DART ™ 1.0 DIAGRAM
Rotor Blade
Landing Gear
The safety guard is easy to clip on and off.Simply pull the clips away
from each motor mount and remove the DART ™ 1.0 from below.
Note:Always have the safety guard attached when flying in T-Mode and Mode 1.
REMOTE DIAGRAM
AUTO Start / land
SPEED START/LAND
Speed Setting Button
Speed Indicator
1 2
3
T
Left Bank Trim
Throttle/Yaw
3 CH Mode

REMOVABLE CONTROLLER GRIPS

Easily slide off and on.(see grip extenders card)
3
Safety Guard
Power On/Off
Calibrate Button
CALIBRATE STUNT
360˚ Stunt Rolls Button
Power Indicator
Forward Trim
3 4 C
Power On/Off
H
Right Bank Trim
Direction Control
3CH 4CH
Removable grip
Extender
4 CH Mode
Backward Trim
DO NOT FLY YOUR DART ™ 1.0 IN FOUL WEATHER!

PREPARING FOR FLIGHT

• Verify that there are 2"AAA"batteries inside the remote control unit and the DART ™ 1.0 has been fully charged.
• Make sure to be in a large space with an open radius of at least 50 feet.
• Make sure the empty space has no obstacles or rivers..Set your DART ™ 1.0 on a clean flat surface before take-off.
DO NOT ATTEMPT TO FLY YOUR DART ™ 1.0 IF THERE IS RAIN, SNOW, HEAVY WINDS, THUNDER OR LIGHTNING
OUTDOORS. IT COULD DAMAGE YOUR PRODUCT AND POSSIBLY EVEN CAUSE BODILY HARM.
SYNCING YOUR DART ™ 1.0
Charging
Important! When syncing your DART ™ 1.0 copter with the controller always make sure that the
Socket
copter is on a flat level surface. This insures that the 6-axis gyro is properly programmed to mimic
your trim settings.
Your utilizes an automatic 2.4G channel selection system that allows up to 8 people to fly side
DART ™ 1.0
by side in the same wireless range.
For One-person Play:
1.Before starting,make sure that the power on both your controller and DART ™ 1.0 are in the OFF
position.Make sure that there are no other 2.4G devices in the area as well.
2.Turn ON the DART ™ 1.0 and set it down on a flat surface.The white and red LED indicators of the
DART ™ 1.0 should flash.
3.Turn ON your remote and you will hear 2 short beeps,the white and red LED lights will start flashing
slower. Push the throttle all the way up and pull it down; You will hear 2 beeps and the LED
lights will turn solid,your DART ™ 1.0 and remote should have successfully synced.Should this
not happen,repeat all steps again.
For Multi-person Play:
4.Before starting,make sure that the power on all DART ™ 1.0s and Controllers are in the OFF position.
Make sure that there are no other 2.4G devices in the area as well.
5.Each person will have to sync their DART ™ 1.0 individually at a different time to avoid
interference.
Follow steps 1 to 3 above,making sure to keep away from other people while also making sure that
no one else is syncing at the same time.
6.After syncing a player's DART ™ 1.0,it should be left ON until all players have synced their DART ™ 1.0s.
7.Should there be a mistake/interference,all players must turn off their controllers and DART ™ 1.0s
and start the process all over again.

FLYING TIPS

• It is recommended that you operate the DART ™ 1.0 in a wide space.The ideal space should have a
61 m/200 ft radius.
• Parental guidance or adult supervision is suggested at all times.
• If you are flying the DART ™ 1.0 with others,make sure all spectators are behind you.
• For best performance,it is recommended that you operate the DART ™ 1.0 in zero wind conditions.
Wind can greatly affect the performance of the DART ™ 1.0.
WARNING
