- Page 1 AMBRIA and RIVA INSTALLATION, USE AND MAINTENANCE MANUAL To be kept by the purchaser Ambria Riva Pellet operated air heating stove...
- Page 2 Dear Customer, thank you for having chosen to heat and save with a Jolly Mec product. Please carefully read and keep this sheet before using the equipment. This sheet provides necessary information and suggestions on how to correctly install, use, clean and maintain the product.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAP.01 PREMISES........................... 4 01.1 WARNINGS ..............................4 01.2 SYMBOLOGY ............................... 5 01.3 APPLIED STANDARDS ..........................5 01.4 USE AND STORING OF THE INSTALLATION AND MAINTENANCE MANUAL ........6 01.5 MANUFACTURER LIABILITY AND WARRANTY CONDITIONS ..............6 CHAP.02 ACCIDENT PREVENTION / SAFETY REGULATIONS .............. 7 02.1 GENERAL CONSIDERATIONS ........................ -
Page 4: Chap.01 Premises
CHAP.01 PREMISES 01.1 WARNINGS • Familiarity and compliance with the instructions given in this manual will ensure quick installation and correct use of the appliance. • Read the manual attentively before commencing installation, and be certain to follow the directions it contains, otherwise the war- ranty could be invalidated and the performance and safety of the appliance jeopardized. • The installation manual is an integral part of the product and must be given to the user. • It must be kept in a safe place and consulted carefully, as all of the warnings provide important information on safety during instal- lation, use and maintenance. • Incorrect installation of the appliance could cause damage and injury to people or animals, for which the manufacture cannot not be held liable. • Installation shall be performed by qualified operators in accordance with the regulations in force in the Country of installation. • The manufacturer declines any contractual or non-contractual liability for damages caused by errors in installation or use of the appliance or failure to follow the instructions contained in this manual. • All rights on the reproduction of this technical manual are owned by Jolly Mec Caminetti S.p.A. The descriptions and illustrations provided in the following publication are not binding. • reserves the right to make any modifications that may be deemed appropriate. • Jolly Mec Caminetti S.p.A This manual cannot be given to third parties for perusal without the written permission of • Jolly Mec Caminetti S.p.A • The technical directions for installation contained in this manual should be considered as basic requirements. Regulations in some countries may be more restrictive; in this instance, comply fully with the regulations prevailing in the country of installation (all laws and local bylaws must be observed when installing and using the appliance, including those referring to national and European standards). -
Page 5: Symbology
This point is particularly important. An important point regarding behaviour for preventing injury and damage to DANGER: materials is expressed. 01.3 APPLIED STANDARDS All JOLLY MEC products are constructed according to the following directives: • EU 305/2011 European construction products regulation. Machines. •... -
Page 6: Use And Storing Of The Installation And Maintenance Manual
01.5 MANUFACTURER LIABILITY AND WARRANTY CONDITIONS Upon the delivery of this manual, Jolly Mec S.p.A. cannot be held liable, whether civil or criminal, for accidents due to partial or total non-compliance with the specifications herein contained. The manufacturer is especially held harmless from any liability in the following cases: •... -
Page 7: Chap.02 Accident Prevention / Safety Regulations
CHAP.02 ACCIDENT PREVENTION / SAFETY REGULATIONS 02.1 GENERAL CONSIDERATIONS • The manual refers to essential aspects of the directives, regulations and dispositions on using the machine, summarising its most significant points. • General legal regulations and mandatory rules regarding injury prevention and environmental protection must be observed. -
Page 8: Safety Regulations For Extraordinary Maintenance And Installation
• The appliance must always be started up with the firebox empty, without pellets and without unburned fuel from previous use. • Do not attempt to ignite the fuel with inflammable liquids or solids; the stove must ignite automatically via the electrical components installed onboard. -
Page 9: Equipment For Operators And Maintenance Personnel
RESIDUAL RISKS Though JOLLY MEC CAMINETTI S.p.A. does everything within its power to produce its systems with the greatest competence regarding safety and consulting all the directives, laws, and regulations available, there are still, if minor, some residual risks during the phases of: •... -
Page 10: Chap.03 Handling And Transport
CHAP.03 HANDLING AND TRANSPORT 03.1 RECEIVING GOODS The product is delivered on pallets, packaged in a cardboard box with a cellophane wrapping. when receiving merchandise, check that: • all packaging is intact • all of the merchandise indicated on the delivery bill has actually been delivered •... -
Page 11: Chap.04 Ecological Regulations
CHAP.04 ECOLOGICAL REGULATIONS 04.1 WASTE MATERIALS AND THEIR DISPOSAL Spare parts replaced during the machine’s product life are to be considered waste and must be taken to special collection centres or entrusted to authorised disposal centres. Ashes must be placed in a metal container with a sealed lid. The closed container must be placed on a non-combustible base and kept away from combustible materials until all the embers have been extinguished. -
Page 12: Chap.05 Description
CHAP.05 DESCRIPTION 05.1 PRODUCT PRESENTATION The AMBRIA and RIVA stoves for air and pellets are heating systems approved to EN 14785:2006 European Standard requirements issued by an independent body accredited by the European Commission for machine commissioning and certification. Jolly-Mec products are the result of over forty years experience in the wooden biomass combustion sector;... -
Page 13: Product Identification
05.2 PRODUCT IDENTIFICATION It is COMPULSORY to indicate the product MODEL, the LOT number and SERIAL NUMBER in all communications with the Manufacturer. Identification numbers are printed on the adhesive plate located on the pellet container as illustrated. Stove performance values measured during inspection tests according to the indicated reference and EC markings are also included on the plate Product model... -
Page 14: Chap.06 Technical Data
CHAP.06 TECHNICAL DATA 06.1 HOMOLOGATION Technical specifications resulting from laboratory tests conducted according to EN 14785:2006 test methods at the CERTIFICATION institute. Description Ambria 6 kW Ambria 9 kW Riva 6 kW Riva 9 kW Thermal power introduced (at rated power) 6,82... -
Page 15: Recommended Fuels
Jolly Mec Caminetti S.p.A strongly recommends the use of the same type of pellets used during first start-up, i.e. when the settings and calibrations were made to suit the loaded combustible materials. Continuous switching of types and qualities of combustible materials will require continuous adjustments to settings by the Technical Assistance Centre, which can not be endorsed by the Manufacturer. -
Page 16: Components
06.3 COMPONENTS The device is supplied with the following components: • Installation, use and maintenance manual. • Power cord to connect the stove to the mains. • Cladding. • Door opening key Part List: Air diffusion grid Handle for opening the door Lid for loading pellets Pellet hopper Ash drawer... -
Page 17: Dimensions
06.4 DIMENSIONS All measurements are in mm. Ambria Riva Ø 505 1020 Ambria Riva... -
Page 18: Chap.07 Positioning And Connections For The Installer
CHAP.07 POSITIONING AND CONNECTIONS FOR THE INSTALLER 07.1 SETTING UP OF EXTERNAL AIR INTAKES AND ELECTRIC CURRENT The device must only be installed indoors and on surfaces that can support the load. If the existing construction does not meet this requirement, it will be necessary to take appropriate measures (e.g. -
Page 19: Flue Or Fume Exhaust System
07.2 FLUE OR FUME EXHAUST SYSTEM The flue or fume exhaust system is a fundamental element for the proper functioning of the stove and must comply with the following general standards: EN1856-1 Chimneys. Requirements for metal chimneys - Part 1: System chimney products EN1856-2 Chimneys. -
Page 20: Installation Room Ventilation
Jolly Mec allows the ducting system at the input of the combustion air within and not over the following limits: the length can’t be longer that 1000 mm, the diameter has to have at least the same section of the stove/boiler connection, it is possible only one 90°... -
Page 21: Electrical Connections
07.4 ELECTRICAL CONNECTIONS Connect the 230Vac 50Hz line with the proper cable with plug, supplied with the stove, which powers up the control unit and all the appliance’s electrical components The device is equipped with a power socket and fuse and a uniipolar switch. In the event that the control unit does not switch on, even after turning the switch to I “ONE”, check that the fuse has not blown. -
Page 22: Control Unit Electrical Wiring Diagram
07.5 CONTROL UNIT ELECTRICAL WIRING DIAGRAM WARNING Electrical connections must be carried out by skilled personnel according to the regulations in force (2014/30/UE and 2014/35/UE). • AMBRIA and RIVA 6 KW TABLE OF COMPONENTS POSITION CODE CODE DESCRIPTION DISPLAY/11 Display... - Page 23 • AMBRIA and RIVA 9 KW TABLE OF COMPONENTS POSITION CODE CODE DESCRIPTION DISPLAY/11 Display QUA/PELLET/1 Electronic card PRESA/2 Electrical socket with uniipolar switch and fuse-holder CAVO/36 Electric power cord with schuko socket VENT/13 Smoke fan RESISTENZA/7 electrical heating element for lighting...
-
Page 24: Chap.08 Use And Maintenance For The User
CHAP.08 USE AND MAINTENANCE FOR THE USER 08.1 APPLIANCE OPERATIONS The STOVE uses pellets as fuel, whose combustion is electronically controlled. Pellets are taken from the storage hopper by the auger controlled by the gear motor and conveyed directly to the burn pot. They are ignited by the hot air produced by the electric heating element (E) and aspirated into the burn pot by the centrifugal fan which is the same that sucks up the fumes produced by combustion, expelling them to the rear part of the stove. -
Page 25: User Lcd Display
08.3 USER LCD DISPLAY • User Display Function Buttons Key Button 1: Rapid access to adjust/increase ambient temp. Increases the value of the displayed settings Pressed together with button 2 activates the Timer function Button 2: Rapid access to adjust/decrease ambient temp. Decreases the value of the displayed settings Pressed together with button 1 activates the Timer function Button 3:... - Page 26 PELLET loading auger gear motor, the icon is signalled by the DGT when the component is running. Fume Extractor Fan, the icon is signalled by the DGT when the component is running. V1 main air exchanger fan, the icon is signalled by the DGT when the component is running. Alarm, the icon is signalled by the DGT when an alarm is triggered.
- Page 27 • Display settings The LCD Display is divided into 4 rows. The first from the top, is the space designated to displaying the settings, time, temperature, output and operating parameters. The second row indicates the ambient temperature with the set output level next to it. The third and fourth row display stove operating messages, occupying both rows or just the fourth one, according to the length of the message.
- Page 28 • Menu page architecture and explanation key User Menu 01 XXX = SET Menu 01 YYY = CLOCK Setting the control unit clock and calendar, essential setting to ensure the Timer works properly. The CLOCK Menu is the first page displayed on pressing button 4. Press button 4 again to change the date settings. CLOCK SETTINGS: button 4 confirm button 4 press button 1 or 2 to change the day, press button 4 to confirm press button 1 or 2 to change the hour, press button 4 to confirm press button 1 or 2 to change the minutes, press button 4 to confirm press button 1 or 2 to change the day number, press button 4 to confirm...
- Page 29 Menu M2-1-001 XXX = DELAY YYY = TURN ON M2-1-001 The DELAY Function settable from MENU 02 – SET CHRONO) consents to set the offset time before switching-on and after scheduled shutdown on the appliance. When the appliance is OFF, set DELAY TURN ON for deferred appliance start or, with the appliance in RUNNING, set DELAY TURN OFF to program shutdown.
- Page 30 How does the STAND-BY mode work? The STD-BY allows the stove to be switched off when it reaches the temperature value set in section 4. The OFF Delta, is the temperature differential between the SET ambient temperature and the actual ambient temperature. Therefore if, for instance, the SET ambient temperature is 19°C, with an OFF Delta of 2°C and a switch-off delay of 5’, when the ambient temperature remains above 21°C for at least 5 minutes, the stove will switch off.
- Page 31 Menu 09 Menu 09 XXX = TECHNIC YYY = SETTINGS Menu with access key, reserved for use by the Assistance Technician only. Menu 10 XXX = SET YYY =ADJUST- Menu 10 Menu to adjust the load PELLET settings and combustion fan speed ADJUSTMENT SETTINGS: button 4, press button 6 to reach the SET ADJUST- page, press button 4 to confirm on page 1, ADJUST PELLET, press button 4 to enter, then press button 1 or 2 to increase or decrease the PELLET load press button 6 to go to the ADJUST CHIMNEY page...
-
Page 32: Appliance Start And Use
08.4 APPLIANCE START AND USE After professionally installing the room ventilation system, the fume exhaust system, the hydraulic system and electrical system according to the relevant regulations, the CAT can commission the first start up. After passing the Service Technician’s inspection, the tank can be filled with pellets of the recommended quality, desired temperature and power set (we recommend setting level 3) and the device turned on with Button 3. -
Page 33: Safety Thermostat With Manual Reset
08.5 SAFETY THERMOSTAT WITH MANUAL RESET A safety thermostat is installed on the device to protect against any overheating of fuel contained in the pellet hopper and cause the device to switch off if the temperature sensor reaches limit values which correspond to the thermostat trigger setting. To restore normal appliance operations following forced shutdown by a thermostat, proceed as follows: 1. -
Page 34: Tips For The User
08.6 TIPS FOR THE USER • The air change fan starts running automatically according to the temperature of the fumes. • Only use original spare parts; original spare parts are available through authorised retailers, authorised Assistance Centres, or directly from JOLLY-MEC. •... -
Page 35: Ordinary Maintenance (By The Costumer)
Time between one cleaning and the next is strictly tied to fuel quality and also the device’s operating time. The most suitable cleaning frequency can only be established a few days after use according to the actual amount of deposited residue and may vary from the intervals imposed by Jolly Mec. - Page 36 Brazier removal for cleaning (daily) With the combustion chamber door open, lift the firebox upwards to remove it (F . 5-6). It is compulsory to clean the firebox thoroughly, making sure no holes are clogged. Remove combustion residues and free all the air passage with a screwdriver or a pointed tool (not supplied with the stove).
- Page 37 Disassembling of the internal parts for cleaning . 13 . 14 (Monthly) Open the door of the stove, by means of a vacuum cleaner remove all the ash, also clean the residues attached to the inner walls of the stove with a brush. Remove the brazier to proceed with the removal of interior walls .
- Page 38 If you have properly done the operation explained in the previous . 21 . 22 point the beat flame (flame arrestor) is now placed as showed in . 21. To complete the removal of the upper beat flame (flame arrestor) rotate towards right or left (it is the same) as much as required to unblock it from the lateral walls and lift it out (F .
- Page 39 Follow the same procedure as for the right wall to remove the . 30 . 31 left wall. . 32 . 33 Remove the two side supports by turning up (F 34-35-36-37), . 34 . 35 after you have done this remove the down beat flame. .
- Page 40 At the bottom of the combustion chamber behind the support of . 38 . 39 the brazier there is another wall to remove, grab her by the edge and pull up (F 38-39). Removed this piece, the two rear walls are released, to remove .
- Page 41 When all surfaces are clean, remove the ash collection drawer . 46 ad thoroughly clean even the latter (F . 46). Finally, use a screwdriver to remove the cap that is located . 47 . 48 under the ash drawer and thoroughly clean even this vain (F 47-48-49).
- Page 42 Glass cleaning (daily) . 53 . 54 Clean the glass daily with a damp sponge or paper hand towels . 53-54). If the glass becomes dirty with black smoke, the brazier is probably dirty or the combustion air must be increased. Be careful not to use overly aggressive products to avoid ruining the paint.
- Page 43 Resetting the safety thermostat (see CHAP. 08.5) . 61 . 62 Unscrew the black hood fastened to the galvanised section at the back of the stove (F . 61). Press the white button (F . 62) until you hear it “CLICK” into the safety reset position. Refit the black hood.
-
Page 44: Scheduled Preventive Maintenance
We wish to remind you that the Extraordinary Maintenance to be carried out on this type of product must be done obligatorily every year by qualified maintenance personnel, in order to maintain its functionality, efficiency and comfort. For any further queries you may have, we invite you to contact the authorised Jolly Mec Technical Assistance Centre through your retailer. Scheduled maintenance must include: •... -
Page 45: Chap.09 Fault Diagnosis And Troubleshooting
09.1 PROBLEMS WARNING In accordance with the laws in force on safety for electrical appliances, a Jolly Mec Technical Assistance Centre or qualified personnel must obligatorily be contacted for all installation, maintenance or interventions that require access to electrical parts. -
Page 46: Alarm Messages
09.2 ALARM MESSAGES Following is an overview on appliance alarms linked to the probable causes and some potential solutions. If an alarm occurs with a certain frequency, contact the Jolly Mec Technical Assistance Centre. Alarm code Alarm test Alarm cause Main solution •... - Page 47 Alarm code Alarm test Alarm cause Main solution • The temperature falls below the THRESHOL WORK • Check that the level of PELLETS inside AL06 setting whilst the stove is running. the hopper is sufficient PELLET • Check the PELLET load times are set correctly •...
- Page 48 Alarm code Alarm test Alarm cause Main solution • The motherboard temperature is over 60°C, non- • Check the pellet load values, they may be AL15 SAFETY modifiable value. excessive and cause overheating inside BOARD the stove cladding. • Check the heat exchange fan is working properly, otherwise it can cause overheating inside the stove cladding.
- Page 49 NOTES...
