Setting Rebound Damping on the Fox DPX2

Rebound is set from the most open (fully counter-clockwise) position.
The rebound setting is determined by the air pressure in the shock.
Refer to the table below for the suggested rebound setting. The number in the chart
refers to how many clicks in (clockwise) from the open setting the rebound should be set.

Setting Air Pressure on the Fox 36 Fork

Fox recommends setting sag between 15% and 20% of the total fork travel. The Shuttle comes with a
150mm fork, so the proper sag measurement is 22.5 - 30.0mm.
The air pressure in the Fox 36 fork should not exceed 8.3 [bar] (120 [psi]).
To achieve the proper sag, reference the chart below for an initail starting point.
AIR PRESSURE
[bar]
[psi]
< 8.3
<120
8.3 - 9.7
120-140
9.7 - 11
140-160
11 - 12.4
160-180
12.4 - 13.8
180-200
13.8 - 15.2
200-220
15.2 - 16.5
220-240
16.5 - 17.9
240-260
17.9 - 19.3
260-280
19.3 - 20.7
280-300
RIDER WEIGHT
[kg]
[lbs]
55 - 59
120 - 130
59 - 64
130 - 140
64 - 68
140 - 150
68 - 73
150 - 160
73 - 77
160 - 170
77 - 82
170 - 180
82 - 86
180 - 190
86 - 91
190 - 200
91 - 95
200 - 210
95 - 100
210 - 220
100 - 105
220 - 230
105 - 109
230 - 240
109 - 114
240 - 250
www.pivotcycles.com
SUGGESTED REBOUND
SETTING
Open
1
2
3
4
6
7
9
11
12
FOX 36
AIR PRESSURE
3.0 [bar] / 43 [psi]
3.2 [bar] / 46 [psi]
3.5 [bar] / 51 [psi]
3.8 [bar] / 55 [psi]
4.1 [bar] / 59 [psi]
4.3 [bar] / 63 [psi]
4.6 [bar] / 67 [psi]
4.9 [bar] / 71 [psi]
5.2 [bar] / 75 [psi]
5.4 [bar] / 79 [psi]
5.7 [bar] / 83 [psi]
6.0 [bar] / 87 [psi]
6.3 [bar] / 91 [psi]
