- Page 1 Residential ventilation DESIGN, DECO, IN LINE Axial fans Selection guide Design Deco In Line Deco Design installation In Line installation...
-
Page 2: Selection Guide
DESIGN 150 DECO 100 DECO 125 All uses IN LINE 100 IN LINE 125 IN LINE 150 Timer switch DESIGN 100 T DESIGN 125 T DESIGN 150 T Ideal for kitchens DECO 100 T DECO 125 T Humidity detection DESIGN 100 H... - Page 3 Axial fans DESIGN Advantages Compliance • Ultra-flat design. • CE electrical safety. • Silent from 26 dB(A). • WEEE recycling. • Very low power consumption : from 5.6 W. • Available with occupancy detection. • Exists in Ø 100, 125 and 150 mm...
- Page 4 Axial fans DECO Advantages Compliance • Aesthetic and discreet. • CE electrical safety. • Silent from 26 dB(A). • WEEE recycling. • Very low power consumption : from 5.6 W. • White or aluminium finish. FIELD OF APPLICATION DIMENSIONS (mm) - WEIGHT •...
- Page 5 Axial fans IN LINE Avantages Compliance • Silent. • CE electrical safety. • Air exhaust or air supply. • WEEE recycling. • No fan in the room (fitted in the duct). FIELD OF APPLICATION DIMENSIONS (mm) - WEIGHT • Intermittent ventilation of a room. Ø...
-
Page 6: Wall Or Ceiling Installation
Axial fans DESIGN - DECO / DECO ALU INSTALLATION 1- Installation 2- removable backdraft damper • Connection diameter: Ø 100/125/150 mm (depending on model). DESIGN DECO DECO Alu • Fitted using 4 screws (supplied). • Wall or ceiling-mounted (fastening screws and plugs supplied). -
Page 7: Electrical Connection And Operation
Axial fans DESIGN - DECO / DECO ALU 5- Electrical connection and operation 1• Manual operation Immediate On/Off control using switch S. DECO DECO Alu 2 • Timed operation The extractor fan is activated using the switch S. Once turned off, the fan continues to operate for the time specified on the timer, between 2 and 30 minutes. -
Page 8: Installation
Axial fans DESIGN - DECO / DECO ALU INSTALLATION 5- Electrical connection and operation (cont.) 3• Humidity-controlled operation The axial fan is activated using the switch S or when the humidity level H, pre-set between 60% and 90%, is exceeded. -
Page 9: Fresh Air Intake
Axial fans DESIGN - DECO / DECO ALU 6- Fresh air intake • Requires an air inlet terminal (with air passage S) or a door undercut (height H). Ø 100 mm 100 cm 1 cm 125 mm 200 cm 2 cm... - Page 10 Axial fans IN LINE INSTALLATION 1- Installation 2- Installation on wall or ceiling • Installation inside a duct. • Maximum temperature of exhaust air: 40 °C • Requires an air inlet terminal or door undercut for correct ventilation of the room. d ≤...
- Page 11 Axial fans IN LINE 6- Fresh air intake • Requires an air inlet terminal (with air passage S) or a door undercut (height H). Ø 100 mm 100 cm 1 cm 125 mm 200 cm 2 cm 150 mm 250 cm 3 cm 7- Authorised installation locations •...
- Page 12 • Multiple operating modes. ■ AlDES AÉRAulIQuE - Headquaters: Tel : +33 4 78 77 15 15 - Fax: +33 4 78 76 15 97 ■ ALDES INTERNATIONAL - Tel: +33 4 78 77 15 34 - Fax: +33 4 78 77 15 56...
