Owner's Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17
Installation Manual
Installation and Appliance Setup
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hearth & Home LCOR-DV36IN
Summary of Contents for Hearth & Home LCOR-DV36IN
- Page 1 See Table of Contents for location of additional Commonwealth gases, unless a certified kit is used. of Massachusetts requirements. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 2: Table Of Contents
C. Non-Combustible Material Installation ....35 = Contains updated information. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 3: Installation Standard Work Checklist
_____________________________________________________________________________________ _________________________________________________________________________________________________ _________________________________________________________________________________________________ Comments Communicated to party responsible ____________________ by ______________________on ___________ (Builder / Gen. Contractor/) (Installer) (Date) = Contains updated information. 2486-982 2/17 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 4: Product Specific And Important Safety Information
Please contact your dealer or distributor to order. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 5: Requirements For The Commonwealth Of Massachusetts
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 6: Getting Started
1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300 ºF minimum continuous exposure rating) One 1/4 in. female connection (for optional fan). Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 7: Inspect Appliance And Components
Call a qualified service technician to inspect the appliance and to replace any part of the control system and/or gas control which has been under water. Figure 2.3 Do Not Remove Standoff Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 8: Framing And Clearances
Location Inches Millimeters 40-1/2 1029 24-1/2 33-1/2 9-1/2 24-1/2 2-1/8 4-1/8 34-5/8 4-1/4 1-1/2 38-1/8 Figure 3.1 Appliance Dimensions - LCOR-DV36IN / RCOR-DV36IN (RCOR-DV36IN Shown) Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 9 DECORATIVE FRONT - COREP-36BK (Model: LCOR-DV36IN/RCOR-DV36IN) COREP-36BK Location Inches Millimeters 20-1/8 22-1/16 25-5/16 1-3/8 6-7/8 32-1/16 33-7/16 Figure 3.2 Decorative Front Dimensions - COR-36BK and COREP-36BK Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 10: Clearances To Combustibles
36 in. LCOR 914 mm 36 in. 914 mm 36 in. 914 mm RCOR 36 in. 914 mm Figure 3.3 Appliance Locations Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 11 (Width) (Width) (Depth) Inches 38-1/8 34-1/8 Millimeters 1016 Adjust framing dimensions for interior sheathing (such as sheetrock) Figure 3.4 Clearances to Combustibles - LCOR-DV36IN, RCOR-DV36IN Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 12: Constructing The Appliance Chase
• The chase must be properly blocked to prevent blown insulation or other combustibles from entering and making contact with fireplace or chimney. • Failure to maintain airspace may cause overheating and a fire. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 13: Termination Location And Vent Information
Over 20/12 to 21/12 ..........8.0 * H minimum may vary depending on regional snowfall. Refer to local codes. Figure 4.1 Minimum Height From Roof to Lowest Discharge Opening Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 14: Chimney Diagram
2 sides beneath the floor. venting system does not meet these requirements. • Vinyl protection kits are suggested for use with vinyl siding. Figure 4.3 Minimum Clearances for Termination Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 15: Approved Pipe
WARNING! Risk of Fire or Asphyxiation. This appli- ance requires a separate vent. DO NOT vent to a pipe serving a separate solid fuel burning appliance. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 16: Use Of Elbows
DVP24 DVP36 25-1/2 DVP48 1219 DVP6A 3 to 6 76 to 152 2-1/8-4-1/4 54-108 DVP12A 3 to 12 76 to 305 2-1/8-8-1/2 54-216 Figure 4.4 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 17: Measuring Standards
Note: Reference Figure 4.21 for special instructions for use of 45º elbow on rear vent appliances. Figure 4.7. Measure to Top of Last Section of Pipe Figure 4.8 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 18 60 ft (18.3 m) max. 2 ft. SLP (305 mm) 4 ft. SLP DVP-SLP24 Adapter DVP-2SL Figure 4.9 Adapt DVP Pipe to SLP Using DVP-SLP24 & DVP-2SL Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 19 4.6 m 6 ft. 1.8 m 18 ft. 5.5 m = 50 ft. (15.2 m) Maximum = 18 ft. (5.5 m) Maximum INSTALLED HORIZONTALLY Figure 4.11 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 20 3 ft. 914 mm 12 ft.* 3.7 m 6 ft 1.8 m = 18 ft. (5.5 m) Maximum = 50 ft. (15.2 m) Maximum Figure 4.12 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 21 6 ft. 1.8 m 6 ft. 1.8 m = 50 ft. (15.2 m) Maximum = 18 ft. (5.5 m) Maximum Installed Vertically Installed Horizontally Figure 4.13 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 22 10-60 feet, an exhaust restrictor may restrictor installation. be needed. The exhaust restrictor can be located in the appliance manual bag. Figure 4.15 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 23 MUST subtract one number from the table above. Example: Top vent 60 ft vertical with DVP pipe = 3-3 Top vent 60 ft vertical with SLP pipe = 2-2 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 24 18 ft. 5.5 m = 50 ft (15.2 m) Maximum *No specific restrictions on this value EXCEPT cannot exceed 50 ft (15.2 m) Figure 4.18 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 25 5.5 m = 18 ft (5.5 m) Maximum *No specific restrictions on this value EXCEPT cannot exceed 50 ft (15.2 m) INSTALLED HORIZONTALLY Figure 4.19 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 26 = 16 in. (406 mm) Maximum No Elbow Figure 4.20 One 45º Elbow DO NOT use a 45º elbow in corner installations. Use two 90º elbow instead. Figure 4.21 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 27 1.2 m 8 ft. 2.4 m = 40 ft (12.2 m) Maximum = 3 ft (94 mm) Maximum = 12 ft (3.7 m) Maximum Figure 4.23 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 28 10 ft. 6 ft. 1.8 m 12 ft. 3.7 m = 50 ft (15.2 m) Maximum = 16 ft (4.9 m) Maximum INSTALLED HORIZONTALLY Figure 4.25 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 29 1.8 m *No specific restrictions on this value EXCEPT cannot exceed 50 ft. (15.2 m) Maximum = 6 ft. (1.8 m) Maximum INSTALLED HORIZONTALLY Figure 4.27 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 30: Vent Clearances And Framing
* Shows center of vent framing hole for top or rear venting. The center of the hole is one (1) inch (25.4 mm) above the center of the horizontal vent pipe. Figure 5.2 Wall Penetration Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 31: Ceiling Firestop/Floor Penetration Framing
INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 5.4 Installing the Attic Shield Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 32: Appliance Preparation
Figure 6.1 Cut the metal retaining band and fold the sides out. Figure 6.2 Fold the center parts of the retaining band up and use to remove the vent cap. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 33 Secure the vent gasket to the appliance with two self-tapping screws found in the manual bag. Note: The vent gasket can found in the manual bag. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 34: Securing And Leveling The Appliance
Note: Diagonal dimensions (A) and (B) must be within 1/4 inch of each other. 90º Figure 6.10 Positioning the Appliance Squarely Figure 6.8 Proper Positioning and Leveling of an Appliance Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 35: Non-Combustible Material Installation
This board must be used. See Figure 6.12. WARNING! Risk of Fire! DO NOT remove factory- installed non-combustible material. NON-COMBUSTIBLE BOARD Figure 6.12 Non-combustible Board Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 36: Venting And Chimneys
If predrilling holes, DO NOT penetrate inner pipe. Figure 7.4 Seams INCORRECT For 90º and 45º elbows that are changing the vent direction Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 37: Assemble Vent Sections
• Only outer pipes need to be sealed. All unit collar, pipe, slip section, elbow and cap outer flues shall be sealed in this manner, unless otherwise stated. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 38: Assemble Slip Sections (Slp & Dvp)
• Only outer pipes are sealed, sealing the inner flue is not required. • All unit collar, pipe, slip section, elbow and cap outer flues shall be sealed. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 39: Disassemble Vent Sections
Figure 7.11. • Pull carefully to separate the pieces of pipe. Figure 7.10 Rotate Seams for Disassembly Figure 7.11 Align and Disassemble Vent Sections Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 40: Vertical Termination Requirements
• Caulk the perimeter of the flashing where it contacts the roof surface. See Figure 7.13. • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 41: Horizontal Termination Requirements
• Rest the small leg on the extended heat shield on top of the pipe section to properly space it from the pipe section. Figure 7.15 Important Notice: Heat shields may not be fi eld constructed. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 42 DVP-TRAP1 can adjust 1-1/2 in. (3-1/8 to 4-5/8 in.) DVP-TRAP2 can adjust 4 in. (5-3/8 to 9-3/8) DVP-HPC1 can adjust 2-1/8 in. (4-1/4 to 6-3/8) DVP-HPC2 can adjust 4-1/8 in. (6-3/8 to 10-1/2) Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 43: Electrical Information
ROMEX CONNECTORS NOTICE: DO NOT wire 110-120 VAC to wall switch. Figure 8.1 Junction Box Detail Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 44: Intellifire™ Touch Ignition System Wiring
Do not store batteries in the battery pack when the appliance is powered by the 6 volt transformer connected to permanent electrical service. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 45 RF MODULE ORANGE 2326-120 GROUND TO FIREPLACE CHASSIS GREEN IFT-RC150 WIRELESS WALL SWITCH WHITE WIRE ASSEMBLY 2118-170 Figure 8.2 IntelliFire Touch Wiring With Wall Switch Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 46 PVI-WH20 PVI-WH40 PVI-WH60 ORANGE PVI-WH80 PVI-WH100 GROUND TO FIREPLACE CHASSIS PVI-SLP-B OR PVLP-SLP GREEN PVLP-SLP PVI-SLP-B Figure 8.3 IntelliFire Touch Wiring With Optional Power Vent Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 47 THREADED STUD USED TO INSTALL TEMPERATURE SENSOR JUNCTION RHEOSTAT SWITCH LOCATION TEMPERATURE SENSOR RHEOSTAT ATTACHMENT TAB BASE PAN Figure 8.4 Fan Location, Fan and Rheostat Wiring Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 48: Gas Information
4500 feet (1370 m). • If substituting for these components, please consult local codes for compliance. Check with your local gas utility to determine proper orifice size. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 49: Air Shutter Setting
Note: All vent runs may need to be evaluated for ideal shutter settings. Shutter distances may vary due to vent run, fuel quality, and elevation. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 50: Finishing
0 in. 0 in. High Temperature Sealant (300° F/149° C min.) Top and Side Seal Joint = Factory-Installed Non-Combustible Board Figure 10.1 Non-combustible Facing Diagram Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 51: Mantel And Wall Projections
MEASUREMENT FROM FIREPLACE OPENING TO BOTTOM OF APPLIANCE= 33-1/2 IN. Figure 10.3 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 52: Appliance Setup
Step 2. Crease flap on top side of splatter guard using GLASS ASSEMBLY the scored line as the guide. See Figure 11.3. Figure 11.1 Fixed Glass Assembly Figure 11.3 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 53 See Figure 11.10. Figure 11.5 Installation of Splatter Guard TOP SLOT Figure 11.6 Top slot Figure 11.9 Opening Lower Access Panel Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 54: Clean The Appliance
Carefully grab splatter guard on or near the vertical cen- ter on the left and right sides. Pull outward gently, but firmly, taking care not to tear or remove the inserted tabs. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 55: Glowing Ember Placement
The embers provided should be enough for 3 to 5 applications. DO NOT PLACE EMBERS IN THE CIRCLED AREAS PILOT LOCATED HERE Figure 11.13 Placement of Embers Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 56: Install The Log Assembly
Log A highlighted in Figure 3. The Y-shaped end of Log #1 will rest on the smooth area of Log B as shown in Figure 4. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 57 Log A highlighted in Figure 9. The Y-shaped end of Log #1 will rest on the smooth area of Log B as shown in Figure 10. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 58: Install Fixed Glass Assembly
• Pull out the four glass latches and place in the grooves on the glass frame top and bottom. • Make sure all sides are replaced properly. Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... -
Page 59: Reference Materials
6 in. (152 mm) 14 IN. (356 MM) 12 IN. (305 MM) DVP-WS (Wall Shield Firestop) DVP-RDS ROOF DECK INSULATION SHIELD Figure 12.1 DVP Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17... - Page 60 Length DVP-TRAP 5-3/8 in. 9-3/8 in. Trap2 Horizontal Termination Cap 137 mm 238 mm DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 DVP-HPC1 DVP-HPC2 Figure 12.2 DVP Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 61 9-1/2 in. (352 mm) (241 mm) 26 in. 660 mm 14 in. (356 mm) DVP-HSM-B DRC-RADIUS Extended Heat Shield Cap Shield Figure 12.3 DVP Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 62 1 in. (25 mm) 7-3/4 to 10-3/8 in. 1-5/8 in. (197 to 264 mm) (41 mm) DVP-FBHT DVP-HPC FireBrickTermination Cap High Performance Cap Figure 12.4 DVP Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 63 213 mm 146 to 213 mm 3° 87° 15 in. (381 mm) 10-1/2 in. 267 mm 10-7/8 in. 276 mm DVP-HRC-SS DVP-HRC-ZC-SS Figure 12.5 Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 64 13-5/8 IN. 16-11/16 IN. 16-11/16 IN. (346 mm) 424 mm (424 mm) 12-1/2 IN. (318 mm) SLP-LPC SLP Low Profile Cap Figure 12.6 PVI-SLP-B Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 65 60 FT PV Wire Harness PVI-WH60 80 FT PV Wire Harness PVI-WH80 100 FT PV Wire Harness PVI-WH100 PVLP-BEK PVLP-HS Brick Kit Heat Shield Figure 12.7 PVLP-SLP Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 66 12 in. 5-1/2 in. 220 mm 38 mm 305 mm 146 mm SLP-WS SLP-FS Wall Shield Firestop Ceiling Firestop Figure 12.8 SLP Series Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 67 12-5/8 IN. 10-5/8 IN. 59 mm 367 mm (321 mm) (270 mm) SLP-RDS SLP-WT-BK ROOF DECK INSULATION SHIELD Wall Thimble-Black Figure 12.9 SLP Series Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 68 343 mm 121 mm 7-3/4 to 10-3/8 in. (197 to 264 mm) DVP-FBHT SLK-SNKD Horizontal Snorkel Termination Cap Termination Cap Figure 12.10 SLP Series Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
- Page 69 8 IN. (203 mm) 15 IN. (381 mm) 12 IN. (305 mm) SLP-HHW2 Horizontal High Wind Termination Cap Figure 12.11 SLP Series Vent Components Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
-
Page 70: Accessories
Please contact your Hearth & Home Technologies dealer with any questions or concerns. For the location of your nearest Hearth & Home Technologies dealer, please visit www.hearthnhome.com. Printed in U.S.A. - Copyright 2017 Hearth & Home Technologies • LCOR-DV36IN, RCOR-DV36IN Installation Manual • 2486-980 Rev. D • 7/17...
