RX-V2065/HTR-6295
Note:
When IC513 of GUI P.C.B. or GUI P.C.B. is replaced, the network function of this unit will not operate
properly without additional setting.
In such case, report the serial number of this unit to the following e-mail address.
Yamaha Corporation will reply providing the setting procedure to make the network function of this
unit operate properly.
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known
and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service
departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and
specifi cations are subject to change without notice or obligation to retrofi t. Should any discrepancy appear to exist, please contact the
distributor's Service Division.
WARNING:
IMPORTANT:
■ CONTENTS
TO SERVICE PERSONNEL ........................................2-3
FRONT PANELS .........................................................3-4
REAR PANELS ...........................................................5-7
REMOTE CONTROL PANELS .......................................8
SPECIFICATIONS ..................................................... 9-15
INTERNAL VIEW .......................................................... 16
SERVICE PRECAUTIONS ............................................ 16
DISASSEMBLY PROCEDURES ............................. 17-19
UPDATING FIRMWARE ..........................................20-29
SELF-DIAGNOSTIC FUNCTION ............................30-66
.......................................................................................67
1 0 1 1 4 7
SERVICE MANUAL
E-mail: ycav-ysiss@gmx.yamaha.com

IMPORTANT NOTICE

Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury,
destruction of expensive components, and failure of the product to perform as specifi ed. For these reasons, we advise
all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or
the appointed service representative.
The presentation or sale of this manual to any individual or fi rm does not constitute authorization, certifi cation or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
DISPLAY DATA .......................................................68-69
IC DATA ...................................................................70-93
PIN CONNECTION DIAGRAMS .............................94-97
BLOCK DIAGRAMS .............................................. 98-101
PRINTED CIRCUIT BOARDS ............................. 102-122
SCHEMATIC DIAGRAMS ................................... 123-139
REPLACEMENT PARTS LIST ............................ 141-156
REMOTE CONTROL ........................................... 157-160
ADVANCED SETUP ............................................ 161-162
Copyright © 2009
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
AV RECEIVER
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'09.08

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha RX-V2065

  • Page 1: Table Of Contents

    This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    RX-V2065/HTR-6295 ■ TO SERVICE PERSONNEL AC LEAKAGE 1. Critical Components Information WALL EQUIPMENT TESTER OR Components having special characteristics are marked OUTLET UNDER TEST EQUIVALENT must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only)
  • Page 3: Front Panels

    Hävitä käytetty peristo valmistajan ohjeiden • Do not disassemble the batteries. mukaisesti. • Never heat batteries or throw them into fire. ■ FRONT PANELS Top view U model C, R, T, K, A, B, G, E, F, L models Front view RX-V2065 (U model)
  • Page 4 RX-V2065/HTR-6295 RX-V2065 (C, R, K, A, B, G, E, F, L models) RX-V2065 (T model) HTR-6295 (C model)
  • Page 5: Rear Panels

    RX-V2065/HTR-6295 ■ REAR PANELS RX-V2065 (U model) RX-V2065 (C model) RX-V2065 (R model)
  • Page 6 RX-V2065/HTR-6295 RX-V2065 (T model) RX-V2065 (K model) RX-V2065 (A model)
  • Page 7 RX-V2065/HTR-6295 RX-V2065 (B, G, E, F models) RX-V2065 (L model) HTR-6295 (C model)
  • Page 8: Remote Control Panels

    RX-V2065/HTR-6295 ■ REMOTE CONTROL PANELS RAV296 RAV297 RAV298 (U model) (C, R, A, L models) (T, K, B, G, E, F models) RAV38 (U, C, R, T, K, A, B, G, E, F, L models)
  • Page 9: Specifications

    RX-V2065/HTR-6295 ■ SPECIFICATIONS ■ Audio Section Signal to Noise Ratio (IHF-A network) Minimum RMS Output Power (Power Amp. Section) PHONO (MM) to REC OUT (Input shorted 5 mV) (20 Hz to 20 kHz, 0.08 % THD, 8 ohms) U, C, R, T models ............ 86 dB or more FRONT L/R .............130 W + 130 W...
  • Page 10 [HTR-6295] Black color ................C model Bluetooth is a registered trademark of Bluetooth SIG and is used by Accessories Yamaha in accordance with a license agreement. Remote control ................x 1 Simplified remote control ..............x 1 Battery (R03, AAA, UM-4) .............x 2 Lithium battery (CR2025) ..............x 1...
  • Page 11 RX-V2065/HTR-6295 • DIMENSIONS “SILENT CINEMA” is a trademark of Yamaha Corporation. Top view SIRIUS, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. and its subsidiaries. All rights reserved. Service not available in Alaska and Hawaii.
  • Page 12 RX-V2065/HTR-6295 • SOUND FIELD PARAMETERS Category Program MOVIE ● Standard ● ● ● ● ● ● ● ● ● ● ● Spectacle ● ● ● ● ● ● ● ● ● ● ● Sci-Fi ● ● ● ● ● ●...
  • Page 13 RX-V2065/HTR-6295 • SET MENU TABLE MAIN MENU SUB-MENU PARAMETER VALUE [INITIAL VALUE] 1 • Speaker Setup 1 Auto Setup (YPAO) Extra Speaker Assignment [Zone2] / Zone2 + Zone3 / Presence / None EQ Type [Natural] / Flat / Front Start...
  • Page 14 RX-V2065/HTR-6295 MAIN MENU SUB-MENU PARAMETER VALUE [INITIAL VALUE] 3 • Function Setup 1 HDMI HDMI Control On / [Off] On / [Off] * This menu is available only when “HDMI Control” is Standby Through set to “Off” . [Amplifier] / TV / Amplifier + TV * This menu is available only when “HDMI Control”...
  • Page 15 RX-V2065/HTR-6295 MAIN MENU SUB-MENU PARAMETER VALUE [INITIAL VALUE] SURROUND DECODE Surround Decoder Pro Logic / PL IIx Movie / PL IIx Music / Decode Type Pro Logic PL IIx Game / Neo:6 Cinema / Neo:6 Music / Neural Sur. (U model)
  • Page 16: Internal View

    RX-V2065/HTR-6295 ■ INTERNAL VIEW OPERATION (2) P.C.B. OPERATION (9) P.C.B. (R, T, K, A, B, G, E, F, L models) HD RADIO TUNER (U model) VIDEO (4) P.C.B. OPERATION (8) P.C.B. ACDC (1) P.C.B. MAIN (1) P.C.B. DIGITAL (3) P.C.B.
  • Page 17: Disassembly Procedures

    RX-V2065/HTR-6295 ■ DISASSEMBLY PROCEDURES (Remove parts in the order as numbered.) Disconnect the power cable from the AC outlet. 1. Removal of Top Cover 2. Removal of Front Panel and Sub-Chassis Unit a. Remove 4 screws ( ① ), 5 screws ( ② ) and screw ( ③ ).
  • Page 18 RX-V2065/HTR-6295 3. Removal of GUI, DIGITAL (1) and (3) P.C.B.s 4. Removal of AMP Unit a. Remove 2 screws ( ⑦ ). (Fig. 2) a. Remove 3 screws ( ⑬ ) and 4 screws ( ⑭ ). (Fig. 2) b. Remove 3 screws ( ⑮ ). (Fig. 2) b.
  • Page 19 RX-V2065/HTR-6295 When checking the P.C.B.s: • Place the P.C.B.s (with rear panel) upright. (Fig. 3) • Connect the ground points of the heatsink, rear panel and MAIN (1) P.C.B. (G1000) to the chassis with a ground lead or the like. (Fig. 3) •...
  • Page 20: Updating Firmware

    RX-V2065/HTR-6295 ■ UPDATING FIRMWARE Note) The user memories (sound field parameters, system memory, tuner presetting, etc.) are preserved even after the firmware is written. When replacing the following parts, be sure to write the latest firmware. Replaced parts Writing method using the USB Writing method using PC (RS232C) DIGITAL P.C.B.
  • Page 21 RX-V2065/HTR-6295 Supplementary information: In this unit, it is possible to check the firmware version by using the ADVANCED SETUP menu as well as the self- diagnostic function menu. Follow the procedures below. 1. While pressing the “STRAIGHT” key of this unit, press the “MAIN ZONE ON/OFF” key of this unit to turn on the power.
  • Page 22 • USB storage device • Firmware RX-V2065 : RX-V2065_xxxx.bin HTR-6295 : HTR-6295_xxxx.bin ● Preparation 1. Download the latest firmware from the specified download source to the folder of the PC. 2. Copy the latest firmware from the PC to the root folder of the USB storage device.
  • Page 23 RX-V2065/HTR-6295 3. When writing of the firmware is completed, “UPDATE SUCCESS” is displayed. When “UPDATE FAIL” is displayed before writing is completed, perform the operation procedures from step 1 to 2 again. 4. Press the “MAIN ZONE ON/OFF” key of this unit to turn off the power.
  • Page 24 RX-V2065/HTR-6295 Writing method using PC (RS232C) ● Required Tools ● Preparation and precautions • Download the firmware downloader program • Firmware downloader program and the firmware from the specified source to the For main microprocessor: same folder of the PC.
  • Page 25 RX-V2065/HTR-6295 ● Operation Procedures Writing to the main microprocessor With the power cable of this unit disconnected from the AC outlet, start up DSP_FLASHER_v3.0.exe. The screen appears as shown below. (Fig. 2) Click [...] and select the firmware name. (Fig. 2) V265xxxx.mot...
  • Page 26 RX-V2065/HTR-6295 Connect the power cable of this unit to the AC outlet. Click [E.P.] to start writing. (Fig. 3) When writing of the firmware is completed, “Program Finished!” is displayed. (Fig. 3) Click [OK]. (Fig. 3) Click [EXIT] to end DSP_FLASHER_v3.0.exe. (Fig. 3) Writing being executed.
  • Page 27 RX-V2065/HTR-6295 Writing to DSP With the power cable of this unit disconnected from the AC outlet, start up DSP_FLASHER Ver2.7.exe. The screen appears as shown below. (Fig. 4) Click [Vx61 DSP]. (Fig. 4) Fig. 4 Click [...] and select the firmware name. (Fig. 5)
  • Page 28 RX-V2065/HTR-6295 Click [RDY]. (Fig. 6) Fig. 6 While pressing the “PURE DIRECT” key of this unit, connect the power cable of this unit to the AC outlet. (Fig. 7) Writing is started automatically. (Fig. 7) This unit “PURE DIRECT” key Writing being executed.
  • Page 29 RX-V2065/HTR-6295 When writing of the firmware is completed, “Vx61 DSP Flash finished!” is displayed. (Fig. 3) Click [EXIT] to end DSP_FLASHER_v2.7.exe. (Fig. 8) Fig. 8 Start up the self-diagnostic function and select “25.ROM VER/SUM/PORT” menu. Using the sub-menu, have the firmware version and checksum displayed, and then check that they are the same as written ones.
  • Page 30: Self-Diagnostic Function

    RX-V2065/HTR-6295 ■ SELF-DIAGNOSTIC FUNCTION CAUTION! Do not disconnect the power cable of this unit from the AC outlet while this unit is in the self-diagnostic function mode, otherwise the user memories (input rename, sound field parameters, system memory, tuner presetting, etc.) will be initialized.
  • Page 31 RX-V2065/HTR-6295 Main menu Sub-menu VIDEO CHECK DIGITAL COMPONENT DIGITAL CVBS DIGITAL Y/C (B, G, E, F models) ANALOG BYPASS TEST PATTERN VIDEO INFORMATION XM STATUS (U model) 1k -1dB /44kHz 1k -61dB /44kHz Mute /44kHz XM Tone /44kHz ISO Tone /44kHz...
  • Page 32 RX-V2065/HTR-6295 Main menu Sub-menu IF STATUS (Not applied to these models.) DSP STATUS BUS CHECK TI BUS BF LOOP NO MENU Invalidity PROTECTION HISTORY HISTORY 1 HISTORY 2 HISTORY 3 HISTORY 4 NO MENU Invalidity UPDATE TI FLASH BOOT (Not applied to these models.)
  • Page 33 RX-V2065/HTR-6295 ● Starting Self-Diagnostic Function While pressing those 2 keys of this unit as shown in the figure below, press the “MAIN ZONE ON/OFF” key to turn on the power. The self-diagnostic function mode is activated. Keys of this unit U, C, R, K, A, B, G, E, F, L models While pressing these keys, turn on the power.
  • Page 34 RX-V2065/HTR-6295 ● Display provided when Self-Diagnostic Function started The display is as described below depending on the situation when the last time the power to this unit is turned off. 1. When the power is turned off by usual operation: The FL display of this unit displays “NO PROTECT”...
  • Page 35 RX-V2065/HTR-6295 2-2. When the protection function worked due to a short between speaker terminals. I P R O T E C T : x x x AD value when the protection function is working Cause: The line between speaker terminals is shorted.
  • Page 36 RX-V2065/HTR-6295 2-4. When the protection function worked due to abnormal voltage in the power supply section. P R V P R T : x x x AD value when the protection function is working Cause: The voltage in the power supply section is abnormal.
  • Page 37 RX-V2065/HTR-6295 ● Operation procedure of Main menu and Sub-menu There are 27 main menu items, each of them having sub-menu items. Main menu selection Select the main menu using “PROGRAM” knob. Sub-menu selection Select the sub-menu using “SCENE RADIO” (forward) and “SCENE CD” (reverse) keys.
  • Page 38 RX-V2065/HTR-6295 ● Details of Self-Diagnostic Function menu 1. BYPASS Using the sub-menu, it is possible to select ANALOG BYPASS output or DSP BYPASS output. ANALOG BYPASS The analog input audio signal is output to FRONT L/R in PURE DIRECT. 1 . A N A L O G B Y P A S...
  • Page 39 RX-V2065/HTR-6295 DSP BYPASS FL / FR LC89058 (DECODE) C / SW (POST PROCESSING) TI D70Y SL / SR SBL / SBR PCM1803 DRAM (Shaded items not used in this example) 2. RAM THROUGH Using the sub-menu, it is possible to select MARGIN output or FULL BIT output.
  • Page 40 RX-V2065/HTR-6295 RAM FULL BIT The audio signal is output in digital full bit without including the head margin. The SUBWOOFER signal is output but not in digital full bit. 2 . R A M F U L L A L L...
  • Page 41 RX-V2065/HTR-6295 RAM FULL CENTER The audio signal is output to only CENTER in digital full bit without including the head margin. 2 . R A M F U L L C INPUT: AV5 ANALOG SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz...
  • Page 42 RX-V2065/HTR-6295 3. HDMI AUDIO Using the sub-menu, the audio signals input to HDMI IN are selected and output. When selecting “DSD”, be sure to connect an HDMI unit equipped with DSD output function to this unit. SPDIF 3 . S P D I F SPDIF signal is output.
  • Page 43 RX-V2065/HTR-6295 FRONT : SML 0dB 4 . F R N T : S M L 0 d B The FRONT L/R signal, when 90 Hz or lower, is mixed to the channel specified by LFE/BASS. CENTER : NONE 4 . C E N T E R : N O N E The CENTER signal is assigned to FRONT L/R.
  • Page 44 RX-V2065/HTR-6295 5. MULTI CH-INPUT The input source “MULTI CHANNEL INPUT” is selected. Using the sub-menu, it is possible to select the 6 ohms/8 ohms. When LIM / PLDET / THM menu is selected, keys become non-operable. However, it is possible to advance to the next main menu by turning the “PROGRAM” knob of this unit.
  • Page 45 RX-V2065/HTR-6295 LIM / PLDET / THM LIM: Setting value of LIM (Limiter control) Do not change the value settings because this menu is only for the use of development staff. PLDET: Power limiter detection The A/D conversion value during operation is displayed.
  • Page 46 RX-V2065/HTR-6295 FL/GUI CHECK This menu is used to check the FL display and video control sections. When checking the video control section, connect a TV monitor to this unit with a component video cable and video pin cable. Using the sub-menu, the FL display section or video control section switches as shown below.
  • Page 47 RX-V2065/HTR-6295 8. MANUAL TEST The built-in noise generator of DSP outputs the test noise through the channels specified by using the sub-menu. The noise frequency for LFE is 30 to 80 Hz. Other than that, the noise frequency is 500 Hz to 2 kHz.
  • Page 48 RX-V2065/HTR-6295 DC/TH Power amplifier DC (DC voltage) output is detected. Normal value: 32 to 74 (Reference voltage: 3.3 V=255) Temperature on the heatsink is detected. Normal value: 0 to 124 (Reference voltage: 3.3 V=255) If DC or TH becomes out of the normal value range, the protection function works to turn off the power.
  • Page 49 RX-V2065/HTR-6295 DST/DK DST: Destination detection (Reference voltage: 3.3 V=255) DOCK type detection (Reference voltage: 3.3 V=255) D S T : 2 1 1 D K : 2 5 5 Destination detection for AD port Pull-up resistance 10 k-ohms Ohm (R3809 VIDEO P.C.B.) 1.2 k...
  • Page 50 RX-V2065/HTR-6295 10. VIDEO CHECK I2C check The I2C (Inter integrated circuit) bus line connection is checked. 0 : No error detected I 2 C : 0 0 0 0 0 0 0 0 1-3 : An error is detected 0 bit : SCALER (IC71, DIGITAL P.C.B.) 1 bit : VIDEO ENCODER (IC72, DIGITAL P.C.B.)
  • Page 51 RX-V2065/HTR-6295 Digital CVBS (Video) The video signal is converted and output as shown below. D I G I T A L C V B S Digital CVBS (Video) DIGITAL DIGITAL IC71 IC7/15 ABT1012 DIGITAL DIGITAL Sil9134 I/P SCALER IC1/2 IC70...
  • Page 52 RX-V2065/HTR-6295 Analog bypass The video signal is converted and output as shown below. A N A L O G B Y P A S S Analog bypass DIGITAL DIGITAL IC71 IC7/15 ABT1012 DIGITAL DIGITAL Sil9134 I/P SCALER IC1/2 IC70 Sil919185A...
  • Page 53 RX-V2065/HTR-6295 11. XM STATUS (U model) This menu is used to check the output of XM Radio Antenna. 1 kHz, -1 dB / 44.1 kHz 1 k - 1 d B / 4 4 The test tone (1 kHz, -1 dB / 44.1 kHz) is output.
  • Page 54 RX-V2065/HTR-6295 12. SIRIUS (U model) The SIRIUS information are displayed. SIRIUS: S I R I U S : - - Connection of the SIRIUS antenna module is checked. OK : Normal NG : Abnormal - - : No connected S R : F F 0 0 F F The connection information of the SIRIUS antenna module is displayed.
  • Page 55 RX-V2065/HTR-6295 14. DOCK This menu is used to check the DOCK connector without the iPod itself. With the power to this unit turned off, short between pins No. 14 (TX) and No. 18 (RX), between pins No. 1 (PWR) and No.
  • Page 56 The product ID of this unit written in HDMI module is displayed. 3143 : RX-V2065 3144 : HTR-6295 HDMI vendor name V N : Y A M A H A The vendor name “YAMAHA” of this unit written in HDMI module is displayed.
  • Page 57 RX-V2065/HTR-6295 16. HDMI SELECT Using the sub-menu, the selected input signal is output to HDMI OUT. Support audio is set to “OTHER”. HDMI none H D M I N O N E No signal is output. HDMI in 1 H D M I I N 1 The signal input from HDMI “IN 1”...
  • Page 58 RX-V2065/HTR-6295 HDMI up-conversion through DIGITAL DIGITAL IC71 IC7/15 ABT1012 DIGITAL DIGITAL Sil9134 I/P SCALER IC1/2 IC70 Up-conversion Sil919185A ADV7800 through VIDEO DIGITAL DECODER IC72 ADV7172 IC506 VIDEO ENCODER AK8814 17. USB The music file stored in the USB storage device is reproduced.
  • Page 59 RX-V2065/HTR-6295 18. IF STATUS (Input function status) Not applied to these models. DSP status D S T : 7 1 0 E 0 F 2 3 9 0 19. BUS CHECK Communication and bus line connection between devices on the DIGITAL P.C.B. are checked.
  • Page 60 RX-V2065/HTR-6295 21. PROTECTION HISTORY The history of protection function is displayed. Select this menu and press the “STRAIGHT” key, all history will be erased. Example History 1 2 1 - 1 . D c x x x L H : When the upper limit of the protection function is exceeded.
  • Page 61 RX-V2065/HTR-6295 23. UPDATE Not applied to these models. UPDATE TI 2 3 . U P D A T E T I 24. FACTORY PRESET This menu is used to reserve/inhibit initialization of the back-up IC. PRESET INHIBIT (Initialization inhibited) / PRESET INHIBIT 2 4 .
  • Page 62 RX-V2065/HTR-6295 25. ROM VER/SUM/PORT The firmware version, checksum values, model name and destination are displayed. The checksum is obtained by adding the data at every 8-bit for each program area and expressing the result as a 4-figure hexadecimal data. The figures in the diagram are given as reference only.
  • Page 63 The model name and destination are displayed. V 2 0 0 0 U 0 2 7 MODEL detection value Detection value 15 – 46 Model name V2 (RX-V2065) H9 (HTR-6295) DESTINATION detection value Detection value 15 – 45 46 – 68 69 – 92 92 –...
  • Page 64 RX-V2065/HTR-6295 26. SERIAL RS-232C loop back check This menu is used to check transmission and reception of the data, and the flow port of hardware. With the power to this unit turned off, short between pins No. 2 (RxD) and No. 3 (TxD), and between pins No. 7 (RTS) and No.
  • Page 65 When IC513 of GUI P.C.B. or GUI P.C.B. is replaced, use this menu to restore the previous MAC address number. Yamaha Corporation will provide the setting procedure for proper operation. Please report the serial number of this unit to the following e-mail address for further instruction.
  • Page 66 RX-V2065/HTR-6295 LINK CHECK A network cable connection is checked. 2 7 . N E T L N K : O K OK: Normal NG: Unconnected NETWORK loop back check This menu is used to check the NETWORK connector. With the power to this unit turned off, short between pins No. 1 (Tx+) and No. 3 (Rx+) and between pins No. 2 (Tx-) and No.
  • Page 67: Confirmation Of Idling Current Of Amp Unit

    RX-V2065/HTR-6295 ■ CONFIRMATION OF IDLING CURRENT OF AMP UNIT ● Right after power is turned on, confirm that the voltage across the terminals of R1152 (SURROUND BACK Rch), R1154 (SURROUND Rch), R1150 (FRONT Rch), R1148 (CENTER), R1149 (FRONT Lch), R1153 (SURROUND Lch), R1151 (SURROUND BACK Lch) are between 0.1mV and 10.0mV.
  • Page 68: Display Data

    RX-V2065/HTR-6295 ■ DISPLAY DATA ● V4001 : 18-MT-09GNK (OPERATION P.C.B.) PATTERN AREA ● PIN CONNECTION Pin No. 68 67 Connection F2 NX 29 28 Pin No. Connection Note : 1) F1, F2 ..Filament pin 2) NP ..No pin 3) NX ..
  • Page 69 RX-V2065/HTR-6295 ● ANODE CONNECTION 1G-14G –...
  • Page 70: Ic Data

    RX-V2065/HTR-6295 ■ IC DATA IC44: D70YE101BRFP266 (DIGITAL P.C.B.) Decoder/Post processor * No replacement part available. SPI0_SIMO EM_CKE SPI0_SOMI/I2C0_SDA EM_CLK AXR0[0] EM_WE_DQM[1] AXR0[1] EM_D[8] AXR0[2] AXR0[3] EM_D[9] EM_D[10] AXR0[4] AXR0[5]/SPI1_SCS EM_D[11] AXR0[6]/SPI1_ENA AXR0[7]/SPI1_CLK EM_D[12] EM_D[13] EM_D[14] AXR0[8]/AXR1[5]/SPI1_SOMI EM_D[15] AXR0[9]/AXR1[4]/SPI1_SIMO EM_D[0] AXR0[10]/AXR1[3]...
  • Page 71 RX-V2065/HTR-6295 Function Name TYPE PULL GPIO Detail of Function (P.C.B.) AHCLKX0/AHCLKX2 – McASP0 and McASP2 transmit master clock AMUTE0 – McASP0 mute output AMUTE1 – McASP1 mute output AHCLKX1 – McASP1 transmit master clock ACLKX1 – McASP1 transmit bit clock...
  • Page 72 RX-V2065/HTR-6295 Function Name TYPE PULL GPIO Detail of Function (P.C.B.) EM_D[10] – EMIF data bus [lower 16-Bits] EM_D[9] – EMIF data bus [lower 16-Bits] CVDD EM_D[8] – EMIF data bus [lower 16-bits] EM_WE_DQM[1] – Write enable or byte enable for EM_D [15:8]...
  • Page 73 RX-V2065/HTR-6295 Function Name TYPE PULL GPIO Detail of Function (P.C.B.) 123 CVDD 124 VSS 125 DVDD McASP0 serial data 8 or McASP1 serial data 5 or SPI1 data pin slave 126 /SPI1_SOMI – out master in McASP0 serial data 9 or McASP1 serial data 4 or SPI1 data pin slave in 127 /SPI1_SIMO –...
  • Page 74 RX-V2065/HTR-6295 IC402: M66003-0131FP (OPERATION P.C.B.) FL display driver Display code CGROM SEG00 (35-bit x 166) (8-bit x 60) Segment SEG25 Code output write SEG26 circuit CGROM SEG34 dot data Serial data (35-bit x 16) write receive Code/ circuit SDATA command...
  • Page 75 RX-V2065/HTR-6295 Pin No. Port Name Function Name Detail of Function Vcc1 Positive power supply for internal logic. SEG34 SEG33 SEG32 SEG31 SEG30 Segment output Connect to segment (anode) pins of VFD. SEG29 SEG28 SEG27 SEG26 Vcc2 Positive power supply for DIG and SEG outputs.
  • Page 76 RX-V2065/HTR-6295 IC41: LC89058WD-E (DIGITAL P.C.B.) Digital audio interface receiver MOUT AUDIO XMODE Fs calculator GPIO0 Microcontroller 40 CL GPIO1 GPIO2 Cbit, Pc GPIO3 RXOUT2 RXOUT1 Input RERR Demodulation Selector & SDIN Data Lock detect Selector RDATA Clock RMCK Clock Selector...
  • Page 77 RX-V2065/HTR-6295 Pin No. Function Name Detail of Function RXOUT1 RX0-6 input S/PDIF through output pin 1 5V withstand voltage TIL input level compatible S/PDIF input pin (connected to GND when RX1 is (pd) set) I(pd) Co-axial compatible S/PDIF input pin (supported demodulation sampling frequency of up to 96 kHz)
  • Page 78 RX-V2065/HTR-6295 IC153: R2A15220FP (MAIN P.C.B.) 8-channel electronic volume with 11 input selector and tone control 49 48 46 45 38 37 34 33 MUTE TRER AVEE AVCC BASSR2 A VEE BASSR1 ADCL 0/-6/-12/-18dB TREL ADCR SUB2 AGND BASSL2 MAIN INR1...
  • Page 79 RX-V2065/HTR-6295 Pin No. Port name Function Name Detail of Function AGND Analog ground of internal circuit SBROUT VOSBL Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel SBR Pre-OUT VOPSBL Pre-output pin of FL/FR/SL/SR/SBL/SBR channel SBRC Connects capacitor for reducing click noise of L/R/C/SW/SL/SR/SBL/SBR channel volume...
  • Page 80 RX-V2065/HTR-6295 Pin No. Port name Function Name Detail of Function INR2 AU1L Input pin of L/R channel (Input selector) INL2 AU1R Input pin of L/R channel (Input selector) INR3 AV-6L Input pin of L/R channel (Input selector) INL3 AV-6R Input pin of L/R channel (Input selector)
  • Page 81 RX-V2065/HTR-6295 IC20: M3087BFKBGP (DIGITAL P.C.B.) Main microprocessor Port P0 Port P1 Port P2 Port P3 Port P4 Port P5 Port P6 < > < > CC1 (3) Peripheral Functions Clock Generation Circuit A/D Converter: 1 circuit Timer (16 bits) Standard: 10 inputs...
  • Page 82 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) TXD4 SCPU_MOSI Synchronous data output for SubCPU CLK4 SCPU_SCK Synchronous clock output for SubCPU P95/ANEX0/CLK4 P94/DA1/TB4in/ SCPU_CTS Input for transmission control for SubCPU (clear to send) CTS4/RTS4/SS4 P93/DA0/TB3in/ AMP_LMT Limiter control output...
  • Page 83 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) /RESET /RESET MCU MCU MCU MCU [MCU] Reset /RESET Xout Xout MCU MCU MCU MCU [MCU] 20 MHz ceramic resonator Xout MCU MCU MCU MCU [MCU] MCU MCU MCU MCU [MCU]...
  • Page 84 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) TxD1 RS232C data output P67/TXD1/SDA1/ 232C_MOSI Pull up at 100 k-ohms SRXD1 TxD1 E8a, ICP (In-Circuit Programmer) data output Vcc1 Vcc1 MCU MCU MCU MCU [MCU] Microprocessor power supply Vcc1 RxD1...
  • Page 85 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) P133 HTX_VSEL P133/OUTC23 MCU MCU MCU MCU [MCU] Microprocessor GND Video I/P & Scaler IC reset P132 ABT_N_RST VID_PON=L: Low fix P132/OUTC26 L: reset Vcc2 Vcc2 MCU MCU MCU MCU [MCU]...
  • Page 86 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) Speaker impedance relay control GND pull down SP_IMP [HiZ] Set to 8 ohms: Hi-Z (Relay OFF, B voltage High) Set to 6 ohms plus during rising temperature: High (Relay ON, B...
  • Page 87 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) XM Radio power supply ON/OFF control XM_PON (U model) P14/D12 H: ON, L: OFF (C, R, T, K, A, B, G, E, F, L, J models) DOCK power supply ON/OFF control...
  • Page 88 RX-V2065/HTR-6295 Function Port Name Name Detail of Function (P.C.B.) ISRXD0 P152/AN152/ E2R_MISO Synchronous data input for EEPROM ISRXD0/RXD5 ISCLK0 FL driver, OSD, IO extended IC (Video), EEPROM synchronous clock P151/AN151/ FLD_SCK output ISCLK0/CLK5 Inhalation attention of power supply off device...
  • Page 89 RX-V2065/HTR-6295 Key detection for A/D port Key input (A/D) pull-up resistance 10 k-ohms +1.0k +1.0k +1.5k +1.5k +2.2k +3.3k +4.7k +22.0k +33.0k 0 – 0.15 0.15 – 0.42 0.43 – 0.70 0.71 – 0.97 0.98 – 1.24 1.25 – 1.53 1.54 –...
  • Page 90 RX-V2065/HTR-6295 IC505: AD91089ZSKBC (GUI P.C.B.) Sub-microprocessor * No replacement part available. Event controller/ JTAG test Watch dock timer and emulation Core timer Real time clock Voltage regulator UART port IrDA® Memory L1 instruction L1 data management memory memory unit Timer0, Timer1, Timer2...
  • Page 91 RX-V2065/HTR-6295 Memory Interface Synchronous memory control Function Name Detail of Function Function Name Detail of Function 121 ADDR19 167 SRAS O Row address strobe 122 ADDR18 166 SCAS O Column address strobe 123 ADDR17 165 SWE O Write enable 173 SCKE...
  • Page 92 RX-V2065/HTR-6295 JTAG port Clock Function Name Detail of Function Function Name Detail of Function 94 TCK JTAG clock Clock/Crystal input (This pin needs to 10 CLKIN be at a level or clocking.) 87 TDO O JTAG serial data out 11 XTAL...
  • Page 93 RX-V2065/HTR-6295 Supplies Function Name Detail of Function Function Name Detail of Function VDDEXT I/O power supply VDDINT Core power supply G External ground 18 VDDRTC Real-time clock power supply...
  • Page 94: Pin Connection Diagrams

    RX-V2065/HTR-6295 ■ PIN CONNECTION DIAGRAMS • ICs 74LVC08APW 74LVC1G08GW 74LVC245APW,118 CS230003-CZZR CXB1442AR-T4 74LVC32APW ABT1012Q100 ADV7800BSTZ-80 ADV7172KST BA00JC5WT-V5 LAN9217-MT AD91089ZSKBC AK8814VQ SiI9134CTU BD9323EFJ-E2 D70YE101BRFP266 FHP3350IM14X K4S641632N-LC60000 M3087BFKBGP SiI9233ACTU F2621E-01-TR ISL83385EIBZ-T ISP1760BE KIA7912PI K4S560832J-UC75000 K8P6415UQB-PI4B000 LA73050-TLM-E LC709004A-TLM-E LC72725KM-UY-TLM-E...
  • Page 95 RX-V2065/HTR-6295 LC89058WD-E LE25LB2562M-TLM-E LM19CIZ/LF M66003-0131FP-R NE5532DR NJM2068MD-TE2 LE25LB643M-TLM-E NJM4565M (TE1) NJM2388F05 NJM2396F05 NJM2581M NJM2867F3-05 NJM7812FA NJM78M05DL1A (TE1) 1. IN 1. V 2. V 1: INPUT 2. V 3: IN 3. GND 2: GND 3. GND 1: OUT 2: COM 4. ON/OFF CONTROL 3: OUTPUT 4.
  • Page 96 RX-V2065/HTR-6295 • Diodes 1N4002S 1SS355 D15XBN20-7001 15A HT18G 1SS133 1SS176 Anode Anode Anode – Cathode Cathode Cathode + AC MAZ8033GHL 3.4V MTZJ10B MTZJ5.1B RB051L-40 P6KE100A UDZ5.1B MTZJ12B MTZJ5.1C MAZ8036GLL 3.5V MTZJ13B MTZJ6.8C MTZJ2.4B MTZJ22C Anode Anode Anode MTZJ3.3B Anode MTZJ39D...
  • Page 102: Printed Circuit Boards

    CB73 CB25 CB71 IC73 IC74 IC71 IC51 IC11 IC21 CB45 IC44 IC15 IC45 IC40 IC61 IC66 IC65 IC68 CB64 CB62 CB61 CB63...
  • Page 106 SW417 SW407 SW410 SW409 SW411 SW406 SW403 SW413 SW401 SW415 SW421 JK401 SW443 CB401 CB402...
  • Page 108 CB453 JK451...
  • Page 110 CB477...
  • Page 112 IC101 W117A CB157 CB152 CB153 CB154 CB155...
  • Page 116 CB349 IC334 CB303 CB332...
  • Page 124 Port P7 Port P8 Port P9 Port P10 < >...
  • Page 125 Sense AMP...
  • Page 137 Sense AMP...
  • Page 140: Replacement Parts List

    RX-V2065/HTR-6295 ■ REPLACEMENT PARTS LIST • ELECTRICAL COMPONENT PARTS WARNING ● Components having special characteristics are marked and must be replaced with parts having specifications equal to those originally installed. ABBREVIATIONS IN THIS LIST ARE AS FOLLOWS: C.A.EL.CHP : CHIP ALUMI.ELECTROLYTIC CAP L.EMIT...
  • Page 141 RX-V2065/HTR-6295 P.C.B. DIGITAL Ref No. Part No. Description Markets Ref No. Part No. Description Markets 95 2%$ &+)+6#. 75 %%'%*2 R( 8 $ 95 2%$ &+)+6#. %46-#. 8 9& %%'%*2 W( 95 2%$ &+)+6#. %  % 75 %%'%*2 W( 95 2%$ &+)+6#.
  • Page 142 RX-V2065/HTR-6295 P.C.B. DIGITAL Ref No. Part No. Description Markets Ref No. Part No. Description Markets % 75 %%'%*2 W( 8 $ % 75 %%'%*2 W( % 75 %%'%*2 W( % 75 %%'%*2 W( % 74 %'. W( % 75 %%'%*2...
  • Page 143 RX-V2065/HTR-6295 P.C.B. DIGITAL Ref No. Part No. Description Markets Ref No. Part No. Description Markets % 75 %%'%*2 W( % 9& %%'%*2 W( % 8< %%'%*2 W( % 74 %'. W( % 8< %%'%*2 W( 8 - % 9, %/;.#4...
  • Page 144 RX-V2065/HTR-6295 P.C.B. DIGITAL and P.C.B. OPERATION Ref No. Part No. Description Markets Ref No. Part No. Description Markets +% :5# +% 0,//&.# :. 8 4504%4;5 /*\ +% :# +% 2%/&$34 :. 8< 4504%4;5 /*\ +% :# +% 2%/&$4 +% :$ +% 6%8*%6#(6 '.-...
  • Page 145 RX-V2065/HTR-6295 P.C.B. OPERATION Ref No. Part No. Description Markets Ref No. Part No. Description Markets % 75 %%'%*2 R( 8 $ % 75 %%'%*2 R( 8 $ % 75 %%'%*2 W( % 9, %/;.#4 R( % 75 %%'%*2 R(...
  • Page 146 RX-V2065/HTR-6295 P.C.B. OPERATION and P.C.B. MAIN Ref No. Part No. Description Markets Ref No. Part No. Description Markets 59 9& 596#%6 5-4)##& % 75 %%'%*2 R( 8 $ 59 9& 596#%6 5-4)##& % 74 %'. W( 59 9& 596#%6 5-4)##&...
  • Page 147 RX-V2065/HTR-6295 P.C.B. MAIN and P.C.B. VIDEO Ref No. Part No. Description Markets Ref No. Part No. Description Markets % 75 %%'%*2 W( 4 *( 4%#4 9 % 75 %%'%*2 W( 8 $ 4 *8 4%#4(2 9 & 84 &+1&'%*2 /# (.#6 62...
  • Page 148 RX-V2065/HTR-6295 P.C.B. VIDEO Ref No. Part No. Description Markets Ref No. Part No. Description Markets % 75 %%'%*2 W( % 9, %/;.#4 W( 8 , % 74 %'. W( % 9, %/;.#4 W( % 75 %%'%*2 W( % 75 %%'%*2...
  • Page 149 RX-V2065/HTR-6295 P.C.B. VIDEO and P.C.B. GUI Ref No. Part No. Description Markets Ref No. Part No. Description Markets 3 9) 64 -6#;72 % 75 %%'%*2 W( 3 K#+ 64 5# ; % 75 %%'%*2 R( 8 $ 3 K%+ 64 5% ;...
  • Page 160: Advanced Setup

    RX-V2065/HTR-6295 ■ ADVANCED SETUP...
  • Page 161 RX-V2065/HTR-6295...
  • Page 162 RX-V2065/HTR-6295 MEMO...
  • Page 163 RX-V2065/HTR-6295...

This manual is also suitable for:

Htr-6295

Table of Contents
