  • Page 1 REICHERT DENSITY4/5 User’s Guide...
  • Page 2 The information contained in this document was accurate at time of publication. Specifications subject to change without notice. Reichert, Inc. reserves the right to make changes in the product described in this manual without notice and without incorporating those changes in any products already sold.

  • Page 3: Table Of Contents

    Connecting DENSITY4/5 Sample Supply ..........14 Connecting Air Pump ................15 Connecting Reichert Universal Display ..........17 Connecting DENSITY4/5 And PC ............17 Connecting DENSITY4/5 To The Local Network ........17 Instructions for Use ..................... 18 Starting The DENSITY4/5 ................18 Keyboards ..................... 19 Icons ......................

  • Page 4: Warnings & Cautions

    Reichert guaran- tees and warrants the proper function of the DENSITY4/5 only, if no unauthorized adjustments are made to mechanical parts, electronic parts and software, and the following points are adhered to. Follow all ad- vises, warnings and instructions in the manual to ensure the correct and safe functioning of the Reichert DENSITY4/5.
  • Page 5 WARNING: ENSURE THAT THE DENSITY4/5 IS LOCATED IN A SUFFICIENTLY VENTILATED AREA, FREE FROM INFLAMMABLE GASES AND VAPORS. WARNING: CONNECT THE DENSITY4/5 TO INPUT POWER VIA A SAFETY SWITCH LOCATED A SAFE DISTANCE FROM THE INSTRUMENT. IN AN EMERGENCY, TURN OFF THE POWER USING THIS SWITCH.
  • Page 6 (continued) CAUTION: YOU CAN ONLY PRINT OUT YOUR MEASUREMENTS WITH A NETWORK-COMPATIBLE PRINTER, IF THE DENSITY4/5 IS ATTACHED TO YOUR NETWORK BY USING THE PROVIDED ADAPTER. CAUTION: DON’T PLUG OUT THE ETHERNET CABLE WHILE PRINTING. THIS COULD LEAD TO DATA LOSS.

  • Page 7: Symbol Information

    Symbol Information Symbol Information The following symbols appear on the instrument. Caution symbol indicating important information and maintenance instructions included in this User’s Guide Warning Alternating Current Power Manufacturer Date of Manufacture 2016 2016 Catalog Number Serial Number Waste of Electrical and Electronic Equipment Compliance to Low Voltage Directive 2006/95/EC Electromagnetic Compatibility Directive 2004/108/EC Fragile Contents in Shipping Container - handle with care...

  • Page 8: Introduction

    Please retain this guide for future reference and to share with other users. For additional copies of this manual or questions related to the DENSITY4/5, refer to the following Reichert webpage. http://www.reichertai.com/products/benchtop-refractometers/...

  • Page 9: Density4/5 Introduction

    (Continued) DENSITY4/5 Introduction The DENSITY4/5 is the new density meter available from Reichert and designed for fast and reliable measurement of relative density and concentration of fluid samples. It is designed for continuous density measurement in a broad range of applications and has a sealed measurement system with the flexibility to measure the density for many fluids.

  • Page 10: Oscillating U-Tube

    P reference Oscillating U-Tube The DENSITY4/5 has a built-in reference oscillating U-Tube, which is a new method of measuring density. Approximately 1.0 ml of sample is needed for a measurement and the device offers very high accuracy and resolution. Working with an oscillating U-Tube is ultra fast compared to other methods and true density is provided in the measurement.

  • Page 11: Instrument Setup

    Instrument Setup Parts ID 1400500-101 Rev. A...

  • Page 12: Accessories

    8. Package of 10 ml Syringes. 9. Package of 5 ml Syringes. 10. Connecting Hoses and Fittings. 11. Air Filter. Note: It is recommended that only Reichert parts be used with the DENSITY4/5 or damage may occur to this instrument. 1400500-101 Rev. A...

  • Page 13: Setting Up The Density4/5

    DENSITY4/5. Screw Holes Figure SU-01, DENSITY4/5 Parts Using the hose and connectors delivered with the DENSITY4/5, connect the outlet side of the Air Cartridge to the rear of the device. Figure SU-02, Attached Air Cartridge -continued-...

  • Page 14: Connecting Density4/5 Sample Supply

    Instrument Setup (continued) Setting Up the DENSITY4/5 (continued) Connecting DENSITY4/5 Sample Supply Screw one side of the Connection Hose Density PTFE into one inlet of the Sample Supply. Screw the Out- let Hose PTFE into the other inlet. NOTE: Always use the same inlet for waste and the same inlet for samples to avoid contamination.

  • Page 15: Connecting Air Pump

    After a measurement you should clean the sample compartment of the DENSITY4/5. • Connect the syringe to the DENSITY4/5 as shown above and flush it with distilled water. • After flushing it with water, blow filtered air into the tubing that goes to the sample compartment to dry the compartment and remove any contaminants.
  • Page 16 Instrument Setup (continued) Setting Up the DENSITY4/5 (continued) Connecting Air Pump (continued) Now connect the delivered Connection Hose Compressed Air and the Luer Adapter female as indicated below. Figure SU-09, Clean with Dry Air Ensure that the open end of the hose from the outlet of the sample compartment is put into the Glass Cyl- inder (~ 130ml) for collecting unwanted fluid and contaminants.

  • Page 17: Connecting Reichert Universal Display

    (continued) Connecting Reichert Universal Display to the DENSITY4/5 Connect one end of the 9 pin Reichert Serial Connector Cable to the serial port of the DENSITY4/5. Figure SU-10, DENSITY4/5 with Universal Display Connect the other end of the 9-pin Reichert Serial Connector Cable to the serial port of your Universal Display.

  • Page 18: Instructions For Use

    After turned on, the DENSITY4/5 automatically performs a brief self test. The process of the start-up pro- cedure is shown graphically on the display. If this is your first use of the DENSITY4/5 you are directed to the main screen.

  • Page 19: Keyboards

    (continued) Keyboards In different menus of the DENSITY4/5 you will need to type various names, passwords or numbers. On the left you can see the default keyboard with capital letters. By pressing the abc button the keyboard changes to small letters. If you press the 123 button you are reaching a keyboard with numbers and some of the most important special characters, that you can see on the picture in the middle.

  • Page 20: Icons

    Instructions for Use (continued) Icons The icons of the Reichert DENSITY4/5 could be divided into two different types. Menu Icons The basic menu icons on on your device. OK – Confirm and close menu Close – Abort and close menu Information – Information, details and help for the current values Settings –...

  • Page 21: Main Menu

    (continued) Main Menu At the main menu you can change all important settings of your Reichert DENSITY4/5. It is possible to generally configure your device, calibrate it or add custom scales. All menus and submenus will be ex- plained on the following pages.

  • Page 22: User Interface

    DO NOT DISCONNECT INPUT POWER OR SET THE DENSITY4/5 TO OFF DURING THE CALIBRATION OR DAMAGE TO THE INSTRUMENT OR SOFTWARE MAY OCCUR. Sometimes you need to (re-)calibrate the touchscreen of your DENSITY4/5. Follow the steps be- low to calibrate: 1.

  • Page 23: Zeroing

    (continued) Zeroing At least once a week you have to set your DENSITY4/5 to zero. Always set the DENSITY4/5 to zero with the temperature you want to achieve higher stability. First select the target temperature as usual. Always set your device to zero with water and air, so do both calibrations after another. To make the unit zero correctly on your DENSITY4/5 follow the steps listed below: 4.

  • Page 24: Measurement

    (continued) Measurement After starting your DENSITY4/5, you will be at the main screen. Please remember the advised warm-up time is 30 minutes! After the unit is warmed up, to start a measurement just press the green Start button. Every decimal place in black is stable, grey numbers are still in the measuring process or just showing the measuring resolution.
  • Page 25 Figure IU-11, Allowed Deviations By pressing the Reichert logo on the upper left, you will select a menu with information about the software version and the device. By pressing the icon in the upper right, you will select the Main Menu.

  • Page 26: Measuring With Syringe

    Connect the syringe and push the sample from the syringe into the device by pressing the plunger down slowly. From now on the Reichert DENSITY4/5 measures and displays the density and other important measurements automatically.

  • Page 27: Density4/5 And Universal Display

    Serial orUSB port. The Serial Interface port is COM1 internally and the four USB ports are COM 2 to COM 5 (refer to the figure below). If you use them with the Reichert USB / Serial Converter please connect those devices in sequential order (do not skip a port).

  • Page 28: Density4/5 Remote Mode

    (continued) DENSITY4/5 Remote Mode After turning ON the DENSITY4/5 and Universal Display you have to configure the display as described in the Universal Display user manual to create a stable connection: If you want to use your DENSITY4/5 with your Universal Display, please connect the DENSITY4/5 with Serial Port (COM1) of the Universal Display.
  • Page 29 (continued) DENSITY4/5 Remote Mode (continued) As long as the DENSITY4/5 is in remote mode, you can not see nor use the buttons . You can still turn on or off the light of the visual sample control by pressing . To end the remote connection, press the button local mode on the DENSITY4/5 display.

  • Page 30: Update Density4/5 Software

    Instructions for Use (continued) DENSITY4/5 Remote Mode (continued) The Calibrate button starts the zeroing menu on the DENSITY4/5 . The Universal Displays shows the mes- sage “Please control the DENSITY4/5 directly” and the calibration itself has to be performed According to the paragraph Instructions for Use, Zeroing. Figure IU-16, Set to Zero by Using the Universal Display...

  • Page 31: Cleaning & Maintenance

    If you measure similar samples in sequence and the samples can be easily removed from the measuring cell, it is not required to rinse the DENSITY4/5 after each measurement. In this case a careful rinsing pro- cedure using adequate purifiers must take place after the measurement sequence.

  • Page 32: Choosing Correct Purifier

    The best way to inspect the device is to remove it from the power supply. It is advised to clean the device after removing. If any deviations are higher than the specified values, please contact the Reichert – cus- tomer service.

  • Page 33: Specifications

    Specifications Technical Specifications DENSITY4/5 Temperature Compensation Minimum Sample Amount Approx. 1 ml Display 3.5” Color-TFT Touchscreen Environment Conditions Temp.: 10° to 35°C / Humidity: < 85% / Altitude up to 2000 m (above mean sea level) Power Supply 90 - 265 V, 50/60 Hz, 150 VA max.

  • Page 34: Warranty

    If notified promptly in writing of any action brought against the purchaser based on a claim that the instru- ment infringes a U.S. patent, Reichert will defend such action at its expense and will pay costs and damages awarded any such action, provided that Reichert shall have sole control of the defense of any such action with information and assistance (at Reichert’s expense) for such defense, and of all negotiation for the settlement...
  • Page 35 Notes 1400500-101 Rev. A...
  • Page 36 Depew, NY 14043 Toll Free: 888-849-8955 Phone: 716-686-4500 Fax: 716-686-4555 Email: reichert.information@ametek.com www.reichert.com Authorized European Representative AMETEK GmbH Business Unit Reichert Carl-von-Linde-Strasse 42 85716 Unterschleissheim/Munich Germany Email: info.reichert-de@ametek.com Tel: +49 (89) 315 8911 0 Fax: +49 (89) 315 891 99 ISO-9001 Certified 1400500-101 Rev.

This manual is also suitable for:

Density5
