Prochem Bravo Safety, Operation & Maintenance Instructions

Portable carpet & upholstery spot cleaning machine

Advertisement

Quick Links

Bravo
PORTABLE CARPET & UPHOLSTERY
SPOT CLEANING MACHINE
SAFETY, OPERATION & MAINTENANCE
INSTRUCTIONS
MODELS:
BV100 BRAVO SPOTTER
BV300 BRAVO PLUS
CAUTION – READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE
Bravo Manual 1/7/15
Page 1 of 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bravo and is the answer not in the manual?

Questions and answers

Summary of Contents for Prochem Bravo

  • Page 1 Bravo PORTABLE CARPET & UPHOLSTERY SPOT CLEANING MACHINE SAFETY, OPERATION & MAINTENANCE INSTRUCTIONS MODELS: BV100 BRAVO SPOTTER BV300 BRAVO PLUS CAUTION – READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE Bravo Manual 1/7/15 Page 1 of 19...
