ITEM PART
ITEM
NO. NUMBER
1 Derailleur Mount Cover 130209
2
Rear Axle 130757 Axle 148 x 12 Boost Locking Blk
3 Bearing Spacer 130759 Top Link Bearing Spacer (Lower)
4 (ST)
Top Link 130762
4 Top Link 130760
5
Box Link 130764
Bearing Cap
6 130765 Top Link Bearing Cap (Lower)
24mm OD
7 Bearing Cap 130778
8
Axle Upper 130780 Top Link Pivot Axle (Upper)
9 Bolt Shoulder 130785
10 Spacer 130789 Top Link Bearing Spacer (Upper)
11 Hanger 130790
12 Bolt Main Pivot 130791
13 Hanger Bolt 130798
14
Cone Adjuster 130807 Cone Adjuster Blk, 8.3 mm Height
15 Bumper 140006
16
O-Ring 140013
17 Plug 140038
Cable Guide
18
140039
Grommet
19 Cable Guide Plug 140040
Cable Guide
20 140042
Grommet
21
Clip 310001
22 Seat Collar 346941
TORQUE
DESCRIPTION QTY.
SPEC.
For Single Ring Setup 1 N/A
11 Nm /
1
100 in-lbs
1 N/A
Forged Top Link 1 N/A
Carbon Top Link 1 N/A
Forged Lower Link 1 N/A
2 N/A
Box Link Bearing Cap 4 N/A
20 Nm /
1
175 in-lbs
20 Nm /
Top Link Pivot Bolt 1
175 in-lbs
2 N/A
Derailleur Hanger Forged 1 N/A
7 Nm /
Box Link Expander Bolt 3
60 in-lbs
11 Nm /
Derailleur Hanger Bolt 1
100 in-lbs
4 N/A
Box Link Bumper 1 N/A
Seat Clamp o-ring 1 N/A
Box Link Pivot Plug 3 N/A
Cable Guide Grommet
2 N/A
(Head Tube)
Cable Guide Plug (Thru) 8 N/A
Cable Guide Grommet
1 N/A
(Rear Triangle)
Cable Guide Clip 2 N/A
Bolt-on 36.1 Blk 1 N/A
ITEM PART
ITEM
NO. NUMBER
23 Zerk Fitting 401011
24 BHCS M5 X 12 410010
25 (ST)
SHCS M6 x 22 410009
25
SHCS M6 x 22 410032
Socket Head, M6 x 22 Titanium
26 FHCS M6 x 12 410037
27 (ST) SHCS M6 x 40 410053
Front Shock Bolt, Socket Head,
27 SHCS M6 x 40 410050
M6 x 40 Titanium S275C SL
28 (ST) SHCS M6 x 45 410054
Rear Shock Bolt, Socket Head,
28
SHCS M6 x 45 410051
M6 x 45 Titanium S275C SL
29
Bearing 7902 430007
MAX Angular Contact Bearing
30 Bearing 6802 430008
31 Guard Flack SS 500254 Flack Guard S275C Seatstay
32 Protector Chainstay 500255
33 Guard Flack DT 500262
34 Guard Flack CS 500263
Decal California
35 500300
Bear
36
Head Badge 500335
37 Front Triangle
38
Rear Triangle
39 Shock
I N T E N S E
TORQUE
DESCRIPTION QTY.
SPEC.
5 Nm /
M6 x 1.0 2
40 in-lbs
Water Bottle Bolt, 6 Nm /
2
Button Head, M5 X 12 54 in-lbs
Cone Adjuster Bolt, 14 Nm /
4
Socket Head, M6 x 22 125 in-lbs
Cone Adjuster Bolt, 14 Nm /
4
125 in-lbs
Front Derailleur Mount Bolt, 7 Nm /
1
Flat Head, M6 x 12 Blk 60 in-lbs
Front Shock Bolt, 7 Nm /
1
Socket Head, M6 x 40 60 in-lbs
7 Nm /
1
60 in-lbs
Rear Shock Bolt, 7 Nm /
1
Socket Head, M6 x 45 60 in-lbs
7 Nm /
1
60 in-lbs
15 x 28 x 7 2RS
4 N/A
15 x 24 x 5 2RS
4 N/A
MAX Radial Bearing
1 N/A
Chain Stay Protector 1 N/A
Down Tube Flack Guard 1 N/A
Chainstay Flack Guard 1 N/A
Decal California Bear 1 N/A
Head Badge Flame Logo 1 N/A
Carbon, 4 Sizes 1 N/A
Carbon, 1 Size 1 N/A
Rear Shock 7.875" x 2"
1 N/A
(200mm x 50.8mm)
