- Page 1 Transient Limiter GPL-5010 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com USER MANUAL GW INSTEK PART NO. ISO-9001 CERTIFIED MANUFACTURER...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company. The information in this manual was correct at the time of printing. However, Good Will continues to improve products and reserves the rights to change specification, equipment, and maintenance procedures at any time without notice.
-
Page 3: Table Of Contents
Table of Contents Table of Contents OVERVIEW ................ 2 PACKAGE CONTENTS ............3 APPLICATION ..............4 SCHEMATIC DIAGRAM ............. 5 APPEARANCE ..............6 APPENDIX ................ 7 GPL-5010 Specifications ......7... -
Page 4: Overview
GPL-5010 User Manual VERVIEW GWINSTEK GPL-5010 transient limiter is commonly used to test electromagnetic interference. For EMI testing, when accidentally overloaded, it can protect the terminal circuit and the valuable EMI test equipment. Meanwhile, together with our GLN-5040A Two Line V- Network, they constitute a complete EMI test system. -
Page 5: Package Contents
PACKAGE CONTENTS ACKAGE CONTENTS Item Quantity Limiter main unit 1 Pcs User instruction manual and warranty card 1 Book Test report 1 Sheet... -
Page 6: Application
GPL-5010 User Manual PPLICATION It can be used in Power supply (switch type and linear) design. It can be used in Inverter/transformer design. It can be used in LED illumination design. ... -
Page 7: Schematic Diagram
SCHEMATIC DIAGRAM CHEMATIC DIAGRAM EMC Receiver LISN GPL-5010 Transient Mains power Limiter... -
Page 8: Appearance
GPL-5010 User Manual PPEARANCE Input Interface: BNC female Output Interface: N male... -
Page 9: Appendix
APPENDIX PPENDIX GPL-5010 Specifications Bandwidth 9kHz-200MHz Limit level 50mW(+17dBm) System impedance 50Ω Input Input : BNC (female) Connectors Output Output : N (male) Continuous: 2.5W(+34dBm) Maximum input level Pulse: 10kW(10uS) DC: ±12V <2kHz >30dB 9kHz-50MHz 10dB±0.5dB Insertion loss 10dB+2.2dB/ 50MHz-200MHz 10dB-0.5dB... - Page 10 GPL-5010 User Manual Figure 1 Frequency Response Curve Figure 2 Amplitude Limiting Specification Curve Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com...
