INSTALLATION MANUAL
VARIABLE SPEED ECM SINGLE PIECE
MULTI-POSITION AIR HANDLERS WITH
FACTORY INSTALLED ELECTRONIC
EXPANSION VALVE (EEV)
MODELS: AVV SERIES
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
DUCT WORK AND CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . .6
COIL METERING DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
REFRIGERANT LINE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . .8
CONDENSATE DRAIN CONNECTIONS . . . . . . . . . . . . . . . . . . . . . .9
ELECTRIC HEATER INSTALLATION . . . . . . . . . . . . . . . . . . . . . . .10
LINE POWER CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
LOW VOLTAGE CONTROL CONNECTIONS . . . . . . . . . . . . . . . . .11
"A" Coil Return Air Duct Attachment & Component Location . . . . . . . .3
"N" Coil Return Air Duct Attachment & Component Location . . . . . . . .3
Pressure Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Typical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Coil Blow Off Wing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Horizontal Suspension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Duct Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Duct Work Transition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Vapor Line Grommet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Line Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
EEV Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Fault Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Heat Relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Physical and Electrical Data - Cooling Only . . . . . . . . . . . . . . . . . . . .16
Electrical Data - Cooling Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Electrical Heat: Minimum Fan Speed . . . . . . . . . . . . . . . . . . . . . . . . .16
The electronic expansion valve (EEV) in this unit is shipped in the closed position to protect the valve during transportation. Prior to brazing, line
power must be applied to the air handler field wiring terminals for 1 minute. The initial power causes the EEV to open allowing nitrogen to flow
through the system during the brazing process.
If power cannot be applied to the EEV control board prior to brazing refrigeration piping, a tool is available to manually operate the EEV. An EEV
manual operating tool can be purchased from Source 1 as part number S1-02649686000. Six revolutions of the tool open the valve fully.
SECTION I: GENERAL
The single piece air handler series provides the flexibility for installation
in any position. This unit may be used for upflow, downflow, horizontal
right, or horizontal left applications.
These units may be located in a closet, utility room, attic, crawl space,
or basement. These versatile models may be used for cooling or heat
pump operation with or without electric heat.
Top or side power and control wiring, color coded leads for control
wiring, easy to install drain connections, and electric heaters all
combine to make the installation easy and minimize installation cost.
Electric heat kits are available as field installed accessories. Single
phase kits are available from 2.5 kW to 25 kW. 208-230 volt three
phase kits are available from 10kW to 25kW.
LIST OF SECTIONS
REQUIRED CONTROL SET-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
AIRFLOW AND COMFORT SETTING SELECTION . . . . . . . . . . . . 15
UNIT DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
AIR SYSTEM ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
INSTALLATION VERIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
INSTRUCTING THE OWNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
START UP SHEET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
LIST OF FIGURES
Accessory Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Main Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Electronic Expansion Valve (EEV) Control Board . . . . . . . . . . . . . . 12
Air Handler with Communicating AC or HP . . . . . . . . . . . . . . . . . . . 13
Multi-wire Terminal Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Duct Static Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Drain Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Location of Coil Trapped and Plugged Drain Connections . . . . . . . . 24
Wiring Diagram - Three Phase Heat Kits 208-230V . . . . . . . . . . . . . 27
LIST OF TABLES
electric heat section.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
IMPORTANT
SECTION II: SAFETY
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words DANGER,
WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
ISO 9001
Certified Quality
Management System
5292157-UIM-B-0317
