- Page 1 4 CHANNEL PASSIVE BALUNS UTP AUTO RECEIVER WITH AUTO VIDEO LEVEL CONTROL SC-TP0404 SC-UR0412A User's Manual SC-TP0404 SC-UR0412A...
- Page 2 Precaution and Safety Guidelines Please read this user’s manual thoroughly prior to use the unit for its easy and convenient use. Do not install the product in the following places: extremely low or high temperature conditions; places exposed to rain, snow, or high humidity;...
- Page 3 1. Introduction 1.1. SC-TP0404 The SC-TP0404 is a 4 ch passive transmitter. Together with active UTP receiver, it can transmit up to 1.2 km via CAT.5 UTP cable. As it is compatible with various applications, it can be linked with any type of analog camera or DVR.
- Page 4 3. Products Parts and Connection Diagram 3.1. Products Parts and Function 3.1.1. SC-TP0404 ① ② ⑤ ③ ④ ① ~ ④ BNC: Video input port from 1~4 channel ⑤ RJ-45 Jack: Video output port 3.1.2. SC-UR0412A ④ ① ⑤ ②...
-
Page 5: Connection Diagram
3 CH VIDEO + Blue + White 3 CH VIDEO - Brown 4 CH VIDEO + Brown 4 CH VIDEO - White 4. Connection Diagram Please refer to the left connection diagram when connecting the SC- UR0412A with SC-TP0404 as transmitter. -
Page 6: Specification
5. Specification MODEL SC-TP0404 Video In / Out CVBS 1.0Vp-p Video In / Out Balanced Differential Signal Bandwidth 6MHz Max. Transmission Distance Video: 1,200m with SC-UR0412A (CAT. 5) Video In BNC- F x 4 Connect Port Video Out RJ-45 x 1 Temperature / Humidity -10°C ~ +50°C / 0 ~ 80%... -
Page 7: Warranty Certificate
6. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide 12 months warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period One (1) year from the date of purchase Name Purchaser Address...
