Version 1.01 | 2016/06/03
User Manual
ONE SEAMLESS
HIGH PERFORMANCE
MORE COVERAGE
NETWORK
Wi-Fi
Covr your Whole Home in High-Power
COVR-3902
AC3900 WHOLE HOME WI-FI SYSTEM
USER MANUAL

Advertisement

   Related Manuals for D-Link COVR-2600R

No related manuals

   Summary of Contents for D-Link COVR-2600R

  • Page 1

    Version 1.01 | 2016/06/03 User Manual ONE SEAMLESS HIGH PERFORMANCE MORE COVERAGE NETWORK Wi-Fi Covr your Whole Home in High-Power COVR-3902 AC3900 WHOLE HOME WI-FI SYSTEM USER MANUAL...

  • Page 2

    Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.

  • Page 3: Table Of Contents

    Introduction ................... 3 IPv6 ..................48 Features .................... 3 Wireless ..................68 Hardware Overview ..............5 Guest Zone ...............70 COVR-2600R LED Indicators ..........5 Network ..................71 COVR-1300E LED Indicators ..........6 USB Sharing ................73 COVR-2600R Back Panel ............. 7 Features ..................74 COVR-2600R Front Panel ............ 8 QoS Engine................74...

  • Page 4

    Connect a Wireless Client to your Router ....126 WPS Button ................126 Wireless Basics ...............127 What is Wireless? ..............128 Tips ....................130 Technical Specifications ..........131 Regulatory Statements - COVR-2600R ......134 Regulatory Statements - COVR-1300E ......154 D-Link COVR-3902 User Manual...

  • Page 5: Product Overview

    Section 1 - Product Overview Product Overview Package Contents COVR-2600R AC2600 Wi-Fi Router Ethernet Cable x 1 COVR-1300E AC1300 Wi-Fi Range Extender Detachable Antenna x 4 Power Adapter x 2 Quick Installation Guide Wi-Fi Configuration Card Wi-Fi Configuration Note If any of the above items are missing or damaged, please contact your local reseller.

  • Page 6: System Requirements

    ® installed. Visit www.java.com to download the latest version. • iPhone®/iPad®/iPod touch®, Android™, or Windows smartphone D-Link Wi-Fi Requirements or tablet. (Please refer to the mobile app's store page to check whether your device is compatible) D-Link COVR-3902 User Manual...

  • Page 7: Introduction

    Wi-Fi, while the Covr Seamless Extender takes care of the outer edge. Automatically connect to the strongest signal as you move through your home for up to 6,000 sq. ft of seamless whole home coverage. With the COVR-3902, D-Link has got you Covr’d.

  • Page 8

    Scale up your Wi-Fi by adding another extender to get true whole-home coverage. • Easy Setup - Through its intuitive web-based user interface or the free D-Link Wi-Fi app, you can quickly set up the COVR-3902 and configure your network to your specific settings in a matter of minutes.

  • Page 9: Hardware Overview

    Section 1 - Product Overview Hardware Overview COVR-2600R LED Indicators A solid green light indicates a proper connection to the power supply. The light will be solid orange during Power LED boot up. A solid green light indicates a connection on the Internet port. If the LED is orange, the router cannot connect Internet LED to the Internet.

  • Page 10: Covr-1300e Led Indicators

    2.4 GHz Downlink LED A solid green light indicates that the 2.4 GHz wireless downlink connection is established. 5 GHz Downlink LED A solid green light indicates that the 5 GHz wireless downlink connection is established. D-Link COVR-3902 User Manual...

  • Page 11: Covr-2600r Back Panel

    Section 1 - Product Overview COVR-2600R Back Panel Power Connector Connector for the supplied power adapter. Power Button Press the power button to power the device on or off. INTERNET Port Using an Ethernet cable, connect your broadband modem to this port.

  • Page 12: Covr-2600r Front Panel

    Section 1 - Product Overview COVR-2600R Front Panel USB 3.0 Port Connect a USB storage device to share files over the network. D-Link COVR-3902 User Manual...

  • Page 13: Covr-1300e Back Panel

    Gigabit LAN Ports Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles. Power Button Press the power button to power the device on or off. Power Input Connector for the supplied power adapter. D-Link COVR-3902 User Manual...

  • Page 14: Covr-1300e Side Panel

    Section 1 - Product Overview COVR-1300E Side Panel WPS Button Press to start the WPS process and automatically create an encrypted connection to a wireless client. D-Link COVR-3902 User Manual...

  • Page 15: Installation

    Wi-Fi app, you must download this app before beginning the installation process. To get the D-Link Wi-Fi app, browse the App Store for Apple devices or the Google Play store and search for D-Link Wi-Fi. You can also scan the QR code below, which will take you to the respective D-Link Wi-Fi app store page directly.

  • Page 16: Before You Begin

    • If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet. D-Link COVR-3902 User Manual...

  • Page 17: Wireless Installation Considerations

    1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

  • Page 18: Hardware Setup

    45-degree angle and the rear antennas into a 90-degree angle to provide optimal wireless coverage. Keep the router in an open area for better wireless coverage. 115° 2. Position your COVR-2600R router near your Internet-connected modem. Place it in an open area for better wireless coverage. Modem COVR-2600R - •...

  • Page 19

    Section 2 - Installation 4. If you are configuring the COVR-2600R wirelessly from a PC, connect to the Wi-Fi network printed on the included Wi-Fi Configuration Card. You can also find the Wi-Fi network name and password printed on the label attached to the bottom of your router.

  • Page 20: Completing Setup

    • D-Link Wi-Fi App - Use your Android device, iPhone, iPad, or iPod touch to configure your router. Refer to D-Link Wi-Fi App on page 17. • D-Link Setup Wizard - This wizard will launch when you log into the router's web-based user interface for the first time. Refer to Web Interface Setup Wizard on page 24.

  • Page 21: D-link Wi-fi App

    Note: The screenshots may be different depending on your mobile device’s OS version. The following steps show the iOS interface of the D-Link Wi-Fi app. If you are using an Android device, the appearance may be different from that of the screenshots, but the process is the same.

  • Page 22

    The default network name (SSID) and password can be found on the included Wi-Fi Configuration Card and on the sticker on the base of the router, and will look something like dlink-XXXX. Once connected, return to the D-Link Wi-Fi app and tap NEXT.

  • Page 23

    120 seconds for the Extender to boot up. If the Extender is powered on, tap Next. Step 4 When your Covr Extender was successfully detected, a message will appear to confirm. Tap Next to continue. D-Link COVR-3902 User Manual...

  • Page 24

    Section 2 - Installation D-Link Wi-Fi (continued) Step 5 The D-Link Wi-Fi app will search for your Covr Whole Home Wi-Fi System. Once found, it will display the product details on the screen. Tap Next to continue. Step 6 Connect the Ethernet cable from your broadband modem to the yellow INTERNET port on the back of the Covr router and follow the on-screen instructions to set up your Internet connection.

  • Page 25

    Create a Network Name (SSID) and password for your Covr Whole Home Network and tap Next. Step 8 Specify an administrator password for your Covr System (note that this should not be the same as your Wi-Fi network password configured in the previous step) and tap Next. D-Link COVR-3902 User Manual...

  • Page 26

    Unplug the Covr Extender and place it anywhere in your home where the Wi-Fi signal is weak. For optimal performance, make sure all five LEDs on the Extender are solid green. If they are not, place the Extender closer to the router until they do. D-Link COVR-3902 User Manual...

  • Page 27

    Step 11 Your Covr Wi-Fi System is now configured and ready to use. You can now connect to the Covr Wi-Fi network listed in the overview. Tap Finish to close the wizard and complete the setup. D-Link COVR-3902 User Manual...

  • Page 28: Web Interface Setup Wizard

    (default: http://192.168.0.1). The wizard is designed to guide you through a step-by-step process to configure your new D-Link router and connect to the Internet. You can change the language of the setup wizard by selecting a language from the drop-down menu in the lower left.

  • Page 29

    If pairing through WPS also fails to detect the Extender, try resetting the Extender by holding down the reset button on the back of the device for roughly 10 seconds using an unfolded paper clip. Once reset, run the Setup Wizard again. D-Link COVR-3902 User Manual...

  • Page 30

    INTERNET to your modem. Click Next to continue. The Covr Router will now detect your Internet connection. If your Internet connection was successfully auto-detected, continue to the Step 9. If your connection was not automatically detected, refer to the following steps. D-Link COVR-3902 User Manual...

  • Page 31

    If the router detected or you selected PPPoE, enter your PPPoE username and password and click Next to continue. Note: Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router. D-Link COVR-3902 User Manual...

  • Page 32

    Note: The COVR-3902 uses a single wireless network for both the 2.4 GHz and 5 GHz wireless bands. When connecting clients to the Covr wireless network, they will be automatically added to the best wireless band, either 2.4 GHz or 5 GHz. D-Link COVR-3902 User Manual...

  • Page 33

    Click Next to continue. Step 11 You will be presented with a summary of your settings. Click Finish to finalize the settings or Back to make changes. D-Link COVR-3902 User Manual...

  • Page 34

    Wi-Fi signal is weak. For optimal performance, make sure all five LEDs on the Extender are solid green. If they are not, place the Extender closer to the router until they do. Click Finish to complete the Setup Wizard. Your Covr network is now configured and ready to use! D-Link COVR-3902 User Manual...

  • Page 35: Configuration - Covr-2600r

    Section 3 - Configuration Configuration - COVR-2600R To access the configuration utility, open a web-browser such as Internet Explorer and enter http://covr.local./ or you may also connect by typing the IP address of the router (by default this is http://192.168.0.1) in the address bar.

  • Page 36: Home

    Internet icon. Click IPv4 or IPv6 to see details of the IPv4 connection and IPv6 connection respectively. Click Release IP Address to disconnect from the Internet. If you do this and wish to reconnect, click Renew. To reconfigure the Internet settings, refer to Internet on page 38. D-Link COVR-3902 User Manual...

  • Page 37: Covr-2600r

    Section 3 - Configuration COVR-2600R Click on the COVR-2600R icon to view details about the router and its wireless settings. Here you can see the router’s current Wi-Fi network name and password, as well as the router's MAC address, IPv4 address, and IPv6 address.

  • Page 38: Connected Clients

    Displays the current IP address of this client. Reserve IP: Enable to reserve this IP address for this client. IP Address Specify an IP address for the COVR-2600R's DHCP server to assign. (Reserved): Parental Control: Allow or block access to the router.

  • Page 39

    Enter the MAC address of the device. Reserve IP: Enable to reserve this IP address for this client. IP Address Specify an IP address for the COVR-2600R's DHCP server to assign. (Reserved): Parental Control: Allow or block access to the router.

  • Page 40: Extenders

    Extenders Click on the Extenders icon to view details about all COVR-1300E extenders connected to the COVR-2600R router. To configure the extender's settings, click Go to settings in the lower right of the client's box, or open a web-browser such as Internet Explorer and enter http://dlinkap.local./ in the address bar.

  • Page 41: Usb Device

    To reconfigure the USB sharing settings, either click Go to settings on the lower right, or click Settings (at the top of the page) and then USB Sharing on the menu that appears. Refer to USB Sharing on page 73 for more information. D-Link COVR-3902 User Manual...

  • Page 42: Settings

    For PPPoE refer to page 41. For PPTP refer to page 43. For L2TP refer to page 45. For DS-Lite refer to page 47. To configure an IPv6 connection, click the IPv6 link. Refer to page 48. D-Link COVR-3902 User Manual...

  • Page 43

    The default MAC address is set to the Internet port’s physical interface Clone: MAC address on the router. You can use the drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 44

    The default MAC address is set to the Internet port’s physical interface Clone: MAC address on the router. You can use the drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 45

    Enter the secondary DNS server IP address assigned by your ISP. Server: MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. Select Manual to define a custom MTU value. The recommended setting is Auto. D-Link COVR-3902 User Manual...

  • Page 46

    The default MAC address is set to the Internet port’s physical interface Clone: MAC address on the router. You can use the drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 47

    Enter the secondary DNS server IP address assigned by your ISP. Server: MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. Select Manual to define a custom MTU value. The recommended setting is Auto. D-Link COVR-3902 User Manual...

  • Page 48

    Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. Select Manual to define a custom MTU value. The recommended setting is Auto. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 49

    Enter the secondary DNS server IP address assigned by your ISP. Server: MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. Select Manual to define a custom MTU value. The recommended setting is Auto. D-Link COVR-3902 User Manual...

  • Page 50

    Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP. Select Manual to define a custom MTU value. The recommended setting is Auto. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 51

    Enter the B4 IPv4 address value used here. WAN IPv6 Once connected, the WAN IPv6 address will be displayed here. Address: IPv6 WAN Default Once connected, the IPv6 WAN default gateway address will be Gateway: displayed here. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 52: Ipv6

    For Auto Configuration (SLAAC/DHCPv6) refer to page 53. For PPPoE refer to page 56. For IPv6 in IPv4 Tunnel refer to page 60. For 6to4 refer to page 63. For 6rd refer to page 65. For Local Connectivity Only refer to page 67. D-Link COVR-3902 User Manual...

  • Page 53

    If you selected Use the following DNS address above, enter the Secondary DNS Server: secondary DNS server address. LAN IPv6 Address Settings LAN IPv6 Address: Displays the currently assigned LAN IPv6 address. LAN IPv6 Link- Displays the router’s LAN link-local address. Local Address: D-Link COVR-3902 User Manual...

  • Page 54

    Enter the starting IPv6 address for the DHCP server’s IPv6 assignment. Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 Address This value is auto-configured with this combination. Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 55

    Enter the subnet prefix length supplied by your ISP. Length: LAN IPv6 Address Settings LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router. LAN IPv6 Link- Displays the router’s LAN link-local address. Local Address: D-Link COVR-3902 User Manual...

  • Page 56

    Enter the starting IPv6 address for the DHCP server’s IPv6 assignment. Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 57

    Displays the router’s LAN link-local address. Local Address: If Enable DHCP-PD is disabled, these additional parameters are available for configuration: LAN IPv6 Address: Enter a valid LAN IPv6 address. LAN IPv6 Link- Displays the router’s LAN link-local address. Local Address: D-Link COVR-3902 User Manual...

  • Page 58

    Enter the starting IPv6 address for the DHCP server’s IPv6 assignment. Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 Address This value is auto-configured with this combination. Lifetime: D-Link COVR-3902 User Manual...

  • Page 59

    Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 This value is automatically received from the DHCP Prefix Delegation. Advertisement Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 60

    If you selected Static IP as the Address Mode and Create a new session as the PPPoE Session: IP Address Enter the IP address provided by your ISP. Service Name Enter the ISP service name (optional). D-Link COVR-3902 User Manual...

  • Page 61

    Local Address: If Enable DHCP-PD is disabled or when the Address Mode is set to Static IP, this additional parameter is available for configuration: LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router. D-Link COVR-3902 User Manual...

  • Page 62

    /63. Contact your ISP for more information. Autoconfiguration Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6. Type: If you selected SLAAC+RDNSS or SLAAC+Stateless DHCP as the Autoconfiguration Type: Router This value is auto-configured with this combination. Advertisement Lifetime: D-Link COVR-3902 User Manual...

  • Page 63

    Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 This value is automatically received from the DHCP Prefix Delegation. Advertisement Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 64

    Select either Obtain DNS server address automatically or Use the DNS Type: following DNS address. If Use the following DNS address is selected: Primary DNS Enter the primary DNS server address. Server: Secondary DNS Enter the secondary DNS server address. Server: D-Link COVR-3902 User Manual...

  • Page 65

    LAN interface. Note: This feature requires a smaller subnet prefix than /64 (i.e. allowing for a larger address allocation), such as /63. Contact your ISP for more information. Select SLAAC+RDNSS, SLAAC+Stateless DHCP, or Stateful DHCPv6. Autoconfiguration Type: D-Link COVR-3902 User Manual...

  • Page 66

    Enter the starting IPv6 address for the DHCP server’s IPv6 assignment. Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 67

    Secondary DNS Enter the secondary DNS server address. Server: LAN IPv6 Address Settings LAN IPv6 Address: Enter the LAN (local) IPv6 address for the router. LAN IPv6 Link- Displays the router’s LAN link-local address. Local Address: D-Link COVR-3902 User Manual...

  • Page 68

    Enter the starting IPv6 address for the DHCP server’s IPv6 assignment. Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 Address This value is auto-configured with this combination. Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 69

    Enter the 6rd border relay IPv4 address supplied by your ISP. IPv4 Address: LAN IPv6 Address Settings LAN IPv6 Address: Displays the router’s LAN IPv6 address link-local address. LAN IPv6 Link- Displays the router’s LAN link-local address. Local Address: D-Link COVR-3902 User Manual...

  • Page 70

    Enter the starting IPv6 address for the DHCP server’s IPv6 assignment. Range (Start): IPv6 Address Enter the ending IPv6 address for the DHCP server’s IPv6 assignment. Range (End): IPv6 Address This value is auto-configured with this combination. Lifetime: Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 71

    If you selected Enable ULA and disabled Default ULA Prefix: ULA Prefix: Enter your own ULA prefix. Current IPv6 ULA Settings Current ULA Displays the current ULA prefix. Prefix: LAN IPv6 ULA: Displays the LAN's IPv6 ULA. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 72: Wireless

    Use the drop-down menu to select the time schedule that the Wi-Fi network will be enabled for. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Schedule on page 88 for more information. D-Link COVR-3902 User Manual...

  • Page 73

    The easiest way to connect your wireless devices to the router is with Wi-Fi Protected Setup (WPS). Using WPS-PIN is disabled by default due to security vulnerabilities. WPS-PBC Status: Enable or disable WPS-PBC (Push Button Configuration) fuctionality. WPS-PIN Status: Enable or disable WPS-PIN fuctionality. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 74: Guest Zone

    Create a password to use for wireless security. Home Network Access Internet Access Enabling this option will confine connectivity to the Internet, Only: preventing guests from accessing other local network devices. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 75: Network

    Local Domain Enter the domain name (optional). Name: Enable DNS Relay: Disable to transfer the DNS server information from your ISP to your computers. If enabled, your computers will use the router for a DNS server. D-Link COVR-3902 User Manual...

  • Page 76

    Enable to allow IPv4 multicast traffic to pass through the router from Stream: the Internet. IPv6 Multicast Enable to allow IPv6 multicast traffic to pass through the router from Stream: the Internet. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 77: Usb Sharing

    Windows File Sharing: the admin password in order to access the shared media, or choose Allow all users to access (no password) to allow clients full access to the shared media. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 78: Features

    If you want to remove a priority assignment from a device and return it to the All Devices list, click the cross (x) icon in the top right of the device card. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 79: Firewall

    IPv6 Ingress If IPv6 Simple Security is disabled, click to enable or disable IPv6 Filtering: ingress filtering. Enabling this feature will cause the router to scan and verify incoming IPv6 traffic and filter out any suspicious packets. D-Link COVR-3902 User Manual...

  • Page 80

    NAT devices and work around them. This ALG may interfere with the operation of such devices. If you are having trouble making VoIP calls, try turning this ALG off. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 81: Ipv4/ipv6 Rules

    The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Refer to Schedule on page 88 for more information. Click Apply when you are done. D-Link COVR-3902 User Manual...

  • Page 82: Port Forwarding

    The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Schedule on page 88 for more information. Click Apply when you are done. D-Link COVR-3902 User Manual...

  • Page 83: Virtual Server

    The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Schedule on page 88 for more information. Click Apply when you are done. D-Link COVR-3902 User Manual...

  • Page 84: Website Filter

    If you wish to remove a rule, click on its trash can icon in the Delete column. If you wish to edit a rule, simply replace the URL or domain. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 85: Static Routes

    Enter a route metric value ranging from 0 to 15. This value indicates the cost of using this route. Interface: Select the interface that the IP packet must use to transit out of the router when this route is used. Click Apply when you are done. D-Link COVR-3902 User Manual...

  • Page 86: Ipv6

    Enter a route metric value ranging from 0 to 15. This value indicates the cost of using this route. Interface: Select the interface that the IP packet must use to transit out of the router when this route is used. Click Apply when you are done. D-Link COVR-3902 User Manual...

  • Page 87: Dynamic Dns

    Enter a time out time (in hours). Click Save when you are done. At the bottom of the page are the IPv6 host settings. To configure an IPv6 dynamic DNS host, refer to IPv6 Host on page 84. D-Link COVR-3902 User Manual...

  • Page 88: Ipv6 Host

    Enter the host name that you registered with your dynamic DNS service provider. IPv6 Address: Enter the IPv6 address of the dynamic DNS server. Alternatively, select the server device in the drop-down menu. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 89: Quick Vpn

    For Apple iOS devices and OS X: From a computer browser click this button to export a profile to simplify setup. E-mail this file as an attachment to your Apple mobile device or open the file in OS X. D-Link COVR-3902 User Manual...

  • Page 90

    Advanced Settings - Address Autoconfiguration Settings Choose the authentication protocol type: MSCHAPv2, PAP, or CHAP. Authentication Protocol: MSCHAPv2 is the default. MPPE: Select the encryption cipher strength: None, RC4-40, or RC4-128. RC4-128 is the default. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 91: Management

    NTP server from the drop-down menu. To configure the router's time and date manually, disable this option and use the drop-down menus that appear to input the time and date. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 92: Schedule

    You can add multiple days to the schedule, but only one period per day. To remove a time period from the schedule, click on the cross icon. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 93: System Log

    Enter the email address your SysLog messages will be sent to. SMTP Server Enter your SMTP server address. Address: SMTP Server Port: Enter your SMTP server port. Enable Check this box if your SMTP server requires authentication. Authentication: D-Link COVR-3902 User Manual...

  • Page 94

    The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section. Refer to Schedule on page 88 for more information. Click Save when you are done. D-Link COVR-3902 User Manual...

  • Page 95: System Admin

    Internet by a web browser. A password is still required to access the web management interface. Remote Admin The port number used to access the COVR-2600R is used in the URL. Port: Example: http://x.x.x.x:8080 where x.x.x.x is the Internet IP address of the COVR-2600R and 8080 is the port used for the web management interface.

  • Page 96: System

    Device: Auto Reboot: You may set the COVR-2600R to automatically reboot at a set time. The options are Never, Daily, Weekly. You may set the hour using a 24 hour format, the minute, and the day you wish to have the COVR-2600R automatically reboot.

  • Page 97: Upgrade

    If you wish to upgrade manually, first download the firmware file you wish to upgrade to. Next, click the Select File button and browse to the Firmware: firmware file you want to install. With the file selected, click Upload to begin the upgrade process. D-Link COVR-3902 User Manual...

  • Page 98: Statistics

    You can view the Internet, LAN, Wi-Fi 2.4 GHz, or Wi-Fi 5 GHz by clicking on the respective tabs at the top. The graph will update in real time. To clear the information on the graph, click Clear. The traffic counter will reset if the device is rebooted. D-Link COVR-3902 User Manual...

  • Page 99: Configuration - Covr-1300e

    COVR-2600R web interface home page. Enter your password. This password is the same password used for accessing the COVR-2600R configuration utility. If you previously followed the setup wizard, please use the admin password you entered during the wizard. Otherwise, leave the password blank. Click Log In to proceed.

  • Page 100: System

    Any settings that have not been saved will be lost, including any rules that you have created. Reboot The Click the Reboot button to reboot the router immediately. Device: D-Link COVR-3902 User Manual...

  • Page 101: Upgrade

    If you wish to upgrade manually, first download the firmware file you wish to upgrade to. Next, click the Select File button and browse to the Firmware: firmware file you want to install. With the file selected, click Upload to begin the upgrade process. D-Link COVR-3902 User Manual...

  • Page 102: Statistics

    5 GHz Extender Wi-Fi by clicking on the respective tabs at the top. The graph will update in real time. To clear the information on the graph, click Clear. The traffic counter will reset if the device is rebooted. D-Link COVR-3902 User Manual...

  • Page 103: Quick Vpn

    Section 4 - Quick VPN Quick VPN This router is equipped with D-Link's Quick VPN technology. Virtual Private Networking (VPN) creates a connection between devices across the Internet. Using Quick VPN allows you to securely connect your computer or mobile device to places with free, untrusted Wi-Fi hotspots in places like coffee shops and hotels by encrypting and relaying it through your home Internet connection.

  • Page 104: Important Information

    Important Information The following instructions explain and help you to configure your D-Link Quick VPN enabled router and devices to create a Virtual Private Network (VPN). This feature is provided for advanced users who wish to connect remotely and use their router's Internet connection to add a layer of security while using untrusted networks.

  • Page 105: Quick Vpn Server Setup Instructions

    Select the encryption cipher strength: None, RC4-40, or RC4-128. RC4-128 is the default. Click Save when you are done. When you are done configuring VPN settings, refer to the following sections for more information on how to set up VPN clients. D-Link COVR-3902 User Manual...

  • Page 106: Ios Devices

    This section provides Quick VPN setup instructions for iOS devices using the Export Profile function. Refer to Quick VPN Server Setup Instructions on page 101 for more information. Open the e-mail containing your Quick VPN profile. Open the attachment. D-Link COVR-3902 User Manual...

  • Page 107

    Section 4 - Quick VPN VPN Setup Instructions (Continued) The Install Profile dialog will appear, tap Install in the upper right-hand corner of your screen. Enter your device's passcode when prompted. D-Link COVR-3902 User Manual...

  • Page 108

    Acknowledge the disclaimer by tapping Install in the upper right-hand corner. Tap the red Install button. Enter the Shared Secret (PSK) from the Quick VPN configuration page. Tap Done. Your iOS device is now configured to connect to your Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 109

    To connect to or disconnect from your Quick VPN server, open Settings and tap the button next to VPN. The VPN icon will appear in the notification area at the top of your screen indicating that your device is currently connected to the Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 110: Mac Os X

    Open the exported profile. The Install Profile dialog will appear; click Continue and Install. Enter your user account password when prompted. Close the Profiles dialog.  > System Preferences... > Network and select the Quick VPN connection Go to and click Authentication Settings. D-Link COVR-3902 User Manual...

  • Page 111

    Section 4 - Quick VPN VPN Setup Instructions (Continued) Enter your Passkey in the Shared Secret text box and click OK, Apply, then OK. Your Mac is now configured to connect to your Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 112

    Section 4 - Quick VPN Connect or Disconnect  > System To connect to or disconnect from your Quick VPN server, go to Preferences... > Network. Select the Quick VPN connection and click on the Connect or Disconnect button. D-Link COVR-3902 User Manual...

  • Page 113: Windows 7

    Enter the IP/DDNS address of your Quick VPN server in the Internet address box, create a name for your connection in the Destination Name, check Don't Connect now; just set it up so I can connect later, and click Next. D-Link COVR-3902 User Manual...

  • Page 114

    Password and check Remember this password. Click Create to continue. Do not click Connect Now. Click Close. Click the Start button and type view network connections into the Search programs and files text box. Select View network connections. D-Link COVR-3902 User Manual...

  • Page 115

    Click Advanced settings. Enter your Passkey in the Key text box under Use preshared key for authentication. Click OK to close Advanced Properties and click OK to close Quick VPN Connection Properties. Your Windows 7 system is now configured to connect to your Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 116

    To connect to or disconnect from your Quick VPN server, click on the Network Settings icon in the notification area of the Windows taskbar and from the Dial Up and VPN section click on your Quick VPN connection and click on the Connect or Disconnect button. D-Link COVR-3902 User Manual...

  • Page 117: Windows 8.1/8

    Windows 8.1/8 VPN Setup Instructions This section provides Quick VPN setup instructions for Windows 8.1/8. Click the Start button and type vpn. Select Manage virtual private networks. From the Network Settings page, click Add a VPN Connection. D-Link COVR-3902 User Manual...

  • Page 118

    Enter your IP/DDNS address of your Quick VPN server. Select User name and password from Type of sign-in info. If you would like windows to remember your sign-in information, enter your User name, Password, and select Remember my sign-in info Choose Save. D-Link COVR-3902 User Manual...

  • Page 119

    Section 4 - Quick VPN VPN Setup Instructions (Continued) Right-click on the Quick VPN Connection you just created and left-click on Properties. Select the Security tab. For the Type of VPN, select Layer 2 Tunneling with IPsec (L2TP/IPSec). D-Link COVR-3902 User Manual...

  • Page 120

    Click the Start button and type view network connections. Select View network connections. Right-click your Quick VPN Connection and left-click Properties. Select the Security tab. For the Type of VPN, select Layer 2 Tunneling with IPsec (L2TP/IPSec). D-Link COVR-3902 User Manual...

  • Page 121

    Click Advanced settings. Enter your Passkey in the Key text box under Use preshared key for authentication. Click OK to close Advanced Properties and click OK to close Quick VPN Properties. Your Windows 8.1/8 system is now configured to connect to your Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 122

    To connect to or disconnect from your Quick VPN server, click on the Network Settings icon in the notification area of the Windows taskbar. Click on your Quick VPN connection and click on the Connect or Disconnect button. D-Link COVR-3902 User Manual...

  • Page 123: Windows 10

    Section 4 - Quick VPN Windows 10 VPN Setup Instructions This section provides Quick VPN setup instructions for Windows 10. Click Start > Settings > Network & Internet > Network and Sharing Center > VPN > Add a VPN Connection. D-Link COVR-3902 User Manual...

  • Page 124

    If you would like windows to remember your sign-in information, enter your User name, Password, and select Remember my sign-in info Choose Save. Your Windows 10 system is now configured to connect to your Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 125

    To connect to or disconnect from your Quick VPN server, click on the Network Settings icon in the notification area of the Windows taskbar and click on your Quick VPN connection. The Network & Internet Settings page will open. Click on the Connect or Disconnect button. D-Link COVR-3902 User Manual...

  • Page 126: Android

    Section 4 - Quick VPN Android VPN Setup Instructions This section provides Quick VPN setup instructions for Android devices. Your device's screens may vary. Go to Settings > More from the Wireless & networks > VPN > + D-Link COVR-3902 User Manual...

  • Page 127

    Select L2TP/IPSec PSK for Type. Enter the IP/DDNS address of your Quick VPN server. Enter your Passkey in IPSec pre-shared key field. Choose Save. Your Android device is now configured to connect to your Quick VPN server. D-Link COVR-3902 User Manual...

  • Page 128

    Section 4 - Quick VPN Connect or Disconnect To connect to or disconnect from your Quick VPN server, go to Settings > More from the Wireless & networks > VPN and select the Quick VPN connection you created. D-Link COVR-3902 User Manual...

  • Page 129

    Section 4 - Quick VPN Connect or Disconnect (Continued) To connect, enter your Username and Password and select CONNECT. To disconnect, select DISCONNECT. D-Link COVR-3902 User Manual...

  • Page 130: Connect A Wireless Client To Your Router

    WPS. After your device's manual, follow the steps below: Step 1 - Press the WPS button on the COVR-2600R for about 1 second. The LED on the front will start to blink. WPS Button Step 2 - Within 2 minutes, press the WPS button on your wireless device (or launch the software utility and start the WPS process).

  • Page 131: Wireless Basics

    D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business, or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when, and where you want it. You will be able to enjoy the freedom that wireless networking delivers.

  • Page 132: What Is Wireless

    Why D-Link Wireless? D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network.

  • Page 133

    Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home Uses/Benefits • Gives everyone at home broadband access •...

  • Page 134: Tips

    The wireless connection in public places is usually called “hotspots”. Using a D-Link USB adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like: airports, hotels, coffee shops, libraries, restaurants, and convention centers.

  • Page 135: Technical Specifications

    Appendix B - Technical Specifications Technical Specifications Technical Specifications - COVR-2600R AC2600 Wi-Fi Router General Device Interfaces • IEEE 802.11 ac/n/g/b/a wireless LAN • Power button • 10/100/1000 Gigabit Ethernet WAN port • Wireless On/Off button • Four 10/100/1000 Gigabit Ethernet LAN ports •...

  • Page 136

    • IEEE 802.11a Minimum Requirements • Windows 10/8.1/8/7 or MAC OS X 10.6 or higher • COVR-2600R Covr System or existing wireless network • Internet Explorer 10, Firefox 28.0, Chrome 28.0, Safari 6.0, or later • Network Interface Card Functionality Security •...

  • Page 137

    • Operating: 0 to 40 °C (32 to 104 °F) • Non-operating: -20 to 65 °C (-4 to 149 °F) Humidity • Operating: 10% to 90% non-condensing • Non-operating: 5% to 95% non-condensing Certifications • FCC • CSA • IC • Wi-Fi Certified • CE D-Link COVR-3902 User Manual...

  • Page 138: Regulatory Statements - Covr-2600r

    Appendix C - Regulatory Information Regulatory Statements - COVR-2600R Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 139

    (i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; D-Link COVR-3902 User Manual...

  • Page 140

    être installé et utilisé avec un minimum de 34 cm de distance entre la source de rayonnement et votre corps. Warning This unit is to be used with a power supply, Model WA-36A12R. Avertissement Cet appareil doit etre utilise avec une source de courrant, modele WA-36A12R. D-Link COVR-3902 User Manual...

  • Page 141

    Potencia máxima de Salida Frequenza/e Potenza max. Output Frequentie(s) Max. Output Power 5.15 – 5.25 GHz 200 mW 5.25 – 5.35 GHz 200 mW 5.47 – 5.725 GHz 2.4 G 2.4 – 2.4835 GHz 100 mW D-Link COVR-3902 User Manual...

  • Page 142

    υλικολογισμικό του προϊόντος είναι διαθέσιμα για λήψη από τη σελίδα του προϊόντος στην τοποθεσία www.dlink. com. Par les présentes, D-Link Corporation déclare que ce produit, ces accessoires et ce logiciel sont conformes aux Français [French] directives 2014/53/UE.Le texte complet de la déclaration de conformité de l'UE et le icroprogramme du produit sont disponibles au téléchargement sur la page des produits à...

  • Page 143

    2014/53/EU. Pełen tekst deklaracji zgodności UE oraz oprogramowanie sprzętowe do produktu można pobrać na stronie produktu w witrynie www.dlink.com. Desta forma, a D-Link Corporation declara que este produto, os acessórios e o software estão em conformidade Português [Portuguese] com a diretiva 2014/53/UE. O texto completo da declaração de conformidade da UE e do firmware...

  • Page 144

    Appendix C - Regulatory Information Hér með lýsir D-Link Corporation því yfir að þessi vara, fylgihlutir og hugbúnaður eru í samræmi við tilskipun Íslenska [Icelandic] 2014/53/EB. Sækja má ESB-samræmisyfirlýsinguna í heild sinni og fastbúnað vörunnar af vefsíðu vörunnar á www.

  • Page 145

    Access Points unterstützen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link COVR-3902 User Manual...

  • Page 146

    5 Ghz dentro de la UE. • Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link COVR-3902 User Manual...

  • Page 147

    Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) en TPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link COVR-3902 User Manual...

  • Page 148

    • Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link COVR-3902 User Manual...

  • Page 149

    • Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link COVR-3902 User Manual...

  • Page 150

    • Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link COVR-3902 User Manual...

  • Page 151

    D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.

  • Page 152

    D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.

  • Page 153

    D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.

  • Page 154

    D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné a nízkotoxické materiály.

  • Page 155

    D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.

  • Page 156

    D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.

  • Page 157

    D-Link och miljön På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.

  • Page 158: Regulatory Statements - Covr-1300e

    Note The country code selection is for non-USA models only and is not available to all USA models. Per FCC regulations, all WiFi product marketed in the USA must be fixed to USA operational channels only. D-Link COVR-3902 User Manual...

  • Page 159

    Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. D-Link COVR-3902 User Manual...

  • Page 160

    This unit is to be used with a power supply, Model WA-12M12R. Avertissement Cet appareil doit etre utilise avec une source de courrant, modele WA-12M12R. NCC 警語 : 以下警語適用台灣地區 依據 低功率電波輻射性電機管理辦法 第十二條: 經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自變更頻率、加大功率或變 更原設計之特性及功能。 第十四條: 低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至 無干擾時方得繼續使用。前項合法通信,指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工 業、科學及醫療用電波輻射性電機設備之干擾。 電磁波曝露量MPE標準值(MPE) 1 mW/cm ,送測產品實值為 0.22134 mW/cm D-Link COVR-3902 User Manual...

  • Page 161

    Potencia máxima de Salida Frequenza/e Potenza max. Output Frequentie(s) Max. Output Power 5.15 – 5.25 GHz 200 mW 5.25 – 5.35 GHz 200 mW 5.47 – 5.725 GHz 2.4 G 2.4 – 2.4835 GHz 100 mW D-Link COVR-3902 User Manual...

  • Page 162

    υλικολογισμικό του προϊόντος είναι διαθέσιμα για λήψη από τη σελίδα του προϊόντος στην τοποθεσία www.dlink. com. Par les présentes, D-Link Corporation déclare que ce produit, ces accessoires et ce logiciel sont conformes aux Français [French] directives 2014/53/UE.Le texte complet de la déclaration de conformité de l'UE et le icroprogramme du produit sont disponibles au téléchargement sur la page des produits à...

  • Page 163

    2014/53/EU. Pełen tekst deklaracji zgodności UE oraz oprogramowanie sprzętowe do produktu można pobrać na stronie produktu w witrynie www.dlink.com. Desta forma, a D-Link Corporation declara que este produto, os acessórios e o software estão em conformidade Português [Portuguese] com a diretiva 2014/53/UE. O texto completo da declaração de conformidade da UE e do firmware...

  • Page 164

    Appendix C - Regulatory Information Hér með lýsir D-Link Corporation því yfir að þessi vara, fylgihlutir og hugbúnaður eru í samræmi við tilskipun Íslenska [Icelandic] 2014/53/EB. Sækja má ESB-samræmisyfirlýsinguna í heild sinni og fastbúnað vörunnar af vefsíðu vörunnar á www.

  • Page 165

    Access Points unterstützen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link COVR-3902 User Manual...

  • Page 166

    5 Ghz dentro de la UE. • Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link COVR-3902 User Manual...

  • Page 167

    Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) en TPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link COVR-3902 User Manual...

  • Page 168

    • Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link COVR-3902 User Manual...

  • Page 169

    • Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link COVR-3902 User Manual...

  • Page 170

    • Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link COVR-3902 User Manual...

  • Page 171

    D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions.

  • Page 172

    D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.

  • Page 173

    D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.

  • Page 174

    D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné a nízkotoxické materiály.

  • Page 175

    D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.

  • Page 176

    D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.

  • Page 177

    D-Link och miljön På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.

This manual also for:

Covr-3902, Covr-1300e

Comments to this Manuals

Symbols: 0
Latest comments:
