Model Nos. V 10 / V10-3 NAT GAS
Model Nos. V12 / V12-3 L.P.G
DECORATIVE COAL EFFECT GAS
USER INSTRUCTIONS
This appliance is only for use on Natural Gas (G20) at a supply
pressure of 20 mbar in GB / IE (Model No. V10/V10-3)
or
Propane G31 at a supply pressure of 37mbar in GB / IE (Model
No. V12/V12-3)
Intrepid 2
Intrepid 3
STOVE
Advertisement
Related Manuals for Vermont Castings Intrepid 2
Summary of Contents for Vermont Castings Intrepid 2
- Page 1 Intrepid 2 Intrepid 3 Model Nos. V 10 / V10-3 NAT GAS Model Nos. V12 / V12-3 L.P.G DECORATIVE COAL EFFECT GAS STOVE USER INSTRUCTIONS This appliance is only for use on Natural Gas (G20) at a supply pressure of 20 mbar in GB / IE (Model No. V10/V10-3) Propane G31 at a supply pressure of 37mbar in GB / IE (Model No.
- Page 2 The Model number of this appliance is V 10;V10-3;V12;V12-3 and it is manufactured by: - The rating plate is located on the control panel on the underside of the appliance VERMONT CASTINGS INC. Trentham Lakes Stoke-on-Trent...
-
Page 3: Important Safety Information
ABOUT YOUR NEW INTREPID GAS STOVE The Intrepid decorative coal effect gas stoves incorporate a unique and highly developed fuel bed, which gives the realism of a loose coal layout, combined with realistic flames and glow. The use of durable hard ceramic material in the construction of the fuelbed components ensures long and troubles free operation. -
Page 4: Operating The Stove
WARNING a) THIS APPLIANCE MUST NEVER BE OPERATED WITH THE DOORS OPEN. b) IF THE GLASS IS CRACKED OR MISSING THE STOVE MUST NOT BE USED. c) THE STOVE IS DEEMED TO BE A WORKING SURFACE AND IS THEREFORE HOT AND SHOULD NOT BE TOUCHED, EXCEPT FOR THE CONTROL KNOB AND ADJACENT PANELS. -
Page 5: Spillage Monitoring System
With a wire brush treat any areas needing attention (only cast iron). Ensure that the surface is clean and dry. Touch-up the area with Vermont Castings High Temperature Stove paint. Take care when using the paint as two coats will give better results than one thick coat. - Page 6 Never use harsh chemicals or abrasives to clean the glass. For any stubborn deposits contact your local dealer for a suitable cleaning agent. Cleaning the griddle on the top of the stove (only applicable to Intrepid 2 models). Leave the stove to cool completely. Due to the griddle been a natural finish, slight discoloration may occur due to the heat of the appliance.
- Page 7 SECTION 3 ASSEMBLING THE CERAMICS, AND FUEL BED a) Place the insulating mat centrally on to the fuelbed support then place the hard ceramic base on top of the insulating mat, and pull both fully forwards to the burner. Make sure that the ceramic base is located centrally.
- Page 8 b) Place both the hard ceramic fuel bed sections on to the base so that the location lugs fit snugly into the recesses on the fuel bed sections. c) Place the Front Ceramic Rails centrally onto the Semi-Circular location plate situated at the front of the burner.
- Page 9 e) Select four of the large coals and two small coals, and place them on the front of the fuel bed directly behind the spaces between the front row of coals. f) Place a row of five coals to occupy the spaces behind the second row of coals. Place the remaining four large coals as shown below (Taking care not to allow the coals to be trapped behind the fuelbed):-...
-
Page 10: User-Replaceable Parts
CORGI registered gas installer. The part numbers of the user replaceable parts are as follows, these are available from VERMONT CASTINGS,INC who may be contacted at the address shown on the rear cover. Fuelbed base... - Page 11 Due to our policy of continual improvement and development the exact accuracy of descriptions and illustrations cannot be guaranteed Part no. V12-40060 Issue 6 VERMONT CASTINGS,INC. Trentham lakes, Stoke-on-trent Staffordshire ST4 4TJ Telephone No 01782 339000 Service / Faults 08700 101187...
