otee!
1
Please note that there can be small differences
between your product and the images in
these instructions.
otee!
1
Please note that during storage and transport,
especially at high ambient temperature, some
of the oil and grease used for assembly may
leak and stain the packaging. This will not
cause damage to the product, wipe off the
excessive oil or grease with a cloth.
Shock absorber for Honda CBR 1000 RR
ho 360
Mounting Instructions
Kit Contents
Description
Shock absorber
Sticker Memo notes
Sticker Öhlins wh/tr
Sticker Öhlins bl/tr
Screw M10
Owner's manual
otee!
1
Before you install this product, check the kit
contents. If anything is missing, please contact
an Öhlins dealer.
⚠
arninge!
Before you install this product, read the Öhlins
Owner's manual. This product is an important
part of the vehicle and the vehicle stability.
Part
o
Pcs
HO360
1
01180-01
1
01185-01
2
01185-04
2
01239-05
1
07242-05
1
Advertisement
Related Manuals for Ohlins HO 360
Summary of Contents for Ohlins HO 360
- Page 1 This will not cause damage to the product, wipe off the excessive oil or grease with a cloth. Shock absorber for Honda CBR 1000 RR ho 360 Mounting Instructions...
- Page 2 Mou tI g I StRuCtIo S ⚠ arninge! We strongly recommend to let an Öhlins dealer Install the Öhlins shock absorber. install this product. ⚠ arninge! Remove the lower left rear sub frame screw. If you work with a lifted vehicle, make sure that it use the screw provided in this kit and install the is safely supported to prevent it from tipping over.
- Page 3 Mou tI g I StRuCtIo S Link screw Fairing screw Reservoir Spring preload adjuster Rear wheel...
- Page 4 aDjuStMe tS Spring preload ⚠ arninge! adjuster Before you ride/drive, always make sure that the setup is according to the recommended setup data. Read about adjustments and setting up in the Öhlins Owner’s Manual before you make any adjustments. Contact an Öhlins dealer if you have any questions about setting up.
