LOW VELOCITY POWDER ACTUATED TOOL
Operator's Instruction & Training Manual
• The Ramset HD22 is a light duty tool designed for applications such as small
room additions and basement remodels. Tool life will vary depending on work site
conditions and application.
• The model HD22 is a low velocity piston type fastening tool. It is designed for
use with Ramset .22 caliber CW powder loads and Ramset fasteners.
• Do not operate the Model HD22 before studying this manual carefully and
thoroughly understanding the material contained herein.
IMPORTANT: The tool warranty is only activated upon receipt by ITW Brands of the
completed Operator's Exam.
THIS TOOL IS FOR USE ONLY BY LICENSED OPERATORS.
YOU MUST OBTAIN A LICENSE BEFORE USING IT. A
TOOL OPERATOR'S CARD WILL BE ISSUED TO YOU
AFTER SUCCESSFULLY COMPLETING THE ENCLOSED
EXAM AND RETURNING IT TO RECEIVE YOUR CARD
AND ACTIVATE YOUR WARRANTY. OPERATOR'S
LICENSE CAN ALSO BE OBTAINED AT: www.ramset.com
MODEL HD22
Part #00022
Rev. 8/07
RD v001MA
Advertisement
Table of Contents
Related Manuals for RAMSET HD22
Summary of Contents for RAMSET HD22
- Page 1 Tool life will vary depending on work site conditions and application. • The model HD22 is a low velocity piston type fastening tool. It is designed for use with Ramset .22 caliber CW powder loads and Ramset fasteners.
-
Page 2: Warranty
The warranty will not be valid until the test is received, along with a copy of your sales receipt, and reviewed by ITW Brands. Operator's license can also be obtained at: www.ramset.com TO AVOID SERIOUS INJURY OR DEATH Operators and bystanders... -
Page 3: Safety Precautions
- the fastener or piston can seriously injure your hand in the event of an accidental discharge. 2. Always use only Ramset fasteners and loads at all times for consistent tool functioning. 3. Operators and bystanders must wear eye and hearing protection at all times. - Page 4 Failure to properly test fire to NOTE: Ramset loads are designed for determine correct power level may result use with Ramset tools. Do not attempt to use other power loads. Doing so may in overpowering the fastener, causing...
- Page 5 SAFETY PRECAUTIONS Operating the Tool 1. Always point the tool away from people and in a safe direction. 2. Never use tool when explosives or flam- mable materials are nearby. 3. Never fire the tool without a fastener. The piston will protrude from the muzzle of the tool, enter the work surface and possibly cause injury to the operator or a bystander.
- Page 6 SAFETY PRECAUTIONS 7. Never fasten into structural steel base STEEL CONCRETE material thinner than 3/16". Never fasten into concrete base material thinner than 3 times shank penetration. Always maintain minimum penetration requirements. 8. Fastening into block and masonry is not recommended.
-
Page 7: Operating Problems
SAFETY PRECAUTIONS 2. Never carry fasteners or other hard objects in the same pocket or container with powder loads. The loads could be set off, causing serious injury or death. 3. A person that is color blind must be extra careful when loading the tool. - Page 8 "Defective - Do Not Use". Call 1-877-ITW-BRANDS (1-877-489-2726) for technical assistance. RAMSET FASTENER SELECTION GUIDE .300 Head Plastic Fluted Drive Pins .300 Head Plastic Fluted Drive Pin with 7/8" Washer...
-
Page 9: Tool Operation
TOOL OPERATION CAUTION! Be sure to read and understand all safety precautions and complete the Operator's Exam before attempting to operate the tool. Check to be sure the tool is unloaded and no foreign objects or fasteners are in the barrel. Perform daily function test before operating. OPERATION Check the functioning of the tool, without a powder load or fastener in the tool, by pushing down against the work surface, checking to be sure the groove portion of... -
Page 10: Thorough Cleaning
TOOL OPERATION 4. Close tool by pulling the barrel back to Semi-close position the semi-closed position. Never attempt to close the tool by exerting force on the front of the barrel. Never place your fingers or hands over the muzzle end of the bar- rel. -
Page 11: Troubleshooting
TROUBLESHOOTING Tool operator must carefully follow all operating instructions and precautions to successfully operate the tool. Following is a list of potential situations an operator may encounter and the probable causes: • If a tool problem occurs and technical assistance is required, please call 1-877-ITW-BRANDS (1-877-489-2726) WARNING: Do not operate a tool that is not functioning properly. - Page 12 TROUBLESHOOTING PISTON OVERDRIVE Piston overdrive is a problem that occurs after TO AVOID PISTON OVERDRIVE the tool is fired. The piston may extend into the • Decrease power level. Note: work surface as much as 1/2". Piston overdrive Always make test fastenings can occur because of several reasons: with lightest load and increase until proper level is found.
- Page 13 APPLICATIONS Wood to Concrete 7/8" washer provides a greater bearing sur- face to the wood member, minimizing uplift. Wood to Steel Fastener should penetrate steel completely for maximum holding power. Furring Strip to Concrete or Masonry Walls When fastening into masonry, shoot into horizontal joints only.
-
Page 14: Permanent Installation
HOW TO SELECT A POWDER ACTUATED FASTENER DETERMINE FASTENER TYPE Drive pins are used to directly fasten an object (permanent installation). Threaded studs are used where the object fastened may later be removed or where shimming is required. The following shows how to determine shank and thread length: PERMANENT INSTALLATION 1A To Concrete 1B To Steel... - Page 15 ■ ■ 15. It is not necessary to read the Operator's 5. A powder actuated tool can be safely used in an Manual prior to operating the Model HD22 low explosive or flammable atmosphere. velocity powder actuated tool. True False ■...
- Page 16 The Model HD22 Tool is warranted for 90 days from date of purchase. I certify that I have read and understand the Model HD22 Tool Operator's Instruction and Training Manual and have taken the Operator's Exam on the reverse side.
