Aviosys IP Power 9820 Lite User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

IP Power 9820 Lite
User Manual
Firmware Version: 2.0D
Date Released: NOV. 2015
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP Power 9820 Lite and is the answer not in the manual?

Questions and answers

Related Manuals for Aviosys IP Power 9820 Lite

Summary of Contents for Aviosys IP Power 9820 Lite

  • Page 1 IP Power 9820 Lite User Manual Firmware Version: 2.0D Date Released: NOV. 2015 - 1 -...
  • Page 2 Warning: Any changes made to this equipment without permission may cause damages to the device! IMPORTANT NOTICE 1. IP Power 9820 Lite was designed for indoor use, we carry no responsibility for possible damages caused by outdoor use, especially in the rain.

  • Page 3: Table Of Contents

    Table of Content WELCOME ......................4 Introduction ..............................4 PRODUCT OVERVIEW ..................5 Features ................................. 5 Specification ..............................6 Minimum System Requirements ......................... 6 Package Contents ............................6 INTERFACE DESCRIPTION ................7 Front View..............................7 Rear View :..............................8 From Left side to Right side ........................8 SETTING UP USER DEVICE ................

  • Page 4: Welcome

    ............................ 67 Welcome Introduction IP Power 9820 Lite is a new generation of the Power Distribution Unit is a new generation of the Power Distribution Unit (PDU) & Remote Power & Remote Power Control (RPC) system. It’s able to...

  • Page 5: Product Overview

    19) Specific software developed by Aviosys and provided free of charge : SDK available : HTTP Command IP Power Center - for control multiple Aviosys IP devices in same software CNT software ( Cross Network Technology )- allows user eliminate set up work on any Router without port forwarding , simply Plug &...

  • Page 6: Specification

    Specification Power input : 100V - 240V ( C20 Inlet )   Maximum loading of each output: 10 amp  Maximum of Total loading : 20Amp / 110V or 15 Amp / 220V Dimensions: 450 x 170 x 45 mm ( L x W x H ) ...

  • Page 7: Interface Description

    Interface Description Front View From Left side to right side Wifi Connection : Connect with the WiFi Antenna in package . Network & USB : Network Connection : For 10/100 Mbps network . There are 2 network RJ45 connect : NET1 - BLUE is for network connection NET2 –...

  • Page 8: Rear View

    To reset to original manufacture settings, hold down the reset button with a sharpen pin for 5- 6 seconds then release. There are THREE beeps response ( short –- mid long – short ) which means reset successfully and 9820 Lite will be rebooted itself ( one beep after reboot ) and most information go back to default setting .

  • Page 9: Setting Up User Device

    Setting up user device Before we Start *Before setting up the device make sure of the following: All the package contents are all included if anything is missing please contact the dealer where the device was purchased from. Check the power input cable is working correctly. Check all cables to make sure there are no problems with it.

  • Page 10: Software Installation

    “autorun.html” file.) 2.) Click on the IP Power Section Bar 3.) Select the IP Power 9820 Lite 4.) All the available downloads for the 9820 Lite will be shown 5.) Download the required software – IPEdit.exe - by clicking on the download button.

  • Page 11: Connection By Wifi- Wps ( Wifi Protection Service )

    WiFi connection of user`s router and IP Power 9820 Lite automatically . Before using WPS function, please check user WiFi router and see if there has WPS function first . There should have a button name “WPS / QCC “ or a sign on the router for user to click easily.
  • Page 12 Step 5: There is one short beep in 45 seconds which means 9820 Lite boot up successfully . Step 6 : Execute IPEDIT.exe . The device name with mean the WiFi IP address of this device . There is WiFi IP address of 9820 Lite shown in IPEDIT.exe as following : If can not see the IP in the area of Local Devices of IPEDIT.exe.

  • Page 13: Connection First By Lan -Network Cable Then Setup For Wifi Connection

    Connection first by LAN –Network cable then setup for WiFi connection Without WPS , user can use LAN network cable to connect 9820 Lite first . Please refer following steps to setup LAN connection Step 1: Connect the LAN cable to 9820 Lite .The LAN cable should be connected to a Router / HUB + Router.
  • Page 14 LAN connect by IP Search software “ IPEDIT “ IP Edit is a search tool designed to search, configure, or access the IP Power 9820 Lite from a local networked computer. IP Power 9820 Lite Default Login / Password Default IP: 192.168.1.168 (When no DHCP is apparently)
  • Page 15 For example: If user have the following information regarding the 9820 Lite and user network User PC Network : Computer IP Address: 192.168.1.122 Gateway: 192.168.1.1 Sub Net mask: 255.255.255.0 Port: 80 User 9820 Lite in IPEDIT : 9820 Lite IP Address: 192.168.100.34 Gateway: 192.168.100.1 Sub Net mask: 255.255.0.0...
  • Page 16 as seeing the suggest wizard Please click APPLY , click " yes " to ignore the remind message of IP being used and then type the username and password to change the IP setting. Username : admin Password : 12345678 Notice : # Segment : The first 9 digits of the IP Address .
  • Page 17 9820 Lite will auto get the most information of user router and user just need to type the password to connect with the WiFi router then click “ Apply “ Then user can get the router information in “ Profile list “ section as following pictures Select the router and press “Activate “...

  • Page 18: Internet Setup

     If just want to control each port ON or OFF in IP Power 9820 Lite , user can install our own software “ IP Power Center “ and enable IP Server function as following . Please refer to the “IP Power Center “...

  • Page 19: Using Ip Server

    Using IP Server IP Server is a function which allows user to search for the device easily without having to remember long complicated IP address. Instead, if user know the device’s name of user IP Power device and user can easily find IP Address with IP Service. To log in the webpage of 9820 Lite on Internet , user still need to do the “Port forwarding “...

  • Page 20: Web Interface

    EX: The 9820 Lite device name as Cathy , and user can search the device easily after log in the webpage and change the default name from “ IP_POWER ” to Cathy 5.) After user have connected to user device, type in the Login and Password for user device Web Interface Connect to user Device Once the 9820 Lite has been setup correctly, log into the device.
  • Page 21 The Control Console The left Menu of the Web Interface control the functionality and setup of the IP Power 9820 Lite . The IP Power 9820 Lite Console consists of seven main sections which will be explained in details below.

  • Page 22: Device Name

    User can change the device name here : Application  IP Server  Device name Change name “ IP_POWER “ as “ IP Power 9820 Lite “ Please change the name in English only and do not use symbol like !@#$%^&*()_+...

  • Page 23: Information

    Information : In this section, there is information of Time . Time : This section showed the time. To amend the time , Please go to “ System  Management  NTP Settings “ , please press “Apply” to save the new setting . Power Control : The Power Control Section allows user to directly / automatically control the outlets of the 9820 Lite as well as schedule daily, weekly, and monthly power cycles.
  • Page 24 Control There are 2 setting pages in this Section. One is “ Power Control “ and another one is “Advance Setup “ A. Power Control : User can do the following 3 basic operation in this page : 1. Manual control each port ON or OFF directly by pressing the power sign. Power cycle : This section allow user to setup the output Reset action.
  • Page 25 Group Control : User can control all 8 ports outlet by press the right side “Apply “ button . For safety concern , each port of 9820 will turn ON or OFF one after one . For convenience of group control setting , the status of each port in Group Control section is OPPOSITE with the real status.
  • Page 26 Alarm Setting : User can setup Alarm by email or by beeper . In this section “ Default Power Status “ , user can setup the outlet status at ON or /OFF as device power reboot Email Alarm Setting : ...
  • Page 27 Shut down on LAN This is a application for PC / Main board to turn off the OS safety IPPowerOFFDelayservice“ User need to install our another software “ in your PC Please contact with us to get this software Please go to PING / Schedule to enable the function NOTE : The delay time setup in this section is for “...
  • Page 28 Schedule In this section , user can see the setting schedule list first up to 4 rules . To setup each schedule , please press “ Schedule Setting “ , then user can get the “ Schedule List “ page as following : Please Click the button to switch between “...
  • Page 29 One the scheduler has been setup , hit the “ ADD No.:X Power Schedule “ button and you will see your setting located on the bottom of the Action section . Edit a schedule event : Step1 : Please select the Rule you want to edit in Scheduler Table. Then the button “ADD No.:X Power Schedule “...
  • Page 30 Ping The ping function allows the device to automatically Ping an IP Address to act as a watchdog to make sure the device getting Pinged is working properly. Please Click the button to switch between “ Ping Setting “ & “ Ping List “ . User can hide the setting section by press “ Ping List “ There are 8 rules for Ping .
  • Page 31 2. Ping Base Setting :  Set Ping Interval (Seconds): The number of seconds between each ping . Set Ping Response Time out ( Sec. / 1000 = Milliseconds): The number of milliseconds the  device will wait for a response from the pinged device if no ping is detected within this time it will be considered a ping failure.
  • Page 32 OR : 9820 Lite will Ping 2 IP address. Either one IP fail times up to the setting times. Action (ON/OFF/RESET) will be activated . AND : 9820 Lite will Ping 2 IP address. Both IP fail up to the setting times. Action (ON/OFF/RESET) will be activated.
  • Page 33  Ping failure action : When the number of Ping Failures times have been reached. The device can be set to “ ON , OFF or Reset “ function Reset: Can set up the time gap of OFF to ON. The “ Sec “ section is for action as Reset only. Select the action as ping failure as no responding.

  • Page 34: Network

    Network : The Network Section allows user to setup LAN –Ethernet or WiFi settings and WPS setting . There are 4 sections : Setting , WiFiInfo , WiFi Survey and WPS . Setting : This Setting section is showed the network status of 9820 Lite . Please select one connect ion –...
  • Page 35  Default Gateway The gateway is the door for Internet connection , Email , DHCP UPNP NET Server . Please select correct Gateway LAN or WAN for the user to log in 9820 Lite form Internet and use above functions . Notice : Under DHCP mode - either select LAN or WiFi connection, 9820 Lite will get the gateway information automatically.
  • Page 36 As the IP from DHCP Service of user`s router will be changed by router . 9820 Lite will remember last IP of 9820 Lite assigned by user`s router in “Last DHCP state “ for information C. PPPOE : Only support for Ethernet connection . Obtain IP address via Internet Service Provider (ISP) through PPPOE service ( The IP address can be reach on Internet but not fixed ) .
  • Page 37  WiFi Network Settings : The WIFI network connection support : Static IP / DHCP A. STATIC (fixed IP) : Setup IP address manually. This allows the 9820 Lite to obtain an IP Address automatically from user`s server connected to Internet . Recommended for users need to control through Internet. Please do fill up the correct gateway for login from Internet .
  • Page 38 WiFi Info : There are 2 sections in this page . One is WiFi information and another one is Profile list . After WiFi connection successfully , 9820 Lite will turn to this page and show the WiFi information . Please refer page 19 to setup the WiFi connection. User can add different router in profile list for 9820 Lite to switch.
  • Page 39 WiFi Survey This section is to arrange WiFi connection. 9820 Lite will auto search the WiFi Router nearby and also their information as boot up , 9820 Lite user can just select the router and type the password to connect with your WiFi router and make connection easily. Add WiFi Router into “...
  • Page 40 Step 2 : 9820 Lite will auto get the most information of your router and you just need to type the password to connect with the WiFi router then click “ Apply “ Then you will see the Router name add in to “Profile list “ Connect 9820 Lite to this add Router : Active the WiFi Router in “...
  • Page 41 Note : Delete the Router form Pro File list do not affect the connection of WiFi. WPS ( WiFi Protection Service ) To connect IP Power 9820 Lite with WiFi router by WPS function . Please check if the router support WPS function fist .
  • Page 42 Step 4 : Press the WPS buttons of WiFi AP ( Router) soon in few seconds Step 5: After few seconds , there are short 2 beeps which means WPS connection successfully. There are messages updated during the configuration in “ WPS status “ section : As WPS connection successfully , there is “Configured “...
  • Page 43 Which means the WPS connection fail and there is one long beep mean the connection fail. Please try again. ) Step: 6 : User can see the WPS connection in section “ WiFi Info “ & “ WiFi Survey “ of Network In “...

  • Page 44: Application Settings

    Application Settings Email In email section , there is 3 function : Receive Email with Current , Voltage & Temperature info. as 9820 Lite device boot up. Email alarm as over setting at Current , Voltage and temperature. Notice : To send out the email successfully , please double check the setting of user DNS . (Network ...
  • Page 45 The 9820 Lite allows user to send from @gmail or @hotmail or @yahoo.com account .  SMTP Server: This is the mail server of sender . If user select @gmail or @hotmail account as SMTP Server , 9820 Lite will fill the SSL & Port automatically Port : This is the port of SMTP Server.
  • Page 46 If user select @gmail or @hotmail account as SMTP Server , 9820 Lite will fill the SSL & Port automatically.  User : The username to login the receiver`s e-mail Ex: aviosys1 or aviosys1@gmail.com  Password: Password for the e-mail address. EX : 12345678 Mail From : sender`s email address . Ex: aviosys@gmail.com  - 46 -...
  • Page 47  Tag : User can use any message for 9820 Lite to recognize this mail as 9820 Lite command mail . As type “ Test “ in TAG area, the command contents is as following: IPPOWERCTRL:TAG=Test;POWER1=OFF;POWER2=OFF;POWER3=OFF;POWER4=OFF Interval (minutes) : The time between send and receive the command email. ...
  • Page 48 IPPOWERCTRL:TAG=Test;POWER1=OFF;POWER2=OFF;POWER3=OFF;POWER4=OFF ;POWER5=ON; POWER6=ON; POWER7=ON; POWER8=ON There are 2 section of the command IPPOWERCTRL:TAG=Test This is command part. Beside the tag message part ( like Test on above example) user can change in setting section , the other command must be CAPITAL and are fixed content . 2.
  • Page 49 DDNS The DDNS section allows user to setup the 9820 Lite with a DDNS server (i.e. www.dyndns.com). After the server has been setup correctly, enter the necessary information into the 9820 Lite DDNS settings. Note : The DNS server will have extra change as apply new account.
  • Page 50 IP SERVER In this section , use can setup IP Server & CNT ( Cross Network Technology ) , IP Manager : Search other IP Power device in the same LAN of 9820 Lite . Get the QR code of 9820 Lite `s IP address. IP Server &...
  • Page 51 IP Manager : User can directly search other IP Power device in h other IP Power device in local network ( LAN ) here . QR code of 9820 Lite : User can create own QR code of the IP create own QR code of the IP information of 9820 Lite ( LAN / WIFI / Internet), and ternet), and scan / record in user QR code APP...
  • Page 52 There is history in QR code app for user to check 9820 Lite IP soon . - To view the 9820 Lite webpage on Internet , please do “ port forwarding “ first in router. - To view the 9820 Lite webpage on LAN , please make sure user smart phone is under same segment ( refer Page#17 , user will need to make sure that the first 3 segments of user 9820 Lite IP Address must match the first 3 segments of user gateway IP.
  • Page 53 Please go to our online IPEDIT : www.myipedit.com Them please select “ Server 2 “ and type the device name ( if change) or 9820 Lite . - 53 -...
  • Page 54 USB WebCam This section allow user to connect USB Webcam ( with UPNP function , M-JPG / YUV format ) and view the webcam in 9820 Lite webpage directly. To work with 9820 Lite , the USB Webcam need to support UPNP and video as M-JPEG or YUV format to view the area near 9820 Lite . Note : The JAVA version should be 1.60 or above for USB Webcam view under web browser Internet Explorer -IE and the gateway setting must be correct - WAN or LAN as port forwarding and view on Internet...

  • Page 55: System Setting

    System Setting Management In this section there are several setting : Administrator setting, Host Connection Interval , NTP setting ,Export Setting , Import Setting , Load Factory Default , Restart System The message show : You may configure administrator account and password, NTP settings here, Save system “...
  • Page 56 Viewer: The viewer can only see the “ IO Control “ section but can not see other page of 9820 Lite . Default Setting of the authorities : Authority Account name Password Admin Admin 12345678 Operator user user Viewer guest guest Note Please amend the password as number or English character from...
  • Page 57 Import Setting User can import the file which was exported from 9820 Lite as “ DAT “ format . It will help user to setup many 9820 Lite device in a short time. As press “ Import “, there is caution message show as following : Before click ok to import please do read following notice : Do NOT import DAT file which is not export form 9820 Lite .
  • Page 58 System Information In this section , user can get the system information and change own Language display in 9820 Lite webpage in “ Language Setting “ : - 58 -...
  • Page 59  Language Setting : User can change the display Language - two customize Language and build own Language by simple procedure . Please refer the following two procedures : Change the text in SDK & Language Customize procedure . A. Change the Text in SDK : A-1 .
  • Page 60 Example: <message msgid="email title" msgstr="E-mail Setting" /> The webpage will display the Text in yellow background as above example Notice : To avoid any update problem , please ONLY change the Texts between the two “ marks after msgstr . A-4.
  • Page 61 Notice : There are 5 languages setting in this section : ENG : Can’t change   Chinese : Can’t change  Simple Chinese : Can’t change Other 1 : Can revise as user’s own Language   Other 2 : Can revise as user’s own Language Only “Other 1”...
  • Page 62 B- 5. Then the webpage will show that you have selected 5 files . Press “Apply “ to execute the update procedure B- 6 . Then the webpage will display “ user select 5 files “ to update. Press “ Apply “ to execute the replacement .
  • Page 63 System Log In this section , user can get the 9820 Lite system operation information and send the information assign Server IP address ( not support name ) . The system information will be deleted after 9820 Lite device power reboot. Please click the IP and save by click “...

  • Page 64: Cgi Http Commands

    CGI HTTP Commands CGI Commands allow you to easily integrate the 9820 with other systems and programs. Please read the instructions carefully on how to use the Http:// Commands To use http:// Commands open up a web browser and type in the command that you would like to use.
  • Page 65 2.4 To set the power on / off ：setpower+p6x=0 or 1 p6x=0 means off，p6x=1means ON，x can be 1 to 4 ( power1 to power 4) Example : Turn on POWER1 and POWER2 and turn off POWER3： http://192.168.1.18/set.cmd?cmd=setpower+p61=0+p62=0+p63=0+p64=0+p65=1+p66= 1+p67=1+p68=1 System return： CGI Command : Data follows p61=0,p62=0,p63=0,p64=0,p65=1,p66=1,p67=1,p68=1 2.5 Setup power to reboot as RESET：setpowercycle+ p6x=delayTime...

  • Page 66: Telnet Control

    Telnet Control User can get the Telnet command by -h - 66 -...
  • Page 67 FAQ : Q1: Why can I see 2 IP address on IPEDIT.exe but can only reach one ? Why did IPEIDT.exe show the LAN IP address as no network cable connect ? Why did IPEDIT.exe show the WIFI IP address as no WIFI router available ? A1: 9820 Lite will remember the LAN / WAN setting one connect .Please select the IP user can log into 9820 Lite to operate.
  • Page 68 Step1: Please connect 9820 Lite to user PC directly and change the IP address of user PC as 192.168.1.xxx ( set the IP of user PC to be the same segment of 9820 Lite . ) xxx can be 1~255 but not 168 . Step 2 : After log in to the 9820 Lite in LAN, please go to Network ...
