- Page 1 UPS2000-G-(1 kVA-3 kVA) Battery Pack Quick Installation Guide Issue Date 2015-10-12 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: About This Document
Indicates a potentially hazardous situation which, if not avoided, could result in equipment damage, data loss, performance deterioration, or unanticipated results. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 4 Issue 03 (2015-10-12) Added the 2 kVA UPS battery pack. Issue 02 (2015-08-10) Updated the dimensions of battery pack. Issue 01 (2015-06-25) This is the first release. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 5: Table Of Contents
4.2 Connecting a Battery Pack and a 2 kVA UPS ......................15 4.3 Connecting a Battery Pack and a 3 kVA UPS ......................17 A Acronyms and Abbreviations ....................20 Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 6: Precautions
UPS2000-G-(1 kVA-3 kVA) Battery Pack Quick Installation Guide 1 Precautions Precautions Only the professional technical personnel designated by Huawei are allowed to install and operate the battery pack. Read this document closely before operating the battery pack. Keep this document for future use. -
Page 7: Appearance And Feature
ESS-96V12-9AHBPVBB02. The appearance for 1 kVA UPS, 2 kVA UPS, and 3 kVA UPS are the same. The figures below based on the 3 kVA UPS, as shown in Figure 2-3. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 8: Features
Two group of battery strings are embedded, each group with three 9 Ah/12 V DC batteries. The output voltage of battery pack is 36 V DC. Basic Features Color: black Panel: plastic Backplane: grey (SECC/SGCC) Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 9: Battery Pack For 2 Kva Ups
Color: black Panel: plastic Backplane: grey (SECC/SGCC) Dimensions (H x W x D): 88 mm x 438 mm x 410 mm Weight: 21.7 kg Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 10: Battery Pack For 3 Kva Ups
Color: black Panel: plastic Backplane: grey (SECC/SGCC) Dimensions (H x W x D): 88 mm x 438 mm x 510 mm Weight: 28.9 kg Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 11 UPS2000-G-(1 kVA-3 kVA) Battery Pack Quick Installation Guide 2 Appearance and Feature Graphics of the Interior Figure 2-6 ESS-96V12-9AHBPVBB02 battery pack interior Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 12: Installing The Battery Pack
Do not transport the battery pack by holding the mounting ears, front panel, or protective cover. Remove rings, watches, and other metal objects before you move the battery pack. 3.2 Preparations Get installation tools insulated to prevent electric shocks. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 13: Installation Procedure
Insulation gloves Hydraulic pliers Cable tie 3.3 Installation Procedure Rack-mounted battery packs can either be rack-mounted or tower-mounted. 3.3.1 Rack-Mounted Battery Pack Procedure: Step 1 Install mounting ears. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 14: Tower-Mounting A Battery Pack
The proposed torque is 3 N•m here. ----End 3.3.2 Tower-mounting a Battery Pack To tower-mount a battery pack, perform the following steps: Procedure: Step 1 Remove the front panel. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 15 Quick Installation Guide 3 Installing the Battery Pack Step 2 Adjust the battery pack panel as shown in the following figure. Step 3 Adjust Huawei logo and reinstall the front panel. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 16 Step 4 Assemble the support base and the extended part. The support base is the accessory of UPS, the accessory of battery pack only is the extended part. Step 5 Install the battery pack. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 17 3 Installing the Battery Pack The lateral dimensions of UPS and battery pack installed as the above figure is about 300 mm. Step 6 The installation is complete. ----End Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 18: Connecting A Battery Pack And A Ups
4.1 Connecting a Battery Pack and a 1 kVA UPS Connect the ESS-36V12-9*2AHBPVBB01 battery packs and the 1 kVA UPS using the battery cable delived with the battery pack, as shown in Figure 4-1. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 19 UPS or battery pack, another can be used to connect an external charger. In the preceding figures, the unused port on the battery pack on the right can connect to an external charger. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 20: Connecting A Battery Pack And A 2 Kva Ups
4.2 Connecting a Battery Pack and a 2 kVA UPS Connect the ESS-72V12-9AHBPVBB01 battery packs and the 2 kVA UPS using the battery cable delived with the battery pack, as shown in Figure 4-2. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 21 UPS2000-G-(1 kVA-3 kVA) Battery Pack Quick Installation Guide 4 Connecting a Battery Pack and a UPS Figure 4-2 Connection between the ESS-72V12-9AHBPVBB01 battery pack and a 2 kVA UPS Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 22: Connecting A Battery Pack And A 3 Kva Ups
4.3 Connecting a Battery Pack and a 3 kVA UPS Connect the ESS-96V12-9AHBPVBB02 battery packs and the 3 kVA UPS using the battery cable delived with the battery pack, as shown in Figure 4-3. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 23 ESS-96V12-9AHBPVBB02 is allowed a maximum of four groups in parallel. The text uses two groups in parallel as an example. If four groups need to be connected, refer to the connection method of two groups. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 24 UPS or battery pack, another can be used to connect an external charger. Before connecting, please make sure that the breaker of the battery pack is in the OFF state. Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 25: A Acronyms And Abbreviations
UPS2000-G-(1 kVA-3 kVA) Battery Pack Quick Installation Guide A Acronyms and Abbreviations Acronyms and Abbreviations uninterruptible power system Issue 03 (2015-10-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
