10
Figure 3. Installing the vent mount to your
vehicle's air vent.
9/21/2006 12:09 PM
To vehicle
dashboard
Figure 4. Attach vehicle mount to back of
SKYFi2 as shown.
Page 11
6. Clip the SKYFi2 vehicle cradle
onto the swivel mount (figure 4).
7. Reassemble the system as in step 2.
8. Attach the antenna as explained
on page 12 and route the antenna
cable as described on page 13.
