Table 1-2 Multi-connector cable description
ID Core
Orange wire
White & black
Yellow wire
1
White & blue
Gray wire
Purple wire
Blue wire
2
3 -
4 -
Brown wire
5
White wire
6 -
1.4 Functional Features

Adopts non-cooling IR focal plane sensor.
Detects 8~14μm LWIR.


Achieves the resolution of 420*315 pixels.

Provides a thermal sensitivity as high as 50 mK.

Supports special lens with 8mm / 15mm / 25mm / 35mm / 50mm focal distance
(optional).

Supports Polarity /LUT switchover: black hot/white hot/rainbow/ironbow

Allows users to set measuring point or area and show and detect temperature: point
measuring (with mouse), area measuring (highest temperature), and full-screen
measuring (highest temperature) (functioning as a temperature measuring and
prewarning product).
Issue V1.0 (2015-11-25)
Function
Cathode of alarm
output 1
Cathode of alarm
output 2
Alarm output 1
Alarm output 2
Cathode of alarm
input
Alarm input 1
Alarm input 2
Network port
Audio input (line
input)
Audio output
RS485RS+
RS485RS-
DC 12V (2A)
Description
Connect to the alarm output device.
Connect to the alarm input device.
Connect with an Ethernet cable.
Input audio signal and receive analog
audio signal from audio pickup and
other devices.
Connect with sound box and other
external audio devices.
Connect with external PTZ and other
devices through the RS485 interface.
Connect with 12 V DC power supply
through the power interface.
