- Page 1 SAFETY, OPERATION & MAINTENANCE INSTRUCTIONS POWERMATE AC1204 • CAUTION-READ THE INSTRUCTION MANUAL BEFORE USING THE APPLIANCE. • ORIGINAL INSTRUCTIONS • MANUAL ALSO AVAILABLE ON-LINE AT WWW.PROCHEM.CO.UK Page 1 of 18 AC1204 Powermate Manual 10/01/18...
- Page 2 Website: www.prochem-uk.com All information and specifications in this manual are current at the date of issue. However, because of Prochem Europe’s policy of continual product improvement, we reserve the right to make changes at any time without notice. Please note that this manual applies to all models and explains variations including accessories used.
- Page 3 CONTENTS PAGE NO. WARRANTY WARNING SECTION IMPORTANT SAFETY INSTRUCTIONS GENERAL DESCRIPTION OF APPLIANCE & IMPORTANT OPERATING INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS GENERAL MAINTENANCE GENERAL FAULT FINDING PARTS DIAGRAM PARTS LIST PARTS DIAGRAM PARTS LIST WIRING DIAGRAMS DECLARATION OF CONFORMITY Page 3 of 18 AC1204 Powermate Manual 10/01/18...
- Page 4 Prochem Europe Sales Department Telephone: +44 (0)20 8974 1515 Prochem Europe Ltd. EEE Producer Registration Number: WEE / AJ0044SY European Directive (2011/65/EU) Restriction of use of certain Hazardous Substances in Electrical and Electronic Equipment (RoHS2). This equipment does not contain more than the maximum permitted levels by...
-
Page 5: Warranty
Your Prochem unit is designed to give you many years of reliable service. If a problem should arise during or after the warranty period, contact the Prochem Authorised Distributor or the Prochem Service Department, for details of the services available. Only the original purchaser of the new equipment may seek performance of this warranty –... - Page 6 WARNINGS! • Warning! Machines shall not be used by children. Children should be supervised to ensure that they do not play with the appliance. This machine can be used by people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the machine in a safe way and understand the hazards involved.
-
Page 7: Important Safety Instructions
SERIOUS INJURY OR DEATH MAY RESULT IF Prochem Distributor or authorised representative in MACHINE IS IMMERSED IN WATER! the correct use of this equipment and suitable chemicals before attempting to clean. - Page 8 ! DO NOT use chemicals in the machine other than solution tank. If not properly dissolved, powdered those manufactured or recommended by Prochem cleaning solution may result in damage to the Europe.
-
Page 9: General Operating Instructions
This equipment has been engineered and manufactured to provide excellent performance and service. To ensure that your equipment will continue to perform as intended: Maintain equipment regularly- following the suggested maintenance schedule provided. Use only original PROCHEM parts when servicing. Operate equipment with care. If additional information is needed, please contact: PROCHEM 0208 974 1515 All information and specifications printed in the manual are current at the time of printing;... - Page 10 Packing up the AC1204 POWERMATE after use. When the cleaning task is finished. Switch off the Powermate the switch illumination will extinguish and the brush will stop turning. Remove the plug from the mains outlet. Flush the Powermate with clean water when you flush the pump system on the parent machine. Disconnect the solution line and release any pressure in the Powermate by depressing the solution valve trigger.
-
Page 11: General Maintenance
Should the power cord require replacement please follow the instructions below. The replacement cord and plug shall be of the same specification as the original, Prochem part number BE4901(3 core, 1.5mm with 13Amp sealed plug unit) Ensure that the machine is disconnected from the electrical supply and open the electrical housing by means of the tool required. -
Page 12: General Fault Finding
GENERAL FAULT-FINDING GUIDE NO POWER With the unit plugged into the mains outlet and the brush motor switched to on. PROBABLE CAUSES CORRECTIVE ACTION Defective power cord Replace Power Cord Blown plug fuse Replace fuse House or Building circuit breaker tripped Reset breaker switch. - Page 13 Page 13 of 18 AC1204 Powermate Manual 10/01/18...
-
Page 14: Parts List
PARTS LIST ITEM STOCK CODE PART NUMBER DESCRIPTION E02200 B02200 CABLE CLAMP D00352-3 LEVER VALVE A00065P ¼ BARB X ¼ MP NYLON H00564-2 WARNING LABEL TO AVOID ELECTRIC SHOCK E00525 G00525 PH VALVE C00303 1/8 X ¾ TUBULAR PIVOT E00095-1 A00168-18 BUSH ¼... - Page 15 Page 15 of 18 AC1204 Powermate Manual 10/01/18...
- Page 16 ITEM STOCK CODE PART NUMBER DESCRIPTION GU00102 A00102 FEMALE QC E00095-1 A00168-18 BRASS BUSHING E11527A 11527A-PW 1/8 HP HOSE ASSY E11593A G13658 VALVE WITH BRACKET CH4018 A00114B HEX NIPPLE 1/4MP X 1/8MP E12964 A12964 ¼ BRASS COUPLER D02382 WAND HANDLE Page 16 of 18 AC1204 Powermate Manual 10/01/18...
-
Page 17: Wiring Diagrams
WIRING DIAGRAM AC1204 Page 17 of 18 AC1204 Powermate Manual 10/01/18... -
Page 18: Declaration Of Conformity
Has been tested to comply with the 2006/95/EC Low Voltage (LVD) Directive A Technical file is held by Prochem Europe Ltd. Certificate of compliance and test reports have been issued by: Signed (For and on behalf of the Importer / EC Responsible Person)
