Convertamatic
Hydro-Retriever
SERVICE MANUAL
Advance MODELS 56372450(260B), 56395700(32B)
56395710(32BD), 56395720(38BD)
56372460(260BHD), 56395715(320BHD), 56395725(380BHD)
™
260B/32B/32BD/38BD
™
260BHD/320BHD/380BHD
8/93 revised 12/00 Form Number 56043021
