1) Power on the SharePod device, it will connect to the target wePresent receiver. The short blinking blue LED indicates the system is trying to connect to target wePresent receiver, and it will switch to long blinking blue LED when it is connected. -
Page 8: Advanced Collaboration
Make annotation on SharePod screen from wePresent pen menu (if available) and save the screenshot to local USB driver. Web Admin 7.1 Login Admin Page 1) Connect the SharePod device to the same network of your laptop, and then open... -
Page 9: System Status
SharePod web admin. 2) Enter the password to login the admin page. (default password: admin) 7.2 System Status 1) Click on “System Status” option, it will show current system status. Model Name: Product model name Versions: Firmware version no.: Product firmware version number. -
Page 10: Device Setup
7.3 Device Setup 1) Click on “Device Setup” option, it will show the device setting items, <Receiver IP Address>: The IP address of target wePresent receiver <Login Code>: The login code of target wePresent receiver. <Sender Name>: The name of this SharePod device ... -
Page 11: Network Setup
7.4 Network Setup 1) Click on “Network Setup” option, it will show the network setting items, < IP Setup> You can select “obtain IP address automatically” or “Use the following IP address” to enter the IP address. The default setting is as following: IP Address: 192.168.100.10. -
Page 12: Change Passwords
Note: 1. The WiFi 5G DFS band is not supported. 7.6 Change Passwords 1) Click on “Change Password” option, you can change the password setting for “Admin”. <Enter New Password> (Length: up to 8 characters) <Confirm New Password> <Apply>: Confirm and Save modifications. -
Page 13: Reset To Default
1) Click on “Reset to Default” option to restore factory default settings. <Apply>: Confirm and take action. *** You can also restore factory default setting from SharePod box reset button. You can find the reset button underneath the box. Please follow below procedures. - Page 14 Warning: Don’t power off wePresent SharePod while firmware upgrade in progress, otherwise you will damage your box and have to return device to your vendor for fixing.
-
Page 15: Reboot System
7.9 Reboot System 1) Click on “Reboot System” option, you can restart the system Click on <Reboot >button: reboot system automatically. 7.10 Logout 1) Click on “logout” on the up right corner, you can logout the administration webpage and return back to the web management front page. - Page 16 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
