You can rely on Defy. To simplify.
AIR FRYER MICROWAVE OVEN
Record in the space below the listed information for future reference.
SERIAL NUMBER
DATE OF PURCHASE
PURCHASED FROM
The manufacturer strives for continuous improvement. For this reason, the text and
inllustrations in this manual are subject to change without notice.
Users Manual
MWA 2434 MM
Before operating this oven, please read
these manual completely.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MWA 2434 MM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Defy MWA 2434 MM

Summary of Contents for Defy MWA 2434 MM

  • Page 1 MWA 2434 MM You can rely on Defy. To simplify. AIR FRYER MICROWAVE OVEN Users Manual Record in the space below the listed information for future reference. SERIAL NUMBER DATE OF PURCHASE PURCHASED FROM The manufacturer strives for continuous improvement. For this reason, the text and inllustrations in this manual are subject to change without notice.

  • Page 2: Precautions To Avoid Possible

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
  • Page 3 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (f) WARNING : This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS • INSTALLATION AND EARTHING INSTRUCTIONS ..........4 • IMPORTANT SAFETY INSTRUCTIONS ..............5 • WHICH UTENSILS CAN BE USED IN THE OVEN? ..........8 • What is a function, STANDBY POWER “0”? ..............9 • CONTROL PANEL ....................10 • ACCESSORIES....................... 11 •...

  • Page 5: Installation And Earthing Instructions

    INSTALLATION AND EARTHING INSTRUCTIONS How to examine your microwave oven after unpacking. Electrical Connection Unpack oven, remove all packing material, and examine the WARNING-THIS APPLIANCE MUST BE EARTHED. oven for any damage such as dents, broken door, latches or REFER TO RATING PLATE FOR VOLTAGE AND CHECK cracks in the door.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1.

  • Page 7: Save These Instructions

    To reduce the risk of injury to 13. The contents of feeding bottles and persons: baby food jars shall be stirred or shaken and the temperature a) Do not overheat the liquid. checked before consumption, in b) Stir the liquid both before and order to avoid burns.
  • Page 8 General Use Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven: 11. Do not use the oven for any reason other than food 14. Do not attempt to remove covers, panels, etc. preparation, such as for drying clothes, paper, or any other nonfood items or for sterilizing purposes.

  • Page 9: Which Utensils Can Be Used In The Oven

    TO AVOID EXPLOSION AND SUDDEN BOILIING 1. Eggs Never cook eggs in their shells. Steam will build up inside WARNING the shell during cooking and the egg will explode. If you want to cook or reheat eggs which have not been Liquids, such as water, coffee, or tea are able to be broken up by scrambling or mixing, you must always overheated beyond the boiling point without appearing to be...

  • Page 10: What Is A Function, Standby Power "0

    What is a function, STANDBY POWER “0”? • Standby power is the electric power consumed by electronic appliances without operating on inserting the plug into a socket. • STANDBY POWER “0” is function reducing standby power consumption. • This product can save energy in a standby mode, by setting the STANDBY POWER "O" mode. To turn on the oven, press and hold ZERO ON button until display is switched on and a beep sounds after plugging in.

  • Page 11: Control Panel

    CONTROL PANEL 1 Display : Cooking time, power level and indicators are displayed. M/W : When flashing, the oven is operating in MICROWAVE COOK. Grill : When flashing, the oven is operating in GRILL. Combi : When flashing, the oven is operating in COMBI. Convection : When flashing, the oven is operating in CONVECTION.

  • Page 12: Accessories

    ACCESSORIES This oven comes equipped with several accessories. They can be used in various ways to facilitate cooking. 1 Glass Turntable - Center the tray on the roller guide 3 Metal Tray - Put food or appropriate cookware directly on when using the microwave features.

  • Page 13: How To Use The Home Fryer Bowl

    How to use the Home Fryer bowl. I Composition of Home Fryer bowl. Fryer fan Fryer support Metal Tray Glass Turntable Roller Guide CAUTION : Please use the kitchen gloves while taking out the Home Fryer bowl because it is very hot. I How to use the Home Fryer bowl.

  • Page 14: Operation

    OPERATION Tips : Also remember to read this operating instructions for proper safety information and instruction before using the oven. Prior to setting the controls, place one cup of water in the oven, on a heat-proof glass measuring cup, for testing purposes. Note : When the cooking time has elapsed the oven beeps three times, “End”...

  • Page 15: Grill Cooking

    GRILL COOKING The grill enables you to heat and brown food quickly, without using microwaves. 1. Press Grill button once. Grill indicator lights. and ":0" is displayed. 2. Turn the dial knob to set the grilling time. For a grilling time of 11 minutes, turn the dial knob to the right to set 11:00.( up to 60 minutes ) “11:00”...

  • Page 16: Convection Cooking (With Pre-Heat)

    CONVECTION COOKING (with pre-heat) For convection cooking, it is recommended that you preheat the oven to the appropriate temperature before placing the food in the oven. (except for 40°C convection mode) The maximum preheating time is 30 minutes. If the cooking is not started immediately after preheating, the convection indicator will continue to flash and the preheated oven temperature will be displayed.

  • Page 17: Convection Cooking (Traditional Cooking)

    CONVECTION COOKING (traditional cooking) The convection mode enables you to cook food in the same way as in a traditional oven. Microwaves are not used. Always use oven gloves when touching the recipients in the oven, as they will be very hot. 1.
  • Page 18 Convection Cooking Recipe Manual Cook Menu Ingredients Method store-bought puff pastry, 50g * 3, All- 1. Dust the work surface and place the puff pastry dough. MINI SAUSAGE purpose flour, for dusting, 2. Place the sausages onto the dough. ROLL sausages 50g *3, 1egg (beaten), freshly 3.

  • Page 19: Combination Cooking

    COMBINATION COOKING ( Microwave + Convection + Upper Grill ) This function allows you to combine convection operation with microwave to produce traditional baked or roasted results in less time. Always use microwave-safe and oven-proof cookware. Glass or ceramic dishes are ideal as they allow the microwaves to penetrate the food evenly.

  • Page 20: Deodorization

    DEODORIZATION You can use the Deodorization function to remove unpleasant smells from the microwave oven. 1. Press Deodorization/Steam cleaning button once. The Deodoriziation indicator lights and "CL-1" is displayed. The oven starts deodorizing for 5 minutes. STEAM CLEANING (with Microwave Feature) This function helps you to clean the inside of oven.

  • Page 21: Weight Defrost

    WEIGHT DEFROST Weight Defrost automatically sets the defrosting times and power levels to give even defrosting results for frozen food. During the defrosting process the oven will beep to remind you to check the food. The oven will beep, open the door, turn the frozen food over and close the door, press the START/+30sec button.

  • Page 22: Home Fryer

    HOME FRYER Convenient function to set the temperature and cooking time automatically and simply by pressing Home Fryer button. Always use oven gloves when touching the recipients in the oven. Please repeat the process from the top when you use the Home Fryer sequentially. User can easily set the cooking time by adjusting the dial when Home Fryer menu 8 is selected.
  • Page 23 Manual Cook Menu Ingredients Method 400g potatoes, 50g ground cheddar 1. Boil the potatoes for 20 minutes and mash after removing the skin. POTATO cheese, 50g ground parmesan cheese, 2 2. Add cheese, 1 egg and spring onions and season with salt and pepper. CROQUETTES chopped spring onions, 50g flour, salt, 3.

  • Page 24: Auto Cook

    AUTO COOK This function allows you to simply and automatically cook a range of popular foods. Always use oven gloves when touching the recipients in the oven. 1. Press Auto Cook button once. Auto Cook indicator light. “AC-1 “ will show in the display. 2.

  • Page 25: 30Sec

    +30sec The +30sec function allows the oven to being cooking immediately on full power. The +30sec button has been pre-programmed to increase in increments of 30 seconds up to a maximum time of 5 minutes. 1. Press START/+30sec button. The oven will be “ : 30” is displayed. M/W indicator lights. And the oven will start immediately.

  • Page 26: General Guidelines

    GENERAL GUIDE LINES Since microwave cooking to some extent is different from Covering food helps: traditional cooking, the following general guidelines should be • To reduce spattering considered whenever you use your microwave oven • To shorten cooking times • To retain food moisture If the food is undercooked All covering, which will allow microwaves to pass through are suitable-See above “Which utensils can be used in the oven?”...

  • Page 27: Keep The Oven Clean

    KEEP THE OVEN CLEAN DOOR While the oven door is still warm, any spatters or food soils should be wiped off with a damp sudsy cloth or sponge. Rinse with water and wipe dry with a cloth. If steam or condensation appears around this area, wipe with a cloth.

  • Page 28: Before Calling For Service

    BEFORE CALLING FOR SERVICE You can often correct operating problems yourself. Note: If your microwave/grill oven fails to work properly, It is quite normal for steam to be emitted around the door locate the operating problem in the chart below and during the cooking cycle.

  • Page 29: Questions And Answers

    QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven without any * Q : What does “standing time” mean? food in it. Is it damaged? A : ”Standing time” means that food should be removed A : Running the oven empty for a short time will not damage from the oven and covered for additional time to allow it the oven.

  • Page 30: Specifications

    SPECIFICATIONS Power supply 230V~, 50Hz Power consumption 1400W Microwave Output power 900W (IEC 705) Frequency 2,450MHz Grill power consumption 2300W Convection power consumption 2300W Combination heating power consumption 2500W Home fryer power consumption 2300W Outside Dimension(WXDXH) 501(19.7) X 494(19.4) X 319(12.6)mm (inch) Cavity Dimensions(WXDXH) 310(12.2) X 328(12.9) X 232(9.1)mm (inch) Net Weight...

  • Page 31: Cooking Instructions

    COOKING INSTRUCTIONS Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry. The following table lists various of utensil and indicates whether and how they should be used in a microwave oven.

  • Page 32: Service Centres

    ,I \RX KDYH IROORZHG WKH LQVWUXFWLRQV DQG VWLOO KDYH D SUREOHP FRQWDFW WKH QHDUHVW 'HI\ 6HUYLFH &HQWUH 7KH\ ZLOO EH DEOH WR DGYLVH \RX RQ DQ\ DVSHFW RI WKH SURGXFW RU VHQG D TXDOLILHG WHFKQLFLDQ WR UHSDLU LW 6RXWK $IULFDQ 6HUYLFH $JHQWV 6XE6DKDUDQ $IULFD 6HUYLFH $JHQWV %/2(0)217(,1 =$0%,$ 6287+*$7( ,19(670(176 /7'...

  • Page 33: Warranty

     )RU ZDUUDQWLHV LQ WKH 5HSXEOLF RI 6RXWK $IULFD DQG 6XE6DKDUDQ $IULFD SOHDVH FRQWDFW \RXU QHDUHVW For warranties in the Republic of South Africa and Sub-Saharan Africa, please contact your nearest Defy office. Please refer to the previous page for respective South African service agents and 'HI\ RIILFH 3OHDVH UHIHU WR SDJH...
