This Configuration Guide lists the configuration options and accessories for the PTU‐D100 E
Series pan‐tilt units with the optional ISM manufactured by FLIR Motion Control Systems, Inc.
Additional information and instructions for PTU‐D100 E Series with ISM are available in the
following documents:
 PTU‐D100 E Series Datasheet
 PTU‐D100 E Series User Manual
 Pan‐Tilt Unit (E Series) Command Reference Manual
 ISM User Manual
Model Numbers
D100E – S S – G G – 000 – S S
Model
S = Standard
V = D300 EX
Available Options
The following configuration and options are available for the PTU‐D100 E Series with ISM:
 Bracket Mount: Payloads can be mounted on the top and/or side. A number of bracket
options are available to suit each application. Page 2.
 Wiring: E Series PTUs with ISM include PL02 wiring. Page 3.
 Range of Motion: If needed, you may request special limits. Page 4.
 Pan‐Tilt Controls: The PTU‐D100 E Series with ISM can be controlled using an ASCI
command set, Ethernet/web connection, or external joystick. Page 5.
 Accessories: Available accessories include cables, converters, power supplies, and starter
kits. Page 6.

890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS
Bracket Mount
S = Dual side hubs
T = Standard

Page 1


03/2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTU-D100 E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FLIR PTU-D100 E Series

  • Page 1   This Configuration Guide lists the configuration options and accessories for the PTU‐D100 E  Series pan‐tilt units with the optional ISM manufactured by FLIR Motion Control Systems, Inc.  Additional information and instructions for PTU‐D100 E Series with ISM are available in the  following documents:   PTU‐D100 E Series Datasheet   PTU‐D100 E Series User Manual   Pan‐Tilt Unit (E Series) Command Reference Manual   ISM User Manual  Model Numbers  D100E – S S – G G – 000 – S S Model Bracket Mount S = Standard S = Dual side hubs V = D300 EX T = Standard  ...
  • Page 2: Bracket Mount

    Side Mount  You may order the PTU‐D100 with one or two  side‐mount bracket (s) with or without a top  bracket.  Part Number: D100E‐_S‐GG‐000‐__   To order a PTU‐D100 with one side‐mount    bracket:     Order the PTU (D100E‐_S‐GG‐000‐__)  plus  one bracket (D100AC‐BKT‐LSTD).   To order a PTU‐D100 with two side‐mount  brackets:   Order the PTU (D100E‐_S‐GG‐000‐__)  plus two brackets  (D100AC‐BKT‐LSTD).   To order a PTU‐D100 with a top bracket and    one or two side brackets:  Order the PTU (D100E‐_T‐GG‐000‐__)  plus one or two brackets  (D100AC‐BKT‐S)  Top Mount  You may order the PTU‐D100 with a top‐mount  configuration and included top bracket.  Part number: D100E‐_T‐GG‐000‐__              Page 2  890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS    03/2011...
  • Page 3: Configuration Guide

    PL02 Wiring  PL02 allows you to route signals to the payload as  Pass Through  PL02  shown in the table via 13 dedicated conductors. A  Conductors  mating connector for cable construction is included.  Power  3  Part number: D100E‐__‐GG‐000‐__  Video  4  General  6  Total  13      Signals at Payload    TTL Outputs  3  PTU Host Control  3  CHA/CHB Serial  8      Base Connector    RS‐232 Host Control   NO  RS‐485 Host Control  YES  Ethernet/Web  YES    Page 3  890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS  03/2011 ...
  • Page 4: Range Of Motion

    PTU‐D100 E Series  Range of Motion  The PTU‐D100 has the following standard factory pan and tilt axis limits. Factory limits define  the range of motion allowed for an axis when limits are enabled, and that axis cannot travel  beyond those limits. The built‐in slip ring allows continuous 360° pan‐axis movement (see Page  2).    ISM: ISM‐equipped PTUs have a tilt range of +30°/‐85° when stabilization is enabled.  Disabling stabilization provides the full range of motion listed above..     Note: You may special order a PTU‐D100 with custom hard stops installed and/or with custom  bracket positioning, factory ranges of motion, etc. Please contact FLIR Motion Control  Systems, Inc. for assistance.      Pan Range Options  Tilt Range Options  Part number: D100E‐__‐GG‐000‐*_    Part number: D100E‐__‐GG‐000‐_*    The part number on your PTU‐D100 with ISM may vary as shown here to reflect any special‐ ordered custom limits, stops, etc.        Page 4  890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS    03/2011...
  • Page 5: Pan/Tilt Control

    Configuration Guide  Pan‐Tilt Control  The PTU‐D300 supports serial, Ethernet/web, binary, and joystick control interfaces that  provide a wide range of system control architectures. The following options are available:  ASCII Command Set  The PTU‐D300 can be controlled via the standard  built‐in serial port (RS‐232 or RS‐485) using simple  ASCII commands. (See the E Series Command  Reference Manual.) This can be done using a  RS-232 terminal program or a custom application.  RS-485 Ethernet/Web Interface  The PTU‐D300 can be controlled via the standard  built‐in Ethernet port and web interface. The  intuitive interface makes configuration and direct  control easy using a mouse and direct text entry.   Ethernet       Gamepad Joystick  A USB gamepad controller is available to control a  SERIAL single PTU and up to two VISCA‐compatible  cameras that are connected to a host computer via  a serial connection. The PTU Joystick Control utility  is included with E Series PTUs.   Part numbers: PT‐PSC (Gamepad Controller)   Note: Cameras should be connected to the host PC using a dedicated serial connection for  each camera.          Page 5  890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS  03/2011 ...
  • Page 6: Power Supply

    PTU‐D100 E Series  Accessories  The following accessories may be ordered for the PTU‐D300. These accessories simplify system  prototyping and fielding.  25’ Breakout Cable  The breakout cable connects to the 32‐pin base connector  (MIL‐C‐26482) on the PTU‐D300 and terminates to standard  connectors for power, serial communication, Ethernet, and  payload signals. The terminating connectors are:  Power (DIN), 2x video (composite), RS‐232 (DB‐9, female), RS‐ 485 (RJ11), Ethernet (RJ45), and payload pass‐through  conductors.  Part number: PTU‐CAB‐E‐25BO  Power Supply  PTU power supply unit. 30VDC output, 110/220VAC input.  Dimensions: 3.44”W x2.01”Hx7.61”L.  Note: Input voltages under 30V can reduce the  maximum speed of the unit by an amount that is  proportional to the voltage difference.  Part number: PTU‐AC‐APS‐30V  Starter Kit  The PTU starter kit includes one power supply (PTU‐AC‐APS‐30V), one 25’ breakout cable (PTU‐ AC‐CAB‐25BO), and one RS‐485 to RS‐232 converter (PTU‐CONV‐RS485C).  Note: Input voltages under 30V can reduce the maximum speed of the unit.    Part number: PTU‐KIT‐E‐STR  Extension Cables  An extension cable extends the length of the breakout cable.  There is a male connector on one end and a female connector  on the other. Available in 50’ and 100’ lengths.  Part numbers: PTU‐CAB‐E‐EXT‐50 (50’) or                             PTU‐CAB‐E‐EXT‐100 (100’)  Page 6  890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS    03/2011...
  • Page 7: Mating Connector

    Configuration Guide  Mating Connector  Mating connector for the 32‐pin base (MIL‐C‐26482) and 19‐ pin payload (IL‐C‐26402) PTU connectors. Use this to make  custom PTU and/or payload cables.  Part numbers: PTU‐CABLE01‐19PMILC (19‐pin payload) or                             PTU‐CABLE03‐32PMILC (32‐pin base)  RS‐485 to RS‐232 Converter  Bi‐directional module that converts signals from RS‐232 to  RS‐485. Includes power supply, coupler, and cable.  Part number: PTU‐CONV‐RS485C  Rugged Joystick and Cable  This rugged joystick allows PTU control without a host  computer. Cable ordered separately.  Part numbers: PT‐DCJ (joystick) and                             PTU‐DCJE‐CABLE (25’ DCJ connection cable)  E Series PL01/PL02 Adapter Cable  These cables allow you to connect an E series PTU to an  existing D series setup without rewiring, except that the  Ethernet/web connection will not be available. Make sure to  order the correct cable for your wiring setup (PL01 or PL02).  Part numbers: PTU‐CAB‐E‐AD‐PL01 (PL01) or                             PTU‐CAB‐E‐AD‐PL02 (PL02)    Page 7  890C Cowan Road, Burlingame, CA 94010 ● Office (650)692‐3900 ● Fax (650)692‐3900 ● MCS@flir.com ● www.flir.com/MCS  03/2011 ...
