SKYFi2 Home
14
Adapter Kit
(SA10103)
Your Delphi XM SKYFi2 Home Adapter
Kit contains the following components:
Setup
SKYFi2 Home Stand
6V AC power
adapter
Figure 7. SKYFi2 Home Adapter Kit components.
9/21/2006 12:09 PM Page 15
Hooking up Your
SKYFi2 Receiver Home Stand
Note: See SKYFi2 User Guide for important
user information.
XM High gain
Caution: Connect only the appropriate input
Indoor/Outdoor
devices to the SKYFi2 Home Adapter Kit jacks.
Home Antenna
Connecting any incorrect input device may
with 25 ft. cable
damage the system and/or the external elec-
tronic device. It is recommended that you use
only the AC power adapter that came with
your SKYFi2 Home Adapter Kit. If you need to
use a different adapter, it must be a 6V, 1000
mA DC adapter and must contain a unified
polarity-type jack, identified by the
symbol.
Audio cable
