IMPORTANT
OUT-A is your primary output and should always be used. It should be connected
to an amp that is properly grounded with a three prong U-ground for safety. Never
remove the safety ground on your amp as this is both illegal and there to protect
you from an electrical shock. Please consult your local electrical authority or
qualifi ed electronic technician for more details.
WARNING
Only connect electrical equipment that is properly grounded with a 3-prong AC plug.
Older amps with 2-prong plugs should be serviced before using them with any amp
switcher. An improperly grounded amp can be a very dangerous thing and never
should be used in multi-amp setups.
Radial Engineering takes no re spon si bil i ty for how the Switchbone V2 is connected or
used. It is the user's full re spon si bil i ty to ensure that proper electrical connections are
maintained on all equipment connected to the Switchbone V2 and that proper building
electrical codes have been followed wherever the Switchbone V2 is used.
Note that damage to the Switchbone V2 or other connected equipment caused by
improper wiring or improperly grounded equipment is not covered under the warranty.
Radial Engineering Ltd.
16
Switchbone V2
RADIAL SWITCHBONE • V2
USER GUIDE

Table of Contents

Introduction ............................................................................. 1
Features and Functions ....................................................... 2-3
Overview ............................................................................. 4-5
Making Connections ............................................................... 6
Standard ABY Setup............................................................ 7-8
Adding a Tuner or Third Amp............................................... 8-9
Baseline Buffer ..................................................................... 10
Power Booster ................................................................. 10-11
Slingshot Remote ................................................................. 12
Slingshot Internal Jumpers ................................................... 13
Block Diagram ................................................................. 14-15
Safety Information ................................................................ 16
Specifi cations ....................................................................... 17
Warranty .................................................................Back Cover
Thank you for purchasing the Tonebone Switchbone V2™. We
are confi dent that once you get to know the extended feature
set, you will come to appreciate the power and control that
is now underfoot! This being said, the Switchbone V2 is both
easy to use, yet featured-packed. So before you start plugging
in, please take the time to read through this manual. Not only
will it help you get the most out of it, it will save you time later
when trying to fi gure out new setups.
After your reading session, if you fi nd yourself wondering about
features that are not well explained or simply have a question,
log onto the Tonebone web site and visit the FAQ page. This
is where we post questions from users and updates. You can
also post a question and we will do our best to reply in short
order. Now get ready to enjoy what is likely the most powerful,
fl exible and cleanest sounding switcher you have ever tried.
Radial Engineering Ltd.
Page
1
Switchbone V2
