- Page 1 A F F I N I T Y S e r i e s 7 0 0 / 9 0 0 S o l t r o n L-7 0 / S o l t r o n X L-7 5 o r C u s t o m D e s i g n s 12 min O P E R AT I N G I N S T R U C T I O N S...
-
Page 3: Operating Instructions
Operating Instructions Type 155023316XXXXXX35 Type 155033316XXXXXX35 Ergoline AFFINITY 700 (AC plus) Ergoline AFFINITY 900 Temptronic Soltron L-70 (AC plus) Soltron XL-75 Temptronic or Custom Designs or Custom Designs 1015420-00 / us / 11.2014... -
Page 4: Contact Information
Contact information Contact information Technical Service JK Products & Services, Inc. #1 Walter Kratz Drive Jonesboro, AR 72401 Phone: 800-445-0624 (toll-free) Fax: 870-935-9046 e-mail: support@jkamerica.com http://support.jkamerica.com WARNING! Read these operating instructions. Failure to observe these instructions: • may result in serious injury and death, •... -
Page 5: Table Of Contents
Table of contents Table of contents Important information on tanning ..........6 Skin types ..................6 Tanning times .................. 6 General ................... 7 Definitions ..................7 Identify your tanning device ............7 Safety notes ................... 8 Description of warning signs ............8 Instructions pertaining to a risk of fire, electric shock, or injury .. - Page 6 Table of contents 6.3.3 Navigation unit ................23 6.3.4 Navigation ..................23 Functions ..................25 6.4.1 Operating panel ................25 Start ....................28 6.5.1 Preparation time ................28 6.5.2 Interrupt or end tanning session ............ 28 Connect MP3 player ..............29 Cleaning and maintenance ............
- Page 7 Table of contents Technical data ................59 Power rating, electrical specifications and noise level ....59 Dimensions ................... 60 Lamp configuration ................ 62 8.3.1 Type 155023316XXXXXX35 ............62 8.3.2 Type 155033316XXXXXX35 ............63 Spare parts and accessories ............64 JK-Products, Inc. – Limited Warranty ........65 Limited Acrylic Warranty ...............
-
Page 8: Important Information On Tanning
Important information on tanning Important information on tanning Skin types Skin type I (Sensitive): Invariably gets sunburn, accepts little natural sunlight and does not tan. Skin type II (Fair): Gets sunburn easily and severely, tans minimally or lightly and peels. Skin type III (Average): Often referred to as 'Average' complexion, gets moderate sunburns and tans about average. -
Page 9: General
General General Definitions Operator People who provide tanning devices to users on a commercial basis. The operator is responsible for the orderly operation of the device as well as com- pliance with the maintenance intervals. User A person who uses the tanning device at a commercial location. Staff People who are responsible for the operation, cleaning as well as general maintenance work and who instruct the users in the operation of the devices. -
Page 10: Safety Notes
Safety notes Safety notes Description of warning signs Danger notices, damage to persons: DANGER! Type and source of danger, e.g. 'DANGER – High voltage!' Description of the consequences, e.g. 'You can be killed or injured by an electric shock!' Countermeasures: –... -
Page 11: Instructions Pertaining To A Risk Of Fire, Electric Shock, Or Injury
Safety notes Instructions pertaining to a risk of fire, electric shock, or injury DANGER – HIGH VOLTAGE! You can be killed or injured by an electric shock! Assembly and electrical connection must comply with national and local regulations. – The device may only be assembled, installed, upgraded or repaired by specially trained and instructed person- nel. - Page 12 Safety notes WARNING! Follow instructions! – Medications (taken internally or otherwise) or cosmetics applied to the skin, may increase sensitivity to ultravio- let light. – A person having a history of skin problems should con- sult a physician before use. WARNING! Danger of long-term consequences! –...
- Page 13 Safety notes WARNING! Danger of ultra violet radiation. Ultra violet radiation - follow instructions. Failure to use protective eyewear may result in severe burns or other eye injury - if discomfort develops, discon- tinue use and consult a physician. – As with natural sunlight, overexposure can cause eye injury and sunburn;...
-
Page 14: Instructions Pertaining To A Risk Of Damage To The Machine
Safety notes Instructions pertaining to a risk of damage to the machine CAUTION! Danger of overheating by obstruction of the air routing! – Do not change, obstruct or block the air inflow and outflow area to the device or make any unauthorized changes to the device. -
Page 15: Information For The Studio Operator
Information for the studio operator Information for the studio operator Intended use The tanning device is intended exclusively for cosmetic tanning of the human skin. This device is used for tanning one adult person at a time. The user must wear suitable eye protection to block UV radiation during ... -
Page 16: Staff Training
Information for the studio operator Staff training As the operator you are obligated to train your personnel and instruct them in the established legal and accident prevention regulations. Ensure that your staff have understood and observe these instructions. This includes: information regarding intended use and foreseeable misuse ... -
Page 17: Export
Information for the studio operator CAUTION! Damage to the device possible! Where there are great differences in temperature between the transport route and the installation site the device may not be put into operation immediately after being set up. – Wait at least 2 hours before connecting the device to the power supply. -
Page 18: Disposal
Information for the studio operator 4.10 Disposal 4.10.1 Environmental regulations – disposal of lamps UV low pressure lamps and UV high pressure lamps contain fluorescent ma- terials and other waste containing mercury. According to the national waste disposal laws and in accordance with the municipal waste regulations, proof must be provided of the proper disposal of UV lamps. -
Page 19: Description
Description Description Scope of delivery Tanning device Lamps Air conditioning system (Type 155023316XXXXXX35: option, Type 155033316XXXXXX35: standard) Connecting lead Protective goggles Suction cup for filter panels Allen-key Technical documentation (folder with instructions, brochures for error ... -
Page 20: Device Description
Description Device description 1. Facial tanner (UV high pressure lamps + UV low pressure lamps) 2. Shoulder tanner with audio system (optional) loudspeaker (2.1), headphone connection (2.2), MP3-connction (2.3) 3. UV low pressure lamps, base 4. Partition (only for devices with air conditioning) 5. -
Page 21: Accessories (Optional)
Description Accessories (optional) 1. Central exhaust air socket 2. Audio system (with Voice Guide) 3. Shoulder tanner 4. Shoulder tanner with audio system (with Voice Guide) Function description Tanning The primary technical components of a tanning device are an artificial source of UV radiation, a variety of filters and reflectors as well as a mechanical structure with a defined active surface. -
Page 22: Operation
Operation Operation Mandatory reading Always read and follow all instructions for proper usage prior to allowing any- one to use the tanning device. The operating instructions included with this device must always be followed to prevent possible injuries. Inform users –... -
Page 23: Use The Tanning Device - But Use It Properly
Operation Use the tanning device – but use it properly! A few things need to be noted to in order to obtain maximum enjoyment from a tanning device. Here are some answers to frequently asked questions. Make-up in the tanning device? Please do not wear make-up. -
Page 24: Operation Overview
Operation Operation overview 6.3.1 Type 155023316XXXXXX35 AC 6.3.2 Type 155033316XXXXXX35 TEMPTRONIC 22/78... -
Page 25: Navigation Unit
Operation 6.3.3 Navigation unit 1. START/STOP button 2. OK button 3. Feature selection 4. Display – Functions … 6.3.4 Navigation Acknowledge selection.This button's availability is displayed on the Operating panel, depending on the function that has been selected. Select device function. Functions or settings can be activated, deactivated or changed. - Page 26 Operation NOTE: If a button is not pressed within 8 seconds, the settings re- turn to default mode. User settings overview All of a device's available functions can be pre-set on the control panel. Fine adjustment is carried out during use. NOTICE: Pressing and holding for 3 seconds opens the 'User...
-
Page 27: Functions
Operation Functions 6.4.1 Operating panel Icon Function / Description Information UV lamps: The tanning time continues to Switches the UV lamps on / off during if the UV lamps are switched the tanning session during tanning session. Select function. … Facial fan, Body fan, Facial tanner …... - Page 28 Operation Icon Function / Description Information Facial tanner: Regulate the facial tanner, levels 0 – 3 Switch the facial tanner off: Hold button ‘minus’ for 3 seconds 1 minute until up to maximum Switch the facial tanner on: Hold button power, then return to the previ- ‘plus’...
- Page 29 Operation Icon Function / Description Information Audio system The +/- buttons can be used to select titles for internal music in Select SD card: demo mode and during tan- Touch button ‘plus’ ning. Select Studio channel: Touch button ‘plus’ Select own music (e.g. MP3 player) AUX: Touch button ‘plus’...
-
Page 30: Start
Operation Start The device is started automatically with an internal or external timer. NOTE: Timer instructions see separate manual (order no. 1008370-..). 6.5.1 Preparation time Before the UV lamps turn on, you have a few minutes to prepare yourself. During the preparation time you can switch on the UV lamps at any time by pressing the START/STOP button. -
Page 31: Connect Mp3 Player
Operation Connect MP3 player DANGER! Danger of hearing damage! Using earphones or headphones at high volume can result in permanent hearing damage. – Do not set the volume too high. The user can connect their own private MP3 player or smartphone to the device. -
Page 32: Cleaning And Maintenance
Cleaning and maintenance Cleaning and maintenance Safety instructions for cleaning and maintenance DANGER – HIGH VOLTAGE! You can be killed or injured by an electric shock! During maintenance work there is a risk of touching live parts and receiving a fatal electric shock. –... -
Page 33: Faults
Cleaning and maintenance WARNING! Injuries and damage due to improper maintenance! If the maintenance intervals for the UV lamps are exceeded or incompatible UV lamps are installed, the share of UVB radiation may increase. Sunburn and other skin damage may result. Improper maintenance can cause the device to be damaged or to become unusable. -
Page 34: Cleaning
Cleaning and maintenance Cleaning WARNING! Infections can be transferred through skin contact. All items/equipment components, with which the user can come into contact during tanning, must be disinfected after every tanning session: – Protective goggles – Acrylic panel – Handles and control panel –... -
Page 35: Filter Panels And Lamps
Cleaning and maintenance Plastic surfaces For cleaning the remaining painted and unpainted plastic surfaces, it is best to use warm water and a cloth. Never use aggressive cleaning agents contain- ing alcohol or essential oils. These may lead to damages not covered by the warranty. -
Page 36: Maintenance
Cleaning and maintenance Component Interval Activity See page Adjustable air nozzles Cleaning and disinfection Acrylic panel Cleaning and disinfection Operating panel Cleaning and disinfection Multifunction control panel Cleaning and disinfection Protective goggles Cleaning and disinfection MP3 cable Cleaning and disinfection Condensation tank Empty Body cooling air nozzles, foot end... -
Page 37: Acrylic Panel
Cleaning and maintenance 7.5.1 Acrylic panel CAUTION! Cosmetics may cause cracks to form on the surface! Over the long-term cosmetics or sunscreens cause damage (e.g. crack formation on the surface). – Ensure that cosmetics and sunscreens are removed before tanning. The acrylic panels for the tanning devices are produced of acrylic glass de- veloped especially for this application. - Page 38 Cleaning and maintenance Component Interval Activity See page AQUA SYSTEM Replace 55, 57 7a-7b AROMA canister Replace Facial tanner UV high pressure lamps Replace 46, 47 Facial tanner UV-B low pressure lamps Replace (TYPE B) Shoulder tanner UV low pressure lamps Replace UV low pressure lamps, base Replace...
- Page 39 Cleaning and maintenance In addition to the maintenance plan on page 36, the following items should be checked to ensure safe operation and use of your tanning system. Component Interval Activity 1 Springs Inspect and replace as necessary Springs Replace 2 Bolts and fasteners of the canopy Inspect and replace as necessary hinge mechanism...
-
Page 40: Cleaning And Maintenance Work Preparation
Cleaning and maintenance Cleaning and maintenance work preparation 7.7.1 Lift up the acrylic panel and remove the partition – Remove the screws. – Lift up the acrylic panel. Lift up the supports and prop the acrylic panel on them. CAUTION! Risk of scratching! –... -
Page 41: Remove The Canopy Panel
Cleaning and maintenance – Replace and retighten the screws. 7.7.2 Remove the canopy panel – Turn the locks through 90°: first the outer locks, then the lock in the mid- dle. – Support the canopy panel with one hand so that it does not fall down. –... -
Page 42: Remove The Side Section Panel
Cleaning and maintenance 7.7.3 Remove the side section panel – Turn the locks through 90°. – Open the panel and lay it down carefully. When assembling the device please note: – Re-lock the locks. – Remove fingerprints and other soiling carefully. 40/78... -
Page 43: Open The Bed Base
Cleaning and maintenance 7.7.4 Open the bed base – Remove the screws. – Press the bed base gently downwards. – Release the lock at the head end. The assembly is the same process in reverse order. When assembling the device please note: –... -
Page 44: Instructions For Replacing The Lamps
Cleaning and maintenance Instructions for replacing the lamps WARNING! Danger of burns from hot lamps and device parts! If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot. – Before replacing lamps or other spare parts, wait until lamps and metal parts of the device have cooled down sufficiently. -
Page 45: Low Pressure Lamps
Cleaning and maintenance 7.8.1 Low pressure lamps WARNING! Danger of burns from hot lamps and device parts! If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot. – Before replacing lamps or other spare parts, wait until lamps and metal parts of the device have cooled down sufficiently. -
Page 46: Starter
Cleaning and maintenance – Turn the lamp 90°. The lettering must be oriented towards the outside (i.e. towards the tan- ning room or towards the user). 7.8.2 Starter Replace faulty starters immediately. You can recognize a faulty starter by the blackened ends of the lamps or when the lamps can no longer be started. - Page 47 Cleaning and maintenance – Release the clamping holder. – Lift the filter panel, pull it out of the guide and remove it. – Unplug the UV lamps. – Clean the reflector. – Only utilize original UV lamps. – Only touch new lamps in the handling zone. –...
-
Page 48: Cleaning Or Replacing Uv Lamps In The Base
Cleaning and maintenance Cleaning or replacing UV lamps in the base – Lift up the acrylic panel and the partition: see page 37. – Remove the lamp covers at the head and foot ends. Replacing lamps: see page 43. The assembly is the same process in reverse order. 7.10 Cleaning or replacing the UV lamps in the side section... -
Page 49: Cleaning Or Replacing Uv Lamps And Filter Panels In The Canopy
Cleaning and maintenance 7.11 Cleaning or replacing UV lamps and filter panels in the canopy – Removing the canopy panel: see page 39. – Remove the screws and then remove the lamp cover. The following components listed in the maintenance plan are fitted in the canopy: UV low pressure lamps: see page 43. -
Page 50: Cleaning Or Replacing The Uv Lamps And Filter Panels In The Shoulder Tanner
Cleaning and maintenance – Remove the two upper low pressure lamps in the canopy so that you can thenaccess the facial tanner's low pressure lamp starter. Replacing the lamps: see page 43. Replacing the starters: see page 44. UV high pressure lamps and filter panels: see page 44. The assembly is the same process in reverse order. -
Page 51: Cleaning The Filters In The Base
Cleaning and maintenance – Remove the screws and then remove the lamp cover. Replacing lamps: see page 43. Replacing starters: see page 44. The assembly is the same process in reverse order. When assembling the device please note: – The bed base must lock with an audible click when closed. 7.13 Cleaning the filters in the base –... -
Page 52: Cleaning The Canopy Filter Mats
Cleaning and maintenance – Cleaning the filters when wet or dry. Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Wet cleaning: Use water and detergent or put in a dish-washer CAUTION! The device may be damaged by moisture! The cleaned filters must be dry before they are replaced. -
Page 53: Cleaning The Filter Mats In Shoulder Tanner
Cleaning and maintenance CAUTION! The device may be damaged by moisture! The cleaned filters must be dry before they are replaced. – Reinstall the cleaned and dried filter mats. 7.15 Cleaning the filter mats in shoulder tanner – Opening the bed base: see page 41. –... - Page 54 Cleaning and maintenance – Dry or moist clean the filter mats or replace with new ones. Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Moist cleaning: Water and detergent – Do not clean in the dish-washer! WARNING! The device may be damaged by moisture! The cleaned filters must be dry before they are replaced.
-
Page 55: Air Conditioning: Empty The Condensation Tank And Clean The Filter
Cleaning and maintenance 7.16 Air conditioning: Empty the condensation tank and clean the filter CAUTION! Damage to the device through soiled filters and cooling fins! Regularly check the filter grill and cooling fins on the air conditioning system and clean if necessary. We recommend using the specially manufactured fin comb, art-no. - Page 56 Cleaning and maintenance – Remove the filter from the holder. – Cleaning the filter when moist or dry. Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Moist cleaning: Water and detergent – Do not clean in the dish-washer! –...
-
Page 57: Aqua / Aroma System Maintenance
Cleaning and maintenance CAUTION! The device may be damaged by moisture! The cleaned filters must be dry before they are replaced. – Reinstall the cleaned and dried filters. – Ensure that the filters are correctly positioned in the holder. Type 155033316XXXXXX35: –... -
Page 58: Changing The Aroma Canister
Cleaning and maintenance WARNING! Customer health hazard! Water that has been contaminated with bacteria can cause skin rashes and other allergic reactions in device users. – Therefore you must never fill the AQUA SYSTEM canister with tap water or other liquids. –... -
Page 59: Replacing The Aqua System Canister
Cleaning and maintenance – Unscrew the lid on the new canister. – Write the date on the canister. – Fit the canister in the holder. – Close the bed base. You should hear the bed base click into place. 7.17.2 Replacing the AQUA SYSTEM canister –... - Page 60 Cleaning and maintenance – Screw the lid with the hose onto the new canister. – Push the hose well down so that it touches the bottom of the canister. – Put the canister back in the device. – Close the bed base. You should hear the bed base click into place. Venting NOTE: To ventilate, access to the Professional Setup Manager is...
-
Page 61: Technical Data
Technical data Technical data Power rating, electrical specifications and noise level Type 155023316XXXXXX35 Nominal power consumption: 12,600 W Rated frequency: 60 Hz Rated voltage: 230 V 3 phase 230 V 1 phase Rated fuses: 40 amp 3-pole 80 amp 2-pole Noise level at 1 m distance from 67.2 dB(A) the device (without exhaust air):... -
Page 62: Dimensions
Technical data Dimensions 17401 / 0 Type 155023316XXXXXX35: Type 155033316XXXXXX35: B + = 54 1/4 in 1378 mm 58 4/16 in 1479 mm B = 52 5/16 in 1328 mm 56 10/16 in 1439 mm B - = 51 9/16 in 1309 mm 55 2/16 in 1400 mm... - Page 63 Technical data Type 155023316XXXXXX35: Type 155033316XXXXXX35: H 4 = 15 12/16 in 400 mm 15 12/16 in 400 mm H 5 = 4 1/2 in 114 mm 4 1/2 in 114 mm H 6 = 74 5/16 in 1887 mm 74 5/16 in 1887 mm H 7 = 77 11/16 in...
-
Page 64: Lamp Configuration
Technical data Lamp configuration CAUTION! The use of other UV lamps and filter panels voids the operating license! 8.3.1 Type 155023316XXXXXX35 Installed lamps Number Description Length Power Control Order no. UV high pressure lamps Ergoline ULTRA 520 W 420 W / 360 W / 12645-.. -
Page 65: Type 155033316Xxxxxx35
Technical data 8.3.2 Type 155033316XXXXXX35 Installed lamps Number Description Length Power Control Order no. UV high pressure lamps Ergoline ULTRA 520 W 420 W / 360 W / 12645-.. C12645 260 W / 0 W Filter panels Ultra Performance 1001524-.. UV low pressure lamps Genesis VHP12 25W 21 in 25 W... -
Page 66: Spare Parts And Accessories
Technical data Spare parts and accessories Number Description Order no. Filter 800278-.. Partition Type 155023316XXXXXX35 800666-.. Type 155033316XXXXXX35 800665-.. Acrylic panel Type 155023316XXXXXX35 1000744-.. Type 155033316XXXXXX35 1000756-.. Filter – Filter 51937-.. Filter 55567-.. AQUA SYSTEM, 1.59 gal (6 l) 3652603-.. AROMA, 3.38 fl oz (100 ml) CABIN 701358-.. -
Page 67: Jk-Products, Inc. - Limited Warranty
JK-Products, Inc. – Limited Warranty JK-Products, Inc. – Limited Warranty JK-Products, Inc. warrants its products to be free from defects in materials and workmanship under intended normal use as described in the unit's Oper- ation and Instruction Manual, for a period of three (3) years from date of sale. This Limited Warranty applies only to the original purchaser of the equipment through JK-Products, Inc. -
Page 68: Limited Acrylic Warranty
JK-Products, Inc. – Limited Warranty Limited Acrylic Warranty JK Products, Inc. warrants its acrylic sheets to be free from defects in material and workmanship, under intended normal use, for a period of one (1) year from date of sale of the tanning bed. Due to the tanning lotions, cosmetics, disinfectant and improper cleaners used on tanning surfaces that cannot be controlled by JK Products, Inc., after the first thirty (30) days of warranty peri- od acrylic will be subject to a prorated cost to the consumer. -
Page 69: Labor Warranty Claim/Credit Procedures
JK-Products, Inc. – Limited Warranty 2. Where to call to place a Warranty Claim: JK-Products, Inc. is supported nationwide by an extensive dealer/distributor network through whom the majority of our units are sold. These deal- ers/distributors are required by contract to stock sufficient parts to meet the various warranty and nonwarranty needs of their customers. -
Page 70: Limited Lifetime Warranty
JK-Products, Inc. – Limited Warranty Limited Lifetime Warranty Global Service USA warrants specific individual components of the tanning system against defects in materials and workmanship for the life of the prod- uct. Coverage is limited to units purchased after November 1, 1994. This warranty is restricted to the following components only: Steel Back Panels ... - Page 71 JK-Products, Inc. – Limited Warranty 11/2014 1015420-00 Operating instructions – 69/78...
- Page 72 JK-Products, Inc. – Limited Warranty 70/78...
-
Page 73: Appendix
Appendix Appendix 10.1 Signs and stickers on the device Signs which warn of danger areas are attached to the device. The signs shown below are examples. Ensure that the instruction signs are always clearly recognizable and easily legible. Any missing instruction signs or stick- ers must be replaced. - Page 74 Appendix 2: Module plate 3: Standards 4: OEM Parts sticker (801138-..) The sticker is mounted on the bottom edge at the front of the bed base and at the control box. 72/78...
- Page 75 Appendix 5: Exposure label 6: Warning sticker (801140-..) 11/2014 1015420-00 Operating instructions – 73/78...
- Page 76 Appendix 7: Lamp cover base sticker (801139-..) 8: Sticker (1014367-..) 9: USA mains connection sticker The sticker is mounted on the rear panel at the left. 10: Power unit components sticker (1501531-..) The sticker is mounted on the control box. 11: Connection terminal block sticker (1001767-..) The sticker is mounted on the control box.
- Page 77 Appendix 13: Air conditioning sticker (1002243-..) 13435 / 0 The sticker is mounted on the air conditioning. 14: ‘Only use original spare parts’ sticker (1002328-..) The sicker is mounted on the controller support. 15: SD card sticker (1002330-..) The sticker is mounted on the controller support. 11/2014 1015420-00 Operating instructions –...
- Page 78 Appendix Canada warning sticker (801371-..) The sticker is mounted on the rear panel. 76/78...
-
Page 79: Index
Index Index Accessories ......19, 64 Electric shock ......9 Acrylic glass (maintenance) ..32 Electrical specifications ..... 59 Acrylic panel (product Electrician ........7 information) ....... 35 Empty the condensation tank ..53 Acrylic panel, load ..... 59 Equipment ......... 17 Adolescents ...... - Page 80 Index Replacing the AQUA SYSTEM canister ..... 57 Maintenance ....30, 32, 34 Replacing the lamps ....42 Maintenance overview....35 Risk of injury ......20 Make-up ........21 Medications ......20 MP3 music ....... 15 Safety notices ......9 Scope of delivery ......
- Page 82 A F F I N I T Y S E R I E S 7 0 0 / 9 0 0 A D VA N C E D P e r f o r m a n c e J K - P ro d u c t s & S e r v i ce s , I n c . 1 Walter Kratz Drive Jonesboro, AR 72401 Phone: 800.643.0086 (Toll-free)
