Printronix M4L Administrator's Manual page 32

Item
Use this item to setup printing darkness. The available setting is from 0 to 30, and
Density
the step is 1. You may need to adjust your density based on selected media.
Use this item to setup print speed. The each increase or decrease is 1 ips. Available
Print Speed
This item is used to fine tune media stop location. Available setting value is from
Tear Off
This item is used to set the print mode. There are 2 modes as below,
Printer Mode
Print mode
Tear Off Mode
Peeler Mode
Print Width This item is used to set print width. The available value is from "0" to "9".
This feature is used to print current printer available fonts list to the label. The
List Fonts
fonts stored in the printer's DRAM, Flash or optional memory card.
This feature is used to print current printer available images list to the label. The
List Images
images stored in the printer's DRAM, Flash or optional memory card.
This feature is used to print current printer available formats list to the label. The
List Formats
formats stored in the printer's DRAM, Flash or optional memory card.
List Setup This feature is used to print current printer configuration to the label.
Control Prefix
Format Prefix
Delimiter Char
This option is used to set the action of the media when you turn on the printer.
Selections
Media Power
Up
Calibration
No Motion
This option is used to set the action of the media when you close the printhead
Selections
Head Close
Calibration
No Motion
This option is used to adjust print position vertically on the label. The range is -
Label Top
This option is used to adjust print position horizontally on the label. The range is -
Left Position
Note: If printing from enclosed software/driver, the software/driver will send out the commands,
which will overwrite the settings set from the LCD panel
Description
setting is from 1 to 6.
"+" to "-" or "0" to "9".
Next label top of form is aligned to the print head
Enable the Label Peel Off mode
This feature is used to set control prefix character.
This feature is used to set format prefix character.
This feature is used to set delimiter character.
Feed Printer will advance one label
Printer will calibrate the sensor levels, determine
Length Printer will determine length and feed label
Feed Printer will advance one label
Printer will calibrate the sensor levels, determine
Length Printer will determine length and feed label
120 to +120 dots.
9999 to +9999 dots.
Description
burn line location
Description
length and feed label
Printer will not move media
Description
length and feed label
Printer will not move media
Default
16
2
0
Tear Off
812
N/A
N/A
N/A
N/A
N/A
N/A
N/A
No Motion
No Motion
0
0
