Rear View

Rear View
Rear View
8 Output Power Ports:
Connect up to 8 separate devices that will be
controlled by the 9258 DS. Ports 1-4
2 Input Power Ports:
The input power sends power to the 2 sets o
9258.
2 Power Switch:
The 2 Power switch turns on the input power
Ports 1-4: Switch 1
Ports 5-8 Switch 2
Replaceable Fuse: The 9258 uses a
TYPE：U/C GFE 10A 250V (PF)
- 9 -
