VF-1200 DMX
VertiFog CO2 FX
fog machine
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stairville VF-1200 DMX VertiFog CO2 FX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for thomann Stairville VF-1200 DMX VertiFog CO2 FX

Summary of Contents for thomann Stairville VF-1200 DMX VertiFog CO2 FX

  • Page 1 VF-1200 DMX VertiFog CO2 FX fog machine user manual...
  • Page 2 Musikhaus Thomann Hans-Thomann-Staße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 25.06.2015, ID: 362289...

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 7 Safety instructions..........................10 Features............................... 17 Installation..............................18 Starting up..............................19 Connections and operating elements................... 21 Operating..............................28 7.1 Operating mode ‘DMX’........................
  • Page 4 Table of contents Protecting the environment......................37 fog machine...

  • Page 5: General Information

    General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual.

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual.
  • Page 8 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 9 General information Warning signs Type of danger Warning – flammable substances. Warning – hot surface. Warning – harmful or irritating substances. Warning – danger zone. VF-1200 DMX VertiFog CO2 FX...

  • Page 10: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used to produce artificial fog by vaporising fog fluid. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 11 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged.
  • Page 12 Safety instructions WARNING! Risk of burns from flammable liquids The use of flammable liquids in this device may cause severe burns and damage to property. Always use approved fog fluids. Never fill flammable liquids into the tank of the device. WARNING! Risk of burns The generated fog at the fog nozzle is hot and can cause burns.
  • Page 13 Safety instructions WARNING! Risk of slipping caused by condensation Fog machines can produce condensation. Do not direct the fog to floors. Floors and surfaces can become slippery by condensed fog. Check at regular intervals whether it is possible to walk on the floors without a slipping hazard, and, if necessary, remove the condensation.
  • Page 14 Safety instructions CAUTION! Possible respiratory problems The device can be operated safely only with the approved fog fluid. The use of other fluids can release toxic gases. Claims for damages caused by the use of non- approved fluids shall be excluded. Do not create fog in closed or poorly ventilated areas.
  • Page 15 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker.
  • Page 16 Safety instructions NOTICE! Possible staining The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet.

  • Page 17: Features

    Features Features Professional vertical fog machine for producing spectacular fog effects in clubs, bars, discothe‐ ques and on stages. Special features of the device: Control via DMX-512 (one channel) or the multi-function control panel Adjustable fog output volume and intervals Suitable for mobile use Specially developed pump system for fog output up to five metres VF-1200 DMX VertiFog CO2 FX...

  • Page 18: Installation

    Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.

  • Page 19: Starting Up

    Starting up Starting up Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables.
  • Page 20 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.

  • Page 21: Connections And Operating Elements

    Connections and operating elements Connections and operating elements Top view VF-1200 DMX VertiFog CO2 FX...
  • Page 22 Connections and operating elements 1 Carrying handle. 2 Fog fluid container with screw-cap. 3 Fog nozzle. fog machine...
  • Page 23 Connections and operating elements Connections VF-1200 DMX VertiFog CO2 FX...
  • Page 24 Connections and operating elements 4 [ON | OFF] Main switch to turn the device on and off. 5 [POWER | FUSE] IEC chassis plug with fuse holder for the power supply. 6 DIP switch for setting the DMX address. 7 [Remote Control] Five-pin connector for the multi-function control panel.
  • Page 25 Connections and operating elements Multi-function control panel VF-1200 DMX VertiFog CO2 FX...
  • Page 26 Connections and operating elements 10 [INTERVAL] With this control you can set the output duration per fog blast in a range between 5 and 150 seconds. 11 [VOLUME] With this control you can adjust the amount of fog to be produced by the device with each blast (between 0 % and 100 %).
  • Page 27 Connections and operating elements 16 The yellow LED indicates that the Timer function is turned on. 17 [TIMER] Press this pushbutton to let the device eject the fog volume set with the [VOLUME] control for the time set with the [INTERVAL] control.

  • Page 28: Operating

    Possible damages caused by unsuitable fog fluid Fog liquids not approved by the manufacturer may permanently damage the unit. Only use the fog fluids listed on www.thomann.de and follow their instructions for use. First, make sure the unit is switched off.
  • Page 29 Operating Turning the unit on NOTICE! Fire hazard Do not operate the machine unattended. Connect the device to the power grid and turn it on with the main switch. As soon as the required operating temperature is reached, the green LED on the control panel When operating, always ensure that there is sufficient fog fluid in the liquid container to avoid no-load running.

  • Page 30: Operating Mode 'Dmx

    Operating 7.1 Operating mode ‘DMX’ Setting the DMX address Use the DIP switches of the device to set the desired DMX address between 1 and 512 (see the following figure). fog machine...
  • Page 31 Operating DMX channel assignment Channe Value Function 0 … 255 No fog output to maximum fog output VF-1200 DMX VertiFog CO2 FX...

  • Page 32: Technical Specifications

    Technical specifications Technical specifications Heater power 1,200 W Power consumption max. 1,250 W Fog output approx. 150 m /min Blast distance 4 … 5 m Fluid consumption approx. 80 ml / min Fluid container capacity 2.5 l Warm-up time approx. 5 min Operating supply voltage AC 230 V , 50 Hz...

  • Page 33: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Symptom Remedy The unit does not work Check the mains connection and the main fuse. No response to the DMX controller 1.
  • Page 34 Troubleshooting If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. fog machine...

  • Page 35: Cleaning

    Possible damages caused by unsuitable cleaning agents Cleaners not approved by the manufacturer may permanently damage the unit. Only use the fog machine cleaners listed on www.thomann.de and follow their instructions for use. Clean the appliance after every 30 operating hours, or if it was not in use for a longer period of time.
  • Page 36 Cleaning Switch the unit to continuous operation and release fog for about 20 seconds. Put the suction hose back into the fluid container of the fog machine and release fog for another 20 seconds. This rinses the pipes. ð The cleaning is completed. fog machine...

  • Page 37: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 38 Notes fog machine...
  • Page 40 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
