Record in the space below the listed information for future reference. The rated current is
printed on the serial number label attached to the oven side trim.
SERIAL NUMBER...............................................................................................
DATE OF PURCHASE..........................................................................................
PURCHASED FROM............................................................................................
.........................................................................................................................
PAGE OF 22
MICROWAVE OVEN
MWM 2030 W
MWM 2030 M
Users Manual
The manufacturer strives for continuous
improvement. For this reason, the text and
illustrations in this manual are subject to change
without notice.
DMO367
DMO368
DMO369
DMO370

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MWM 2030 W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Defy MWM 2030 W

Summary of Contents for Defy MWM 2030 W

  • Page 1 DMO368 DMO369 DMO370 MICROWAVE OVEN MWM 2030 W MWM 2030 M Users Manual Record in the space below the listed information for future reference. The rated current is printed on the serial number label attached to the oven side trim.

  • Page 2: Table Of Contents

    CONTENTS AND PAGE NUMBER IMPORTANT SAFETY INSTRUCTIONS SPECIFICATIONS EXAMINING YOUR MICROWAVE OVEN AFTER UNPACKING REDUCE THE RISK OF INJURY TO PERSONS EARTHING INSTALLATION RADIO INTERFERENCE ARCING UTENSIL AND COOKWARE GUIDE OVEN PARTS AND ACCESSORIES COUNTERTOP INSTALLATION OPERATING INSTRUCTIONS MICROWAVE COOKING GUIDE TROUBLE SHOOTING CLEANING AND CARE GENERAL GUIDELINES...

  • Page 3: Important Safety Instructions

    MPORTANT SAFETY INSTRUCTIONS his appliance is classified as Group 2 Class B ISM. Defined as (Industrial, Scientific and Medical) equipment in which radio-frequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and spark erosion equipment.
  • Page 4 o not use recycled paper products for cooking. They may contain impurities which could cause sparks and/or fires when used during cooking. o not pop popcorn unless popped in a microwave approved popcorn popper or unless it has been commercially packaged and is recommended especially for microwave ovens.
  • Page 5 icrowave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container. o reduce the risk of injury to persons: o not overheat liquids. tir the liquid both before and halfway through heating it. o not use straight-sided containers with narrow necks.
  • Page 6 o not operate the oven without the tray, the rotating base, and the shaft in their proper positions. ake sure that the power supply cord is undamaged and does not run under the oven or over any hot or sharp surface. he wall socket must be readily accessible so that the Microwaves plug can be easily unplugged in an emergency.

  • Page 7: Specifications

    SPECIFICATIONS DMO367, DMO369 DMO368, DMO370 Model: MWM 2030 W MWM 2030 M Rated Voltage: 230V~50Hz. 230V~50Hz. Rated Input Power: (Microwave) 1200 W 1200 W Rated Output Power: (Microwave) 700 W 700 W Operation Frequency: 2450 MHz 2450 MHz Oven Capacity (L)

  • Page 8: Reduce The Risk Of Injury To Persons

    REDUCE THE RISK OF INJURY TO PERSONS DANGER Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance. WARNING Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

  • Page 9: Radio Interference

    RADIO INTERFERENCE Microwave ovens can cause radio and TV interference. This may be reduced or eliminated by taking the following measures: 1. Clean the door and sealing surfaces of the oven. 2. Reorient the receiving antenna of the radio or the television. 3.

  • Page 10: Oven Parts And Accessories

    OVEN PARTS AND ACCESSORIES Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray x 1 Turntable ring assembly x 1 Instruction Manual x 1 Never place the glass tray upside Door Safety Lock System down.

  • Page 11: Countertop Installation

    COUNTERTOP INSTALLATION Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. Installation 1.Select a level surface that provides enough open space for the intake and/or outlet vents.

  • Page 12: Operating Instructions

    OPERATION INSTRUCTIONS The control panel consists of two function operators. One is a timer knob, and another a power knob. Power/Action Selector Use this operator knob to choose a cooking power level. It is the first step to start a cooking session.

  • Page 13: Microwave Cooking Guide

    TO START A COOKING SESSION Place food in oven and close the door. Turn Power Selector to select a power level. Use Timer knob to set a cooking time. NOTE: As soon as the timer is turned, oven starts cooking. When selecting time for less than 2 minutes, turn timer past 2 minutes and then return to the correct time.

  • Page 14: Trouble Shooting

    TROUBLE SHOOTING Normal occurrences. These are not a fault. Microwave oven interfering with TV reception. Radio and TV reception may be interfered with when microwave oven is operating. It is similar to the interference of small electrical appliances for example mixers, vacuum cleaners and electric fans.

  • Page 15: Cleaning And Care

    4) The oven should not be adjusted or repaired by anyone except a properly trained service technician. If it becomes necessary to replace the oven lamp, consult a Defy Service Centre to have it replaced. Replacement lamps are not covered by the warranty. The oven should be cleaned regularly and any food deposits removed.

  • Page 16: General Guidelines

    GENERAL GUIDELINES As microwave cooking differs from traditional cooking, the following guidelines should be considered whenever you use your microwave oven If the food is undercooked. Check if: • You have selected the correct power level. • The selected time is sufficient. Selected times depend on initial temperature, weight and density of the food etc.

  • Page 17: Microwave Recipes

    Use a tall, narrow container rather than a low and wide container. When reheating gravy, sauce or soup, do not fill the container more than 2/3. When cooking or reheating whole fish, score the skin. This prevents cracking. Shield the tail and head with small pieces of foil to prevent over-cooking but ensure the foil does not touch the sides of the oven.
  • Page 18 MICROWAVE RECIPES Easy Whole wheat Loaf Cooking Time: 17 minutes. An easy step by step method of making your own bread. Helpful Hints: Sunflower seeds may turn green if used untoasted. To toast, place in flat glass container, microwave on 100% (High) power, 10 minutes per 125ml of seeds or until brown, stirring frequently.
  • Page 19 MICROWAVE RECIPES Courgette and carrot muffins Cooking Time: 9 mins Serves: 15 people These muffins are excellent lunch-box fillers and an ideal way of getting the kids to eat their veggies. Ingredients: Self-raising flour, sifted (2 cups). 500 ml Bicarbonate of soda (1/2 tsp). 2.5 ml Ground cinnamon (1/2 tsp).

  • Page 20: Frequently Asked Questions

    FREQUENTLY ASKED QUETIONS Q : I accidentally ran my microwave oven without any food in it. Is it damaged? A : Running the oven empty for a short time will not damage the oven. However, it is not recommended. Q : Can the oven be used with the tray or tray rack removed? A : No.

  • Page 21: Service Centres

    SERVICE CENTRES If you have followed the instructions and still have a problem, contact the nearest Defy Service Centre. They will be able to advise you on any aspect of the product or send a qualified technician to repair it.

  • Page 22: Warranty

    WARRANTY 1 This certificate is issued by DEFY APPLIANCES (PTY) LIMITED manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
