8.2 Electromagnetic Compatibility Tests

Purpose:
This test series was performed to determine if the NET485 would meet selected requirements of the IEC
61000-6-1 and IEC 61000-6-3 specifications.
Deviations, Additions and Exclusions:
There were no deviations, additions to, or exclusions from the test specification during this test series.
EMC Laboratory Identification:
The electromagnetic compatibility tests were performed by Elite Electronic Engineering Incorporated of
Downers Grove, Illinois. Engineering Test Report No. 1302913-01.
Summary of Tests Performed:
The following electromagnetic compatibility tests were performed on the EUT in accordance with
61000-6-1 and IEC 61000-6-3:
Test Description
RE Radiated Emissions
ESD Electrostatic Discharge
Radiated Immunity
RI
EFT Electrical Fast Trans - Power
Conducted Immunity
CI
IEC 61000-6-1:2005 "Electromagnetic Compatibility (EMC) - Part 6-1: Generic standards – Immunity for
residential, commercial and light-industrial environments"
IEC 61000-6-3:2011 "Electromagnetic Compatibility (EMC) - Part 6-3: Generic standards – Emission
standard for residential, commercial and light-industrial environments"
IEC 61000-4-2:2008 "Electromagnetic Compatibility (EMC), Part 4: Testing and Measurement Techniques,
Section 2: Electrostatic Discharge Test"
IEC 61000-4-3:2010 "Electromagnetic Compatibility (EMC) - Part 4: Testing and Measurement Techniques,
Section 3: Radiated, Radio-Frequency, Electromagnetic Fields"
IEC 61000-4-4:2011 "Electromagnetic Compatibility (EMC) - Part 4: Testing and Measurement Techniques,
Section 4: Electrical Fast Transient/Burst Immunity"
IEC 61000-4-6:2008 "Electromagnetic Compatibility (EMC), Part 4: Testing and Measurement Techniques,
Section 6: Immunity to conducted disturbances, induced by radio frequency fields"
NET485 User Guide
Test Range Result
30MHz to 1GHz Pass
4kV Pass
80MHz to 2.7GHz Pass
500V Pass
150kHz to 80MHz Pass
Tables
IEC
8-3
