Toshiba RD-XV47KE Service Manual

Hdd&dvd / videocassetterecorder
Hide thumbs

Advertisement

SERVICE MANUAL
PAL
PAL
SECAM
/ Video Cassette Recorder
The above models are classified as green products (*1), as indicated by the underlined serial
numbers. This Service Manual describes replacement parts for the green products. When
repairing these green product(s), use the part(s) described in this manual and lead-free solder (*2).
For (*1) and (*2), see the next page.
TOSHIBA CORPORATION 2007
VCR
I/
I/
VCR
REC
REC
ON / STANDBY
ON / STANDBY
FILE NO. 810-200719GR
HDD & DVD
RD-XV47KE
RD-XV47KB
RD-XV47KF
HDD/DVD
PROGRAM
HDD/DVD
PROGRAM
DUBBING
VCR
HDD
DVD
REC
HDD
DUBBING
VCR
DVD
REC
VCR
DVD
DVD
HDD
DVD
VCR
HDD
DVD
DVD
HDD
HDD
DVD
Published in Japan, July 2007 GREEN
REVISED: 01

Advertisement

loading

  Also See for Toshiba RD-XV47KE

  Related Manuals for Toshiba RD-XV47KE

  Summary of Contents for Toshiba RD-XV47KE

  • Page 1 This Service Manual describes replacement parts for the green products. When repairing these green product(s), use the part(s) described in this manual and lead-free solder (*2). For (*1) and (*2), see the next page. TOSHIBA CORPORATION 2007 Published in Japan, July 2007 GREEN...
  • Page 2 Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing of new products containing the restricted substances. Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities.
  • Page 3: Table Of Contents

    MAIN SECTION HDD & DVD / Video Cassette Recorder RD-XV47KE/RD-XV47KB/RD-XV47KF Main Section I Specifications I Preparation for Servicing I Adjustment Procedures I Schematic Diagrams I BOARD’s I Exploded Views I Parts List TABLE OF CONTENTS Specifications ................1-1-1 Laser Beam Safety Precautions.
  • Page 4: Specifications

    435 x 99.5 x 380 mm Operating temperature 5°C to 40°C Operating humidity Less than 80% (no condensation) TV format AL / SECAM - BG / DK (RD-XV47KE) PAL-I (RD-XV47KB) SECAM LL, PAL B / G (RD-XV47KF) Recording Recording format Video Recording format (DVD-RW only),...
  • Page 5: Laser Beam Safety Precautions

    LASER BEAM SAFETY PRECAUTIONS This DVD player uses a pickup that emits a laser beam. Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin. The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30 cm away from the pickup lens when the diode is turned on.
  • Page 6: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Product Safety Notice K. When connecting or disconnecting the internal connectors, first, disconnect the AC plug from the Some electrical and mechanical parts have special AC outlet. safety-related characteristics which are often not evi- dent from visual inspection, nor can the protection they give necessarily be obtained by replacing them with components rated for higher voltage, wattage, etc.
  • Page 7 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, Chassis or Secondary Conductor parts, and wires have been returned to their original positions. Afterwards, do the following tests and con- Primary Circuit firm the specified values to verify compliance with safety standards.
  • Page 8: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Circuit Board Indications Pb (Lead) Free Solder 1. The output pin of the 3 pin Regulator ICs is When soldering, be sure to use the Pb free solder. indicated as shown. How to Remove / Install Flat Pack-IC Top View Bottom View...
  • Page 9 3. The flat pack-IC on the BOARD is affixed with With Soldering Iron: glue, so be careful not to break or damage the foil 1. Using desoldering braid, remove the solder from of each pin or the solder lands under the IC when all pins of the flat pack-IC.
  • Page 10 With Iron Wire: 2. Installation 1. Using desoldering braid, remove the solder from 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder the foil of each pin of the flat pack-IC on the flux which is applied to all pins of the flat pack-IC, BOARD so you can install a replacement flat pack- you can remove it easily.
  • Page 11 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.
  • Page 12: Handling Precautions For Hdd

    HANDLING PRECAUTIONS FOR HDD CAUTION: 4. OTHERS a. Be careful so as not to do the followings. 1. SHOCK Otherwise, HDD might be damaged. a. Exposing HDD to shock may be the biggest - DO NOT disassemble HDD. damaging factor. Please note that HDD is easily - When handling HDD, be sure to hold both sides damaged even if dropped from any height.
  • Page 13: Preparation For Servicing

    PREPARATION FOR SERVICING How to Enter the Service Mode About Optical Sensors Caution: An optical sensor system is used for the Tape Start and End Sensors on this equipment. Carefully read and follow the instructions below. Otherwise the unit may operate erratically. What to do for preparation Insert a tape into the Deck Mechanism Assembly and press [VCR PLAY] button.
  • Page 14: Cabinet Disassembly Instructions

    CABINET DISASSEMBLY INSTRUCTIONS NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1. Disassembly Flowchart REMOVAL This flowchart indicates the disassembly steps to gain REMOVE/*UNHOOK/ LOC. PART Fig. access to item(s) to be serviced. When reassembling, UNLOCK/RELEASE/ Note follow the steps in reverse order. Bend, route, and UNPLUG/DESOLDER dress the cables as they were originally.
  • Page 15 Reference Notes 1. Locking Tabs (L-1) and (L-2) are fragile. Be careful (S-3B) not to break them. [3] Front Bracket 1-1. Remove Screw (S-2). (S-3B) 1-2. Release five Locking Tabs (L-1). (S-3) Front 1-3. Release three Locking Tabs (L-2) and Support remove the Front Assembly.
  • Page 16 CN3002 [14] BOARD SWITCH CN3001 (S-7) Desolder [9] BOARD ATA [15] BOARD FRONT JACK (S-14) (S-12) [7] HDD Unit CL1001 (S-7) (S-13) HDD Rubber CN3001 [8] HDD Support [13] BOARD POWER HDD Rubber SUPPLY (S-8) (S-8) Insulation Sheet (S-7B) Fig. D6 [6] HDD Bracket (S-16) (S-15)
  • Page 17 Cylinder Assembly FE Head ACE Head Assembly SW507 LD-SW [17] Deck Assembly [18] BOARD [19] BOARD [18] BOARD POWER POWER SWITCH [17] Deck Assembly Cam Gear Hole (S-18) Shaft [18] BOARD POWER Desolder (S-19) Hole LD-SW [18] BOARD POWER Lead with blue stripe From FE Head...
  • Page 18 (S-20) [20] Deck Pedestal (S-20) [21] Front Bracket R [22] Bracket R (S-22) (S-21) Fig. D9 3. How to Eject Manually Note: When rotating the gear, be careful not to damage the gear. 1. Remove the Cover Top. 2. Rotate the gear in the direction of the arrow manually as shown below. View for A Rotate this gear in the direction of the arrow...
  • Page 19: Electrical Adjustment Instructions

    ELECTRICAL ADJUSTMENT INSTRUCTIONS NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. NOTE: 1.Electrical adjustments are required after replacing circuit components and certain mechanical parts. It is important to do these adjustments only after Figure 1 all repairs and replacements have been com- pleted.
  • Page 20: How To Self-Check And Initialize The Hdd & Dvd/Vcr

    HOW TO SELF-CHECK AND INITIALIZE THE HDD & DVD/VCR 1. Turn on the HDD & DVD/VCR. 2. To put the HDD & DVD/VCR into the HDD mode, press [HDD] on the remote control unit. 3. To put the HDD & DVD/VCR into the self-check mode, after pressing [VARIABLE SKIP] button, press the [3], [6], and [9] buttons on the remote control in that order within three seconds.
  • Page 21 Table 2: Indication of DVD self-check (*7) INDICATION DESCRIPTION Connection of DVD is normal. NOT FOUND DVD drive cannot be found. FFC cable (connecting to CN401) between the DVD drive and the DVD/HDD MAIN BOARD CABLE ERROR is not connected correctly. Table 3: Indication of HDD self-check (*8) INDICATION DESCRIPTION...
  • Page 22: Firmware Renewal Mode

    FIRMWARE RENEWAL MODE 1. Update Contents 4. Load the update disc. The TV screen will display Fig. c. Item Status - If the update disc contains only a single file, the update will initiate automatically when the disc is Update B/E FIRMWARE inserted.
  • Page 23 The status displayed in *2 is as shown below. 3. How to Verify the Firmware Version Display Status 1. Turn the power on and remove the disc in the tray. Loading F/W from Update Disc or EXECUTING writing to Flash memory 2.
  • Page 24: Troubleshooting

    TROUBLESHOOTING NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1 Power Supply Section FLOW CHART NO.1 The power cannot be turned on. See FLOW CHART No.2 <The fuse blows out.> Is the fuse normal? Is normal state restored when once unplugged Check for lead or short-circuiting of primary power cord is plugged again after several seconds.
  • Page 25 FLOW CHART NO.6 AL+44V is not outputted. Check D013, D1104, C013, and their periphery, Is 44V voltage supplied to the emitter of Q1511? and service it if defective. Is the "L" pulse (approximately 0V) inputted to Is the "H" pulse (approximately 5V) inputted to the base of Q1511? the base of Q1512? Replace Q1511.
  • Page 26 FLOW CHART NO.11 HDD+5V is not outputted. Is 5V voltage supplied to the emitter of Q1102? Check D016, D1032, D1102, C1104, C1105 and their periphery, and service it if defective. Is the "L" pulse outputted to the collector of Q1104? Check Q1104, D1117 and their periphery, and service it if defective.
  • Page 27 2 HDD/DVD Section FLOW CHART NO.1 The key operation is not functioning. Are the contact point and the installation state of Re-install the key switches correctly or replace the key switches normal? the poor switch. Is the control voltage normally inputted into Check the key switches and their periphery, and Pin(82, 83) of IC1501? service it if defective.
  • Page 28 FLOW CHART NO.4 VIDEO E-E does not appear normally. Are the video signals inputted to each pin of Check the line between video input terminal and IC1509? each pin of IC1509. → JK1504 IC1509 16PIN VIDEO-IN 1 (AV1) IC1509 16PIN VIDEO-IN 1 (AV1) →...
  • Page 29 Replace the DVD MECHANISM & DVD MAIN Are the video signals outputted to each pin of BOARD ASSEMBLY. CN1502? CN1502 24PIN VIDEO-Y(I/P)-OUT CN1502 30PIN VIDEO-Y(I)-OUT CN1502 26PIN VIDEO-Pr/Cr-OUT CN1502 28PIN VIDEO-Pb/Cb-OUT CN1502 22PIN VIDEO-C-OUT Are the video signals shown above inputted into Check the line between each pin of CN1502 and each pin of IC1509? each pin of IC1509, and service it if defective.
  • Page 30 FLOW CHART NO.5 Picture does not appear normally. Set the disc on the disc tray, and playback it. (DVD MODE) Or, playback by selecting the picture in HDD top menu. (HDD MODE) Replace the DVD MECHANISM & DVD MAIN Are the video signals outputted to each pin of BOARD ASSEMBLY.
  • Page 31 FLOW CHART NO.6 Check the line between audio input terminal and Audio E-E does not appear normally. each pin of IC1509, and service it if defective. No (Rear →JK1504 IC1509 93,94PIN AUDIO-IN1 (AV1) or Front →JK3002, IC1509 91,92PIN AUDIO-IN1 (FRONT) input) Are the audio signals inputted to each pin of JK3003...
  • Page 32 Replace the DVD MECHANISM & DVD MAIN Are the analog audio signals outputted to each pin BOARD ASSEMBLY. of CN1502? CN1502 14PIN AUDIO (L)-OUT CN1502 16PIN AUDIO (R)-OUT Are the analog audio signals inputted to each pin Check each line between each pin of CN1502 and each pin of IC1508, and service it if defective.
  • Page 33 FLOW CHART NO.7 Audio is not outputted during playback. Set the disc on the disc tray, and playback it. (DVD MODE) Or, playback by selecting the picture in HDD top menu. (HDD MODE) Replace the DVD MECHANISM & DVD MAIN Are the analog audio signals outputted to each pin BOARD ASSEMBLY.
  • Page 34 3 VCR Section FLOW CHART NO.1 The key operation is not functioning. Are the contact point and the installation state of Re-install some key switches correctly or the key switches normal? replace some key switches. Check the key switches and their periphery, and Is the control voltage normally inputted into service it if defective.
  • Page 35 FLOW CHART NO.3 Cassette tape can not be loaded. When loading a cassette tape, on Pin(10) of Check the line between the start sensor and IC501, does the "L" pulse switch to the "H" pulse? Pin(10) of IC501, and service it if defective. When loading a cassette tape, is the specified Replace the Capstan Motor Unit.
  • Page 36 FLOW CHART NO.6 Capstan Motor does not rotate. Is 5V voltage supplied to Pin(2) of CN502? Check the P-ON+5V line and service it if defective. Is over approximately 2.6V voltage supplied to Check the line between Pin(5) of CN502 and Pin(5) of CN502? Pin(76) of IC501, and service it if defective.
  • Page 37 FLOW CHART NO.10 Video E-E does not appear normally. Are the video signals inputted to each pin of Check the line between video input terminal and IC1509? each pin of IC1509. → JK1504 IC1509 16PIN VIDEO-IN 1 (AV1) IC1509 16PIN VIDEO-IN 1 (AV1) →...
  • Page 38 FLOW CHART NO.11 Check the line between audio input terminal and Hi-Fi E-E audio does not operate normally. each pin of IC1509, and service it if defective. No (Rear or Front →JK1504 IC1509 93,94PIN AUDIO-IN1 (AV1) input) Are the audio signals inputted to each pin of →JK3002, IC1509 91,92PIN...
  • Page 39 FLOW CHART NO.12 Hi-Fi audio can not be recorded normally. (E-E mode is normal.) Is the Hi-Fi-COM signal outputted to Pin(26) of Replace IC451. IC451? Check the line between Pin(8) of CN251 and Is the line between Pin(8) of CN251 and Pin(26) of IC451, and service it if defective.
  • Page 40 FLOW CHART NO.15 Hi-Fi audio can not be playbacked normally in the linear audio mode. (E-E mode is normal.) Is the audio signal supplied to Pin(5) of IC301? Is the audio signal outputted to Pin(11) of IC301? Check the line between Pin(11) of Replace IC301 and Pin(80) of IC451, and IC301.
  • Page 41: Function Indicator Symbols

    FUNCTION INDICATOR SYMBOLS < VCR Section > When the power comes on again after that by pressing [ ] button, an error message is displayed on the TV screen as follows. When reel or capstan mechanism is not functioning P-ON+5V Power safety detection correctly 0:00:00 0:00:00...
  • Page 42: Block Diagrams

    SW507 IC501 Models & Marks (SERVO/SYSTEM CONTROL) BOARD POWER LD-SW ACE HEAD ASSEMBLY CN504 AL+5V(2) LD-SW Model Mark CTL(+) CONTROL CTL(+) RD-XV47KE HEAD CTL(-) KEY- 1 CTL(-) KEY SWITCH RD-XV47KB ST-S REC-SAF-SW 31 AL+5V(2) RD-XV47KF END-S SW506 TP502 T-REEL REC-SAFETY...
  • Page 43 Sub System Control Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. IC1501 (SUB MICRO CONTROLLER) REG-CONT IC1502 REG-CONT PWR -SW Q1527 TO SUB PW-SW LOW-POW RESET RESET TIMER+5V POWER SUPPLY LOW-POW FAN-LOCK BLOCK DIAGRAM FAN-LOCK FAN-CONT1 FAN-CONT1 P-DOWN BUP+5V Q1528 C1511 (BACKUP CAPACITOR) FL-DIN...
  • Page 44 Digital Signal Process Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. REC VIDEO SIGNAL PB VIDEO SIGNAL REC AUDIO SIGNAL PB AUDIO SIGNAL CN3001 CN3002 CN901 HARD DISK DRIVE IC201 IC101 BOARD ATA ERROR AMP DVD MECHANISM CN201 VIDEO ENCODER VIDEO TILT PICK...
  • Page 45 Video Selector Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. REC VIDEO SIGNAL PB VIDEO SIGNAL IC1509 (VIDEO SELECTOR) BOARD BOARD REAR JACK POWER Q2001 JK2001 CN2001 CN1506 VIDEO OUT2 BUFFER VIDEO-OUT2 DRIVER VIDEO-G VIDEO-G-IN JK2001 CN1506 CN2001 VIDEO-B VIDEO-B-IN VIDEO-IN2 VIDEO VIDEO-R...
  • Page 46: Video Block Diagram

    Video Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. REC-VIDEO SIGNAL PB-VIDEO SIGNAL MODE: SP/REC Comparison Chart of Models & Marks Model Mark RD-XV47KE IC501 (OSD) RD-XV47KB IIC-BUS SCL TO SERVO/SYSTEM RD-XV47KF CHARACTER CONTROL BLOCK IIC-BUS SDA COLOR DIAGRAM Q402...
  • Page 47 Audio Selector Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. REC AUDIO SIGNAL PB AUDIO SIGNAL BOARD REAR JACK IC1509(AUDIO SELECTOR) JK2001 BOARD POWER CN1506 CN2001 AUDIO(L)-IN2 AUDIO(L)-IN2 TO SUB SYSTEM AUDIO(R)-IN2 AUDIO(R)-IN2 CONTROL AUDIO(L)-OUT2 AUDIO(L)-OUT2 BLOCK DIAGRAM AUDIO(R)-OUT2 AUDIO(R)-OUT2 AUDIO-MUTE MUTE-ON MUTE-ON...
  • Page 48: Audio Block Diagram

    Audio Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. PB-AUDIO SIGNAL REC-AUDIO SIGNAL Mode : SP/REC BOARD POWER N-A-PB TO Hi-Fi AUDIO N-A-REC BLOCK DIGRAM IC301 (AUDIO SIGNAL PROCESS) PB-ON LINE MUTE (DECK ASSEMBLY) SP/LP-ON P-ON+5V ACE HEAD ASSEMBLY REC-ON Q404 CN504 AUDIO...
  • Page 49 Hi-Fi Audio Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. PB-AUDIO SIGNAL REC-AUDIO SIGNAL Mode : SP/REC BOARD POWER VCR-AUDIO-IN(L) TO AUDIO VCR-AUDIO-IN(R) SELECTOR BLOCK DIAGRAM IC451 ( Hi-Fi AUDIO PROCESS) R-CH IIC-BUS SDA SERIAL COMP NOISE DATA IIC-BUS SCL DECODER R-CH SERVO/ SYSTEM...
  • Page 50: Power Supply Block Diagram

    Power Supply Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. CAUTION ! CAUTION ! NOTE: Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. For continued protection against fire hazard, The voltage for parts in hot circuit is measured using If Main Fuse (F1001) is blown , check to see that all components in the power supply replace only with the same type fuse.
  • Page 51 Sub Power Supply Block Diagram NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. CN1503 1 AL-30V J902 2 AL+44V AL+44V Q1511 3,4 AL+16.3V P-ON+15V 7,8 AL+12V 14 P-ON+9V Q1512 15,16 P-ON+5V 17,18 AL+5V(3) Q1508 22 AL+5V POWER SUPPLY AL+16V/+12V BLOCK DIAGRAM 23 F1 (CL1001) 24 F2 Q1509...
  • Page 52: Schematic Diagrams / Board's And Test Points

    SCHEMATIC DIAGRAMS / BOARD’S AND TEST POINTS NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Standard Notes WARNING Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
  • Page 53 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE. 2. CAUTION: Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F1001) is blown, first check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply.
  • Page 54 POWER 1/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Comparison Chart of Models and Marks MODEL MARK RD-XV47KE RD-XV47KB RD-XV47KF 1-14-3 E3B90SCP1...
  • Page 55 POWER 2/10 & SENSOR Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. FL601 MATRIX CHART G7(GR7) G6(GR6) G5(GR5) G4(GR4) G3(GR3) G2(GR2) G1(GR1) (SG1) (SG2) (SG3) (S3) (SG4) (SG5) (S2) (SG6) (SG7) (S1) (SG8) P-SCAN (SG9) TIME P-SCAN SHIFT CD R...
  • Page 56 POWER 3/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Comparison Chart of Models and Marks MODEL MARK RD-XV47KE RD-XV47KB RD-XV47KF 1-14-5 E3B90SCP3...
  • Page 57 POWER 4/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-6 E3B90SCP4...
  • Page 58 You can choose either Group. The difference between Group A and Group B is shown below. Group A Group B IC1502A R3112N211A-TR-F ---------- IC1502B ---------- PST3621NR C1505A 0.015 ---------- C1505B ---------- 0.15 Comparison Chart of Models and Marks MODEL MARK RD-XV47KE RD-XV47KB RD-XV47KF 1-14-7 E3B90SCP5...
  • Page 59 POWER 6/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-8 E3B90SCP6...
  • Page 60 POWER 7/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-9 E3B90SCP7...
  • Page 61 POWER 8/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-10 E3B90SCP8...
  • Page 62 POWER 9/10 Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-11 E3B90SCP9...
  • Page 63 POWER 10/10 Schematic Diagram ( C ) < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Comparison Chart of Models and Marks MODEL MARK RD-XV47KE RD-XV47KB RD-XV47KF 1-14-12 E3B92SCP10...
  • Page 64 POWER SUPPLY Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. CAUTION ! CAUTION ! NOTE: Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. For continued protection against fire hazard, The voltage for parts in hot circuit is measured using If Main Fuse (F1001) is blown , check to see that all components in the power supply replace only with the same type fuse.
  • Page 65 FRONT JACK & SWITCH Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-14 E3B90SCFJ...
  • Page 66 REAR JACK Schematic Diagram < VCR Section > ATA Schematic Diagram < DVD/HDD Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. E3B90SCRJ E3B90SCAT 1-14-15...
  • Page 67 AFV Schematic Diagram < VCR Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Comparison Chart of Models and Marks MODEL MARK RD-XV47KE RD-XV47KB RD-XV47KF 1-14-16 E3B90SCAFV...
  • Page 68 DVD/HDD MAIN 1/5 Schematic Diagram < DVD/HDD Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 2 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD/HDD Main Schematic Diagram Section. 1-14-17 E3B90SCD1...
  • Page 69 DVD/HDD MAIN 2/5 Schematic Diagram < DVD/HDD Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 2 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD/HDD Main Schematic Diagram Section. 1-14-18 E3B90SCD2...
  • Page 70 DVD/HDD MAIN 3/5 Schematic Diagram < DVD/HDD Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 2 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD/HDD Main Schematic Diagram Section. 1-14-19 E3B90SCD3...
  • Page 71 DVD/HDD MAIN 4/5 Schematic Diagram < DVD/HDD Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 2 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD/HDD Main Schematic Diagram Section. 1-14-20 E3B90SCD4...
  • Page 72 DVD/HDD MAIN 5/5 Schematic Diagram < DVD/HDD Section > NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 2 NOTE: The order of pins shown in this diagram is different from that of actual IC101. IC101 is divided into five and shown as IC101 (1/5) ~ IC101 (5/5) in this DVD/HDD Main Schematic Diagram Section. 1-14-21 E3B90SCD5...
  • Page 73 BOARD POWER Top View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. BOARD SENSOR View TO BOARD SENSOR (END-SENSOR) TP504 VR501 TP503 SW-POINT RF-SW BHF300F01012A TP301 C-PB BHF300F01012B J308 AV1-V-OUT TO BOARD SENSOR (START-SENSOR) 1-14-22 BE3B00F01011A...
  • Page 74 BOARD POWER Bottom View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. PIN 56 OF IC301 PIN 30 OF IC1509 PIN 28 OF CN1502 PIN 26 OF CN1502 PIN 24 OF CN1502 PIN 22 OF CN1502 PIN 14 OF CN1502 WF10 PIN 28OF CN1503 1-14-23 BE3B00F01011A...
  • Page 75 BOARD POWER SUPPLY Top View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. Because a hot chassis ground is present in the power CAUTION ! CAUTION ! supply circut, an isolation transformer must be used. For continued protection against fire hazard, Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. Also, in order to have the ability to increase the input replace only with the same type fuse.
  • Page 76 BOARD POWER SUPPLY Bottom View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. CAUTION ! Because a hot chassis ground is present in the power CAUTION ! supply circut, an isolation transformer must be used. For continued protection against fire hazard, Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. Also, in order to have the ability to increase the input replace only with the same type fuse.
  • Page 77 BOARD FRONT JACK Top View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. BOARD SWITCH BOARD SWITCH Top View Bottom View BOARD FRONT JACK Bottom View BE3B00F01021B BE3B00F01021C 1-14-26...
  • Page 78 BOARD REAR JACK Top View BOARD REAR JACK Bottom View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. BE3B00F01021D BOARD POWER SWITCH BOARD POWER SWITCH BOARD ATA Bottom View BOARD ATA Top View Top View Bottom View BE3B00F01011B BE4340F01032 1-14-27...
  • Page 79 BOARD AFV Top View BOARD AFV Bottom View NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. 1-14-28 BE6800F01091...
  • Page 80: Waveforms

    WAVEFORMS NOTE: Input: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL) Pin 56 of IC301 Pin 22 of CN1502 Pin 14 of CN1502 V-OUT E-E 0.2V 20μs VIDEO-C 0.2V 20μs AUDIO(L)-OUT 0.5ms Pin 56 of IC301 UPPER Pin 30 of IC1509 Pin 28 of CN1503 TP504 WF10...
  • Page 81: Wiring Diagram

    WIRING DIAGRAM NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. REAR CN1503 DIGITAL AL-30V 1 AUDIO OUT VIDEO- VIDEO- VIDEO- S-VIDEO AUDIO(L) AUDIO(R) AL+44V 2 Y-OUT Pb/Cb-OUT Pr/Cr-OUT -OUT -OUT ANT-IN ANT-OUT COAXIAL AL+16.3V 3 AL+16.3V 4 (DECK ASSEMBLY) JK1504 GND 5 (AV1) GND 6 AL+12V 7...
  • Page 82 WIRING DIAGRAM NOTE: BOARD MEANS PRINTED CIRCUIT BOARD. DVD MECHANISM & DVD MAIN BOARD ASSEMBLY DVD MECHANISM CN1001 CN301 CN101 CN1001 CL1001 2 SW1 GND 1 AV-30V 1 CN1003 3 SL(-) GND 2 AL+44V 2 4 SL(+) GND 3 AL+16.3V 3 SLED 5 GND P-ON+10.5V 4...
  • Page 83: Ic Pin Function Descriptions

    Signal Mark Function Name Comparison Chart of Models and Marks Not Used Model Mark Not Used RD-XV47KE Not Used RD-XV47KB Recording Safety SW RD-XV47KF REC-SAF- Detect (With Record IC501 ( SERVO / SYSTEM CONTROL ) tab=”L”/ With out Record tab=”H”)
  • Page 84 Signal Signal Mark Function Mark Function Name Name Capstan Motor Rotation OUT C-POW-SW Capstan Power IN C-FG Detection Pulse Switching Signal AMPVss Ground Not Used IN SECAM-H SECAM Mode at High Not Used Drum Motor Phase/ Not Used IN D-PFG Frequency Generator Special playback = "H"...
  • Page 85 IC612 ( VFD DRIVER ) Signal Function Name IN CLK Clock Input IN STB Serial Interface Strobe Not Used Not Used Ground Power Supply OUT SG1 OUT SG2 OUT SG3 10 OUT SG4 Segment Output 11 OUT SG5 12 OUT SG6 13 OUT SG7 14 OUT SG8 Pull Down Level...
  • Page 86: Lead Identifications

    LEAD IDENTIFICATIONS KRA103M-AT/P 2SC2120-(Y)(TE2 F T) KTC2026-Y/P 2SK3798(Q) KRA104M-AT/P KTA-1266-GR-AT/P KRC103M-AT/P KTC3203-Y-AT/P KRC106M-AT/P KTC3198-Y-AT/P KTA1267Y-AT/P KTC3266-GR-AT/P KTA1281Y-AT/P KTC3199-(BL,Y)-AT/P B C E G D S E C B E C B PT204-6B-12 KIA431-AT/P PQ070XF01SZH KIA4558P/P TLV1117I TO-220 UTC4580 ADJ/GND INPUT R A K OUTPUT 1 2 3 4 EL817A...
  • Page 87: Exploded Views

    EXPLODED VIEWS Cabinet L-12 A,B,C,D,E See Electrical Parts List for parts with this mark. B-24 D,E,F ( P3-3 ) BOARD REAR JACK B-10 ( P5 ) TU1501 BOARD AFV ( P4 ) JW2001 B-15 BOARD SENSOR ( P6 ) BOARD ATA L-11 B-31 B-19...
  • Page 88 (P1) POWER ASSEMBLY (P4) BOARD SENSOR ( P5 ) B-10 BOARD AFV TU1501 ( P4 ) BOARD SENSOR BOARD POWER B-31 B-16 ( P1 ) POWER ASSEMBLY BOARD POWER SWITCH (P5) BOARD AFV ( P5 ) BOARD AFV 1-19-2 E3B90CEX...
  • Page 89 (P2) DVD MECHANISM & DVD/HDD MAIN BOARD ASSEMBLY ( P2 ) DVD MECHANISM & DVD/HDD MAIN BOARD ASSEMBLY (P3) BOARD PW/SW Note : Refer to the Parts List for P3, BOARD PW/SW B-24 A,B,C JW2001 ( P3-3 ) AC1001 BOARD REAR JACK ( P3-2 ) BOARD FRONT JACK ( P3 )
  • Page 90 Packing [RD-XV47KE/RD-XV47KF] Lower Side Upper Side X-2D X-2C X-2B X-2A Comparison Chart of Models and Marks Model Mark RD-XV47KE RD-XV47KF 1-19-4 E3B90PEX...
  • Page 91 Packing [RD-XV47KB] Lower Side Upper Side X-30 X-29 1-19-5 E3B90PEX...
  • Page 92: Mechanical Parts List

    MECHANICAL PARTS LIST PRODUCT SAFETY NOTE: Products marked with a Loca- Mark TSB P/N Reference No. Description ! have special characteristics important to safety. tion No. Before replacing any of these components, read L-1A GBHC3050 SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI carefully the product safety notice in this service L-1B GBHC3050...
  • Page 93 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. L-9Q 0VM412937A SCREW C-TIGHT M3X6 P000484000 1VMN23453 QUICK GUIDE E3B91BD E5610UD P000484110 1VMN23456 QUICK GUIDE E3B92FD L-9R 0VM412937A SCREW C-TIGHT M3X6 P000460030 WPZ0122LG001 RF CORD PAL 1.2M E5610UD X-29 1VM424769...
  • Page 94: Electrical Parts List

    ELECTRICAL PARTS LIST PRODUCT SAFETY NOTE: Products marked with a Loca- Mark TSB P/N Reference No. Description ! have special characteristics important to safety. tion No. Before replacing any of these components, read C254 CE1JMAVSL1R0 ELECTROLYTIC CAP . 1μF/ 50V M H7 carefully the product safety notice in this service C301 CHD1JK30B223...
  • Page 95 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. C346 CHD1JZ30F104 CHIP CERAMIC C453 CE1AMAVSL220 ELECTROLYTIC CAP . CAP .(1608) F Z 0.1μF/50V 22μF/10V M H7 C347 CHD1EK30B104 CHIP CERAMIC C454 CHD1JZ30F104 CHIP CERAMIC CAP .(1608) B K 0.1μF/25V...
  • Page 96 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. C509 CHD1JK30B102 CHIP CERAMIC C612 CHD1JK30B472 CHIP CERAMIC CAP .(1608) B K 1000pF/ CAP .(1608) B K 4700pF/ C510 CHD1JK30B472 CHIP CERAMIC C614 CHD1JZ30F104 CHIP CERAMIC...
  • Page 97 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. C1542 CHD1JZ30F104 CHIP CERAMIC C1589 CE1JMASDLR47 ELECTROLYTIC CAP . CAP .(1608) F Z 0.1μF/50V 0.47μF/50V M C1544 CHD1JZ30F104 CHIP CERAMIC C1590 CE1JMASDLR47 ELECTROLYTIC CAP . CAP .(1608) F Z 0.1μF/50V 0.47μF/50V M C1545...
  • Page 98 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. C1629 CHD1JZ30F104 CHIP CERAMIC C1678 CHD1JZ30F104 CHIP CERAMIC CAP .(1608) F Z 0.1μF/50V CAP .(1608) F Z 0.1μF/50V C1630 CHD1JZ30F104 CHIP CERAMIC C1681 CE1JMASDL1R0 ELECTROLYTIC CAP .
  • Page 99 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. D1527 QDTZ001SS133 SWITCHING DIODE If IC1502B is PST3621NR, then C1505B is 0.15μF. 1SS133(T-77) IC1502B P000483900 QSZBA0TMM162 SYSTEM RESET IC D1528 QDTB0MTZJ5R6 ZENER DIODE MTZJT- PST3621NR 775.6B C1505B...
  • Page 100 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. Q406 NQ1YKTC3875S CHIP TRANSISTOR Q1542 NQSYKTC3199P TRANSISTOR KTC3199-Y- KTC3875S-Y-RTK/P AT/P Q451 NQ1ZKRC103SP TRANSISTOR KRC103S- Q1543 NQSYKTC3199P TRANSISTOR KTC3199-Y- RTK/P AT/P Q506 NPWZT2046B12 PHOTO TRANSISTOR Q1544 NQSYKTC3199P TRANSISTOR KTC3199-Y- PT204-6B-12...
  • Page 101 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. CHIP RES. 1/10W J 470 Ω CHIP RES. 1/10W J 1k Ω R463 RRXAJR5Z0471 R623 RRXAJR5Z0102 CHIP RES. 1/10W J 3.3k Ω R464 RRXAJR5Z0332 R624...
  • Page 102 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. CHIP RES. 1/10W J 3.3k Ω R1585 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 R1645 RRXAJR5Z0332 Ω CHIP RES. 1/10W J 470 Ω R1646 RRXAJR5Z0471 CHIP RES.
  • Page 103 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. R1711 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0 R1771 RCX6JATZ0123 CARBON RES. 1/6W J 12k Ω Ω CHIP RES. 1/10W J 1.8k Ω CHIP RES. 1/10W J 12k Ω R1712 RRXAJR5Z0182 R1772...
  • Page 104 BOARD POWER SUPPLY Loca- Mark TSB P/N Reference No. Description tion No. Loca- VR501 VRCB104HH014 CARBON P .O.T. VZ067TL1 Mark TSB P/N Reference No. Description tion No. B104 PB(F) ! P3-4 P000483760 1VSA15686-4 BOARD POWER SUPPLY X301 P000468200 FXC445LLN004 XTAL 4.433619MHz (PW/SW-A) X501 P000468220 FXD126LCHE01 QUARTS CRYSTAL...
  • Page 105 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. C1132 CE0KMASDL102 ELECTROLYTIC CAP . D1115 QDTZ001SS133 SWITCHING DIODE 1000μF/6.3V M 1SS133(T-77) C1133 CA2A102DT018 POLYESTER FILM CAP . D1116 QDTZ001SS133 SWITCHING DIODE (PB FREE) 0.001μF/100V J 1SS133(T-77) C1138...
  • Page 106 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. L1001-2 XL03010XM001 BEAD CORE B16 RH R1029 RCX4JATZ0184 CARBON RES. 1/4W J 180k Ω 3.5X10X1.3 R1033 RCX4JATZ0560 CARBON RES. 1/4W J 56 Ω...
  • Page 107 BOARD FRONT JACK Loca- Mark TSB P/N Reference No. Description tion No. Loca- R1149 RCX4JATZ0682 CARBON RES. 1/4W J Mark TSB P/N Reference No. Description tion No. 6.8k Ω P3-2 P000483740 1VSA15686-2 BOARD FRONT JACK R1150 RCX4JATZ0682 CARBON RES. 1/4W J (PW/SW-B) 6.8k Ω...
  • Page 108 Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. SW3004 P000483300 SST0101AL041 TACT SWITCH C2009 CE1JMASDL1R0 ELECTROLYTIC CAP . 1μF/ SKQSAF001A 50V M SW3005 P000483300 SST0101AL041 TACT SWITCH C2010 CE1JMASDL1R0 ELECTROLYTIC CAP . 1μF/ SKQSAF001A 50V M SW3006...
  • Page 109 BOARD AFV BOARD ATA Loca- Loca- Mark TSB P/N Reference No. Description Mark TSB P/N Reference No. Description tion No. tion No. P000483720 1VSA15656 BOARD AFV P000472730 1VSA13582 BOARD ATA Consists of the following: P000484120 1VSA15657 BOARD AFV CONNECTORS Consists of the following: CN3001 JCYKC40JC002 IDC SOCKET 40PIN VT...
  • Page 110 DECK MECHANISM SECTION HDD & DVD / Video Cassette Recorder RD-XV47KE/RD-XV47KB/RD-XV47KF Deck Mechanism Section I Standard Maintenance I Mechanism Alignment Procedures I Disassembly / Assembly of Mechanism I Deck Exploded Views I Deck Parts List TABLE OF CONTENTS Standard Maintenance ..............2-1-1 Service Fixture and Tools.
  • Page 111: Standard Maintenance

    STANDARD MAINTENANCE Service Schedule of Components This maintenance chart shows you the standard of replacement and cleaning time for each part. Because those may replace depending on environment and purpose for use, use the chart for reference. I: Replace h: Hours : Cleaning Deck Periodic Service Schedule...
  • Page 112 Cleaning Cleaning of ACE Head Clean the head with a cotton swab. Cleaning of Video Head Procedure Clean the head with a head cleaning stick or chamois 1.Remove the top cabinet. cloth. 2.Dip the cotton swab in 90% ethyl alcohol and clean Procedure the ACE Head.
  • Page 113: Service Fixture And Tools

    SERVICE FIXTURE AND TOOLS J-1-1, J-1-2 Ref. No. Name Part No. Adjustment J-1-1 Alignment Tape FL6A Head Adjustment of ACE Head J-1-2 Alignment Tape FL6N8 Azimuth and X Value Adjustment of ACE Head / (2 Head model) Adjustment of Envelope Waveform FL6NS8 (4 Head model) Guide Roller Adj.
  • Page 114: Mechanical Alignment Procedures

    MECHANICAL ALIGNMENT PROCEDURES Explanation of alignment for the tape to correctly run B. Method to place the Cassette Holder in the tape- starts on the next page. Refer to the information below loaded position without a cassette tape on this page if a tape gets stuck, for example, in the 1.
  • Page 115 1. Tape Interchangeability Alignment Note: To do these alignment procedures, make sure that the Tracking Control Circuit is set to the preset position every time a tape is loaded or unloaded. (Refer to page 2-3-4, procedure 1-C, step 2.) Equipment required: Dual Trace Oscilloscope VHS Alignment Tape (FL6NS8) Guide Roller Adj.
  • Page 116 1-A. Preliminary/Final Checking and 4. If creasing or snaking is apparent, adjust the Tilt Alignment of Tape Path Adj. Screw of the ACE Head. (Fig. M6) Purpose: To make sure that the tape path is well stabilized. Azimuth Adj. Screw Symptom of Misalignment: If the tape path is unstable, the tape will be damaged.
  • Page 117 5. When Guide Rollers [2] and [3] (Refer to Fig. M3) 5. To shift the CTL waveform, press [PROGRAM are aligned properly, there is no envelope drop or [PROGRAM ] button. Then make sure that either at the beginning or end of track as shown in the maximum output position of PB FM envelope Fig.
  • Page 118 1-D. Azimuth Alignment of Audio/Con- 2. When the tape has been curled up or bent, turn the trol/ Erase Head alignment screw to adjust the height of REV Post. (Refer to Fig. M11 and M13.) Purpose: To correct the Azimuth alignment so that the Audio/ Control/Erase Head meets tape tracks properly.
  • Page 119: Disassembly/Assembly Procedures Of Deck Mechanism

    DISASSEMBLY/ASSEMBLY PROCEDURES OF DECK MECHANISM Before following the procedures described below, be sure to remove the deck assembly from the cabinet. (Refer to CABINET DISASSEMBLY INSTRUCTIONS.) All the following procedures, including those for adjustment and replacement of parts, should be done in Eject mode;...
  • Page 120 REMOVAL INSTALLATION STEP START- REMOVE/*UNHOOK/ /LOC. PART ADJUSTMENT Fig. No. UNLOCK/RELEASE/ CONDITION UNPLUG/DESOLDER Loading Arm (SP) (+)Refer to Alignment DM2H, DM14H [34] [26] Assembly Sec.Page 2-5-1 Loading Arm (TU) (+)Refer to Alignment [35] [34] DM2H, DM14H Assembly Sec.Page 2-5-1 M Brake (TU) [36] [16],[26] DM1H, DM15H...
  • Page 121 Top View [44] [45] [49] [46] [14] [13] [11] [15] [38] [10] [12] [37] [36] [43] [32] [41] [31] [40] [42] Fig. DM1H Bottom View [19] [35] [34] [25] [23] [24] [26] [27] [22] [28] [20] [33] Fig. DM2H 2-4-3 U29PHSDA...
  • Page 122 (S-1) (S-1) (L-1) (L-3) (L-2) (S-1A) (P-1) Installation of [3] and [6] First, insert [6] diagonally in [3] as shown below. Then, install [6] in [3] while pushing (L-1) in the direction of the arrow. After installing [6] in [3], confirm that pin A of [3] enters hole A of [6] properly.
  • Page 123 [11] (S-4A) (L-4) [49] (P-3) [13] [50] Removal of [11] [12] (L-12) 1) Remove screw (S-4A). 2) Unhook spring (P-2). [10] Release (L-4) while (P-2) holding [12] with a finger. Loosen a finger holding [12] and remove [11]. (S-2) Pin of [12] Pin of [10] Groove of [27] When reassembling [10] and...
  • Page 124 Installation of [13] and [12] (S-5) [14] (S-6) [13] [15] Hook spring (P-3) up to [12] and [13], then install them to (P-3) the specified position so that [12] will be floated slightly while holding [12] and [13]. (Refer to Fig. A.) [12] Fig.
  • Page 125 (C-1) turn [22] (S-8) [20] (L-6) [21] [19] Cap Belt Pin on [22] Installation position of Cap Belt [20] Cap Belt [27] Position of pin on [22] Fig. DM12H [19] View for A Fig. DM11H 2-4-7 U29PHSDA...
  • Page 126 Installation of [26] [26] (C-3) Position of Mode Lever when installed Pin of [33] Pin of [37] (S-9) Pin of [36] (L-8) [23] (L-7) Bottom View [24] (C-5) [26] (C-4) (C-2) [28] [27] [25] [29] [30] Align [26] and [27] as shown. [27] First groove on [27] First tooth on [47]...
  • Page 127 [38] [36] [43] (P-6) turn [39] (L-10) turn [42] turn [47] [48] Slide [37] Fig. DM17H (C-7) [41] (C-6) [40] Fig. DM15H [45] [44] [46] (L-11) Slide Plate (S-11) Fig. DM16H 2-4-9 U29PHSDA...
  • Page 128: Alignment Procedures Of Mechanism

    ALIGNMENT PROCEDURES OF MECHANISM The following procedures describe how to align the Alignment 1 individual gears and levers that make up the tape Loading Arm (SP) and (TU) Assembly loading/unloading mechanism. Since information about the state of the mechanism is provided to the Install Loading Arm (SP) and (TU) Assembly so that System Control Circuit only through the Mode Switch, their triangle marks point to each other as shown in...
  • Page 129: Deck Exploded Views

    DECK EXPLODED VIEWS Deck Mechanism View 1 Mark Description Floil G-684G or Multemp MH-D (Blue grease) SLIDUS OIL #150 B494 L1467 B553 L1191 B411 B567 L1053 B410 L1051 Chassis Assembly Top View (Lubricating Point) L1322 B501 L1450 L1450 L1466 B121 B126 B492 B571...
  • Page 130 Deck Mechanism View 2 Mark Description Floil G-684G or Multemp MH-D (Blue grease) B587 B521 B487 SLIDUS OIL #150 B416 B591 SANKOUL FG84M (Yellow grease) B590 B522 L1406 B148 B573 B499 B508 B574 B592 B585 B518 B558 B564 B557 B414 B572 B565 L1151...
  • Page 131 Deck Mechanism View 3 Mark Description Floil G-684G or Multemp MH-D (Blue grease) L1321 SLIDUS OIL #150 B347 L1321 B355 B354 B483 L1341 B425 B482 B562 B300 B563 B313 B529 B360 B359 B361 B555 B303 Some Ref. Numbers are not in sequence. B514 2-6-3 U29P4HSDEX...
  • Page 132: Deck Parts List

    DECK PARTS LIST Loca- TSB P/N Reference No. Description Loca- tion No. TSB P/N Reference No. Description tion No. B558 P000483820 MMDZB12MF003 LOADING MOTOR RF-500TB- P000468620 1VSA14761 CYLINDER ASSEMBLY(N236C) 12560 MK14 PAL 6HD B559 P000468020 0VSA13450 CLUTCH ASSEMBLY(HI) MK12 P000468180 1VSA12912 LOADING MOTOR ASSEMBLY B562...
  • Page 133 Appendix: RD-XV47KE, RD-XV47KB, RD-XV47KF REVISION HISTORY Date Reason for Change 07/31/07 Changed Parts List due to add the TSB P/N for LED, Location No. D555...

This manual is also suitable for:

Rd-xv47kfRd-xv47kb
