3.) Interface Description

Front View

Front View
4 Port Ethernet Hub:
Connect up to 4 separate devices with the
built in hub.
1 Serial Ports:
Serial Port 1: Regular Speed
Reset Button:
To reset to original manufacture settings,
hold down the reset button with a pen or a
pin for 15 seconds until will hear a long
beep sound.
Power Status Indicator:
The Power Status indicator
- 8 -
