PART LIST—Model No. PETL78132
To locate the parts listed below, see the EXPLODED DRAWING attached in the centre of this manual.
Key No. Qty. Description
1 1 Left Foot Rail
2 12 Foot Rail Screw
3 2 Isolator Bolt (Top)
4 2 Isolator Decal
5 2 Isolator Top Cap
6 2 Gray Isolator Spring
7 2 Isolator
8 2 Isolator Bottom Cap
9 2 Isolator Bracket Cover
10 2 Isolator Bracket
11 4 Isolator Bracket Bolt
12 2 Isolator Bolt
13 1 Walking Platform
14 2 Belt Guide
15 4 Belt Guide Screw
16 2 Walking Platform Screw (Rear)
17 2 Frame Pivot Bolt
18 1 Front Roller/Pulley
19 1 Magnet
20 9 Pivot Nut
21 2 Pivot Bushing
22 1 Reed Switch
23 1 Reed Switch Screw
24 1 Reed Switch Clip
25 2 Lift Pivot Bolt
26 2 Motor Washer
27 1 Pulley/Flywheel/Fan
28 1 Motor Pulley
29* 1 Idler Arm Assembly
30 1 Idler Arm Pivot Bolt
31 1 Motor
32 1 Idler Arm
33 1 Lift Frame
34 1 Motor Pivot Nut
35 2 Walking Platform Nut
36 1 Idler Pivot Washer
37 1 Incline Motor
38 4 Incline Motor Bolt
39 2 1/4" Washer
40 1 Roller Star Washer
41 1 Front Roller Adj. Bolt
42 2 Walking Platform Screw (Front)
43 1 Transformer
44 3 Hood Screw
45 1 Hood Cover
46 1 Hood Decal
47 1 Circuit Breaker
48 1 Controller
49 2 Power Cord
50 1 Receptical
R0404A
Key No. Qty. Description
51 2 Static Decal
52 10 3/4" Tek Screw
53 1 Belly Pan Clip
54 1 Belly Pan
55 1 Releasable Tie
56 1 Clamp Screw
57 1 Tie Holder Clamp
58 1 Cable Tie
59 1 Frame
60 1 Right Rear Foot
61 1 Chest Pulse Strap
62 2 Rear Roller Adj, Bolt
63 1 Rear Roller
64 1 Hex Key
65 1 5/32" Hex Key
66 1 Left Rear Foot
67 1 Right Foot Rail
68 1 Walking Belt
69 2 Warning Decal
70 2 Blue Isolator Spring
71 1 Pulse Bar
72 4 Pulse Bar Screw
73 1 Splitter
74 1 Wire Harness
75 1 Right Top Endcap
76 4 Console Bolt
77 4 Internal Star Washer
78 5 Hood Cover Screw
79 2 Upright Spacer
80 1 Right Upright
81 1 Left Top Endcap
82 1 Latch Assembly
83 1 Controller Wire
84 1 Left Upright
85 2 CD Holder
86 4 Upright Bolt
87 8 U-Nut
88 2 Upright Endcap (Lower)
89* 2 Extension Leg Assembly
90 2 Wheel Bolt
91 2 Warning Decal
92 2 Extension Leg
93 1 Small Nut
94 2 Wheel
95 2 Levelling Foot
96 4 Extension Leg Bolt
97 1 Upright Base
98 1 Photo Switch
99 2 Base Pad
100 2 Upright Base Endcap
34

IMPORTANT PRECAUTIONS

WARNING:
To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described.
3. Place the treadmill on a level surface, with at
least 2.5 m (8 ft.) of clearance behind it and
0.5 m (2 ft.) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 125 kg (275 lbs.) or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women. Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. When connecting the power cord (see page
10), plug the power cord into an earthed cir-
cuit. No other appliance should be on the
same circuit. When replacing the fuse, an
ASTA approved BS1362 type should be fitted
to the fuse carrier. A 13 amp fuse should be
used.
11. If an extension cord is needed, use only a 3-
conductor, 1mm 2 (14-gauge) cord that is no
longer than 1.5 m (5 ft.).
12. Keep the power cord away from heated sur-
faces.
13. Never move the walking belt whilst the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See BE-
FORE YOU BEGIN on page 5 if the treadmill is
not working properly.)
14. Never start the treadmill whilst you are stand-
ing on the walking belt. Always hold the
handrails whilst using the treadmill.
15. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
16. The pulse sensors are not medical devices.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensors are intended
only as exercise aids in determining heart
rate trends in general.
17. Never leave the treadmill unattended whilst it
is running. Always remove the key, unplug
the power cord and move the on/off switch to
the off position when the treadmill is not in
use. (See the drawing on page 5 for the loca-
tion of the on/off switch.)
18. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 27.)
You must be able to safely lift 20 kg (45 lbs.) to
raise, lower, or move the treadmill.
19. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
20. When using iFIT.com CDs and videos, an
electronic "chirping" sound will alert you
when the speed and/or incline of the treadmill
is about to change. Always listen for the
"chirp" and be prepared for speed and/or in-
cline changes. In some instances, the speed
and/or incline may change before the per-
sonal trainer describes the change.
3
