Meter Description

CL200 Front Panel Description
®
The ExStik's keys have functions which
change depending on the electrode
attached (pH, ORP or Chlorine). Key
descriptions here apply for the ExStik
a chlorine electrode attached.
1. Battery compartment
2. LCD Display
3. MODE/HOLD button (store data)
4. CAL/RECALL button (change temperature units
and recall data. Calibration not required
for chlorine)
5. ON/OFF button
6. Electrode Collar
7. Electrode
(Note: The Electrode cap is not shown)
®
ExStik CL200 Display
1. Bargraph display
2. Measurement display
3. BAT (low battery) and
HOLD (data hold) indicators
4. Temperature display
5. Bargraph scale designations
6. Unit of measure
Accessories
•
®
CL203 – ExTab
•
CL205 – Spare chlorine electrode
•
EX006 – Weighted base with 5 solution cups
•
PH100 – pH Electrode
•
RE300 – ORP Electrode
•
EX007 – Solution cups (24 pack)
Reagent tablets (10-pack for 100 tests)
3
®
with
1
2
3
4
5
6
CL200 V6.0 06/05
