Oase FILTOCLEAR 3.000 Warranty, Safety And Operating Instructions page 16

16
Cleaning the quartz tube
1. Disconnect the mains plug of the Filtoclear UVC.
2. Switch off the pump and make sure that it cannot be switched
on unintentionally.
3. Unscrew the four screws of the Filtoclear UVC and carefully
pull the lamp from the lid of the filter. Note: The screws are
screwed in very deep (approx. 0,7 inch) in order to allow greater
torque to be applied.
4. Clean the quartz tube with a damp cloth.
5. Pull out the flat seal and the protective tube between the lid and
the Filtoclear UVC and clean with water. Check the parts for
damage and replace if necessary. Fit the flat seal under the ring
of the protective tube (see illustration) and insert in lid together.
6. Insert the Filtoclear UVC in the lid of the filter and screw the
four screws on tight by hand (1,5 ft-lb).
7. Start the pressure filter up again. (see "Starting up the pressure
filter")
Replace UVC lamp
The UVC lamp must be replaced after 8.000 hours of operation in
order to ensure that the Filtoclear UVC continues to operate with
optimum effectiveness.
1. Disconnect the mains plug of the Filtoclear UVC.
2. Switch off the pump and make sure that it cannot be switched
on unintentionally.
3. Unscrew the four screws of the Filtoclear UVC and carefully
pull the lamp from the lid of the filter. Note: The screws are
screwed in very deep (approx. 0,7 inch) in order to allow greater
torque to be applied.
4. Unscrew the clamping screw in an anti-clockwise direction
and remove the quartz tube with O-ring.
5. Pull out the UVC lamp and replace it.
Note: Due to a built-in safety switch the UVC lamp only
works after complete assembly of the Filtoclear. Only lamps
of the type 9W UV-C, G23 may be used.
6. Clean the quartz tube with a damp cloth.
7. Check the quartz tube and O-ring for damage and replace if
necessary.
8. Screw the clamping screw with quartz tube and O-ring on tight
in a clockwise direction.
English
