Combi Switches - TATA Motors NEXON Owner's Manual

Reverse gear reminder
When Reverse Gear is engaged, audio
warning for 1 sec will alert you.
Seat belt reminder
If driver seat belt is not fastened and ve-
hicle speed goes above 15
alarm will start and continue for 3
onds. Seat belt Tell tale will remain con-
tinuously 'ON' when audio alarm is ac-
tive.
Day Time Running Lamps (DRL) (if
equipped)
Day time Running Lamps
(DRL) are used to increase the
visibility of the vehicle to other drivers
during daytime.
To activate and deactivate DRL, keep
the Ignition switch is 'ON' position and
switch ON-OFF parking lamp twice within
approx. 3 seconds.
Nexon/Rev01,Sept 17
Combi-Switch (RH Stalk)
kmph, audio
sec-
0
1. Left Turn signal - Move the lever
fully upward.
2. Right Turn signal - Move the lever
fully downward.
When the turn is completed, the
signal will cancel and the lever will
return to its normal position.
3. High beam - Move the lever forward
to select the High Beam function.
NOTE
DASHBOARD AND FEATURES
Pull the lever back to normal for low
beam.
4. High beam Flash (spring return)
To flash the high beam, pull the lever
towards you from the normal posi-
tion. It will return to its normal posi-
tion when you release it.
5. Headlamp Rotary Switch
i) OFF Position
All lamps will remain 'OFF'.
ii) Parking Lamp
Rotate stalk to turn 'ON' the Parking
lamps.
NOTE
DRL (if equipped) will turn 'ON' as
long as parking lamp input is 'OFF'
and engine is running.
To temporary deactivate DRL turn
'ON' and 'OFF' the park lamp
switch two times within 3 seconds.
The lamp can be activated again
by performing the same action.
51
