- Page 1 QL10 - TL10 QL15 - TL15 I N S T A L L A T I O N , U S E A N D MAINTENANCE MANUAL To be kept by the purchaser TL10 TL15 QL10 QL15 Wood operated air system stove...
- Page 2 Dear Customer, thank you for having chosen to heat and save with a Jolly Mec product. Please carefully read and keep this sheet before using the equipment. This sheet provides necessary information and suggestions on how to correctly install, use, clean and maintain the product.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAP.01 PREMISES........................... 4 01.1 WARNINGS ..............................4 01.2 SYMBOLOGY ............................... 5 01.3 APPLIED STANDARDS ..........................5 01.4 USE AND STORING OF THE INSTALLATION AND MAINTENANCE MANUAL ......... 6 01.5 MANUFACTURER’S LIABILITY AND WARRANTY CONDITIONS .............. 6 CHAP.02 ACCIDENT PREVENTION / SAFETY REGULATIONS .............. 7 02.1 GENERAL CONSIDERATIONS ........................ -
Page 4: Chap.01 Premises
CHAP.01 PREMISES 01.1 WARNINGS • Familiarity and compliance with the instructions given in this manual will ensure quick installation and correct use of the appliance. • Read the manual attentively before commencing installation, and be certain to follow the directions it contains, otherwise the war- ranty could be invalidated and the performance and safety of the appliance jeopardized. • The installation manual is an integral part of the product and must be given to the user. • It must be kept in a safe place and consulted carefully, as all of the warnings provide important information on safety during instal- lation, use and maintenance. • Incorrect installation of the appliance could cause damage and injury to people or animals, for which the manufacture cannot not be held liable. • Installation shall be performed by qualified operators in accordance with the regulations in force in the Country of installation. • The manufacturer declines any contractual or non-contractual liability for damages caused by errors in installation or use of the appliance or failure to follow the instructions contained in this manual. • All rights on the reproduction of this technical manual are owned by Jolly Mec Caminetti S.p.A. The descriptions and illustrations provided in the following publication are not binding. • reserves the right to make any modifications that may be deemed appropriate. • Jolly Mec Caminetti S.p.A This manual cannot be given to third parties for perusal without the written permission of • Jolly Mec Caminetti S.p.A • The technical directions for installation contained in this manual should be considered as basic requirements. Regulations in some countries may be more restrictive; in this instance, comply fully with the regulations prevailing in the country of installation (all laws and local bylaws must be observed when installing and using the appliance, including those referring to national and European standards). -
Page 5: Symbology
This point is particularly important. An important point regarding behaviour for preventing injury and damage to DANGER: materials is expressed. 01.3 APPLIED STANDARDS All JOLLY MEC products are constructed according to the following directives: • EU 305/2011 European construction products regulation. Machines. •... -
Page 6: Use And Storing Of The Installation And Maintenance Manual
01.5 MANUFACTURER’S LIABILITY AND WARRANTY CONDITIONS Upon the delivery of this manual, Jolly Mec S.p.A. cannot be held liable, whether civil or criminal, for accidents due to partial or total non-compliance with the specifications herein contained. The manufacturer is especially held harmless from any liability in the following cases: •... -
Page 7: Chap.02 Accident Prevention / Safety Regulations
CHAP.02 ACCIDENT PREVENTION / SAFETY REGULATIONS 02.1 GENERAL CONSIDERATIONS • The manual refers to essential aspects of the directives, regulations and dispositions on using the machine, summarising its most significant points. • General legal regulations and mandatory rules regarding injury prevention and environmental protection must be observed. -
Page 8: Safety Regulations For Extraordinary Maintenance And Installation
• Keep the ventilation grids in the area the appliance is installed in clean conditions. • Do not burn any fuel except wood. • Check and periodically clean the fume exhaust pipe, from the appliance to the flue (Union). • It is strictly prohibited to start up the product with the combustion chamber door open or allow it to run with the glass broken. -
Page 9: Equipment For Operators And Maintenance Personnel
RESIDUAL RISKS Though JOLLY MEC CAMINETTI S.p.A. does everything within its power to produce its systems with the greatest competence regarding safety and consulting all the directives, laws, and regulations available, there are still, if minor, some residual risks during the phases of: •... -
Page 10: Chap.03 Handling And Transport
CHAP.03 HANDLING AND TRANSPORT 03.1 RECEIVING GOODS The device is delivered on a pallet in a cardboard box and protected with shrink wrap cover sheet when receiving merchandise, check that: • all packaging is intact • all of the merchandise indicated on the delivery bill has actually been delivered •... -
Page 11: Chap.04 Ecological Regulations
CHAP.04 ECOLOGICAL REGULATIONS 04.1 WASTE MATERIALS AND THEIR DISPOSAL Spare parts replaced during the machine’s product life are to be considered waste and must be taken to special collection centres or entrusted to authorised disposal centres. Ashes must be placed in a metal container with a sealed lid. The closed container must be placed on a non-combustible base and kept away from combustible materials until all the embers have been extinguished. -
Page 12: Chap.05 Description
Combustion has been optimised to guarantee consistent reloading (about 45 min). The QL10, TL10, QL15 and TL15 stoves are equipped with a door to avoid combustion product from exiting, with self-cleaning glass. -
Page 13: Product Identification
05.2 PRODUCT IDENTIFICATION It is COMPULSORY to indicate the product MODEL, the LOT number and SERIAL NUMBER in all communications with the Manufacturer. Identification numbers are printed on the adhesive plate located on the back of the appliance as illustrated. Appliance performance values measured during inspection tests according to the indicated reference and EC markings are also included on the plate. -
Page 14: Chap.06 Technical Data
All appliance tests, final inspection and fine-tuning was performed using the recommended fuels. Jolly Mec Caminetti S.p.A. is not responsible for malfunctions, breakdowns or problems due to the use of wood logs that are not recommended, as combustion parameters vary according to the quality of the fuel. -
Page 15: Recommended Fuels
06.2 RECOMMENDED FUELS WARNING WOOD QUALITY IS VERY IMPORTANT; PLEASE READ THIS SECTION CAREFULLY. The characteristics of fuel wood for stoves and fireplaces are defined by quality classes A1 and A2 set forth by UNI EN ISO 17225-5 standard. WOOD COMBUSTION Wood clean burning is a process that reflects the natural decomposition itself;... -
Page 16: Components
06.3 COMPONENTS The appliance comes on a pallet covered by a cardboard box and with the following additional components: • Installation, use and maintenance manual • Use and maintenance accessories • Joint to pick external comburent air (9). • Heat proof glove •... -
Page 17: Dimensions
06.4 DIMENSIONS All measurements are in mm. Model QL10 1100 TL10 1100 QL15 1380 TL15 1380 TL10 QL10 QL15 TL15... -
Page 18: Chap.07 Positioning And Connections For The Installer
CHAP.07 POSITIONING AND CONNECTIONS FOR THE INSTALLER 07.1 FLUE OR FUME EXHAUST SYSTEM The flue or fume exhaust system is a fundamental element for the proper functioning of the stove and must comply with the following general standards: EN1856-1 Chimneys. Requirements for metal chimneys - Part 1: System chimney products EN1856-2 Chimneys. -
Page 19: Installation Room Ventilation
The use of counter slope elements is forbidden.The flue union must have a constant section and allow soot to be collected and swept away. Changes in cross-section are only allowed at the outlet of the heat generator: the use of adaptors on the coupling with the chimney flue is prohibited. -
Page 20: Assembly Sequence
07.3 ASSEMBLY SEQUENCE Install the fireplace as follows: Unpack the stove by removing the cardboard. Remove the mounting brackets and gently move the stove until you put it on the floor. Place the stove in the location where you want to install it. - Page 21 . 5). b) Top fume exhaust outlet for QL15 and TL15 • Loosen the two front screws (right (A) and left (B)) to remove the top, using a small cross-head screwdriver in between the front slots .
- Page 22 . 10 . 11 c) Rear fume exhaust outlet for QL15 and TL15 . 12 • Loosen the two front screws (right (A) and left (B)) to remove the top, using a small cross-head screwdriver in between the front slots . 6 - 6a). • Unscrew the two rear screws C and D •...
- Page 23 • Position the elbow section supplied (CURVA/TLQL) on the stove . 13 fume exhaust outlet collar, paying attention to the previously fitted sealing cord. Turn the elbow section by 90 degrees to insert part A inside hole B on the rear plate .
- Page 24 . 19 d) Top fume exhaust outlet with refractory materials for QL15 and TL15 See manuals AD108 and AD107 respectively. e) Rear fume exhaust outlet with refractory materials for QL15 and TL15 See manuals AD108 and AD107 respectively.
-
Page 25: Safety Distances From Surrounding Flammable Materials
. 4 are shown the safety distances from surrounding flammable materials applicable to all installation types available: Flammable Wall TL10 QL10 TL15 QL15 A Straight Distance from flammable side 500 mm walls (both sides) B Straight Distance from flammable rear 200 mm walls R Min. -
Page 26: Chap.08 Use And Maintenance For The User
. 2) (Max length 25 cm and width approx. 8-10 cm per side. Use of pieces of chopped wood is recommended) - QL15 model: charge 2 blocks of approx. 0,8 kg each with the primary air closed (F . 2) (Max length 30 cm and width approx. -
Page 27: Tips For The User
08.2 TIPS FOR THE USER • The glass door must remain closed during wood combustion; it can only be opened to add more wood. • When purchasing firewood, it is advisable to vary the sizes, but with a length as to be able to light quickly, but also long charges and, if the quality of the wood is good, efficiency and functionality will also be excellent. -
Page 28: Routine Maintenance
Time between one cleaning and the next is strictly tied to fuel quality. The most suitable cleaning frequency can only be established a few days after use according to the actual amount of deposited residue and may vary from recommended Jolly Mec intervals. -
Page 29: Extraordinary Maintenance
08.4 EXTRAORDINARY MAINTENANCE We wish to remind you that the Extraordinary Maintenance to be carried out on this type of product must be done obligatorily every year by qualified maintenance personnel, in order to maintain its functionality, efficiency and comfort. For any further queries you may have, we invite you to contact the specialised Technical Service Center through your retailer. -
Page 30: Chap.09 Fault Diagnosis And Troubleshooting
CHAP.09 FAULT DIAGNOSIS AND TROUBLESHOOTING 09.1 PROBLEMS WARNING In accordance with the laws in force on safety for electrical appliances, a specialised Technical Service Center or qualified personnel must obligatorily be contacted for all installation, maintenance or interventions that require access to electrical parts. - Page 31 NOTES...
