WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency, or the gas supplier.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
- I nst al l at i on m us t be per for m ed by a qual i f ie d i ns ta l le r, s er vic e a gency or the ga s s uppl i er
IF YOU SMELL GAS
¥ Do not try to light any appliance.
¥ Do not touch any electrical switch; do not use any phone in your building.
¥ Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
¥ If you cannot reach your gas supplier, call the fire department.
Installer: After installation give this manual
to the homeowner and explain
operation of this heater.
$10.00
Chelan B-Vent
- April, 1999 -
93508078
(700 B-Vent)
Gas Stove
and
Fireplace Insert
¥ Freestanding Stove
¥ Masonry Fireplace Insert
¥ Factory Built (Z.C.) Fireplace
Insert
10850 117th Place N.E. Kirkland, WA 98033
Listed
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Avalon CHELAN B-VENT 700 B-VENT
Summary of Contents for Avalon CHELAN B-VENT 700 B-VENT
-
Page 1: Introduction & Important Information
Installer: After installation give this manual to the homeowner and explain operation of this heater. $10.00 Chelan B-Vent Fireplace Insert ¥ Freestanding Stove ¥ Masonry Fireplace Insert ¥ Factory Built (Z.C.) Fireplace Insert - April, 1999 - 93508078 (700 B-Vent) -
Page 2: If You Smell Gas
AFETY RECAUTIONS ¥ IF YOU SMELL GAS: * Do not light any appliance * Extinguish any open flame * Do not touch any electrical switch or plug or unplug anything * Open windows and vacate building * Call gas supplier from neighbor's house, if not reached, call fire department ¥... - Page 3 AFETY ¥ Do not place clothing or other flammable items on or near the heater. Because this heater can be controlled by a thermostat there is a possibility of the heater turning on and igniting any items placed on or near it. ¥...
-
Page 4: Table Of Contents
Turning the Heater On and Off ...18 Adjusting the Flame Height...18 Adjusting the Blower Speed...19 Normal Operating Sounds ...19 Maintaining Your Heater Maintaining Your Stove's Appearance...20 Yearly Service Procedure...20 Troubleshooting Troubleshooting Table...21 How this Heater Works ...22 What Turns the Main Burners On and Off ...22... -
Page 5: Electrical Specifications
Installation Options: ¥ Freestanding ¥ Masonry Fireplace Insert ¥ Zero-Clearance (Metal) Fireplace Insert Heating Specifications: Approximate Heating Capacity (in square feet)* AFUE (Annual Fuel Utilization Efficiency) High Burn Input Rate (In BTU's) Low Burn Input Rate (In BTU's) Efficiency** Heating capacity will vary with the home's floor plan and insulation, natural gas or Propane BTU rating, and outside temperature. ** Efficiency rating is a product of thermal efficiency rating determined under continuous operation independent of installed system. -
Page 6: Stove Installation
¥ Log Set (2 Logs, 2 Twigs, Embers) ¥ 2 Leveling Bolts (3/8"-16 x 3" Carriage Bolts - not used for stove installations) Order of Installation Attach the legs or pedestal (see page 26) If the heater is to use propane, install the propane conversion kit (see page 31) Position the heater, use floor protection if needed Attach any optional equipment. -
Page 7: Heater Placement Requirements
¥ When the stove is installed directly on carpeting, vinyl or other combustible material other than wood flooring or a high pressure laminate wood floor, the stove must be installed on a metal or wood protection panel extending the full width and depth of the heater (Minimum 23-3/4"... -
Page 8: Vent Requirements
The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance. ¥ Minimum 5' vertical rise from top of stove (see the illustration below) ¥ When the vent passes through a wall, a wall thimble is required. -
Page 9: Insert Installation
Installation Preparation This appliance must be installed in accordance with all local codes, if any; if not, follow ANSI Z223.1 and the requirements listed in this manual. Failure to follow all of the requirements may result in property damage, bodily injury, or even death. Notify your insurance company before hooking up this heater. - Page 10 NSERT NSTALLATION Re-Routing the Power Cord to the Front (continued) 2 Carefully pull on the power cord until the molex connector is exposed. Disconnect the molex connector. Wires Leading from the Heater 3 Pry out one of the button plugs on either side of the insert (see the illustration below). 4 Open the control cover and locate the wires leading from the power cord molex connector (green, white, and black wires).
-
Page 11: Insert Placement
The Insert Must be Placed 13" into the Fireplace. Use the leveling bolts for fireplaces with recessed floors (included with the stove). Run the power cord to either side of the insert along the facing. Zero-Clearance (Metal) Fireplace Requirements: ¥ The damper ("... -
Page 12: Gas Line Connection
.) - For qualified installers only! Rear Panel Use a pipe wrench to tighten in place. NOTE: Apply thread sealant prior to installing. Gas Inlet (3/8" diameter pipe) Minimum Input Pressure 5.5" W.C. 11" W.C. 1-1/2" 7-1/2" 1-5/8" Center of Stove... -
Page 13: Vent Requirements
NSERT Vent Requirements Always maintain the required 1" clearance to combustible materials to prevent a fire hazard. The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance. ¥... -
Page 14: Remove The Door
INALIZING THE Turn the gas control valve to "OFF" prior to conducting any service. Unscrew and remove the door handle. 1 Remove the door. Burner Pan 2 Install the logs, twigs, and embers. The front log rests on these platforms. Twig Installation Align the holes... -
Page 15: Replace The Door
3 Replace the door (follow step # 1 in reverse order). 4 Turn on gas to the The pilot flame should impinge the top 3/8Ó (10 mm) of the thermopile. If it does not, you may need to heater. Leak test all turn the pilot up. -
Page 16: Operating Your Heater
PERATING Before You Begin Read this entire manual before you use your new heater (especially the section "Safety Precautions" on pages 2 & 3). Failure to follow the instructions may result in property damage, bodily injury, or even death. Location of Controls - See explanation below Control Valve PILOT ADJ... -
Page 17: Starting The Pilot
It will stay lit unless the gas control valve is turned to "OFF". However, the pilot will go out if the gas is shut off or if the stove malfunctions. If the pilot turns off frequently, call your dealer for information. To start the pilot follow the directions below: NOTE: IF YOU'RE TRYING TO RE-LIGHT THE PILOT BECAUSE SERVICE WAS PERFORMED ON THE UNIT (I.E. -
Page 18: Starting The Heater For The First Time
PERATING Starting the Heater for the First Time ¥ Painted Stoves require the paint to be cured. Start the heater and burn on low for 20 minutes. Turn off and let cool. Repeat twice to fully cure the paint. + Fumes and smoke from the paint curing and oil burning off the steel may occur the first time you start your heater. -
Page 19: Adjusting The Blower Speed
Adjusting the Blower Speed + The blower helps transfer the heat from the heater into the room. It will not turn on until the heater is up to temperature (approximately 10 minutes after starting). See the illustration below for instructions on adjusting the blower speed. PILOT IGNITER Normal Operating Sounds... -
Page 20: Maintaining Your Heater
AINTAINING Maintaining Your Stove's Appearance The optional brass door may be cleaned with a non-abrasive polish (such as Flitz¨). The brass trim is anodized and should not be polished. Yearly Service Procedure Failure to inspect and maintain the heater may lead to improper combustion and a potentially dangerous situation. -
Page 21: Troubleshooting Table
Problem: Pilot Will Not Light A gas shut off valve is turned off The valve control knob isn't turned to "PILOT" The valve control knob isn't pushed in The igniter wasn't pressed repeatedly Main Burners Will Not The pilot light has gone out Start The ON/OFF switch is turned to "OFF"... -
Page 22: Troubleshooting
ROUBLESHOOTING How this Heater Works This heater was designed with safety as the primary concern. Many of the components inside this heater are for safety purposes. Therefore, only certified gas service technicians should service this heater. What Turns the Main Burners On and Off This heater uses a millivolt system to control its operation (a millivolt is a very small amount of electricity). -
Page 23: Why Nothing Should Be Placed Against The Heater
Why Nothing Should Be Placed Against the Heater Your heater has a grill on the sides and top that must not be blocked. The area around the control cover allows air into the firebox. If it is blocked the combustion inside the firebox will not burn normally. -
Page 24: Warranty
ARRANTY To register your TRAVIS INDUSTRIES, INC. 7 Year Warranty, complete the enclosed warranty card and mail it within ten (10) days of the appliance purchase date to: TRAVIS INDUSTRIES, INC., 10850 117th Place N.E., Kirkland, Washington 98033. TRAVIS INDUSTRIES, INC. warrants this gas appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Years 1 &... -
Page 25: Listing Information
The safety label can be found on the rear panel. A copy is shown below. Tested & Beaverton, Listed by OR. USA Tested to ANSI Z21.11.1-1991, ANSI Z21.11.1a-1993, CAN/CGA 2.1M88, CAN/CGA 2.17M91 Must be installed in accordance with all local codes, if any; if not, follow ANSI Z223.1 in USA, CAN B149 in Canada, and the requirements listed in the accompanying owner's manual. -
Page 26: Optional Equipment
PTIONAL Stove Leg Installation Raise the stove 8" (use lumber or other sturdy device). Attach each leg following the instructions below. Attach each leg to the stove by inserting a bolt and washer through the hole or slot in the leg and into the threaded hole on the stove. -
Page 27: Surround Panel Installation
Surround Panel Installation + The surround panels come in the sizes listed below PANEL SIZE 8" 10" 12" 1 The insert must be in place with the gas line and vent attached prior to installing the panels. The rear edge of the insert must be 13" behind the facing of the fireplace for the panels to fit correctly. 2 Run the power cord to either side of the insert several inches in front of the facing. -
Page 28: Thermostat
PTIONAL Thermostat (Part # 99300650) Do not connect 120 VAC to the gas control valve or wiring of this unit. 1 Route the thermostat wire through the rear panel (run it through one of the ventilation holes) and attach to the on/off switch (see the illustration below). Open the access door. -
Page 29: Remote Control Thermostat
Remote Thermostat Do not connect 110-120 VAC to the gas control valve or wiring system of this unit. ¥ Follow the instructions included with the remote thermostat for installation. IMPORTANT OPERATIONAL NOTE FOR REMOTE THERMOSTAT USE: Included with the remote thermostat is a set of instructions that should be given to the homeowner. Please be aware that the remote thermostat has a 1 to 2 minute lag time between the time the thermostat is turned up and the heater turns on. -
Page 30: Propane Conversion Kit
PTIONAL Propane Conversion Kit The propane conversion kit should be installed prior to installing the heater (if not, shut off gas and disconnect the heater from the gas line). Items Needed For Assembly ¥ 1/4" Nutdriver ¥ Phillips Screwdriver ¥ Thread sealant Packing List ¥... - Page 31 3 Remove the burner pan from the burner pan box following the instructions below. Remove the two screws holding the burner box front in place. 1/4" Nutdriver Remove the burner box front. Rotate the burner pan upwards. Slide the burner pan to the left until the fixed shutter disengages from the orifice.
- Page 32 PTIONAL 4 Follow the directions below to remove the natural gas orifice. Apply thread sealant to the LP orifice (#49 - it has "49" stamped on it) and tighten in place with a 1/2" open end wrench. Replace the spring. Slide the adjustable shutter back in place. Push the adjustable shutter to the left, off the orifice (be careful not to bend the shutter linkage).
- Page 33 7 Replace the pilot assembly (follow the instructions in step 6 in reverse order). Make sure the pilot assembly gasket is placed correctly. 8 Replace the rear log shelf (see step 2). Install the logs and embers. Replace the door. 9 Remove the regulator from the front of the gas control valve.
-
Page 34: Index
Pedestal (installation) ...26 Pilot (starting) ...17 Propane Conversion Instructions ...31 Propane Line Install (gas line install - insert) ...12 Propane Line Install (gas line install - stove)...7 Propane Verses Natural Gas Heater ...2 Purging Gas Line ...14 Remote Control (installation)...29 Remote Control (operation) ...18...
