Birlea CORONA 3+2 Assembly Instructions Manual

Birlea CORONA 3+2 Assembly Instructions Manual

Drawer chest

Advertisement

Quick Links

Vendor: S000242
ASSEMBLY INSTRUCTIONS
CORONA 3+2 DRAWER CHEST
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR CORONA 3+2 DRAWER CHEST
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
ASSEMBLY INSTRUCTIONS:
Please check contents and read instructions carefully before commencing assembly
To avoid damages assemble the item on a soft, clean surface
HEALTH & SAFETY:
DO NOT use this chest if any parts are missing, damaged or worn
DO NOT use this chest unless all fixings are secured
Always use on a level, even surface
It is recommended that two people handle and assemble the item
CARE & MAINTENANCE: To enjoy your furniture for many years please follow our recommendations
below:
This product is manufactured in pine which is a wood with natural characteristics including knots, grains,
clusters or indentations
On unpacking the item you may notice an odour due to the production process. However, this will disappear
after a period of time.
Do not place the item next to a radiator or direct sunlight – this item is manufactured in pine but is susceptible
to temperature change. It is recommended an even room temperature be maintained with no sudden
fluctuations.
Do not place hot or cold items directly onto the surface of the item – always use a placemat or marking will
occur
For general cleaning use a duster or damp cloth (almost dry) not wet – do not use soap and water, detergents,
aerosol sprays or any polish. The use of these materials would invalidate any claims.
You may wish to retreat the surface to maintain the original finish – this can be done using block wax (un-
perfumed). Please follow the manufacturer's instructions carefully
Do not place the item onto wet or damp flooring as staining may occur to the floor
Periodically check all screws & fixings to ensure they are secure
DO NOT push the chest as this will damage the base
Keep any sharp objects away from the chest
www.birlea.com
Page 1 of 9
